Assembly overview - window guide

Note

The right side is shown. The left side is similar.

For a better representation the illustration is drawn without door outer panel.

1 - Window guide
2 - Trim
3 - Bolt

❑ Qty. 2
❑ 2 Nm

4 - Window frame on door inner

part

2.8

Removing and installing window guide

Note

The removal and installation sequence is only for the right

window guide. The removal and installation of the left window

guide is similar.

For a better representation the removal and installation is

drawn without door outer panel.

General body repairs, exterior - Edition 04.2008

2. Front door windows

201

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.8.1

Removing

– Remove exterior mirror

⇒ page 227

 .

– Pull window guide -1- out of mounting.
– Remove bolts -3- (Qty. 2) and pull trim plate -2- off in direction

of B-pillar -direction of arrow-.

– Pull window guide -1- off all around window frame -4- and re‐

move upwards out of window slot.

2.8.2

Installing

Installation is carried out in reverse order of removal.

Note

Ensure window guide seats evenly when installing (wind noises).

General body repairs, exterior - Edition 04.2008

202

     Rep. Gr.64 - Glazing

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.9

Assembly overview - window regulator

Note

The right side is shown. The left side is similar.

1 - Window regulator

❑ Removing and installing

⇒ page 203

2 - Bolt

❑ Qty. 4
❑ 8 Nm

3 - Bolt

❑ Qty. 5 on 4-door models
❑ Qty. 4 on 2-door models
❑ 8 Nm

4 - Drive
5 - Mounting plate

2.10

Removing and installing window regula‐

tor

Note

The removal and installation sequence is only for the right

window regulator. Removal and installation of the left window

regulator is similar.

The removal and installation procedures may have to be modi‐

fied slightly depending on 2 or 4-door models

General body repairs, exterior - Edition 04.2008

2. Front door windows

203

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.10.1

Removing

– Remove door outer panel

⇒ page 94

 .

– Remove side impact protection

⇒ page 74

– Remove door window

⇒ page 195

 .

– Remove bolts -2- from mounting plate -5-.
– Remove window regulator bolts -3-.
– Remove window regulator -1- with drive -4- and window reg‐

ulator motor mounting plate -5- off door inner part.

– Disconnect window regulator motor connector

⇒ page 199

2.10.2

Installing

Installation is carried out in reverse order of removal.
• Carry out functional check before installing door outer panel.

General body repairs, exterior - Edition 04.2008
