7.7.1 Assembly overview 1 - Hexagon head flange bolt ❑ 23 Nm 2 - Hexagon head flange bolts ❑ 23 Nm 3 - Bracket ❑ 52 Nm 6 - Protective cap ❑ 4.5 Nm 9 - Hexagon nut ❑ 2 Nm 12 - Cross-head screw ❑ 2 Nm 13 - Voltage regulator -C1- ❑ Removing and installing ⇒ page 168 14 - Alternator -C- ❑ Removing and installing ⇒ page 107 ❑ Checking ⇒ page 89 ❑ Securing battery posi‐ tive wire ⇒ page 88 15 - Poly V-belt ❑ Checking ⇒ page 88 ❑ Removing and installing ⇒ Engine; Rep. gr. 13 16 - Ancillary bracket ❑ For alternator -C- and air conditioner compressor 17 - Poly V-belt tensioning element ❑ 23 Nm Not illustrated 106
|
