Peugeot 3008 (2017 year). Manual

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Remote control

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the
vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk of stopping it from
working and the remote control would have to be reinitialised.
The remote control does not operate when the key is in the ignition, even when the ignition is switched off.

Locking the vehicle

Driving with the doors locked may make access to the passenger compartment by the emergency services more difficult in an emergency.
As a safety precaution (with children on board), remove the key from the ignition or take the electronic key when you leave the vehicle, even for
a short time.

Electrical interference

The Keyless Entry and Starting electronic key may not operate if close to certain electronic devices: telephone, laptop computer, strong
magnetic fields, ...

Anti-theft protection

Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions.
For vehicles with an ignition switch, do not forget to remove the key and turn the steering to engage the steering lock.

Lost keys, remote control, electronic key

Visit a PEUGEOT dealer with the vehicle's registration certificate, your personal identification documents and if possible, the label bearing the
key code.
The PEUGEOT dealer will be able to retrieve the key code and the transponder code required to order a new key.

Do not throw the remote control batteries away, they contain metals which are harmful to the environment.
Take them to an approved collection point.

When purchasing a second-hand vehicle

Have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones which can start the vehicle.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Back-up procedures

These procedures should be used in the
following cases:
-

remote control cell battery flat,

remote control fault,

vehicle in an area subject to strong
electromagnetic interference.

In the first case, you can also replace the
remote control cell battery.
Refer to the corresponding section.
In the second case, you can also reinitialise the
remote control.
Refer to the corresponding section.

Unlocking

F Insert the key in the door lock barrel.
F Turn the key towards the front of the

vehicle.

For versions without alarm, the unlocking is
confirmed by flashing of the direction indicators
for a few seconds.
Depending on version, the door mirrors unfold.

If the alarm is activated, the siren
sounds on opening the door; switch on
the ignition to stop it.

Normal locking

F Insert the key in the door lock barrel.
F Turn the key towards the rear of the

vehicle.

For versions without alarm, the locking is
confirmed by flashing of the direction indicators
for a few seconds.
Depending on version, the door mirrors fold.

If your vehicle is fitted with an alarm,
this function will not be activated when
locking with the key.

Total unlocking / locking of the vehicle with the key

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Deadlocking

Without central locking

These procedures should be used in the
following cases:
-

central locking fault,

battery disconnected or discharged.

Driver's door

F Turn the key towards the rear of the vehicle

to lock it, or towards the front to unlock it.

Passenger doors

Unlocking a door
F Pull the interior opening control for the

door.

Locking

F Open the doors.
F For the rear doors, check that the child lock

is not on.

Refer to the corresponding section.
F Remove the black cap on the edge of the

door, using the key.

F Without forcing, insert the key into the

aperture; then, without turning it, move the
latch sideways towards the inside of the
door.

F Remove the key and refit the black cap.
F Close the doors and check from the

outside that the vehicle is locked.

F Insert the key in the door lock barrel.
F Turn the key towards the rear of the vehicle

to lock it.

F Within five seconds, turn the key towards

the rear of the vehicle again to deadlock it.

For versions without alarm, at the second
manoeuvre the deadlocking is confirmed
by flashing of the direction indicators for
a few seconds.
Depending on version, the door mirrors fold.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Changing the battery

A message appears in the instrument panel screen when replacement of the battery is needed.

Version without Keyless Entry and Starting
Battery type: CR1620 / 3 volts.

Version with Keyless Entry and Starting
Battery type: CR2032 / 3 volts.

F Unclip the cover using a small screwdriver

at the cut-out.

F Lift off the cover.
F Remove the discharged battery from its

housing.

F Fit the new battery into its housing

observing the polarity.

F Clip the cover onto the casing.

The remote control must be reinitialised after
replacing the battery.
For more information on reinitialising the
remote control, refer to the corresponding
section.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Following replacement of the battery or in the event of a remote control fault, it may be necessary to reinitialise the remote control.

Version with Keyless Entry and
Starting

Reinitialising the remote control

Version without Keyless Entry
and Starting

F Place the electronic key against the back-

up reader on the steering column and hold
it there until the ignition is switched on.

F Switch on the ignition by pressing the

"START/STOP" button.

The electronic key is now fully operational
again.

F  Switch off the ignition.
F  Turn the key to position 2 (ignition on).
F  Press the closed padlock button for a few

seconds.

F Switch off the ignition and remove the key

from the switch.

The remote control is now fully operational
again.

F If your vehicle has a manual gearbox, place

the gear lever in neutral then fully depress
the clutch pedal.

F If your vehicle has an automatic gearbox,

select position P then press the brake
pedal firmly.

If the fault persists after reinitialisation, contact
a PEUGEOT dealer or a qualified workshop
without delay.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Central locking

Manual mode

Unlocking

This function allows the doors and boot to be locked or unlocked simultaneously from inside the vehicle.

Locking

When locking / deadlocking
from the outside

When the vehicle is locked or
deadlocked from the outside, the red
indicator lamp flashes and the button is
inactive.
F After normal locking, pull one of the

interior door levers to unlock the
vehicle.

F After deadlocking, it is necessary

to use the remote control, Keyless
Entry and Starting or the integral
key to unlock the vehicle.

Automatic mode

This is the automatic central locking of the
vehicle when driving, also called anti-intrusion
security.

For more information on Anti-intrusion
security, refer to the corresponding section.

If one of the doors is open, the central
locking from the inside does not take
place.

F Press this button to lock the

vehicle.

The red indicator lamp in the button
comes on.

F Press this button again to unlock

the vehicle.

The red indicator lamp in the button
goes off.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Activation / Deactivation

Anti-intrusion security

Operation

This system allows automatic simultaneous locking of the doors and boot as soon as the speed of the vehicle exceeds 6 mph (10 km/h).

If one of the doors or the boot is open, the
automatic central locking does not take place.

Carrying long or
voluminous objects

If you want to drive with the boot open,
you should press the central locking
button to lock the doors. Otherwise,
every time the speed of the vehicle
exceeds 6 mph (10 km/h), the locks
will rebound and the alerts mentioned
above will appear.
Pressing the central locking button
unlocks the vehicle.
Above 6 mph (10 km/h), this unlocking
is temporary.

You can activate or deactivate this function
permanently.

Driving with the doors locked may
render access for the emergency
services difficult in an emergency.

This is signalled by the sound of
the locks rebounding, accompanied
by illumination of this symbol in the
instrument panel, an audible signal
and the display of an alert message.

The state of the system stays in memory when
switching off the ignition.

F With the ignition on, press this

button until an audible signal
starts and a corresponding
message is displayed.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

* Depending on version.

Alarm*

- exterior perimeter

The system checks for opening of the vehicle.
The alarm is triggered if anyone tries to open a
door, the boot, the bonnet...

- interior volumetric

The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks a
window, enters the passenger compartment or
moves inside the vehicle.

- anti-tilt**

The system checks for any change in the
attitude of the vehicle.
The alarm is triggered if the vehicle is lifted,
moved or knocked.

Self-protection function

The system checks for the putting out of
service of its components.
The alarm is triggered if the battery, the central
control or the siren wiring are put out of service
or damaged.

For all work on the alarm system,
contact a PEUGEOT dealer or a
qualified workshop.

** Depending on engine.

System which protects and provides a deterrent
against theft and break-ins. It provides the
following types of monitoring:

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Locking the vehicle with full
alarm system

Activation

F Switch off the ignition and get out of the

vehicle.

F Lock the vehicle with the remote control or

the Keyless Entry and Starting system.

The monitoring system is active: the indicator
lamp in the button flashes once per second
and the direction indicators come on for about
2 seconds.

Deactivation

F Press the unlocking button on the remote

control.

or
F Unlock the vehicle with the "Keyless Entry

and Starting" system.

The monitoring system is deactivated: the
indicator lamp in the button goes off and the
direction indicators flash for about 2 seconds.

Following an instruction to lock
the vehicle, the exterior perimeter
monitoring is activated after a delay of
5 seconds and the interior volumetric
and anti-tilt monitoring after a delay of
45 seconds.
If an opening (door, boot or bonnet)
is not fully closed, the vehicle is not
locked but the exterior perimeter
monitoring will be activated after a
delay of 45 seconds at the same time
as the interior volumetric and anti-tilt
monitoring.

When the vehicle automatically locks
itself again (as happens if a door or
boot is not opened within 30 seconds
of unlocking), the monitoring system is
also reactivated.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Locking the vehicle
with exterior perimeter
monitoring only

Deactivating the interior
volumetric and anti-tilt monitoring

F Switch off the ignition and within

10 seconds, press the button until the
indicator lamp is on continuously.

F Get out of the vehicle.
F Immediately lock the vehicle using the

remote control or the Keyless Entry and
Starting system.

The exterior perimeter monitoring alone is
activated: the indicator lamp in the button
flashes once per second.

Reactivating the interior
volumetric and anti-tilt
monitoring

F Deactivate the perimeter monitoring by

unlocking the vehicle with the remote
control or the Keyless Entry and Starting
system.

The indicator lamp in the button goes off.
F Reactivate all monitoring by locking the

vehicle with the remote control or the
Keyless Entry and starting system.

The indicator lamp in the button flashes once
per second again.

Deactivate the interior volumetric and anti-tilt
monitoring to avoid unwanted triggering of the
alarm in certain cases such as:
-

leaving a pet in the vehicle,

leaving a window or sunroof partially open,

washing your vehicle,

changing a wheel,

having your vehicle towed,

transport by sea.

To be effective, the deactivation must
be carried out each time the ignition is
switched off.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Operating fault

When the ignition is switched on, fixed
illumination of the indicator lamp in the button
indicates a fault with the system.
Have it checked by a PEUGEOT dealer or a
qualified workshop.

Failure of the remote control

To deactivate the monitoring functions:
F unlock the vehicle using the key (integral to

the remote control) in the driver's door lock,

F open the door; the alarm is triggered,
F switch on the ignition; the alarm stops; the

indicator lamp in the button goes off.

Locking the vehicle without
activating the alarm

Triggering of the alarm

This is indicated by sounding of the siren
and flashing of the direction indicators for
30 seconds.
The monitoring functions remain active until
the alarm has been triggered eleven times in
succession.
When the vehicle is unlocked using the remote
control or the Keyless Entry and Starting
system, rapid flashing of the indicator lamp
in the button informs you that the alarm was
triggered during your absence. When the
ignition is switched on, this flashing stops
immediately.

F Lock or deadlock the vehicle using the

key (integral to the remote control) in the
driver's door lock.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Doors

Opening

From outside

F After unlocking the vehicle or with the

electronic key of the Keyless Entry and
Starting system in the recognition zone,
pull the door handle.

From inside

F Pull the interior control lever of a front door;

this unlocks the vehicle completely.

Closing

with the engine running or the
vehicle moving (speed below
6 mph (10 km/h)), this warning
lamp comes on, accompanied
by an alert message for a few
seconds.

With the selective unlocking activated:
-

opening the driver's door unlocks
the driver's door only (if the vehicle
has not already been completely
unlocked).

opening one of the passenger
doors unlocks the rest of the
vehicle.

When the selective unlocking is
activated, the first press of the remote
control unlocking button permits
unlocking of the driver's door only.

When a door is not closed correctly:

with the vehicle moving (speed above
6 mph (10 km/h)), in addition to the warning
lamp and alert message, there is an
audible signal for a few seconds.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Boot

Opening the tailgate

F With the vehicle unlocked or with the

electronic key of the Keyless Entry and
Starting system in the recognition zone,
press the central tailgate control.

F Raise the tailgate.

Closing the tailgate

When selective unlocking is activated,
the electronic key must be close to the
rear of the vehicle.

F Lower the tailgate using the interior grips.
F Release the grips and press down on the

outside of the tailgate to close it.

With the exterior tailgate control

The tailgate is not designed to take a
bicycle carrier.

If the tailgate is not properly closed:

engine running, this warning
lamp and a message appear in
the instrument panel for a few
seconds,

vehicle running (speed above 6 mph
(10 km/h)), this warning lamp and a
message appear in the instrument panel
for a few seconds, accompanied by an
audible signal.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Hands-free tailgate

General points

The motorised operation of the tailgate can be
activated or deactivated in the vehicle settings
menu.
The motorised tailgate must only be operated
with the vehicle stationary.

Never introduce a finger in the locking
system of the motorised tailgate - Risk
of a serious injury!

Anti-pinch

The motorised tailgate has an obstacle
detection system that automatically interrupts
and reverses its movement by a few degrees to
allow the obstacle to be cleared.
Please note that this anti-pinch system is not
active at the end of the closing travel (around
1 cm from completely closed).

Bicycle carrier / Towbar

The motorised tailgate is not designed to
support a bicycle carrier.
When installing a bicycle carrier on a towbar
with connection of a cable to the towbar socket,
the motorised operation of the tailgate will be
automatically deactivated.
If using a towbar or bicycle carrier not
recommended by PEUGEOT, it is essential
to deactivate the motorised operation of the
tailgate.

Check that there is enough space to
allow for the movement of the motorised
tailgate.

To avoid the risk of injury through
pinching or trapping, before and during
operation of the motorised tailgate:
-

ensure that there is no person close
to the rear of the vehicle,

watch the activity of your
passengers, particularly any
children.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

Operation

There are several ways of operating the
motorised tailgate:
A. using the electronic key of the Keyless

Entry and Starting system,

B.  using the exterior control on the tailgate,
C.  using the interior tailgate control,
D.  using the control on the dashboard,
E.  using the "hands-free access" procedure

below the rear bumper.

Motorised opening

There are several possibilities.
F Make a long press on the central button A

of the electronic key.

or
F Press the exterior control B on the tailgate

with the electronic key on your person.

or
F Press twice in succession on the

dashboard control D.

The command is confirmed by an audible
signal.
The tailgate opens, either completely as the
default setting, or to the memorised position.

Motorised closing

There are several possibilities.
F Make a long press on the central button A

of the electronic key.

or
F  Press the exterior control B on the tailgate.
or
F  Press the interior tailgate control C.
or
F  Press twice in succession on the

dashboard control D.

The command is confirmed by an audible
signal.

Activation and deactivation of
motorised operation of the tailgate
is done in the Driving menu of the
touch screen.

This function is deactivated by default.

It is possible to stop the movement of
the tailgate.
Pressing one of these controls again
interrupts the movement.
Following the interruption of a
movement, pressing one of these
controls again resumes the movement.

Access

3008-2_en_Chap02_ouvertures_ed01-2016

"Hands-free" motorised
opening

This movement first unlocks just the
boot, or the vehicle if the latter was
locked.

F With the electronic key of the Keyless Entry

and Starting system on your person,

F Use the "hands-free" access E by passing

a foot rapidly below the rear bumper.

The command is confirmed by an audible
signal.
The tailgate opens, either completely by
default, or to the memorised position.

Ensure that you are steady on your feet
before passing a foot rapidly below the
rear bumper.
Take care not to touch the exhaust
system, which may be hot - Risk of
burns!

Passing your foot rapidly below the
bumper again while the tailgate is
opening interrupts the movement.
A third pass of your foot reverses the
direction of movement.

"Hands-free" motorised closing

F With the electronic key of the Keyless Entry

and Starting system on your person,

F Use the "hands-free" access E by passing

a foot rapidly below the rear bumper.

The command is confirmed by an audible
signal.

Passing your foot rapidly below the
bumper again while the tailgate is
closing interrupts the movement.
A third pass of your foot reverses the
direction of movement.

Activation / deactivation of the
Hands-Free Tailgate Access function
is done in the Driving menu of the
touch screen.

This function is deactivated by default.

Peugeot 3008 (2017 year). Manual - part 5
