CONNECTOR PART NUMBERS - GF00.19-P-8100BV



038 545 48 28

3-pin MCP coupling, B,
white



Remove female contact

AR00.19-P-0120-09A



038 545 49 28

3-pin MCP coupling, C,
blue



Remove female contact

AR00.19-P-0120-09A



038 545 55 28

2-pin MQS coupling, C,
yellow



Remove female contact

AR00.19-P-0120-04A



038 545 56 28

2-pin MQS plug, C,
yellow



Remove contact pin

AR00.19-P-0120-03A



038 545 61 28

4-pin MQS coupling, E,
green



Remove female contact

AR00.19-P-0120-04A



038 545 71 28

6-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



038 545 72 28

6-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



038 545 73 28

4-pin MQS coupling, C,
black



Remove female contact

AR00.19-P-0120-04A



038 545 75 28

4-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



038 545 76 28

4-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



038 545 78 28

2-pin Siemens ELO
coupling, B, yellow



Remove female contact

AR00.19-P-0120-23A



038 545 80 28

2-pin Siemens ELO plug,
B, yellow



Remove contact pin

AR00.19-P-0120-24A



038 545 90 28

10-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02A



038 545 91 28

10-pin SLK coupling, D,
violet



Remove female contact

AR00.19-P-0120-02A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 168



Part number

Designation, Coding,
Color





168 540 01 81

2-pin MQS coupling, B,
black



Remove female contact

AR00.19-P-0120-04A



168 540 11 81

3-pin MQS plug, A,
black



Remove contact pin

AR00.19-P-0120-03A



168 545 03 28

4-pin MQS coupling, A,
yellow



Remove female contact

AR00.19-P-0120-04A



168 545 04 28

4-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



168 545 05 28

4-pin JPT coupling, A,
black



Remove female contact

AR00.19-P-0120-07A



168 545 06 28

9-pin JPT coupling, A,
black



Remove female contact

AR00.19-P-0120-07A



168 545 07 28

24-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



168 545 08 28

2 x 26-pin MQS
coupling, A, black



Remove female contact

AR00.19-P-0120-04A



168 545 09 28

2 x 20-pin MQS
coupling, A, black



Remove female contact

AR00.19-P-0120-04A



168 545 10 28

9-pin JPT coupling, B,
white



Remove female contact

AR00.19-P-0120-07A



168 545 13 28

52-pin MQS coupling, -,
-



Remove female contact

AR00.19-P-0120-04A



168 545 17 28

4-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A

168 545 18 28

4-pin JPT plug, A, black



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





Remove contact pin

AR00.19-P-0120-08A



168 545 21 28

2-pin JPT plug, A, black
Remove contact pin

AR00.19-P-0120-08A



168 545 23 28

2-pin JPT plug, A, black
Remove contact pin

AR00.19-P-0120-08A



168 545 25 28

3-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



168 545 27 28

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



168 545 29 28

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



168 545 30 28

2-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02B



168 545 36 28

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



168 545 37 28

2-pin SLK plug, A, black
Remove contact pin

AR00.19-P-0120-01B



168 545 42 28

10-pin MQS plug, -, -



Remove contact pin

AR00.19-P-0120-03A



168 545 43 28

10-pin MQS plug, A,
black



Remove contact pin

AR00.19-P-0120-03A



168 545 58 28

2-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02B



168 545 59 28

10-pin MQS plug, B,
transparent



Remove contact pin

AR00.19-P-0120-03A



168 545 65 28

2-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02B



168 545 67 28

2-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02B



168 545 69 28

10-pin MQS plug, C,
blue



Remove contact pin

AR00.19-P-0120-03A

168 545 70 28

3-pin SLK coupling, B,





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONTACT PART NUMBERS - GF00.19-P-8100BW

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 170

CONTACT PART NUMBERS - GF00.19-P-8100BY

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 202



white
Remove female contact

AR00.19-P-0120-02B

168 545 18 40

38-pin JPT, MQS
coupling, -, black





Remove JPT female
contact

AR00.19-
P-0120-
07A



Remove MQS female
contact

AR00.19-
P-0120-
04B



Part number

Designation, Coding,
Color





170 545 01 28

5-pin JPT coupling, B,
white



Remove female contact

AR00.19-P-0120-07A

170 545 05 28

47-pin MQS, MCP
coupling, D, black





Remove MQS female
contact

AR00.19-
P-0120-
04B

Remove MCP female
contact

AR00.19-P-0120-09A



170 545 43 28

47-pin MQS, MCP
coupling, D, black



Remove MQS female
contact

AR00.19-P-0120-04B

Remove MCP female
contact

AR00.19-P-0120-09A

Designation, Coding,



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
