1. Oil pump z With pressure relief valve of 12 bar z Before installing, check that both dowel sleeves for centralizing oil pump/cylinder block are z Removing and installing. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND 2. 15 N.m 3. Chain sprocket z For oil pump drive 4. Bearing shells 1,2, 3, 4 and 5 z Classification for ordering spare parts. See Fig. 57 z For bearing cap without oil groove z For cylinder block with oil groove z Do not interchange used bearing shells (mark) 5. 65 N.m + 90° (1/4 turn) further z Replace z Threaded along complete length (screw) z Tighten to 65 N.m when measuring crankshaft radial clearance 6. Bearing cap z Bearing cap 1: Poly V-belt pulley end z Bearing cap 3 with recesses for thrust washers z Bearing shell retaining lugs (cylinder block/bearing cap) must be on same side 7. Bearing shell 3 z See item - 4 - z Do not interchange used bearing shells (mark) 8. Sensor wheel z Replace z For Engine speed (RPM) sensor -G28- z Can only be installed in one position. Holes are offset 9. 10 N.m + 1/4 turn (90°) further z Replace 10. Thrust washer z For bearing 3 bearing cap z Production version (1-part), upper thrust washers discontinued, item -12- z Observe method of securing z Lettering faces mounting bracket NOTE: The following list refers to items in Fig. 55 .
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
|
