REMOVING AND INSTALLING REAR WINDOW WIPER MOTOR - AR82.30-P-6900GH

MODEL 163

Fig. 183: Identifying Rear Window Wiper Motor Components

wiper linkage (2) to wiper
motor (M6/1)

5

Disconnect connector
(X88/2)

 Installation: Move

wiper motor to park
position

AR82.30-P-6800-01E

6

Remove wiper motor
(M6/1)





7

Reinstall in opposite
order









Removal, installation







Injury hazard from
pinching and crushing, in
extreme cases extremities
can even be cut off when
caught in windshield
wiper mechanism.

Always remove ignition
key before working on
windshield wiper
mechanism.

AS82.30-Z-0001-01A

1

Move wiper motor to
park position



AR82.30-P-6800-01E

2

Remove line on tailgate



AR72.20-P-3520GH

3

Remove wiper arm on
tailgate



AR82.30-P-6910GH

4

Remove center high-
mounted stop lamp



AR82.10-P-5375GH

5

Disconnect connector (3)



6

Disconnect washing
water line from connector
(1)







2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



REMOVING AND INSTALLING TAILGATE WIPER ARM - AR82.30-P-6910GH

MODEL 163

Fig. 184: Identifying Tailgate Wiper Arm Components

7

Unscrew screw for wiper
system on tailgate (2)





8

Remove rear window
wiper motor (M6/4)

 When installing:

Replace rear window
grommet if necessary,
observe installation
position



9

Reinstall in opposite
order









Removal, installation







Injury hazard from
pinching and crushing, in
extreme cases extremities
can even be cut off when
caught in windshield
wiper mechanism.

Always remove ignition
key before working on
windshield wiper
mechanism.

AS82.30-Z-0001-01A

1

Open cover (1)

 Wiper motor must be

in park position, if
necessary ?







move wiper motor to park
position

AR82.30-P-6800-01E

2

Unscrew nut on wiper
arm (2)

 Caution, do not

damage washer nozzle









*BA82.30-P-1001-01C

3

Remove wiper arm (3)

 Pivot wiper arm back

and remove, if
necessary ?





2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



 Wiper

Fig. 185: Identifying Puller (001 589 38 33 00)

REMOVE/INSTALL RAIN SENSOR - AR82.30-P-7700GH

MODELS 163.113 /128 /154 /157 /172 /174 /175 with CODE (345a) Rain sensor







Fig. 185

4

Reinstall in opposite
order

 When installing:

Attach wiper arms so that
wiper arm points toward
left (driver's side)



Number

Designation

Model 163

BA82.30-P-1001-01C

Nut for rear window
wiper arm

Nm 15



2001 Mercedes-Benz ML320

1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis



me



Fig. 186: Identifying Rain Sensor Components

Modification notes

11.4.03

Disconnecting ground
lead from battery newly
included

Step 1







Remove/Install





1

Disconnect ground
cable of battery



AR54.10-P-0003A

2

Remove rearview
mirror (1).

Models 163.154/172#A up to
145272, Models 163.154/172#X up
to 708318

AR68.40-P-0001GH





Models 163.154/172#A as of
145273, Models 163.154/172#X as
of 708319, Models
163.113/128/157/174/175

AR68.40-P-0001GI

3

Disconnect electrical
connector (2) from
rain sensor(B38)





4

Press retaining lugs
(arrows) downward





5

Remove rain sensor
(B38)

 Lens of rain sensor (B38) is

bonded to the windshield and may
