z

Attach T 10014 bracket to cylinder block using threaded hole in water pump area (as illustrated).

Fig. 74: Attaching T 10014 Bracket To Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift engine slightly using second spindle -A- until spindle -B- is relieved.

z

Remove spindle -B-.

z

Position engine at TDC with camshaft sprocket loosened and toothed belt removed from camshaft
sprocket. See TOOTHED BELTS, REMOVING, INSTALLING, TENSIONING

z

Remove tension roller and camshaft sprocket.

bracket must be attached to the block to support the engine.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Unscrew upper bolt of belt guard, rear.

z

Loosen socket head bolts in sequence given, then remove bolts completely.

Fig. 75: Loosening Head Bolts In Sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully lift off cylinder head.

Installing

z

Turn crankshaft to TDC mark before installing cylinder head.

z

Turn crankshaft against engine direction of rotation until all pistons are approximately equally spaced
below TDC.

z

To centralize: screw guide pins from 3070/9 into outer threaded holes on intake side.

NOTE:

z

Always replace cylinder head bolts.

z

Make sure that there isn't any oil or coolant in the cylinder head bolt
hollows (in the cylinder head).

z

Only remove the new cylinder head gasket from its packing immediately
before installing.

z

When repairing, carefully remove any gasket remains from the cylinder
head and cylinder block. Ensure that no long grooves or scratches are
created. When using abrasive paper do not use a grade coarser than 100
(e.g. 80).

z

Carefully remove any emery or abrasive remains.

z

Handle the new gasket with extreme care. Damaging will lead to leaks.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 76: Identifying Screw Guide Pins
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install new cylinder head gasket.

z

Lettering (Part No.) must be readable.

z

Install cylinder head, screw in 8 remaining head bolts and tighten by hand.

z

Remove guide pins with removal tool from 3070 by turning removal tool counter-clockwise until pins are
free

z

Install remaining cylinder head bolts and tighten hand-tight.

z

Tighten cylinder head in following four stage sequence:

z

Tighten initially using torque wrench:

Stage I = 40 N.m (30 ft lb)

Stage II = 60 N.m (44 ft lb)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
