– Tighten threaded connections to specified torques ⇒ page 106 . – Connect battery -A- ⇒ page 4 . Caution Observe notes for battery pole terminal clamp bolt ⇒ page 1 . – Start engine and check belt is running correctly. 7.8 Alternator -C- 1.6l FSI engine 7.8.1 Assembly overview 1 - Hexagon bolt ❑ 40 Nm 2 - Washer ❑ 4.5 Nm 8 - Hexagon nut ❑ 2 Nm 12 - Cross-head screw ❑ 2 Nm 13 - Voltage regulator -C1- ❑ Removing and installing ⇒ page 168 14 - Alternator -C- ❑ Removing and installing ⇒ page 111 ❑ Checking ⇒ page 89 ❑ Securing battery posi‐ tive wire ⇒ page 88 15 - Poly V-belt ❑ Checking ⇒ page 88 ❑ Removing and installing ⇒ Engine; Rep. gr. 13 ❑ Poly V-belt routing ⇒ Engine; Rep. gr. 13 110
|
