Volkswagen New Beetle. Manual - part 1055





Fig. 49: Installing Crankshaft Toothed Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install toothed belt and adjust timing. See TOOTHED BELTS, REMOVING, INSTALLING AND
TENSIONING
 .

z

Install tensioning element for ribbed belt.

z

Install ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

Drive plate, removing and installing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

VW 558 Counter support tool

NOTE:

Thread and shoulder must be free of oil and grease.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Hex bolt M8 x 45 and two M10 hex nuts

z

Depth gauge

Fig. 50: Identifying Special Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Loosening and tightening drive plate



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Secure counter support tool VW 558 to the drive plate with a M8 x 45 hex bolt. Place two M10 hex nuts
between counter support tool and drive plate.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
