Volkswagen New Beetle. Manual - part 1017





Fig. 39: Tightening Toothed Belt Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Notch and raised portion (arrows) must move apart.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Release thumb pressure on toothed belt.

Tensioning roller must move back to its initial position, notch and raised portion must align again.

SEALING FLANGE AND FLYWHEEL/DRIVE PLATE, REMOVING AND INSTALLING

1. 15 N.m (11 ft lb)

2. Oil seal

z

Replacing. See SEALING RING (CRANKSHAFT PULLEY SIDE), REPLACING

3. Sealing flange, front

z

Must be located on dowel sleeves

z

Removing and installing. See SEALING FLANGE (FRONT), REMOVING AND
INSTALLING


4. Engine block

z

Crankshaft, removing and installing. See CRANKSHAFT, REMOVING AND INSTALLING

z

Pistons and connecting rods, disassembling and assembling. See PISTONS AND CONNECTING
RODS, DISASSEMBLING AND ASSEMBLING


5. Flywheel/drive plate

z

to remove and install flywheel, counter-hold using 3067

z

Drive plate, removing and installing: See DRIVE PLATE, REMOVING AND INSTALLING

6. 60 N.m (44 ft lb) plus additional 1/4 turn (90°) further

z

Always replace

7. Intermediate plate

z

Must be located on dowel sleeves

z

Do not damage/bend when assembling

8. Sealing flange with oil seal

z

Only replace as an assembly

z

Lightly oil sealing lip on oil seal

NOTE:

For clutch repairs: See CLUTCH ASSEMBLY

NOTE:

The following list refers to items in Fig. 40 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 40: Identifying Sealing Flange And Flywheel/Drive Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Sealing ring (crankshaft pulley side), replacing

Special tools and equipment

z

2080 A sleeve

z

3415 Counter support

z

3203 Seal remover

z

3265 Sleeve installer



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

VAG 1331 Torque wrench: 5 to 50 N (3.7 to 37 ft lb)

z

VAG 1332 Torque wrench: 40 to 200 N.m (30 to 148 ft lb)

Fig. 41: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Remove toothed belt. See TOOTHED BELTS, REMOVING, INSTALLING, TENSIONING .

z

Remove crankshaft toothed belt sprocket by counter-holding sprocket using 3415.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
