z

Turn further with a normal wrench:

Stage III 1/4 turn (90°)

Stage IV 1/4 turn (90°)

Assembly is basically a reverse of the disassembly sequence.

z

Installing toothed belt and timing adjustment. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING


z

Coolant, filling. See COOLING SYSTEM, DRAINING AND FILLING

Fig. 77: Tightening Cylinder Head Bolts In Sequence
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Compression pressure, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Special tools and equipment

z

3220 Hinged socket

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

z

VAG 1381/12 Adaptor

z

VAG 1763 Compression tester

Fig. 78: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Engine oil temperature must be 30°C minimum.

Test sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Disconnect fuel cut-off valve on Diesel injection pump.

z

Disconnect Quantity adjuster harness connector on Diesel injection pump.

z

Remove all glow plugs using 3220 flexible wrench.

z

Screw in VAG 1381/12 adaptor in place of glow plugs.

Fig. 79: Checking Compression With Compression Tester
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check compression using VAG 1763 compression tester.

z

Operate starter until tester display shows no further increase.

Compression pressure:

z

New: 25 to 31 bar

z

Wear limit: 19 bar

Permissible difference between all cylinders:

z

5 bar

z

Install glow plugs using 3220 flexible wrench

z

Tightening torque: 15 N.m (11 ft lb)

z

Check Diagnostic Trouble Code (DTC) memory:

See DTC MEMORY, CHECKING

VALVE TRAIN, SERVICING

NOTE:

Trouble codes will be stored because the Diesel injection pump harness
connector has been disconnected. Check and erase DTC memory.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



1. Bearing cap

z

Installation position. See Camshaft bearing caps, installed position

z

Installation sequence. See CAMSHAFT, REMOVING AND INSTALLING

2. 20 N.m (15 ft lb)

3. Camshaft

z

Axial clearance, checking. See Camshaft axial clearance, checking

z

Removing and installing: See CAMSHAFT, REMOVING AND INSTALLING

z

Checking radial clearance with plastigage Wear limit: 0.11 mm

z

Run-out: max. 0.01 mm

z

Identification and valve timing. See Identification

4. Hydraulic lifter

z

Do not interchange

z

Checking. See HYDRAULIC LIFTERS, CHECKING

z

Store with cam contact surface facing downward

z

Before installing, check camshaft axial clearance. See Camshaft axial clearance, checking

z

Oil contact surfaces

5. Keepers

6. Upper valve spring plate

7. Valve spring

z

Removing and installing: With cylinder head removed Use 2037 With cylinder head installed. See
VALVE STEM SEALS, REPLACING

8. Valve stem seal

z

Replacing. See VALVE STEM SEALS, REPLACING

9. Valve guide

z

Checking. See VALVE GUIDES, CHECKING

z

Replacing. See VALVE GUIDES, REPLACING

z

Service version with collar

10. Oil seal

z

To remove and install, remove bearing cap

z

Toothed belt, removing and installing. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING


11. Cylinder head

NOTE:

Cylinder heads with cracks between the valve seats may be used without
reducing engine life, provided the cracks are small and not more than 0.5 mm
wide.

NOTE:

The following list refers to items in Fig. 80 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
