Remove female contact

AR00.19-P-0120-04A



002 540 59 81

10-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A

002 540 61 81

3+2-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A

002 540 62 81

3+2-pin MQS, MCP
coupling, B, white





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A

002 540 63 81

3+2-pin MQS, MCP
coupling, C, blue





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A

002 540 64 81

3+2-pin MQS, MCP
coupling, D, violet





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A

002 540 65 81

3+2-pin MQS, MCP
coupling, E, green





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100AD

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463

002 540 67 81

3+3-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A



002 540 75 81

8-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



002 540 76 81

8-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



002 540 77 81

8-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



002 540 78 81

10-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



002 540 79 81

10-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A

002 545 47 40

3+3-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04A



Remove MCP female
contact

AR00.19-
P-0120-
09A



002 545 48 40

10-pin MQS coupling, -,
-



Remove female contact

AR00.19-P-0120-04A



002 545 49 40

10-pin MQS coupling, -,
black



Remove female contact

AR00.19-P-0120-04A



002 545 85 40

12-pin MQS coupling, -,
black



Remove female contact

AR00.19-P-0120-04A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



plugs and couplings, part initial numbers 003

CONNECTOR PART NUMBERS - GF00.19-P-8100AF



Part number

Designation, Coding,
Color





003 540 27 81

8-pin MQS coupling, -, -



Remove female contact

AR00.19-P-0120-04A



003 540 28 81

8-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



003 540 45 81

12-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



003 540 47 81

20-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



003 540 81 81

10-pin MQS coupling, D,
violet



Remove female contact

AR00.19-P-0120-04A



003 540 82 81

14-pin MQS plug, -,
yellow



Remove contact pin

AR00.19-P-0120-03A



003 545 01 40

12-pin MQS coupling, -, -
Remove female contact

AR00.19-P-0120-04A



003 545 79 40

10-pin MQS coupling, -,
black



Remove female contact

AR00.19-P-0120-04A



003 545 80 40

10-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



003 545 81 40

10-pin MQS coupling, B,
transparent



Remove female contact

AR00.19-P-0120-04A



003 545 82 40

10-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



003 546 01 40

12-pin MQS coupling, -,
black



Remove female contact

AR00.19-P-0120-04A



003 546 20 40

10-pin SLK coupling, -,
black (voltage distributor)



Remove female contact

AR00.19-P-0120-04A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 005

CONTACT PART NUMBERS - GF00.19-P-8100AM

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 012

CONTACT PART NUMBERS - GF00.19-P-8100AO



Part number

Designation, Coding,
Color





005 540 19 81

14-pin MQS connector, -, -
Remove contact pin

AR00.19-P-0120-03A



005 545 25 30

18-pin MQS coupling, C,
black



Remove female contact

AR00.19-P-0120-04A



005 545 28 30

32-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



005 545 29 30

10-pin MQS coupling, B,
black



Remove female contact

AR00.19-P-0120-04A



005 545 34 30

29-pin E 95 coupling, B,
black



Remove female contact

AR00.19-P-0120-05A



005 545 44 30

18-pin MQS coupling, D,
black



Remove female contact

AR00.19-P-0120-04A



Part number

Designation, coding,
color





012 545 70 26

3-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



012 545 71 26

3-pin SLK coupling, B,
white



Remove female contact

AR00.19-P-0120-02A



012 545 72 26

3-pin SLK coupling, C,
blue



Remove female contact

AR00.19-P-0120-02A
