Volkswagen New Beetle. Manual - part 1032





Fig. 91: Identifying 3120 Reamer And Cutting Fluid
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Clean and check cylinder head.

z

Press out worn valve guides using 3121 from camshaft side (valve guides with shoulder service version
from combustion chamber side).

Installing

z

Press new guides in up to shoulder (moistened with oil) from camshaft side in cold cylinder head using
3121 drift.

z

Ream out guides with 3120 hand reamer and plenty of cutting fluid.

z

Rework valve seats. See VALVE SEATS, REWORKING

Valve stem seals, replacing

Special tools and equipment

z

2036 Adjustable rod

z

3047A Slide hammer

z

3129 Seal driver

NOTE:

Do not replace the valve guides in cylinder heads where the valve seats
can no longer be reworked, or cylinder heads which have already been
machined to the minimum dimension.

NOTE:

When the valve guide shoulder makes contact, do NOT allow the pressure
to exceed 2000 psi or shoulder could break off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

VW 541/1A Valve spring lever

z

VW 541/5 Thrust piece

Fig. 92: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

(with cylinder head installed)

z

Remove camshaft. See CAMSHAFT, REMOVING AND INSTALLING

z

Remove hydraulic lifters and set them with contact surfaces facing down. Make sure lifters are not
interchanged in process.

z

Set piston of respective cylinder to Top Dead Center.

z

Install 2036 adjustable rod and adjust mountings to height of studs.

Fig. 93: Installing 2036 Adjustable Rod And Adjust Mountings
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Remove valve springs with VW 541/1A lever and VW 541/5 press piece.

z

Remove valve stem seals using 3047A.

Fig. 94: Removing Valve Stem Seals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Place plastic sleeve supplied on appropriate valve stem. This will prevent new valve stem seal from being
damaged.

z

Insert new valve stem seal in 3129 installation tool.

z

Oil valve stem seal sealing lip and press carefully onto valve guide.

Fig. 95: Installing Plastic Sleeve On Valve Stem
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The valves are supported by the piston crown.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Camshaft, removing and installing

Special tools and equipment

z

3359 Rig pin

z

3418 Adjustment guide

z

V159 Nut wrench

z

VAG 1331 Torque wrench: 5 to 50 N.m (3.7 to 37 ft lb)

Fig. 96: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove connecting pipe between charge air cooler and intake hose. See CHARGE AIR COOLER
COMPONENTS, REMOVING AND INSTALLING


z

Remove toothed belt guard, upper section.

z

Remove valve cover.

z

Remove brake booster vacuum pump.

Vehicles with manual transmission:

z

Turn crankshaft to cyl. 1 TDC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle
