SEATS
TABLE OF CONTENTS
page
ARMREST
REMOVAL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
INSTALLATION
. . . . . . . . . . . . . . . . . . . . . . . . . 79
HEADREST
SEAT - FRONT
. . . . . . . . . . . . . . . . . . . . . . . . . 80
SEAT BACK - FRONT
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
SEAT CUSHION - FRONT
. . . . . . . . . . . . . . . . . . . . . . . . . 81
SEAT ADJUSTERS - FRONT
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
SEAT - REAR
. . . . . . . . . . . . . . . . . . . . . . . . . 82
REAR SEAT BACK SHIELD
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
SEAT BACK CUSHION/COVER - REAR
SEAT CUSHION/COVER - REAR
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
. . . . . . . . . . . . . . . . . . . . . . . . . 83
(1) Remove the screws and remove the armrest
cover.
(2) Remove the three bolts and remove the arm-
rest from the seat back.
(1) Install the armrest and install the three bolts.(2) Install the armrest cover and install the
screws.
(1) Press the release button and remove the head-
rest. (Fig. 1)
(1) Insert headrest posts into seat back and seat
fully.
(1) Disconnect and isolate battery negative cable.(2) Remove the seat belt anchor bolt.(3) Remove the seat bolts.
Fig. 1 HEAD REST
1 - HEADREST2 - RELEASE BUTTON
