Volkswagen New Beetle. Manual - part 1023





Fig. 62: Identifying Piston Installation Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Piston for cylinder 1 and 2: marked 1/2

z

Piston for cylinder 3 and 4: marked 3/4

Piston projection at TDC, checking

Special tools and equipment

z

VW 382/7

NOTE:

New piston/cylinder allocations are shown by a colored mark on the piston
crown.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 63: Identifying VW 382/7
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VW 385/17



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 64: Identifying VW 385/17
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

Piston projection at TDC must be measured when installing new pistons or a short block. Depending upon
piston projection, install the corresponding cylinder head gasket using the following table:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 65: Measuring Piston Projection At TDC
Courtesy of VOLKSWAGEN OF AMERICA, INC.

PISTON PROJECTION IDENTIFICATION

Cylinder head gasket, identification

Piston projection

Identification: holes / notches

0.91 mm to 1.00 mm

1

1.01 mm to 1.10 mm

2

1.11 mm to 1.20 mm

3



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
