Volkswagen New Beetle. Manual - part 1030





Fig. 84: Identifying Camshaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Valve timing at 1 mm valve lift

VALVE TIMING CHART

Valve seats, reworking

Special tools and equipment

Engine code

ALH

Intake opens after TDC

16 °

Intake closes after BDC

25 °

Exhaust opens before BDC

28 °

Exhaust closes before TDC

19 °



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Depth gauge

z

Valve seat refacing tool

Maximum permissible reworking dimension, calculating:

z

Insert valve and press firmly against seat.

z

Measure distance -a- between end of valve stem and upper edge of cylinder head.

z

Calculate maximum permissible reworking dimension from measured distance -a- and minimum
dimension.

NOTE:

z

When repairing engines with leaking valves, it is not always sufficient to
merely reface or replace valve seats and valves. It is also necessary to
check the valve guides for wear. This is particularly important on high
mileage engines.

z

The valve seats should only be reworked enough to produce a perfect
seating pattern. The maximum permissible reworking dimension must be
calculated before reworking starts. If this dimension is exceeded, the
hydraulic lifter function can no longer be guaranteed and the cylinder head
should be replaced.

NOTE:

If the valve will be replaced as part of a repair, use the new valve for the
calculation.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 85: Measuring Distance Between End Of Valve Stem And Upper Edge Of Cylinder Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Minimum dimension:

Intake valve 35.8 mm

Exhaust valve 36.1 mm

Measured distance minus minimum dimension = Maximum permissible reworking dimension.

Example:

MAXIMUM PERMISSIBLE REWORKING DIMENSION (EXAMPLE)

Dimension

Measurement

Measured distance

36.5 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Intake valve seat, reworking

a = 35.7 mm diameter

b =1.6 mm

45° = Valve seat angle

Minus Minimum dimension

35.8 mm

= Max. perm. rework dimension

0.7 mm

NOTE:

The 30° lower valve seat chamfer is necessary to make sure that the intake
channel flow characteristics are maintained.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
