Peugeot 3008 (2017 year). Manual - part 27

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Radio Media

Source

Radio

Select change of source.

USB

iPod

AUX

Bluetooth

Radio Media

Frequency /

Presets

Frequency

Carry out an automatic or manual search for radio
stations.

Presets

Make a long press on an empty location to preset
a station.

Radio Media

Band

Press the Band button to change waveband.

DAB

Radio Media

List

Radio stations

Open the list and press a radio station to select it.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

13
14
15

10
11

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Comments

Radio Media

OPTIONS

Audio settings

Ambience

Select the sound ambience.

Distribution

Sound distribution by the Arkamys

system.

Sound

Adjust the volume or activate volume linked to
speed.

Voice

Adjust the voice volume.

Ringtone

Adjust the ringtone volume.

Save settings.

Radio Media

OPTIONS

Radio settings

General

Activate or deactivate settings.

Announcements

Save settings.

Radio Media

OPTIONS

Radio stations

Display the list of radio stations for the band
selected.

DAB

Presets

Select a preset radio station.

Frequency

Enter a frequency manually.

Change the screen display mode.

Update the list according to reception.

18 19 20

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Comments

Radio Media

OPTIONS

Music files

Albums

Choose a selection mode.

Artists

Genres

Playlists

Folders

Radio Media

OPTIONS

Managing photos

USB

Display photos.
The system supports the following image formats:
.gif, .jpg, .jpeg, .bmp, .png, .raw and .tiff with a
maximum file size of 10 Mb per image.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Press

Radio Media to display the

menu.

Press the "

OPTIONS " button to go to

the secondary page.

Press "

Frequency ".

Press "

Frequency ".

Enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.

Press one of the buttons for an
automatic search for radio stations.

Press

Radio Media to display the

primary page.

Radio

Selecting a station

Radio reception may be affected by
the use of electrical equipment not
approved by the Brand, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Select "

Radio stations " in the

secondary page.

Move the cursor for a manual search
for frequencies up or down.

Select a radio station or frequency.
(refer to the corresponding section)

Press "

Presets ".

Make a long press on one of the
buttons to preset the station.

Preset a station

Press "

OK " to confirm.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Press

Radio Media to display the

primary page.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Radio settings ".

Select "

Radio settings ".

Select "

General ".

Select "

General ".

Select "

Announcements ".

Activate/deactivate "

Station follow ".

Activate / Deactivate "

Display radio

text ".

Activate / Deactivate "

Traffic

announcement ".

Activate/Deactivate RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. This explains the loss of
reception of the station during a journey.

Press "

OK " to confirm.

Press "

OK " to confirm.

Press "

OK " to confirm.

The "Radio Text" function allows
information transmitted by the radio
station, relating to the station or the
song playing, to be displayed.

Display text information

Play TA messages

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
that carries this type of message. While
traffic information is being broadcast,
the current media is automatically
interrupted so that the TA message can
be heard. Normal play of the media
previously playing is resumed at the
end of the message.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Select the audio source.

Press

Radio Media to display the

primary page.

Press "

Band " to select the " DAB "

waveband.

Press

Radio Media to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

DAB-FM auto tracking

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB-FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If "DAB-FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a
variation in volume.
Once the digital signal is restored, the
system automatically changes back to
"DAB".

Digital radio provides higher quality
reception.
The different multiplexes offer a
choice of radio stations arranged in
alphabetical order.

If the "DAB" station being listened to
is not available on "FM" ("

DAB-FM "

option greyed out), or "DAB/FM auto
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.

Select "

Radio settings ".

Select "

General ".

Activate / Deactivate "

Station

follow ".

Press "

OK ".

DAB radio (Digital Audio Broadcasting)

Terrestrial Digital Radio

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Media

USB port

Selecting the source

Select "

Source ".

Press

Radio Media to display the

primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a USB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Auxiliary (AUX) socket

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

This source is only available if "Auxiliary input"
has been checked in the audio settings.

(depending on equipment)

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

Choose the source.

Bluetooth

Bluetooth audio streaming

  Streaming allows you to listen to music from
your  telephone.
  The Bluetooth profile must be activated. First
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.

To protect the system, do not use a
USB hub.

CD player

(depending on equipment)
Insert the CD in the player.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Connecting Apple

Connecting Apple players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts).
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

The audio equipment will only play audio
files with ".wma, .aac, .flac, .ogg and .mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4,...) can be played.
".wma" files must be of the standard wma 9 type.
The sampling rates supported are 32, 44 and
48 KHz.

In order to be able to play a burned CDR or
CDRW, when burning it is preferable to select
standards ISO 9660 level 1, 2 or Joliet.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with as low a speed as possible (4x maximum)
for the best sound quality.
In the particular case of a multi-session CD,
the Joliet standard is recommended.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

Use only USB memory sticks formatted FAT 32
(file allocation table).

The system supports USB mass
storage devices, BlackBerry

devices

or Apple

players via USB ports. The

adaptor cable is not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

It is recommended that the original USB
cable for the portable device is used.

To protect the system, do not use a
USB hub.

12:13

18,5

21,5

23 °C

12:13

18,5

21,5

23 °C

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Telephone

Level 1

Level 2

Level 3

12
13

5
6
7

8
9

10
11

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Telephone

Bluetooth

Contact

All

View contacts according to presentation choices.
Select a contact or a favourite saved in the
system via the profile selected to start the call.

Telephone

Address

Favourites

Sort the contacts by Surname-First name or First
name-Surname.

Update the contacts from the telephone.

Search

Search for a contact in the directory.

Create

Telephone

Create a new contact in the system.

Address

Telephone

Bluetooth

Calls

All

View calls according to choice of presentation.
Select a contact to start the call.

Incoming

Outgoing

Missed

View details for the contact.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Comments

Telephone

OPTIONS

Bluetooth

connection

All

Display all telephones detected and saved.

Connected

Display all connected telephones.

Search

Start the search for a device to connect.

Telephone

OPTIONS

Messages

All

Display messages according to the choice made.

Received

Sent

Telephone

OPTIONS

Email

Received

Display emails according to the choice made.

Sent

Not read

Mailbox

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Content .. 25 26 27 28 ..
