Fig. 46: Identifying VW 558 Counter-Hold Tool Drive plate, loosening and tightening z Secure VW 558 counterhold to drive plate using M8 x 45 hex bolt. z Place two M10 hex nuts between counterhold and drive plate. Position of counterhold tool: z A - To loosen z B - To tighten Fig. 47: Holding Drive Plate Drive plate, installing z Position drive plate and backing plate with recesses -1-.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
|
