 Seat belts/belt tensioners

Fig. 70: Identifying Assembly Wedge (115 589 03 59 00)

REMOVING AND INSTALLING SPARE WHEEL COVER - AR68.30-P-4610GH

MODEL 163.174

end fitting (2) of rear seat
belt

1001-01D

9

Remove brackets (4) (2
each.) from lining (8)





10

Open cover (5) and remove





11

Unscrew screw (6)





12

Unscrew screw (7)





13

Remove lining (8)

 As of VIN A145273, X708319 up to VIN

A289564, X754619: two clips on inside of paneling
in roof area.

 Installation: Check clips and replace if

necessary. Properly insert height adjuster for seat
belt into paneling. Check function Install paneling in
edge molding of floor covering







 Long wedge

Fig. 6

14

Pull seat belt out of lining





15

Remove lead from 12V
socket

 At right paneling



16

Install in the reverse order





Number

Designation

Model 163 up to 08/99 Model 163 as of 09/99

BA91.40-P-1001-01D Screw on belt end fitting

Nm 35

35



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Interior Equipment - 163 Chassis



me



Fig. 71: Identifying Spare Wheel Cover Components

 Wheels

REMOVE/INSTALL PANELING ON B-PILLAR - AR68.30-P-4700GH





Removal, installation





1

Remove cargo space cover

 See Owner's Manual.



2

Loosen retaining straps (2) and remove
spare wheel cover front section (1)





3

Remove spare wheel



*BA40.10-P-
1002-01A

4

Remove electric air pump (3)





5

Unscrew screws (4) and remove spare
wheel mount (5)





6

Remove bracket (6)

 Turn in clockwise direction until

bracket (6) releases at D-pillar.



7

Remove rear wall on spare wheel cover

 2 screws.



8

Install in opposite order





Number

Designation

Model 163.174

BA40.10-P-1002-01A

Bolt for spare wheel on inside of spare wheel mount

Nm 50



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Interior Equipment - 163 Chassis



me



MODEL 163.113 /128 /136 /154 /157 /172 /174 /175

Fig. 72: Identifying Paneling On B-Pillar Components



  Remove/install







Removal

Risk of fracture and cracking
of plastic paneling parts and the
associated clip retainers





1

Remove door sill molding



AR68.30-P-
4100GH

2

Pull off front and rear rubber
door seal in the area of the B-
pillar





3

Unscrew screw for belt end
fitting (1) from seat



*BA91.40-P-
1001-01D

4

Remove bottom paneling (3)





5.1

Remove SRS label and unscrew
screw behind

 As of 1.9.01.



6

Unscrew sheet metal screws (4)
from upper paneling





 As of 1.9.01: clips are no longer present.

Installation: The lug of the seat belt



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Interior Equipment - 163 Chassis



me



 Safety belts/emergency tensioning retractors

REMOVING AND INSTALLING INSIDE REARVIEW MIRROR - AR68.40-P-0001GH

MODEL 163.136 /154 /172 #A up to 145272, 163.136 /154 /172 #X up to 708318

Fig. 73: Identifying Inside Rearview Mirror Components

REMOVE/INSTALL INSIDE REARVIEW MIRROR - AR68.40-P-0001GI

7.1

Unclip top panel (5)

adjusting device (6) must align with the
recess of the paneling. Check mounting clips
and replace if damaged.



8

Install in the reverse order





Number

Designation

Model 163 up to 08/99

Model 163 as of 09/99

BA91.40-P-1001-01D

Belt end fitting screw

Nm 35

35





Remove/install





1

Disconnect connector (H7/1x1) from rear of
inside rearview mirror (H7/1)

 Only with code (249a), automatic

dimming inside rearview mirror



2

Remove cable duct (1) from mirror shaft

 Only with code (249a), automatic

dimming inside rearview mirror



3

Push cable duct (2) together and remove

 Only with code (249a), automatic

dimming inside rearview mirror



4

Turn mirror shaft 90 degrees and pull out of
mirror base (3) downward

 Inside rearview mirror is arrested on

mirror base with spring tension



5

Install in the reverse order







2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Interior Equipment - 163 Chassis



me
