Volkswagen New Beetle. Manual - part 1031





Fig. 86: Identifying Intake Valve Seat Angle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Exhaust valve seat, reworking

a = 31.4 mm diameter

b =2.7 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



45°= Valve seat angle

Fig. 87: Identifying Exhaust Valve Seat Angle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Valve guides, checking

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

Dial gauge



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 88: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Insert new valve into guide until end of valve stem is flush with end of guide. Due to slight differences in
stem dimensions, make sure that an intake valve is used in intake guide and an exhaust valve in exhaust
guide.

z

Rock: 1.3 mm maximum

Fig. 89: Measuring Valve Rock
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Valve guides, replacing

Special tools and equipment

z

3121 Drift

Fig. 90: Identifying 3121 Drift
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

3120 Reamer and cutting fluid



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
