Volkswagen Golf Variant / Jetta. Manual - part 100





locking plate.

4. Selector Mechanism through 02/2009

31

ble in the direction of -arrow-.

The locking strap must be pushed forward in order to remove the

cable in direction of -arrow 1-.
– Push the -pin- upward in direction of -arrow 2-at the same time

with a screwdriver .

– Insert the -screwdriver- from underneath while pushing the

securing tab forward.

32

4. Selector Mechanism through 02/2009

33

the cable bracket on the transmission. Do not secure it there.

– When installing, make sure the selector lever cable is routed

correctly.

34
