Volkswagen New Beetle. Manual - part 1054





Fig. 46: Removing Crankshaft Toothed Belt Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drain engine oil.

z

Remove oil sump. See OIL SUMP, REMOVING AND INSTALLING .

z

Unbolt front sealing flange.

z

Take off sealing flange, release using light blows with a rubber headed hammer if necessary.

z

Remove sealant residue from cylinder block with a flat scraper.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 47: Removing Sealant Remains On Front Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Cover oil seal with a clean cloth.

z

Remove sealant remains on sealing flange with a rotating plastic brush (wear protective goggles).

z

Clean sealing surfaces. Surfaces must be free of oil and grease.

Installing

z

Cut off tube nozzle at front marking (nozzle approx. 3 mm diameter).

z

Apply silicone sealing compound, as shown, to clean sealing surface of sealing flange.

z

Thickness of sealant bead (arrows): 2 ... 3 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 48: Applying Silicone Sealing Compound To Sealing Surface Of Front Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

Before applying sealing bead, cover the oil seal with a clean
cloth.

z

The sealing compound bead must not be thicker, otherwise
excessive sealing compound will enter the sump and may block



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



PTFE sealing rings

Coil spring seals

Continuation for all seals

z

Install sealing flange immediately and lightly tighten all bolts.

z

Tighten sealing flange securing bolts using an alternating sequence and torque to 15 N.m.

z

Remove excess sealing compound.

z

Install sump. See OIL SUMP, REMOVING AND INSTALLING .

z

Install crankshaft toothed belt pulley and counter support with 3415. Torque bolts to 90 N.m + 1/4 turn
(90°) further.

the oil suction pipe strainer.

z

Note the use-by date of the sealant.

z

The sealing flange must be installed within 5 minutes of
applying the silicone sealing compound.

NOTE:

Use guide sleeve T10053/1 to fit sealing flange with the oil seal already
installed.

NOTE:

Use guide sleeve 2080 A to fit sealing flange with the oil seal already installed.

NOTE:

The sealant must be allowed to cure for approx. 30 minutes after installing the
sump. After this time the engine may be filled with engine oil.
