Volkswagen Golf / Golf Plus. Manual - part 269





s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.4

Adjusting door window

– Remove front door trim ⇒  General body repairs, interior; Rep.

Gr.  70 ; Trim, insulation; Door trims .

– Lever out caps -4-.
– Lower door window -1- until clamping bolts -3- for mounting

-2- are accessible.

WARNING

Remove bolt -3- from interior by turning to right.

– Loosen bolts -3- (do not remove) from inside by turning to right

and press clamping jaws apart.

General body repairs, exterior - Edition 04.2008

2. Front door windows

197

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

– Applying light pressure press door window -1- in clamping

jaws in -direction of arrow- and align door window tension free

at rear window guide.

– When doing so, ensure that door window -1- is positioned par‐

allel to window guide.

– Tighten clamping jaws by turning bolts -3- to left from interior.
Specified torque for bolt: 8 Nm.
• Then check for correct operation.
Further installation is performed in the reverse order of removal.

2.5

Assembly overview - window regulator motor

Note

The right side is shown. The left side is similar.

1 - Window regulator motor

❑ Removing and installing

⇒ page 199

2 - Bolt

❑ Qty. 3
❑ 3.5 Nm

General body repairs, exterior - Edition 04.2008

198

     Rep. Gr.64 - Glazing

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

2.6

Removing and installing window regula‐

tor motor

Note

The removal and installation sequence is only for the right door

window regulator. The removal and installation of the left door

window regulator is similar.

The window regulator motor can also be removed with mount‐

ing plate when door outer panel is removed.

2.6.1

Removing

– Remove front door trim ⇒  General body repairs, interior; Rep.

Gr.  70 ; Trim, insulation; Door trims .

– Secure door window against sliding down with adhesive tape.
– Release connectors -arrows- using a screwdriver in

-direction of arrow-.

– Remove the three bolts -2-.

General body repairs, exterior - Edition 04.2008

2. Front door windows

199

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

– Remove window regulator motor and control unit -1- from

mounting plate.

2.6.2

Installing

– Place window regulator motor -1- on and attach connectors

-arrows-.

– Move door window lightly up and down so that the splines be‐

tween motor and cable drum engage easier.

– Tighten window regulator motor bolts -2- specified torque (3.5

Nm).

– Run window twice to upper stop and then down to lower stop.

This normalises and readies the window, it also activates the

pinch/roll-back function.

Then perform remaining installation in reverse order of removal.

General body repairs, exterior - Edition 04.2008

200

     Rep. Gr.64 - Glazing
