INSTALLATION Passenger Van (1) Position trim panels and seat push-pin fasten- ers fully. (2) Install d-pillar trim, if necessary. (Refer to 23 - BODY/INTERIOR/D-PILLAR TRIM - INSTALLA- (3) Install seats, if necessary. (Refer to 23 - BODY/ SEATS/SEAT - INSTALLATION) Cargo Van (1) Install paneling and replace rivets. REAR VIEW MIRROR REMOVAL (1) Slide mirror off support bracket. INSTALLATION INSTALLATION (1) Install the support bracket if necessary. (Refer to 23 - BODY/INTERIOR/REAR VIEW MIRROR - (2) Slide mirror onto support bracket fully. INSTALLATION - REAR VIEW MIRROR SUP- (1) Mark the position for the mirror bracket on the outside of the windshield glass with a wax pencil. (2) Clean the bracket contact area on the glass. Use a mild powdered cleanser on a cloth saturated (3) Sand the surface on the support bracket with fine grit-sandpaper. Wipe the bracket surface clean (4) Apply accelerator to the surface on the bracket according to the following instructions: (a) Crush the vial to saturate the felt applicator. the bracket. (d) Allow the accelerator to dry for five minutes. after the accelerator has been applied. tact surface on the windshield glass. Allow the accel- surface after the accelerator has been applied. (6) Install the bracket according to the following instructions: (a) Apply one drop of adhesive at the center of the bracket contact-surface on the windshield (b) Apply an even coat of adhesive to the contact surface on the bracket. (c) Align the bracket with the marked position on the windshield glass. (d) Press and hold the bracket in place for at least one minute. NOTE: Verify that the mirror support bracket is cor- (7) Allow the adhesive to cure for 8-10 minutes. Remove any excess adhesive with an alcohol-damp- (8) Allow the adhesive to cure for an additional 8-10 minutes before installing the mirror. STEPWELL SCUFF PADS REMOVAL (1) Remove screws and remove seat bracket if nec- essary. (2) Remove trim plugs and screws. (Fig. 8) and (Fig. 9) (3) Remove stepwell scuffs. Fig. 8 STEPWELL SCUFF PADS 1 - TRIM PLUGS VA INTERIOR 23 - 75 |
