Mercedes-Benz ML320. Service manual - part 524





CONNECTOR PART NUMBERS - GF00.19-P-8100BZ

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


plugs and couplings, part initial numbers 203



Part number

Color





202 540 59 81

16-pin MT -3 coupling, -,
black



Remove MT -3 female
contact

AR00.19-P-0120-06A

202 545 43 28

47-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-
P-0120-
04B

Remove MCP female
contact

AR00.19-P-0120-09A



Part number

Designation, Coding,
Color





203 540 03 81

3-pin MQS plug, B, black
Remove contact pin

AR00.19-P-0120-03A



203 545 01 28

6-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



203 545 03 28

6-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



203 545 05 28

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



203 545 19 28

47-pin MQS, MCP
coupling, A, black





Remove MQS female
contact

AR00.19-P-0120-04B



Remove MCP female
contact

AR00.19-P-0120-09A



203 545 20 28

47-pin MQS, MCP
coupling, B, black





Remove MQS female
contact

AR00.19-P-0120-04B

Remove MCP female

AR00.19-P-0120-09A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONTACT PART NUMBERS - GF00.19-P-8100CA

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 208



contact



203 545 25 28

2-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



203 545 30 28

3-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02A



203 545 36 28

4-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



203 545 38 28

3-pin SLK coupling, A,
black



Remove female contact

AR00.19-P-0120-02B



203 545 46 28

2-pin MLK coupling, A,
black



Remove female contact

AR00.19-P-0120-26A



203 545 48 28

3-pin SLK coupling, -, -



Remove female contact

AR00.19-P-0120-02A



203 545 49 28

3-pin SLK coupling, B,
gray



Remove female contact

AR00.19-P-0120-02A



203 545 51 28

4-pin JPT coupling, A,
gray



Remove female contact

AR00.19-P-0120-07A



Part number

Designation, Coding,
Color





208 540 01 81

14-pin MQS coupling, Z,
black



Remove female contact

AR00.19-P-0120-04A



208 540 05 81

14-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



208 545 02 28

8-pin MQS coupling, Z,
blue



Remove female contact

AR00.19-P-0120-04A

208 545 03 28

8-pin MQS coupling, C,





2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



CONNECTOR PART NUMBERS - GF00.19-P-8100CB

MODEL 124, 126, 129, 140, 163, 164, 168, 169, 170, 171, 199, 202, 203, 208, 209, 210, 211, 215, 216, 219,
220, 221, 230, 240, 245, 251, 414, 461, 463


Connector and couplings part-original-number 210



blue
Remove female contact

AR00.19-P-0120-04A



208 545 04 28

8-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



208 545 05 28

8-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



208 545 07 30

14-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



208 545 08 30

14-pin MQS coupling, Z,
black



Remove female contact

AR00.19-P-0120-04A



208 545 09 28

8-pin MQS coupling, E,
green



Remove female contact

AR00.19-P-0120-04A



208 545 10 28

8-pin MQS coupling, F,
brown



Remove female contact

AR00.19-P-0120-04A



Part number

Designation, Coding,
Color





210 440 01 81

6-pin SPT coupling, a



Remove female contact

AR00.19-P-0120-10A



210 440 03 81

6-pin SPT coupling, A,
black



Remove female contact

AR00.19-P-0120-10A



210 440 04 81

6-pin SPT coupling, A,
black



Remove female contact

AR00.19-P-0120-10A



210 440 05 81

6-pin SPT coupling, A,
black



Remove female contact

AR00.19-P-0120-10A



210 540 13 81

12-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me





210 540 14 81

18-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



210 540 20 81

2-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



210 540 21 81

3-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



210 540 30 81

12-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



210 540 32 81

18-pin MQS coupling, B,
white



Remove female contact

AR00.19-P-0120-04A



210 540 36 81

6-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



210 540 43 81

4-pin MQS coupling, A,
black



Remove female contact

AR00.19-P-0120-04A



210 540 47 81

2-pin MQS plug, A,
black



Remove contact pin

AR00.19-P-0120-03A



210 540 49 81

4-pin MQS plug, A,
black



Remove contact pin

AR00.19-P-0120-03A



210 540 74 81

4-pin E 95 coupling, B
black



Remove female contact

AR00.19-P-0120-05A



210 545 01 30

8-pin JPT coupling, A,
black



Remove female contact

AR00.19-P-0120-07A

210 545 01 45

9-pin E 95, JPT
coupling, B, black





Remove E 95 female
contact

AR00.19-
P-0120-
05A



Remove JPT female
contact

AR00.19-
P-0120-
07A

210 545 02 46

4-pin MPT, JPT
coupling





Remove MPT female

AR00.19-



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
