Volkswagen New Beetle. Manual - part 1016





Fig. 36: Installing Drift Through Hole In Rear Of Toothed Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install toothed belts (note engine direction of rotation) on crankshaft toothed belt sprocket, intermediate
wheel, injection pump sprocket and tensioning roller.

z

Install camshaft sprocket together with toothed belt and position using mounting bolt.

z

Camshaft sprocket should still turn

z

Tension toothed belt; using pin wrench on eccentric, turn clockwise until notch and raised mark align
(arrows).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 37: Tightening Lock Nut On Tensioning Roller
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten lock nut on tensioning roller.

z

Tightening torque: 20 N.m (15 ft lb)

NOTE:

Observe correct installation of tension roller in rear toothed belt guard
(arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 38: Identifying Correct Installation Of Tension Roller
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check TDC mark on flywheel again.

z

Tighten camshaft sprocket mounting bolt.

z

45 N.m (33 ft lb)

z

Tighten the new mounting bolts of injection pump sprocket

z

Tightening torque: 20 N.m (15 ft lb)

NOTE:

z

After dynamically checking the "start of injection", the mounting
bolts must be retightened 90° (1/4 turn).

See DIESEL INJECTION PUMP, REMOVING AND INSTALLIN



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Remove 2065A setting bar from camshaft.

z

Remove pin.

z

Turn crankshaft two rotations in engine direction of rotation and set again to cylinder 1 TDC.

z

Attach bracket to engine block.

z

Install engine mount (replace mounting bolts).

z

Tightening torque: 40 N.m (30 ft lb) plus additional 90° (1/4 turn)

z

Securely install mount for engine to engine bracket (replace mounting bolts)

z

Tightening torque: 60 N.m (44 ft lb) plus additional 90° (1/4 turn)

z

Install bracket for subassembly/body

z

Tightening torque: 25 N.m (18 ft lb)

z

Install vacuum pump.

z

Install toothed belt guard, vibration damper, belt pulley, and valve cover.

z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING .

z

Install sound dampening tray and engine cover

z

Remove pipe between charge air cooler and turbocharger. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING
 .

z

Install fuel filter with bracket

z

Disconnect fuel supply and return lines at fuel filter.

z

Install pipe between charge air cooler and intake pipe. See CHARGE AIR COOLER COMPONENTS,
REMOVING AND INSTALLING
 .

z

Check Diesel injection pump "start of delivery"

See START OF INJECTION, DYNAMICALLY CHECKING AND ADJUSTING

Semi-automatic toothed belt tensioning roller, checking

Test sequence

z

Tighten toothed belt with firm thumb pressure.

z

The mounting bolts should only be used one time, since by design
they have a reduced shank



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
