See note. See VALVE TRAIN, SERVICING

z

Valve seats, reworking. See VALVE SEATS, REWORKING

12. Valves

z

Valve dimensions. See Valve dimensions

Fig. 80: Identifying Valve Train
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Camshaft axial clearance, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 81: Checking Camshaft Axial Clearance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

Dial gauge

NOTE:

Check with hydraulic lifters removed and with first and last bearing caps



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Wear limit: max. 0.15 mm

Camshaft bearing caps, installed position

Fig. 82: Identifying Camshaft Bearing Caps Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

fitted.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Note offset. Before installing camshaft trial install the bearing caps and determine the correct position.

Valve dimensions

Fig. 83: Identifying Valve Dimensions
Courtesy of VOLKSWAGEN OF AMERICA, INC.

VALVE DIMENSION CHART

Camshaft identification, valve timing

Identification

z

Cam base diameter: a = 38 mm diameter

z

Camshaft is identified by stamped numbers and letters between intake and exhaust cams:

CAMSHAFT IDENTIFICATION

NOTE:

Valves must not be reworked. Only lapping-in is permitted.

Dimension

Intake valve

Exhaust valve

diameter a mm

35.95

31.45

diameter b mm

6.963

6.943

c mm

96.85

96.85

"ALPHA ANGLE" °

45

45

Engine code

ALH

Cylinder 1 (arrow -A-)

38K

Cylinder 2 (arrow -B-)

DE



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
