Mercedes-Benz ML320. Service manual - part 521





CONNECTOR PART NUMBERS - GF00.19-P-8100BJ

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 034



Part number

Designation, Coding,
Color





033 545 00 28

4-pin MQS coupling, D,
yellow



Remove female contact

AR00.19-P-0120-04A



033 545 09 28

3-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



033 545 10 28

3-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



033 545 50 28

4-pin MQS plug, D,
yellow



Remove contact pin

AR00.19-P-0120-03A



033 545 57 28

6-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



033 545 58 28

6-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



033 545 59 28

6-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



033 545 60 28

6-pin MQS coupling, D,
yellow



Remove female contact

AR00.19-P-0120-04A



033 545 61 28

6-pin MQS coupling, E,
green



Remove female contact

AR00.19-P-0120-04A



033 545 67 28

2-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



Part number

Designation, Coding,
Color





034 545 40 28

5-pin JPT coupling, -, -



Remove female contact

AR00.19-P-0120-07A

034 545 41 28

5-pin JPT coupling, A,





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





black
Remove female contact

AR00.19-P-0120-07A



034 545 42 28

5-pin JPT coupling, B,
white



Remove female contact

AR00.19-P-0120-07A



034 545 61 28

4-pin RK 2.5 solder
contact plug, A, yellow



Remove contact pin

AR00.19-P-0120-18A



034 545 63 28

4-pin RK 2.5 solder
contact coupling, A,
yellow



Remove female contact

AR00.19-P-0120-17A



034 545 72 28

2-pin RK 2.5 variant 1
coupling, D, violet



Remove female contact

AR00.19-P-0120-15A



034 545 73 28

2-pin RK 2.5 variant 1
plug, D, violet



Remove contact pin

AR00.19-P-0120-16A



034 545 75 28

8-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



034 545 76 28

8-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



034 545 77 28

8-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



034 545 78 28

8-pin MQS coupling, E,
green



Remove female contact

AR00.19-P-0120-04A



034 545 80 28

8-pin MQS coupling, Z,
water blue



Remove female contact

AR00.19-P-0120-04A

034 545 93 28

3+4-pin JPT, LSK
coupling, B, white





Remove JPT female
contact

AR00.19-
P-0120-
07A



Remove LSK female
contact

AR00.19-
P-0120-
12A

034 545 94 28

3+4-pin JPT, LSK
coupling, C, blue





Remove JPT female

AR00.19-



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100BK

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 035

contact

P-0120-
07A



Remove LSK female
contact

AR00.19-
P-0120-
12A



Part number

Designation, Coding,
Color





035 545 26 28

4-pin RK 2.5 variant 1
coupling, D, violet



Remove female contact

AR00.19-P-0120-15A



035 545 27 28

4-pin RK 2.5 variant 1
plug, D, violet



Remove contact pin

AR00.19-P-0120-16A



035 545 30 28

8-pin RK 2.5 variant 1
coupling, D, violet



Remove female contact

AR00.19-P-0120-15A



035 545 31 28

8-pin RK 2.5 variant 1
plug, D, violet



Remove contact pin

AR00.19-P-0120-16A



035 545 33 28

4-pin RK 2.5 variant 1
coupling, E, green



Remove female contact

AR00.19-P-0120-15A



035 545 34 28

8-pin RK 2.5 variant 1
coupling, E, green



Remove female contact

AR00.19-P-0120-15A



035 545 35 28

8-pin RK 2.5 variant 1
plug, E, green



Remove contact pin

AR00.19-P-0120-16A



035 545 36 28

4-pin RK 2.5 variant 1
plug, E, green



Remove contact pin

AR00.19-P-0120-16A



035 545 45 28

6-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A

035 545 46 28

6-pin MQS coupling, B,
white





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100BL

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 036



Remove female contact

AR00.19-P-0120-04A



035 545 89 28

2-pin MQS connector, B,
white



Remove contact pin

AR00.19-P-0120-03A



035 545 90 28

2-pin MQS plug, C, blue



Remove contact pin

AR00.19-P-0120-03A



Part number

Designation, Coding,
Color





036 545 10 28

2-pin JPT coupling, -, -



Remove female contact

AR00.19-P-0120-07A



036 545 11 28

2-pin JPT coupling, A,
black



Remove female contact

AR00.19-P-0120-07A



036 545 12 28

2-pin JPT coupling, B,
transparent



Remove female contact

AR00.19-P-0120-07A



036 545 13 28

2-pin JPT coupling, C,
blue



Remove female contact

AR00.19-P-0120-07A



036 545 21 28

20-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



036 545 23 28

3-pin RK 2.5 solder
contact connector, 3, red



Remove contact pin

AR00.19-P-0120-18A



036 545 55 28

5-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



036 545 56 28

5-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



036 545 67 28

3-pin MQS coupling, D,
violet



Remove female contact

AR00.19-P-0120-04A



036 545 68 28

4-pin MQS coupling, D,
violet



Remove female contact

AR00.19-P-0120-04A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
