Volkswagen New Beetle. Manual - part 1018





Fig. 42: Removing Crankshaft Toothed Belt Sprocket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To guide seal extractor, hand screw center bolt into crankshaft onto stop.

z

Unscrew inner part of oil seal extractor 3203 two turns (approx. 3 mm) out of outer part and lock with
knurled screw.

z

Lubricate threaded head of oil seal extractor, place it in position and while exerting firm pressure, screw it
in as far as possible into the oil seal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 43: Removing Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen knurled screw and turn inner part against crankshaft until the oil seal is pulled out.

Installing

z

Lightly oil sealing lip of oil seal.

z

Install guide sleeve from 2080 A onto crankshaft journal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 44: Installing Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve.

z

Press in sealing ring with press sleeve from 3265 up to the stop using center bolt -1-



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 45: Installing Sealing Ring
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install crankshaft toothed belt sprocket and hold using 3099 counterhold.

z

Install toothed belt and tension. See TOOTHED BELTS, REMOVING, INSTALLING,
TENSIONING


z

Install ribbed belt. See RIBBED BELT TENSIONER, REMOVING AND INSTALLING

Drive plate, removing and installing

Special tools and equipment

z

VW 558 Counter-hold tool

z

Hex bolt M8x45 and two M10 hex nuts

z

Depth gauge



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
