26. Glow plug

z

15 N.m (11 ft lb)

z

Checking:

See GLOW PLUGS -Q6-, CHECKING

27. Cylinder head gasket

z

Replace

z

Note marking. See Cylinder head gasket, identification

z

If replaced; also replace entire engine coolant



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 67: Exploded View Of Cylinder Head Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Cylinder head distortion, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 68: Checking Cylinder Head Distortion
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Max. permissible distortion: 0.1 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Cylinder head gasket, identification

Fig. 69: Identifying Cylinder Head Gasket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Part No. = arrow -1-

z

Production control code = arrow -2- (ignore)

z

Holes = arrow -3-

NOTE:

Reworking Diesel cylinder heads is not permissible.

NOTE:

Different thicknesses of cylinder head gasket are installed depending on
the piston projection dimension. When replacing the cylinder head gasket,
install a new gasket with the same identification.
