Mercedes-Benz ML320. Service manual - part 519





MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 014

CONNECTOR PART NUMBERS - GF00.19-P-8100AR

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 017

CONNECTOR PART NUMBERS - GF00.19-P-8100AT

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 019



Part number

Designation, coding,
color





014 545 29 26

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



014 545 30 26

2-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



014 545 31 26

2-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02A



Part number

Designation, Coding,
Color





017 545 06 28

4-pin RK 2.5 solder
contact connector, -, black



Remove contact pin

AR00.19-P-0120-18A



017 545 17 28

4-pin RK 2.5 solder
contact coupling, -, black



Remove female contact

AR00.19-P-0120-17A



017 545 19 28

6-pin RK 2.5 solder
contact coupling, -, black



Remove female contact

AR00.19-P-0120-17A



Part number

Designation, Coding,
Color





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100AX

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 023

CONNECTOR PART NUMBERS - GF00.19-P-8100BA

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 026



019 545 19 28

3-pin RK 2.5 solder
contact connector, -, red



Remove contact pin

AR00.19-P-0120-18A



019 545 48 28

8-pin RK 2.5 solder
contact coupling, -, black



Remove female contact

AR00.19-P-0120-17A



019 545 49 28

8-pin RK 2.5 solder
contact plug, -, black



Remove contact pin

AR00.19-P-0120-18A



Part number

Designation, Coding,
Color





023 545 06 26

5-pin SLK coupling, B,
transparent



Remove female contact

AR00.19-P-0120-02B



023 545 51 26

3-pin SLK coupling, A, -



Remove female contact

AR00.19-P-0120-02A



023 545 51 28

8-pin RK 2.5 solder
contact coupling, -, brown



Remove female contact

AR00.19-P-0120-17A



023 545 52 26

3-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



023 545 53 26

3-pin SLK coupling, B,
transparent



Remove female contact

AR00.19-P-0120-02A



Part number

Designation, Coding,
Color



026 545 82 28

3-pin RK 2.5 solder





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100BD

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 028

CONNECTOR PART NUMBERS - GF00.19-P-8100BE

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 029



contact coupling, 3, red
Remove female contact

AR00.19-P-0120-17A



026 545 91 28

6-pin RK 2.5 solder
contact coupling, -, green



Remove female contact

AR00.19-P-0120-17A



Part number

Designation, Coding,
Color





028 545 27 28

6-pin RK 2.5, variant 1
coupling, B, orange



Remove female contact

AR00.19-P-0120-15A



028 545 38 28

4-pin SPT coupling, B,
black



Remove female contact

AR00.19-P-0120-10A



028 545 83 28

8-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



028 545 84 28

4-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



Part number

Designation, Coding,
Color





029 545 13 28

5-pin SPT coupling, A,
black



Remove female contact

AR00.19-P-0120-10A



029 545 19 28

8-pin RK 2.5 variant 1
coupling, A, black



Remove female contact

AR00.19-P-0120-15A

029 545 21 28

4-pin RK 2.5 variant 1





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100BF

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 030



coupling, A, black
Remove female contact

AR00.19-P-0120-15A



029 545 23 28

12-pin RK 2.5 variant 1
coupling, A, black



Remove female contact

AR00.19-P-0120-15A



029 545 25 28

8-pin RK 2.5 variant 1
plug, A, black Remove
contact pin

AR00.19-P-0120-16A



029 545 27 28

4-pin RK 2.5 variant 1
plug, A, black



Remove contact pin

AR00.19-P-0120-16A



029 545 29 28

12-pin RK 2.5 variant 1
plug, A, black



Remove contact pin

AR00.19-P-0120-16A



029 545 55 28

3-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



029 545 75 28

15-pin RK 2.5 variant 1
coupling, Z, black



Remove female contact

AR00.19-P-0120-15A



Part number

Designation, Coding,
Color





030 545 02 28

3-pin MQS coupling, D,
yellow



Remove female contact

AR00.19-P-0120-04A



030 545 19 28

6-pin RK 2.5 solder
contact coupling, B, white



Remove female contact

AR00.19-P-0120-17A



030 545 28 28

2-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



030 545 59 28

3-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



030 545 60 28

3-pin MQS connector, D,
yellow



Remove contact pin

AR00.19-P-0120-03A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
