Mercedes-Benz ML320. Service manual - part 517





CONNECTOR PART NUMBERS - GF00.19-P-8100AA

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-numbers 000

Plugs and couplings., part
initial numbers 050

GF00.19-P-8100EC

Plugs and couplings., part
initial numbers 051

GF00.19-P-8100EB

Plugs and couplings., part
initial numbers 052

GF00.19-P-8100EF

Plugs and couplings., part
initial numbers 053

GF00.19-P-8100EG

Plugs and couplings., part
initial numbers 168

GF00.19-P-8100BV

Plugs and couplings., part
initial numbers 169

GF00.19-P-8100EE

Plugs and couplings., part
initial numbers 170

GF00.19-P-8100BW

Plugs and couplings., part
initial numbers 193

GF00.19-P-8100BX

Plugs and couplings., part
initial numbers 202

GF00.19-P-8100BY

Plugs and couplings., part
initial numbers 203

GF00.19-P-8100BZ

Plugs and couplings., part
initial numbers 208

GF00.19-P-8100CA

Plugs and couplings., part
initial numbers 210

GF00.19-P-8100CB

Plugs and couplings., part
initial numbers 211

GF00.19-P-8100CC

Plugs and couplings., part
initial numbers 220

GF00.19-P-8100CD

Plugs and couplings., part
initial numbers 221

GF00.19-P-8100CF

Plugs and couplings., part
initial numbers 230

GF00.19-P-8100CE



Part number

Designation, Coding,
Color





000 153 08 42

4-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100AB



000 153 09 42

4-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02B



000 545 22 46

2-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



000 545 39 30

12-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



000 545 40 30

12-pin MQS coupling, B,
black



Remove female contact

AR00.19-P-0120-04A



000 545 42 30

18-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



000 545 44 30

18-pin MQS coupling, B,
black



Remove female contact

AR00.19-P-0120-04A



000 545 46 30

10-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



000 545 63 30

14-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



000 545 70 30

14-pin MQS coupling, B,
blue



Remove female contact

AR00.19-P-0120-04A



000 545 71 30

14-pin MQS coupling, C,
violet



Remove female contact

AR00.19-P-0120-04A



000 545 72 30

14-pin MQS coupling, D,
white



Remove female contact

AR00.19-P-0120-04A



000 545 86 30

12+2-pin MQS, LWL
coupling, -



Remove female contact

AR00.19-P-0120-04A



000 545 87 30

12+2-pin MQS, LWL
coupling, A, black



Remove female contact

AR00.19-P-0120-04A



000 545 88 30

12+2-pin MQS, LWL
coupling, B, transparent



Remove female contact

AR00.19-P-0120-04A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 001



Part number

Designation, Coding,
Color





001 540 24 81

4-pin LKS plug, A, black



Remove contact pin

AR00.19-P-0120-20A



001 540 28 81

6-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



001 540 32 81

6-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



001 540 79 81

18-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



001 540 97 81

6-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



001 545 03 30

12+2-pin MQS, LWL
coupling, A, water blue



Remove female contact

AR00.19-P-0120-04A



001 545 08 30

58-pin SLK coupling, -, -



Remove female contact

AR00.19-P-0120-02B



001 545 09 30

58-pin SLK coupling, 0,
black



Remove female contact

AR00.19-P-0120-02B



001 545 12 30

10-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



001 545 13 30

10-pin MQS coupling, B,
transparent



Remove female contact

AR00.19-P-0120-04A



001 545 14 30

10-pin MQS coupling, -, -
Remove female contact

AR00.19-P-0120-04A



001 545 50 40

28-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



001 545 59 40

10-pin MQS coupling, -,
black



Remove female contact

AR00.19-P-0120-04A

001 545 00 73

12+4-pin MQS, JPT
coupling, A, black





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100AC

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 002



Remove MQS female
contact

AR00.19-P-0120-04A

Remove JPT female
contact

AR00.19-P-0120-07A



001 545 01 73

5-pin MQS coupling, A,
yellow



Remove female contact

AR00.19-P-0120-04A



001 545 04 73

10-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



001 545 08 73

10-pin MQS coupling, A,
yellow



Remove female contact

AR00.19-P-0120-04A



001 545 13 73

10-pin MQS coupling, B,
blue



Remove female contact

AR00.19-P-0120-04A



001 545 14 73

10-pin MQS coupling, C,
violet



Remove female contact

AR00.19-P-0120-04A



001 545 08 83

28-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



Part number

Designation, Coding,
Color





002 540 04 81

6-pin MQS plug, B,
white



Remove contact pin

AR00.19-P-0120-03A



002 540 30 81

4-pin LKS plug, D, violet
Remove contact pin

AR00.19-P-0120-20A



002 540 31 81

4-pin LKS coupling, D,
white



Remove female contact

AR00.19-P-0120-19A



002 540 33 81

4-pin LKS coupling, D,
violet



Remove female contact

AR00.19-P-0120-19A

002 540 53 81

6-pin MQS coupling, D,



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
