Volkswagen New Beetle. Manual - part 1052





Fig. 38: Identifying Oil Seals (Crankshaft, Pulley End)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Before installing, remove oil remains from crankshaft journal with a clean cloth.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



PTFE sealing rings

z

Mount guide sleeve T10053/1 onto crankshaft journal.

Fig. 39: Mounting Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve onto crankshaft journal.

z

Press in oil seal onto limit stop using press sleeve T10053 and bolt T10053/2 (M16 x 1.5 x 60).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Fig. 40: Pressing In Crankshaft Front Oil Seal (PTFE)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Coil spring seals

z

Lightly oil sealing lip of oil seal.

z

Mount guide sleeve from 2080 A onto crankshaft journal.

Fig. 41: Mounting Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press seal against limit stop using press sleeve from 3266. To do this, use old center bolt for crankshaft
toothed belt sprocket:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
