Mercedes-Benz ML320. Service manual - part 522





CONNECTOR PART NUMBERS - GF00.19-P-8100BM

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 037



036 545 73 28

2-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



036 545 87 28

14-pin SLK plug, B, white
Remove contact pin

AR00.19-P-0120-01A



Part number

Designation, Coding,
Color





037 545 05 28

2 x 2-pin SLK plug, A,
black



Remove contact pin

AR00.19-P-0120-01A



037 545 06 28

2 x 2-pin SLK plug, B,
transparent



Remove contact pin

AR00.19-P-0120-01A



037 545 07 28

2 x 2-pin SLK plug, C,
blue



Remove contact pin

AR00.19-P-0120-01A



037 545 08 28

2 x 2-pin SLK plug, D,
violet



Remove contact pin

AR00.19-P-0120-01A



037 545 09 28

4-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02A



037 545 10 28

4-pin SLK coupling, D,
violet



Remove female contact

AR00.19-P-0120-02A



037 545 11 28

2-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02A



037 545 12 28

2-pin SLK coupling, D,
yellow



Remove female contact

AR00.19-P-0120-02A



037 545 13 28

2-pin SLK plug, A, black
Remove contact pin

AR00.19-P-0120-01A



037 545 14 28

2-pin SLK plug, B, white
Remove contact pin

AR00.19-P-0120-01A



037 545 15 28

2-pin SLK plug, C, blue



Remove contact pin

AR00.19-P-0120-01A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





037 545 16 28

2-pin SLK plug, D,
yellow



Remove contact pin

AR00.19-P-0120-01A



037 545 19 28

2-pin SLK plug, -, -



Remove contact pin

AR00.19-P-0120-01A



037 545 20 28

6-pin SLK plug, B, white
Remove contact pin

AR00.19-P-0120-01A



037 545 25 28

2-pin MCP coupling, A,
black



Remove female contact

AR00.19-P-0120-09A



037 545 26 28

2-pin MCP coupling, B,
white



Remove female contact

AR00.19-P-0120-09A



037 545 27 28

2-pin MCP coupling, C,
blue



Remove female contact

AR00.19-P-0120-09A



037 545 28 28

2-pin MCP coupling, D,
violet



Remove female contact

AR00.19-P-0120-09A



037 545 29 28

2-pin MCP coupling, E,
green



Remove female contact

AR00.19-P-0120-09A



037 545 30 28

4-pin MCP coupling, -, -
Remove female contact

AR00.19-P-0120-09A



037 545 31 28

4-pin MCP coupling, A,
black



Remove female contact

AR00.19-P-0120-09A



037 545 32 28

4-pin MCP coupling, C,
blue



Remove female contact

AR00.19-P-0120-09A



037 545 33 28

4-pin MCP coupling, D,
violet



Remove female contact

AR00.19-P-0120-09A



037 545 34 28

6-pin MCP coupling, -, -
Remove female contact

AR00.19-P-0120-09A



037 545 35 28

6-pin MCP coupling, A,
black



Remove female contact

AR00.19-P-0120-09A



037 545 36 28

6-pin MCP coupling, C,
blue



Remove female contact

AR00.19-P-0120-09A

037 545 37 28

6-pin MCP coupling, D,
violet





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





Remove female contact

AR00.19-P-0120-09A



037 545 39 28

10-pin SLK plug, A,
black



Remove contact pin

AR00.19-P-0120-01A



037 545 40 28

10-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



037 545 53 28

8-pin MQS coupling, F,
brown



Remove female contact

AR00.19-P-0120-04A



037 545 55 28

8-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



037 545 56 28

12-pin SLK coupling, -, -
Remove female contact

AR00.19-P-0120-02A



037 545 57 28

12-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



037 545 59 28

2-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



037 545 60 28

2-pin MQS coupling, D,
violet



Remove female contact

AR00.19-P-0120-04A



037 545 61 28

2-pin MQS coupling, E,
green



Remove female contact

AR00.19-P-0120-04A



037 545 63 28

3-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



037 545 64 28

4-pin MQS coupling, -, -
Remove female contact

AR00.19-P-0120-04A



037 545 65 28

4-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A

037 545 66 28

5+2-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONTACT PART NUMBERS - GF00.19-P-8100BN

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 038

037 545 67 28

5+3-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A



037 545 73 28

3-pin SLK plug, B, white
Remove contact pin

AR00.19-P-0120-01A



037 545 86 28

4-pin MCP coupling, B,
white



Remove female contact

AR00.19-P-0120-09A



037 545 94 28

6-pin SLK plug, A, black
Remove contact pin

AR00.19-P-0120-01A



037 545 97 28

4-pin SLK coupling, D,
yellow



Remove female contact

AR00.19-P-0120-02A



037 545 98 28

2 x 2-pin SLK plug, D,
yellow



Remove contact pin

AR00.19-P-0120-01A



Part number

Designation, Coding,
Color





038 545 12 28

4-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A

038 545 13 28

5+3-pin MQS, MCP
coupling, B, white





Remove MQS female
contact

AR00.19-
P-0120-
04A

Remove MCP female
contact

AR00.19-P-0120-09A



038 545 47 28

3-pin MCP coupling, A,
black



Remove female contact

AR00.19-P-0120-09A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
