Fig. 57: Checking Crankshaft Dowel Pin Projection Dowel pin projection -3- out of crankshaft a = 2.5 to 3.0 mm Crankshaft dimensions (mm) CRANKSHAFT DIMENSIONS CHART Honing dimension Main journal diameter Con-rod journal diameter Basic -0.022 54.00 -0.042 -0.022 47.80 -0.042 1st undersize -0.022 53.75 -0.042 -0.022 47.55 -0.042 2nd undersize -0.022 53.50 -0.022 47.30
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
|
