Mercedes-Benz ML320. Service manual - part 89





183

Controls in detail

Useful features

Step 5:

When the indicator lamp 6 flashes
rapidly, release both buttons.

Step 6:

Press and hold the just-trained inte-
grated signal transmitter button and
observe the indicator lamp 6.

If the indicator lamp 6 stays on con-
stantly, programming is complete and
your device should activate when the
integrated signal transmitter button is
pressed and released.

Step 7:

To program the remaining two buttons,
repeat the steps above starting with
step 3.

Rolling code programming

To train a garage door opener (or other roll-
ing code devices) with the rolling code fea-
ture, follow these instructions after
completing the “Programming” portion
(steps 1 through 6) of this text. (A second
person may make the following training
procedures quicker and easier.)

Step 8:

Locate “training” button on the garage
door opener motor head unit.

Exact location and color of the button
may vary by garage door opener brand.
Depending on manufacturer, the “train-
ing” button may also be referred to as
“learn”or “smart” button. If there is dif-
ficulty locating the transmitting button,
refer to the garage door opener opera-
tor’s manual.

i

The indicator lamp 6 flashes the first
time the signal transmitter button is
programmed. If this button has already
been programmed, the indicator lamp
will only start flashing after 20 sec-
onds.

i

If the indicator lamp 6 flashes rapidly
for about two seconds and then turns
to a constant light, continue with pro-
gramming steps 8 through 12 as your
garage door opener may be equipped
with the “rolling code” feature.

컄컄

184

Controls in detail

Useful features

Step 9:

Press “training” button on the garage
door opener motor head unit.

The “training light” is activated.

You have 30 seconds to initiate the follow-
ing step.

Step 10:

Firmly press, hold for two seconds and
release the programmed integrated
signal transmitter button (3, 4
or 5).

Step 11:

Press, hold for two seconds and re-
lease same button a second time to
complete the training process.

Some garage door openers (or other rolling
code equipped devices) may require you to
perform this procedure a third time to
complete the training.

Step 12:

Confirm the garage door operation by
pressing the programmed integrated
signal transmitter button (3, 4
or 5).

Step 13:

To program the remaining two buttons,
repeat the steps above starting with
step 3.

Gate operator/Canadian programming

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
which may not be long enough for the inte-
grated signal transmitter to pick up the sig-
nal during programming. Similar to this
Canadian law, some U.S. gate operators
are designed to “time-out” in the same
manner.

If you live in Canada or if you are having dif-
ficulties programming a gate operator (re-
gardless of where you live) by using the
programming procedures, replace step 4
with the following:

컄컄

185

Controls in detail

Useful features

Step 4:

Continue to press and hold the inte-
grated signal transmitter button (3,
4 or 5) while you press and re-press
(“cycle”) your hand-held remote con-
trol transmitter 1 every two seconds
until the frequency signal has been
learned. Upon successful training, the
indicator lamp 6 will flash slowly and
then rapidly after several seconds.

Proceed with programming step 5 and
step 6 to complete.

Operation of remote control

 Switch on ignition.

Select and press the appropriate inte-
grated signal transmitter button (3,
4 or 5 to activate the remote con-
trolled device.

The integrated remote control trans-
mitter continues to send the signal as
long as the button is pressed – up to
20 seconds.

Erasing the remote control memory

 Switch on ignition.

Simultaneously hold down the signal
transmitter buttons 3 and 5, for ap-
proximately 20 seconds, or until the in-
dicator lamp 6 flashes rapidly. Do not
hold for longer than 30 seconds.

The codes of all three channels are
erased.

Reprogramming a single integrated
signal transmitter button

To program a device using a signal trans-
mitter button previously trained, follow
these steps:

Press and hold the desired signal trans-
mitter button (3, 4 or 5). Do not re-
lease the button.

The indicator lamp will begin to flash af-
ter 20 seconds. Without releasing the
integrated signal transmitter button,
proceed with programming starting
with step 3.

i

If you sell your vehicle, erase the codes
of all three channels.

186

Controls in detail

Useful features

Trip computer*

The trip computer is located in the
overhead console.

1 RESET
2 MODE
3 Display

Switching on the trip computer

Switch on ignition.

Display 3 shows one of the available
functions.

If a function display does not appear,
press MODE 2.

Selecting functions

Press MODE 2 repeatedly until the
desired display appears.

The functions are displayed in the follow-
ing order:

Date

Compass

Stop watch

Present fuel consumption

Average fuel consumption

Distance remaining

Country

Switching off trip computer

Setting the date

Press MODE 2 repeatedly until the
date appears.

Press RESET 1.

The month shown flashes.

Press MODE 2 to advance to selected
month.

Press RESET 1.

The day shown flashes.

Press MODE 2 to advance to selected
day.

Press RESET 1.

The year shown flashes.

Press MODE 2 to advance to selected
year.

Press RESET 1.

The display stops flashing and the date
is set.

i

With engine not running, the display
switches off automatically 30 seconds
after the last entry.
