CONNECTOR PART NUMBERS - GF00.19-P-8100BG

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 031



030 545 76 28

3-pin MQS coupling, A,
yellow



Remove female contact

AR00.19-P-0120-04A



030 545 77 28

3-pin RK 2.5 solder
contact coupling, -, orange



Remove female contact

AR00.19-P-0120-17A



030 545 78 28

3-pin RK 2.5 solder
contact plug, -, orange



Remove contact pin

AR00.19-P-0120-18A



Part number

Designation, Coding,
Color





031 545 00 28

6-pin E95 coupling, -, red
Remove female contact

AR00.19-P-0120-05A



031 545 55 28

2-pin LSK coupling, A,
black



Remove female contact

AR00.19-P-0120-12A



031 545 56 28

3+4-pin JPT, LSK
coupling, A, black



Remove JPT female
contact

AR00.19-P-0120-07A

Remove LSK female
contact

AR00.19-P-0120-12A



031 545 57 28

2-pin LSK plug, A, black



Remove contact pin

AR00.19-P-0120-13A



031 545 58 28

2-pin RK 2.5 variant 1
plug, -, -



Remove contact pin

AR00.19-P-0120-16A



031 545 59 28

2-pin RK 2.5 variant 1
plug, C, blue



Remove contact pin

AR00.19-P-0120-16A



031 545 60 28

2-pin RK 2.5 variant 1
plug, D, yellow



Remove contact pin

AR00.19-P-0120-16A



031 545 62 28

2-pin RK 2.5 variant 1
coupling, C, blue



Remove female contact

AR00.19-P-0120-15A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





031 545 63 28

2-pin RK 2.5 variant 1
coupling, D, yellow



Remove female contact

AR00.19-P-0120-15A



031 545 64 28

4-pin RK 2.5 variant 1
plug, B, white



Remove contact pin

AR00.19-P-0120-16A



031 545 65 28

4-pin RK 2.5 variant 1
plug, C, blue



Remove contact pin

AR00.19-P-0120-16A



031 545 66 28

8-pin RK 2.5 variant 1
coupling, B, orange



Remove female contact

AR00.19-P-0120-15A



031 545 67 28

8-pin RK 2.5 variant 1
coupling, C, blue



Remove female contact

AR00.19-P-0120-15A



031 545 68 28

8-pin RK 2.5 variant 1
coupling, D, yellow



Remove female contact

AR00.19-P-0120-15A



031 545 69 28

8-pin RK 2.5 variant 1
plug, B, orange



Remove contact pin

AR00.19-P-0120-16A



031 545 70 28

8-pin RK 2.5 variant 1
plug, C, blue



Remove contact pin

AR00.19-P-0120-16A



031 545 71 28

8-pin RK 2.5 variant 1
plug, D, yellow



Remove contact pin

AR00.19-P-0120-16A



031 545 72 28

4-pin RK 2.5 variant 1
coupling, B, white



Remove female contact

AR00.19-P-0120-15A



031 545 73 28

4-pin RK 2.5 variant 1
coupling, C, blue



Remove female contact

AR00.19-P-0120-15A



031 545 75 28

18-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



031 545 78 28

2-pin RK 2.5 variant 1
coupling, A, black



Remove female contact

AR00.19-P-0120-15A



031 545 79 28

2-pin RK 2.5 variant 1
plug, -, -



Remove contact pin

AR00.19-P-0120-16A

031 545 80 28

2-pin RK 2.5 variant 1
plug, A, black





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100BH

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 032



Remove contact pin

AR00.19-P-0120-16A



031 545 81 28

8-pin RK 2.5 variant 1
coupling, B, gray



Remove female contact

AR00.19-P-0120-15A



031 545 82 28

8-pin RK 2.5 variant 1
plug, B, gray



Remove contact pin

AR00.19-P-0120-16A



031 545 88 28

18-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



Part number

Designation, Coding,
Color





032 545 03 28

3-pin RK 2.5 variant 1
plug, A, black



Remove contact pin

AR00.19-P-0120-16A



032 545 05 28

3-pin RK 2.5 variant 1
coupling, A, black



Remove female contact

AR00.19-P-0120-15A



032 545 09 28

2-pin RK 2.5 variant 1
coupling, B, white



Remove female contact

AR00.19-P-0120-15A



032 545 10 28

2-pin RK 2.5 variant 1
plug, B, white



Remove contact pin

AR00.19-P-0120-16A



032 545 16 28

1-pin RK 2.5 variant 1
coupling, A, black



Remove female contact

AR00.19-P-0120-15A



032 545 17 28

1-pin RK 2.5 variant 1
plug, A, black



Remove contact pin

AR00.19-P-0120-16A



032 545 18 28

15-pin RK 2.5 variant 1
coupling, A, black



Remove female contact

AR00.19-P-0120-15A



032 545 19 28

2-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A

032 545 20 28

2-pin MQS coupling, C,





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONTACT PART NUMBERS - GF00.19-P-8100BI

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 033



blue
Remove female contact

AR00.19-P-0120-04A



032 545 21 28

2-pin MQS coupling, D,
violet



Remove female contact

AR00.19-P-0120-04A



032 545 24 28

2-pin MQS coupling, Z,
blue



Remove female contact

AR00.19-P-0120-04A



032 545 52 28

8-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



032 545 53 28

8-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



032 545 68 28

4-pin MQS coupling, D,
violet



Remove female contact

AR00.19-P-0120-04A



032 545 70 28

4-pin MQS plug, A, black
Remove contact pin

AR00.19-P-0120-03A



032 545 83 28

12-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



032 545 84 28

12-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



032 545 85 28

12-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A



032 545 86 28

12-pin MQS coupling, D,
yellow



Remove female contact

AR00.19-P-0120-04A



032 545 98 28

4-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



032 545 99 28

4-pin MQS coupling, C,
blue



Remove female contact

AR00.19-P-0120-04A
