(6) Install the headrest sleeves. SEATS/HEADREST - INSTALLATION) (8) Install the seat belt buckles. (Refer to 8 - ELECTRICAL/RESTRAINTS/REAR SEAT BELT BUCKLE - INSTALLATION) (9) Install the seat belts. (Refer to 8 - ELECTRI- CAL/RESTRAINTS/REAR SEAT BELT & RETRAC- (10) Install the seat back shield. (Refer to 23 - BODY/SEATS/REAR SEAT BACK SHIELD - INSTALLATION) (11) Install seat. (Refer to 23 - BODY/SEATS/ SEAT - REAR - INSTALLATION) SEAT CUSHION / COVER - REMOVAL (1) Remove seat. (Refer to 23 - BODY/SEATS/ SEAT - REAR - REMOVAL) (2) Remove seat back shield. (Refer to 23 - BODY/ SEATS/REAR SEAT BACK SHIELD - REMOVAL) (3) Remove the lower seat belt anchors as neces- sary. (Refer to 8 - ELECTRICAL/RESTRAINTS/ (4) Remove seat belt buckles as necessary. (Refer to 8 - ELECTRICAL/RESTRAINTS/REAR SEAT BELT BUCKLE - REMOVAL) (5) Partially de-trim lower part of seat back. the seat cushion and cover from seat frame. INSTALLATION (1) Install seat cushion and cover. ELECTRICAL/RESTRAINTS/REAR SEAT BELT BUCKLE - INSTALLATION) (5) Install the seat belt anchors. (Refer to 8 - ELECTRICAL/RESTRAINTS/REAR SEAT BELT & (6) Install the seat back shield. (Refer to 23 - BODY/SEATS/REAR SEAT BACK SHIELD - INSTALLATION) (7) Install seat. (Refer to 23 - BODY/SEATS/SEAT - REAR - INSTALLATION) VA SEATS 23 - 83 |
