Peugeot 3008 (2017 year). Manual - part 28

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Comments

Telephone

OPTIONS

Settings

Security

Make driving safe.

Voicemail

Enter and save the number for the telephone
voicemail.

Ringtone

Adjust the ringtone volume.

Statistics

Display data for the telephone connected.

Save the options.

Telephone

OPTIONS

Quick messages

Delayed

Select a quick message from the categories, as
required.

My arrival

Not available

Other

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Pairing a Bluetooth

Pairing a Bluetooth telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with theBluetooth hands-free
system of your audio system must be
done with the

vehicle stationary and

the ignition on.

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press on

Telephone to display the

primary page.

Press on "

Bluetooth search ".

Select "

Search ".

The list of telephones detected is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.

The system offers to connect the telephone
with 3 profiles:
-

Telephone (hands-free kit, telephone

only),

Streaming (wireless play of audio files on

the telephone),

Mobile internet data .

Depending on the type of telephone,
you may be asked to accept or not
the transfer of your contacts and
messages.

Select the name of the chosen
telephone in the list.

Press "

OK " to confirm.

Select one or more profiles.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

The "

Mobile internet data " profile

must be activated for connected
navigation, having first activated
sharing of the connection on your
smartphone.

Connection sharing

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Press

Telephone to display the

primary page.

Select "

Bluetooth connection " to

display the list of paired devices.

On return to the vehicle, if the last
telephone connected is present again,
it is automatically recognised and
within about 30 seconds of switching
on the ignition, the connection is
established without any action on your
part (Bluetooth activated).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check in your telephone's
manual and with your service provider
for the services available to you.

The ability of the system to connect
with just one profile depends on the
telephone.
All three profiles may connect by default.

Go to the Brand's website for more information
(compatibility, additional help, ...).

To modify the connection profile :

Automatic reconnection

Press the "details" button.

Press the "

OPTIONS " button to go to

the secondary page.

Press "

OK " to confirm.

Select one or more profiles.

The profiles compatible with the system
are HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted

TEL button to accept an

incoming call.

Make a long press

on the steering mounted

TEL button

to reject the call.

And

Select "

End call ".

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Select the basket at top right of the
screen to display a basket alongside
the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press

Telephone to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Bluetooth connection " to

display the list of paired peripheral
devices.

Deleting a telephone

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

on the steering mounted button.

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Making a call

Calling a new number

Press

Telephone to display the

primary page.

Enter the phone number using the
digital keypad.

Press "

Call " to start the call.

Calling a contact

Press

Telephone to display the

primary page.

Or make a long press

on the steering mounted

TEL button.

Select "

Contact ".

Select the desired contact from the list offered.

Select "

Call ".

Calling a recently used number

Press

Telephone to display the

primary page.

Make a long press

Select "

Calls ".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

12
13
14

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

The access to "

Messages " depends on

the compatibility of the smartphone and
the integral system.
Depending on the smartphone, access
to your messages or email may be
slow.

Managing messages

The "

Email " function allows email

addresses to be entered for a contact,
but the system is not able to send
emails.

Managing contacts / entries

Press

Telephone to display the

primary page.

Select "

Contact ".

Select "

Create " to add a new contact.

In the "

Telephone " tab, enter the

telephone numbers for the contact.

In the "

Address " tab, enter the

addresses for the contact.

In the "

Email " tab, enter the email

addresses for the contact.

Press "

Answer " to send a quick

message stored in the system.

Press

Telephone to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Messages " to display the list

of messages.

Select the "

All " or " Received " or

Sent " tab.

Select the detail of the message
chosen in one of the lists

Press "

Call " to start the call.

Press "

Play " to hear the message.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used.
Check in the manual for your
smartphone and with your service
provider for the services available to
you.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Managing email

Press

Telephone to display the

primary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Email " to display the list of

messages.

Select the "

Received " or " Sent " or

Not read " tab.

Select the email chosen in the list.

Press "

Play " to start playing the

email.

Access to "

Email " depends on the

compatibility of the smartphone and the
integral system.

Managing quick messages

Press

Telephone to display the

primary page.

Press on the "

OPTIONS " button to

go to the secondary page.

Select "

Quick messages " to display

the list of messages.

Select the "

Delayed " or " My arrival "

or "

Not available " or " Other " tab

with the possibility of creating new
messages.

Select the message chosen in one of
the lists.

Press "

Create " to write a new

message.

Press "

Transfer " to select the

addressee(s).

Press "

Play " to start playing the

message.

12:13

18,5

21,5

23 °C

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Settings

According to version

Level 1

Level 2

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Settings

Color schemes

Color schemes: 1,2,3, ...

Having chosen the color scheme, save the
setting.

Settings

Audio settings

Ambience

Select the sound ambience.

Distribution

Sound distribution by the Arkamys

system.

Sound

Adjust the volume or activate linked to speed.

Voice

Adjust the voice volume.

Ringtone

Adjust the ringtone volume.

Save the settings.

Settings

Turn off screen

Function allowing the display to be switched off.
Pressing the screen reactivates it.

Settings

Profile (1, 2, 3)

Activate the profile selected.

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Level 4

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Level 4

Comments

Settings

OPTIONS

System

settings

Units

Distance and fuel
consumption

Set the units used for distance, fuel consumption
and temperature.

Temperature

Factory settings

Reinitialize

Restore the factory settings.

System info

View

View the versions of the different modules
(system, mapping, risk areas) installed in the
system as well as the updates available.

Save the settings.

Settings

OPTIONS

Languages

All

Select the language then confirm.

Europe

Asia

America

Having selected the language, save the setting.

Settings

OPTIONS

Screen configuration

Animation

Activate or deactivate settings.

Brightness

Move the cursor to adjust the brightness of the
screen and/or of the instrument panel.

Save the settings.

20 21

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Level 4

21
22

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Level 2

Level 3

Level 4

Comments

Settings

OPTIONS

Setting

the time-date

Date

Date

Enter the date and select the date format.

Date format:

Time

Time

Set the time.

Time Zone

Define the time zone.

Time format:

Select the time format: 12h / 24h.

Synchronisation with
GPS (UTC):

Activate or deactivate synchronisation with the
satellites.

Save the settings.

Settings

OPTIONS

Setting of the

profiles

Profile 1

Enter settings for the profiles.

Profile 2

Profile 3

Common profile

Save the settings.

Settings

OPTIONS

Driver screen

configuration

Personalisation of the

dashboard

Choose and select the display information
required on the dashboard.

Confirm the selections.

3
4
5
6

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Press

Settings to display the primary

page.

Profile settings

Audio settings

Press

Settings to display the primary

page.

Select "

Audio settings ".

Select "

Ambience "

Position "

Sound "

Voice "

Ringtone ".

On-board audio: Arkamys

Sound

Staging optimises the distribution of
sound in the passenger compartment.

The settings for "

Position " (All

passengers, Driver and Front only) are
common to all sources.

Activate or Deactivate "

Touch tones ",

Volume linked to speed " and

Auxiliary input ".

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.
Available only with the front and rear
speakers configuration.

The audio

Ambience settings

(6 ambiences available) as well as the

Bass , Medium and Treble settings

are different and independent for each
sound source.
Activate or Deactivate "

Loudness ".

Press "

OK " to save the settings.

Press "

OK " to confirm.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Profile 1 ", " Profile 2 ",

Profile 3 " or " Common profile ".

Select "

Setting of the profiles ".

Press this button to enter a name for
the profile using the virtual keypad.

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the

vehicle stationary .

vehicle stationary

4
5
6

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Select a "

Profile " (1 or 2 or 3) to

associate the "

Audio settings " with

it.
Select "

Audio settings ".

Select "

Ambience ".

Distribution ".

Sound ".

Voice ".

Ringtone ".

The location for the photograph is
square; the system deforms the original
photograph if in another format.

Initialisation of the profile selected
activates the English language by default.

Press "

OK " to save the settings.

Press "

OK " to accept the transfer of

the photograph.

Press "

OK " again to save the

settings.

Press this button to add a photograph
to the profile.

Insert a USB memory stick containing
the photograph in the USB port.
Select the photograph.

Press this button to initialise the
profile selected.

8
9

Audio and Telematics

Transversal-Peugeot_en_Chap01_NAC-2-2-0_ed01-2016

Press

Settings to display the primary

page.

Press

Settings to display the primary

page.

Press

Settings to display the primary

page.

Press the "

OPTIONS " button to go to

the secondary page.

Press the "

OPTIONS " button to go to

the secondary page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

System settings ".

Select "

Screen configuration ".

Select "

Units " to change the units

for distance, fuel consumption and
temperature.

Select "

Languages " to change the

language.

Activate or deactivate "

Automatic

scrolling ".

Move the cursor to adjust the
brightness of the screen and/or of the
instrument panel.

Select "

Factory settings " to return

to the initial settings.

Select "

System info " to display the

versions of the different modules
installed in the system.

Modifying system settings

Returning the system to factory settings
activates the English language by
default.

Select "

Animation ".

Select "

Brightness ".

Select the language

Press

Settings to display the primary

page.

Press the "

OPTIONS " button to go to

the secondary page.

Select "

Setting the time-date ".

Setting the date

Content .. 26 27 28 29 ..
