2-70

Instruments and controls

JVI1509X

CONSOLE BOX

Front

To open the console box lid from the front
seat, push up the knob

and pull up the lid.

To open the console box lid from the 2nd
row seat, push the knob

.

To close, push the lid down until the lock
latches.

SIC4422

Rear (if so equipped)

To open the lid, push the knob up

and pull

up the lid.
To close, push the lid down until the lock
latches.

CAUTION

Do not sit or step on the center console.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SIC4423

Pocket:

To open the pocket, pull the knob

.

To close, push the lid until the lock latches.

SIC3505

COAT HOOKS

The coat hooks are equipped at the rear
assist grips.

CAUTION

Do not place items which are more than
2 lb (1 kg) on the hook.

SIC4446

LUGGAGE HOOKS

WARNING

.

Always make sure that the cargo is
properly secured. Use the suitable
ropes and hooks.

.

Unsecured cargo can become danger-
ous in an accident or sudden stop.

.

Never allow anyone to ride in the
luggage area. It is extremely danger-
ous to ride in a cargo area inside of a
vehicle. In a collision, people riding in
these areas are more likely to be
seriously injured or killed.

Instruments and controls

2-71

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-72

Instruments and controls

.

Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat belts.

.

The child restraint top tether strap
may be damaged by contact with
items in the cargo area. Secure any
items in the cargo area. Your child
could be seriously injured or killed in a
collision if the top tether strap is
damaged.

.

Be sure everyone in your vehicle is in
a seat and using a seat belt properly.

CAUTION

Do not apply a total load of more than
22 lb (10 kg)

or 7 lb (3 kg)

to the

hook.

JVI0309X

CARGO FLOOR BOX

Push the handle to open the cargo floor
board

.

JVI1741X

ROOF RACK

Do not apply any load directly to the roof
side rails. Cross bars must be installed before
applying load/cargo/luggage to the roof of
the vehicle. Genuine INFINITI accessory
cross bars are available through an INFINITI
retailer. It is recommended that you visit an
INFINITI retailer for additional information.
The service load capacity for the roof side
rails is 221 lb (100 kg), however do not
exceed the accessory cross bars load capa-
city.
Be careful that your vehicle does not exceed
the Gross Vehicle Weight Rating (GVWR) or
its Gross Axle Weight Rating (GAWR front

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

and rear). The GVWR and GAWR are
located on the F.M.V.S.S. or C.V.M.S.S.
certification label (located on the driver’s
door pillar). For additional information re-
garding GVWR and GAWR, refer to “Vehicle
loading information” (P.10-15).

WARNING

.

Always install the cross bars onto the
roof side rails before loading cargo of
any kind. Loading cargo directly onto
the roof side rails or the vehicle’s roof
may cause vehicle damage.

.

Drive extra carefully when the vehicle
is loaded at or near the cargo carrying
capacity, especially if the significant
portion of that load is carried on the
roof rack.

.

Heavy loading of the roof rack has
the potential to affect the vehicle
stability and handling during sudden
or unusual handling maneuvers.

.

Roof rack load should be evenly
distributed.

.

Do not exceed maximum roof rack
load weight capacity.

.

Properly secure all cargo with ropes
or straps to help prevent it from
sliding or shifting. In a sudden stop

or collision, unsecured cargo could
cause personal injury.

The sound with a feeling of oppression may
occur with the rear windows open and front
windows close. To reduce the sound, slightly
open either a front window or the moonroof.

POWER WINDOWS

WARNING

The driver is always responsible for all
the power window operation including
passenger’s operation. Be sure to ob-
serve the following warnings for safety.

.

Never allow anyone to extend any
portion of their body or objects out of
the opening while the vehicle is in
motion. Otherwise they may be ser-
iously damaged by coming into con-
tact with objects outside the vehicle
or when abruptly braking.

.

Make sure that all passengers have
their hands, etc. inside the vehicle
before operating the power win-
dows. Do not intentionally activate
the auto-reverse function. If their
hands or faces are caught in the
windows, it could cause serious in-
jury.

.

Never allow children to operate the
power window. Improper operation
by children could lead to an accident.

Instruments and controls

2-73

WINDOWS

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-74

Instruments and controls

Depress the window lock button
since children or other persons could
be caught in the power window and
this may cause serious damage.

.

When operating the power windows,
let children know it and make sure
that their hands, arms, etc. are not
placed near the power windows.
Otherwise they may be caught in
the power windows.

.

Make sure that the ignition switch is
in the OFF position and do not leave
the Intelligent Key and children un-
attended inside the vehicle. They
could unknowingly activate switches
or controls. Unattended children
could become involved in serious
accidents.

.

To help avoid risk of injury or death
through unintended operation of the
vehicle and or its systems, including
entrapment in windows or inadver-
tent door lock activation, do not
leave children, people who require
the assistance of others or pets
unattended in your vehicle. Addition-
ally, the temperature inside a closed
vehicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.

The power windows operate when the
ignition switch is in the ON position or for
about 45 seconds after the ignition switch is
pushed to the OFF position. If the driver’s or
front passenger’s door is opened during this
period of about 45 seconds, power to the
windows is canceled.

SIC4352

1.

Driver side window

2.

Front passenger side window

3.

Rear left passenger side window

4.

Rear right passenger side window

5.

Window lock button

Main power window switch (dri-
ver’s side)

To open or close the window, push down
or pull up

the switch and hold it. The main

switch (driver side switches) will open or
close all the windows.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking passengers’ windows

When the lock button

is pushed in, only

the driver side window can be opened or
closed. Push it in again to cancel.

SIC4353

Passenger side power window
switch

The passenger side switch will open or close
only the corresponding window. To open or
close the window, push down or pull up the
switch and hold it.

SIC4354

Automatic operation

To fully open or close the window, comple-
tely push down or pull up the switch and
release it; it need not be held. The window
will automatically open or close all the way.
To stop the window, just push or lift the
switch in the opposite direction.
A light push or pull on the switch will cause
the window to open or close until the switch
is released.

Instruments and controls

2-75

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-76

Instruments and controls

Auto reverse function

WARNING

There are some small distances immedi-
ately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., inside
the vehicle before closing the window.

If the control unit detects something caught
in the window as it is closing, the window
will be immediately lowered.
The auto reverse function can be activated
when the window is closed by automatic
operation when the ignition switch is in the
ON position or for 45 seconds after the
ignition switch is pushed to the OFF posi-
tion.

Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.

If the windows do not close auto-
matically

If the power window automatic function
(closing only) does not operate properly,
perform the following procedure to initialize

the power window system.
1. Push the ignition switch to start the

engine.

2. Close the door.
3. After starting the engine, open the

window completely by operating the
power window switch.

4. Pull the power window switch and hold it

to close the window, and then hold the
switch more than 3 seconds after the
window is closed completely.

5. Release the power window switch. Op-

erate the window by the automatic
function to confirm the initialization is
complete.

6. Perform steps 2 through 5 above for

other windows.

If the power window automatic function
does not operate properly after performing
the procedure above, have your vehicle
checked. It is recommended you visit an
INFINITI retailer for this service.

WARNING

.

In an accident you could be thrown
from the vehicle through an open
moonroof. Always use seat belts
and child restraints.

.

Do not allow anyone to stand up or
extend any portion of their body out
of the moonroof opening while the
vehicle is in motion or while the
moonroof is closing.

CAUTION

.

Remove water drops, snow, ice or
sand from the moonroof before
opening.

.

Do not place any heavy object on the
moonroof or surrounding area.

MOONROOF

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

POWER MOONROOF

The moonroof only operates when the
ignition switch is in the ON position.
The moonroof is operational for about 45
seconds, even if the ignition switch is pushed
to the OFF position. If the driver’s door or
the passenger’s door is opened during this
period of about 45 seconds, power to the
moonroof is canceled.

JVI0614X

Sunshade

The sunshade will open automatically when
the moonroof is opened. However, it must
be closed manually.

Tilting the moonroof

To tilt up, first close the moonroof, then
push the switch to the TILT UP position
and release it; it need not be held. To tilt
down the moonroof, push the switch to the
TILT DOWN

position.

Sliding the moonroof

To fully open or close the moonroof, push
the switch to the OPEN

or CLOSE

position and release it; it need not be held.

The roof will automatically open or close all
the way. To stop the roof, push the switch
once more while it is opening or closing.

Auto reverse function

WARNING

There are some small distances immedi-
ately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., inside
the vehicle before closing the moonroof.

If the control unit detects something caught
in the moonroof when it is closing, the
moonroof will be immediately opened.
The auto reverse function can be activated
when the moonroof is closed by automatic
operation when the ignition switch is in the
ON position or for about 45 seconds after
the ignition switch is pushed to the OFF
position.
If the moonroof cannot be closed automa-
tically when the auto reverse function
activates due to a malfunction, push and
hold the switch to the CLOSE

position.

Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to

Instruments and controls

2-77

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-78

Instruments and controls

something being caught in the moonroof
occurs.

If the moonroof does not operate

If the moonroof does not operate properly,
perform the following procedure to initialize
the moonroof operation system.
1. If the moonroof is open, close it fully by

repeatedly pushing the moonroof switch
to the CLOSE

position.

2. Push and hold the switch to the CLOSE

position.

3. Release the moonroof switch after the

moonroof moves slightly up and down.

4. Push and hold the switch to the OPEN

position to fully tilt the moonroof down.

5. Check if the moonroof switch operates

normally.

If the moonroof does not operate properly
after performing the procedure above, have
your vehicle checked. It is recommended you
visit an INFINITI retailer for this service.

SIC3642

To activate or deactivate the welcome light
function, perform the following procedure.
1. Push the ignition switch to the ON

position.

2. Open the driver’s side door.
3. Within 20 seconds after the ignition

switch is pushed to the ON position,
push the door open request switch on
the driver’s side door handle for more
than 5 seconds with the driver’s door
open.

4. A chime sounds when the setting is

completed.

Once the welcome light function is active,
the puddle light

and the passenger cabin

illumination will illuminate when you ap-
proach the vehicle with the Intelligent Key
(within approximately 3.3 ft (1 m) of the
antenna built inside the door handles) and
the following conditions are met.

.

All doors are closed and locked.

.

The ignition switch is in the LOCK or OFF

position.

.

The Intelligent Key is outside the vehicle.

.

The puddle light operates within a set

duration.

BATTERY SAVER SYSTEM

The welcome light function will be deacti-
vated automatically to prevent battery dis-
charge under the following conditions. To
activate the welcome light function again,
unlock any door.

.

If the welcome light function does not

operate within a set duration. Note that
the duration is set to 9 days as the
factory default setting.

.

If the welcome light function is activated

15 consecutive times when you approach
and leave the vehicle with the Intelligent
Key without the doors being unlocked.

WELCOME LIGHT

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

.

Turn off the lights when you leave
the vehicle.

.

Do not use the lights for extended
periods of time with the engine
stopped. This could result in a dis-
charged battery.

JVI0760X

INTERIOR LIGHT SWITCH

ON switch

When the ON switch

is pushed in, the map

lights and rear personal lights will illuminate.

DOOR OFF switch

When the switch

is not pushed in, the map

lights and rear personal lights will illuminate
for a period of time under the following
conditions:

.

when the ignition switch is placed in the

OFF position.

.

when doors are unlocked by pushing the

UNLOCK

button on the Intelligent

Key or door handle request switch with

the ignition switch in the OFF position.

.

when any door is opened and then closed

with the ignition switch in the OFF
position.

.

when any door is opened with the

ignition switch in the ACC or ON posi-
tion.
— The lights will remain on while the

door is opened. When the door is
closed, the lights will turn off.

When the "Auto Room Lamp" feature is set
to be OFF (see “Vehicle settings” (P.2-23)),
the lights will illuminate under the following
condition:

.

any door is opened with the ignition

switch in any position
— remain on while the door is opened.

When the door is closed, the lights go
off.

When the switch

is pushed in, the map

lights and rear personal lights will not
illuminate under the above condition.

Instruments and controls

2-79

INTERIOR LIGHTS

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-80

Instruments and controls

JVI0759X

CONSOLE LIGHT

The console light will turn on whenever the
front parking lights or headlights are illumi-
nated.

JVI0758X

MAP LIGHTS

Push the button as illustrated to turn the
light on or off.

SIC3250

REAR PERSONAL LIGHTS

Push the button as illustrated to turn the
light on or off.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SIC4448

The light on the vanity mirror will turn on
when the cover on the vanity mirror is
opened.
When the cover is closed, the light will turn
off.

The lights will also turn off after a period of
time when the lights remain illuminated to
prevent the battery from becoming dis-
charged.

SIC4418

The cargo light switch has three positions:
ON

, center

and OFF

.

ON position
When the switch is in the ON position

, the

cargo light will illuminate.
Center position
When the switch is in the center position

,

the cargo light will illuminate when the
liftgate is opened.
OFF position
When the switch is in the OFF position

,

the cargo light will not illuminate.

The HomeLink

®

Universal Transceiver pro-

vides a convenient way to consolidate the
functions of up to three individual hand-held
transmitters into one built-in device.
HomeLink

®

Universal Transceiver:

.

Will operate most Radio Frequency (RF)

devices such as garage doors, gates,
home and office lighting, entry door
locks and security systems.

.

Is powered by your vehicle’s battery. No

separate batteries are required. If the
vehicle’s battery is discharged or is
disconnected, HomeLink

®

will retain all

programming.

When the HomeLink

®

Universal Transceiver

is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink

®

Universal Transceiver buttons

should be erased for security purposes. For
additional information, refer to “Program-
ming HomeLink

®

” (P.2-82).

WARNING

.

Do not use the HomeLink

®

Universal

Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-

Instruments and controls

2-81

VANITY MIRROR LIGHTS

CARGO LIGHT

HomeLink

®

UNIVERSAL

TRANSCEIVER (Type A) (if so equipped)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-82

Instruments and controls

dards became effective for opener
models manufactured after April 1,
1982.) A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.

.

During the programming procedure
your garage door or security gate will
open and close (if the transmitter is
within range). Make sure that people
or objects are clear of the garage
door, gate, etc. that you are pro-
gramming.

.

Your vehicle’s engine should be
turned off while programming the
HomeLink

®

Universal Transceiver.

Do not breathe exhaust gases; they
contain colorless and odorless carbon
monoxide. Carbon monoxide is dan-
gerous. It can cause unconsciousness
or death.

PROGRAMMING HomeLink

®

The following steps show generic instruc-
tions how to program a HomeLink

®

button.

If you have any questions or are having
difficulty programming your HomeLink

®

buttons, refer to the HomeLink

®

web site

at: www.homelink.com/infiniti or call 1-
800-355-3515.

NOTE:

It is also recommended that a new battery
be placed in the hand-held transmitter of
t h e d e v i c e b e i n g p r o g r a m m e d t o
HomeLink

®

for quicker programming and

accurate transmission of the radio-fre-
quency.

1. Position the end of your hand-held

transmitter 1-3 in (26-76 mm) away
from the HomeLink

®

surface, keeping

the HomeLink

®

indicator light

in view.

JVI0428X

2. Using both hands, simultaneously press

and hold the desired HomeLink

®

button

and handheld transmitter button. DO
NOT release until the HomeLink

®

indi-

cator light

flashes slowly and then

rapidly. When the indicator light flashes
rapidly, both buttons may be released.
(The rapid flashing indicates successful
programming.)

NOTE:
Some devices to be programmed may
require you to replace Step 2 with the
cycling procedure noted in the “Pro-
gramming HomeLink

®

for Canadian cus-

tomers and gate openers” (P.2-83).

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVI0429X

3. Press the button for 2 seconds up to 3

times.

.

If the garage door responds, program-

ing is completed.

.

If the garage door does not respond,

continue with Steps 4-6 for a rolling
code device. A second person may
make the following steps easier. Use a
ladder or other device. Do not stand
on your vehicle to perform the next
steps.

4. At the receiver located on the garage

door opener motor in the garage, locate
the “Learn” or “Set” button (the name
and color of the button may vary by
manufacturer but it is usually located

near where the hanging antenna wire is
attached to the unit). If there is difficulty
locating the button, reference the garage
door opener’s manual.

5. Press and release the “Learn” or “Set”

button.

NOTE:
Once the button is pressed, you have
approximately 30 seconds to initiate the
next step.

6. Return to the vehicle and firmly press

and hold the programmed HomeLink

®

button for two seconds and release.
Repeat the “press/hold/release” se-
quence up to 3 times to complete the
programming process. HomeLink

®

should now activate your rolling code
equipped device.

7. If you have any questions or are having

difficulty programming your HomeLink

®

buttons, refer to the HomeLink

®

web

site at: www. homelink.com/infiniti or
call 1-800-355-3515.

PROGRAMMING HomeLink

®

FOR

CANADIAN CUSTOMERS AND
GATE OPENERS

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission –
which may not be long enough for
HomeLink

®

to pick up the signal during

programming. Similar to this Canadian law,
some U.S. gate operators are designed to
“time-out” in the same manner.
If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the “Program-
ming HomeLink

®

” procedures, replace “Pro-

gramming HomeLink

®

” Step 2 with the

following:

NOTE:

When programming a garage door opener,
etc., unplug the device during the “cycling”
process to prevent possible damage to the
garage door opener components.

Step 2: Using both hands, simultaneously
press and hold the desired HomeLink

®

button and the hand-held transmitter but-
ton. During programming, your hand-held
transmitter may automatically stop trans-
mitting. Continue to press and hold the
desired HomeLink

®

button while you press

and re-press (“cycle”) your hand-held trans-

Instruments and controls

2-83

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-84

Instruments and controls

mitter every two seconds until the frequency
signal has been learned. The HomeLink

®

indicator light will flash slowly and then
rapidly after several seconds upon success-
ful programming.

DO NOT

release until the

HomeLink

®

indicator light flashes slowly and

then rapidly. When the indicator light flashes
rapidly, both buttons may be released. The
rapid flashing indicates successful program-
ming.
Proceed with “Programming HomeLink

®

step 3 to complete.
Remember to plug the device back in when
programming is completed.

OPERATING THE HomeLink

®

UNIVERSAL TRANSCEIVER

The HomeLink

®

Universal Transceiver, after

it is programmed, can be used to activate the
programmed device. To operate, simply
press and release the appropriate pro-
grammed HomeLink

®

Universal Transceiver

button. The amber indicator light will illumi-
nate while the signal is being transmitted.
For convenience, the hand-held transmitter
of the device may also be used at any time.

PROGRAMMING TROUBLE-
SHOOTING

If the HomeLink

®

does not quickly learn the

hand-held transmitter information:

.

replace the hand-held transmitter bat-

teries with new batteries.

.

position the hand-held transmitter with

its battery area facing away from the
HomeLink

®

surface.

.

press and hold both the HomeLink

®

and

hand-held transmitter buttons without
interruption.

.

position the hand-held transmitter 1-3 in

(26-76 mm) away from the HomeLink

®

surface. Hold the transmitter in that
position for up to 15 seconds. If
HomeLink

®

is not programmed within

that time, try holding the transmitter in
another position - keeping the indicator
light in view at all times.

If you have any questions or are having
difficulty programming your HomeLink

®

buttons, refer to the HomeLink

®

web site

at: www. homelink.com/infiniti or 1-800-
355-3515.

CLEARING THE PROGRAMMED
INFORMATION

The following procedure clears the pro-
grammed information from both buttons.
Individual buttons cannot be cleared. How-
ever, individual buttons can be repro-
grammed, see “Reprogramming a single
HomeLink

®

button” (P.2-84).

To clear all programming

1. Press and hold the two outer HomeLink

®

buttons until the indicator light begins to
flash in approximately 10 seconds. Do
not hold for longer than 20 seconds.

2. Release both buttons.
HomeLink

®

is now in the programming mode

and can be programmed at any time begin-
ning with “Programming HomeLink

®

” - Step

1.

REPROGRAMMING A SINGLE
HomeLink

®

BUTTON

To reprogram a HomeLink

®

Universal Trans-

ceiver button, complete the following.
1. Press and hold the desired HomeLink

®

button.

Do not

release the button.

2. The indicator light will begin to flash

after 20 seconds. Without releasing the
HomeLink

®

button, proceed with “Pro-

gramming HomeLink

®

” - Step 1.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

For questions or comments, contact
HomeLink

®

at: www. homelink.com/infiniti

or 1-800-355-3515.
The HomeLink

®

Universal Transceiver but-

ton has now been reprogrammed. The new
device can be activated by pushing the
HomeLink

®

button that was just pro-

grammed. This procedure will not affect
any other programmed HomeLink

®

buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change
the codes of any non-rolling code device that
has been programmed into HomeLink

®

.

Consult the Owner’s Manual of each device
or call the manufacturer or retailer of those
devices for additional information.

When your vehicle is recovered, you will
need to reprogram the HomeLink

®

Univer-

sal Transceiver with your new transmitter
information.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.

For Canada:

This device contains licence-exempt trans-
mitter(s)/receiver(s) that comply with In-
n o v a t i o n , S c i e n c e a n d E c o n o m i c
Development Canada’s licence-exempt
RSS(s). Operation is subject to the follow-
ing two conditions: (1) This device may not
cause interference. (2) This device must
accept any interference, including interfer-
ence that may cause undesired operation of
the device.

The HomeLink

®

Universal Transceiver pro-

vides a convenient way to consolidate the
functions of up to three individual hand-held
transmitters into one built-in device.
HomeLink

®

Universal Transceiver:

.

Will operate most Radio Frequency (RF)

devices such as garage doors, gates,
home and office lighting, entry door
locks and security systems.

.

Is powered by your vehicle’s battery. No

separate batteries are required. If the
vehicle’s battery is discharged or is
disconnected, HomeLink

®

will retain all

programming.

When the HomeLink

®

Universal Transceiver

is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink

®

Universal Transceiver buttons

should be erased for security purposes. For
additional information, refer to “Program-
ming HomeLink

®

” (P.2-86).

WARNING

.

Do not use the HomeLink

®

Universal

Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-

Instruments and controls

2-85

HomeLink

®

UNIVERSAL

TRANSCEIVER (Type B) (if so equipped)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-86

Instruments and controls

dards became effective for opener
models manufactured after April 1,
1982.) A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.

.

During the programming procedure
your garage door or security gate will
open and close (if the transmitter is
within range). Make sure that people
or objects are clear of the garage
door, gate, etc. that you are pro-
gramming.

.

Your vehicle’s engine should be
turned off while programming the
HomeLink

®

Universal Transceiver.

Do not breathe exhaust gases; they
contain colorless and odorless carbon
monoxide. Carbon monoxide is dan-
gerous. It can cause unconsciousness
or death.

NOTE:

If your vehicle is equipped with Smart
Rearview Mirror, you may have to complete
additional programming to enable Two-
Way Communication. The mirror can pro-

vide the status of your garage door (open/
close).

PROGRAMMING HomeLink

®

The following steps show generic instruc-
tions how to program a HomeLink

®

button.

If you have any questions or are having
difficulty programming your HomeLink

®

buttons, refer to the HomeLink

®

web site

at: www.homelink.com/infiniti or call 1-
800-355-3515.

NOTE:

It is also recommended that a new battery
be placed in the hand-held transmitter of
t h e d e v i c e b e i n g p r o g r a m m e d t o
HomeLink

®

for quicker programming and

accurate transmission of the radio-fre-
quency.

WAC0378X

HomeLink

®

buttons (1-3)

Indicator light (appears above each
HomeLink

®

button)

Status display (where the current con-
dition of the HomeLink

®

is displayed)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WAC0381X

1. Press and release the HomeLink

®

button

that you would like to program. The
HomeLink

®

indicator light will flash in

orange slowly and “TRAINING” is dis-
played on the lower right of the mirror (if
not, refer to “Clearing the programmed
information” (P.2-90).).

2. Position the hand-held transmitter (gar-

age door opener remote) 1-3 inches (2-8
cm) away from the HomeLink

®

button

that you would light to program.

NOTE:
Some hand-held transmitter (garage
door opener remotes) may actually train
better at a distance of 6-12 inches (15-
20 cm). Keep this in mind if you have

difficulty with the programming pro-
cess.

3. While the HomeLink

®

indicator light is

flashing in orange, press and hold the
hand-held transmitter button. Continue
pressing the hand-held transmitter but-
ton until the HomeLink

®

indicator light

changes from orange to green and
“TRAINED” is displayed on the lower
right of the mirror. You may now release
the hand-held transmitter button.

NOTE:
Some devices to be programmed may
require you to replace the Step 3 with
the cycling procedure noted in “Pro-
gramming HomeLink

®

for Canadian cus-

tomers and gate openers” (P.2-89).

4.

Wait until your garage door has stopped
moving

before completing the next

steps.

5. Press the HomeLink

®

button and ob-

serve the indicator light.

.

If the indicator light remains constant

green, your device should operate
when the HomeLink

®

button is

pressed. At this point, if your device
operates, programming is complete.

.

If the indicator light rapidly flashes in

green, firmly press,

hold for two

seconds

and release the HomeLink

®

button up to three times to complete

the programming process.

Do not

press the HomeLink

®

button rapidly

.

At this point if your device operates,
programming is complete. If the de-
vice does not operate or operates but
no door status indicator with Two-
Way Communication

*1

, continue with

the next step of the programming
instructions.

6. At the garage door opener motor (se-

curity gate motor, etc.), locate the
“Learn” or “Set” button. This can usually
be found where the hanging antenna
wire is attached to the motor-head unit
(see the device’s manual to identify this
button.). The name and color of the
button may vary by manufacturer.

NOTE:
A ladder and/or second person may
simplify the following steps. Do not
stand on your vehicle to perform the
next steps.

Instruments and controls

2-87

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-88

Instruments and controls

WAC0258X

Example

7. Firmly press and release the “Learn” or

“Set” button until the indicator illumi-
nates. Once the button is pressed, you
have approximately 30 seconds to initi-
ate the next step.

8. Return to the vehicle and firmly press,

hold for two seconds and release the
HomeLink

®

button up to three times.

Do

not press the HomeLink

®

button rapidly.

At this point programming is complete
and your device should operate when the
HomeLink

®

button is pressed and re-

leased.

9. If you have any questions or are having

difficulty programming your HomeLink

®

buttons, refer to the HomeLink

®

web

site at: www.homelink.com/infiniti or
call 1-800-355-3515.

*1: Programming Two-Way Communication

To check if your garage door opener is
compatible with this feature, refer to the
homelink.com/compatible/two-way-com-
munication website. If your garage door
opener has this functionality, HomeLink

®

mirror garage door status indicators may
appear after completion of programming.

NOTE:

It is possible for the HomeLink

®

to stop

working with the garage door system
shortly after initial programming if the
Two-Way Communication programming is
not completed. If this is the case, following
the steps below will restore door operation.

1. In your vehicle, press and hold the trained

HomeLink

®

button for 2 seconds, then

release. Confirm that the garage door is
moving. When the garage door stops,
you will have one minute to complete the
following steps:

NOTE:
A ladder and/or second person may
simplify the following steps. Do not
stand on your vehicle to perform the
next steps.

2. On your garage door opener in your

garage, locate the “Learn” or “Set”
button (usually near where the hanging
antenna wire is attached to the garage
door opener). If there is difficulty locat-
ing this button, refer to the device’s
owner’s manual.

3. Press and release the “Learn” or “Set”

button.

4. A light on your garage door opener may

flash, and your two-way HomeLink

®

indicators in your vehicle may flash,
confirming completion of the process.

5. Pressing the trained HomeLink

®

button

will now activate your garage door. The
status indicators will show when the
door is moving.

6. Your two-way enrollment is now com-

plete.

USING THE GARAGE DOOR
TWO-WAY COMMUNICATION

HomeLink

®

has the function of communi-

cating with garage door opener systems. If
your garage door openers are compatible
with HomeLink

®

, the HomeLink

®

can:

.

receive and display “closing” or “opening”

status from your garage door opener.

.

recall and display the garage door being

“closed” or “opened”.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

HomeLink

®

can receive the status from a

garage door opener at a range up to 820 ft
(250 m), but it varies depending on the
environment. You may need to reduce
vehicle speed to successfully receive the
garage door opener communication.

WAC0379X

Using two-way communication

Press and hold the HomeLink

®

buttons (1

and 2) simultaneously for 2 seconds to recall
and display the last recorded garage door
status communicated to HomeLink

®

.

HomeLink

®

will display the last recorded

status for 3 seconds.
If two-way communication programming is
successful, HomeLink

®

will display the sta-

tus of your garage door opener with the
status indicator

, which changes depending

on the status. The garage door opener
status indicator shows the garage door
opener status as follows:

Flashing in orange – Closing

Flashing in orange – Opening
Illuminating in green – Closed
Illuminating in green – Opened

The status indicator stops to flash after an
open/close signal is received or no signal is
received within 30 seconds from the garage
door opener.

PROGRAMMING HomeLink

®

FOR

CANADIAN CUSTOMERS AND
GATE OPENERS

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission –
which may not be long enough for
HomeLink

®

to pick up the signal during

programming. Similar to this Canadian law,
some U.S. gate operators are designed to
“time-out” in the same manner.
If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the “Program-
ming HomeLink

®

” procedures, replace “Pro-

gramming HomeLink

®

” Step 3 with the

following:

NOTE:

When programming a garage door opener,
etc., unplug the device during the “cycling”
process to prevent possible damage to the
device components.

Instruments and controls

2-89

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-90

Instruments and controls

Step 3: While the HomeLink

®

indicator light

is flashing in orange, press and release
(“cycling”) the hand-held transmitter button
every 2 seconds. Continue to press and
release the hand-held transmitter button
until the HomeLink

®

indicator light changes

from orange to green. When the indicator
light illuminates in green, hand-held trans-
mitter button may be released.
Proceed with “Programming HomeLink

®

step 4 to complete.
Remember to plug the device back in when
programming is completed.

OPERATING THE HomeLink

®

UNIVERSAL TRANSCEIVER

The HomeLink

®

Universal Transceiver, after

it is programmed, can be used to activate the
programmed device. To operate, firmly press
the appropriate programmed HomeLink

®

button. The indicator light will illuminate in
green with three parenthesis

on the

mirror while the signal is being transmitted.

PROGRAMMING TROUBLE-
SHOOTING

If the HomeLink

®

does not quickly learn the

hand-held transmitter information:

.

replace the hand-held transmitter bat-

teries with new batteries.

.

position the hand-held transmitter with

its battery area facing away from the
HomeLink

®

button.

.

press and hold the HomeLink

®

button

and hand-held transmitter button in
each step without interruption.

.

position the hand-held transmitter 1 to 3

in (2 to 8 cm) away from the HomeLink

®

button. Hold the transmitter in that
position for up to 15 seconds. If
HomeLink

®

is not programmed within

that time, try holding the transmitter in
another position - for example, 6 to 12 in
(15 to 30 cm) away, keeping the
HomeLink

®

button in view at all times.

If you have any questions or are having
difficulty programming your HomeLink

®

buttons, refer to the HomeLink

®

web site

at: www.homelink.com/infiniti or 1-800-
355-3515.

CLEARING THE PROGRAMMED
INFORMATION

The following procedure clears the pro-
grammed information from three buttons.
Individual buttons cannot be cleared. How-
ever, individual buttons can be repro-
grammed, see “Reprogramming a single
HomeLink

®

button” (P.2-90).

To clear all programming

1. Press and hold the two outer HomeLink

®

buttons until the indicator light begins to
flash in green and “CLEARED” is dis-
played on the mirror, in approximately 10
seconds. Do not hold for longer than 20
seconds.

2. Release both buttons.
HomeLink

®

is now in the programming mode

and can be programmed at any time begin-
ning with “Programming HomeLink

®

” - Step

1.

REPROGRAMMING A SINGLE
HomeLink

®

BUTTON

To reprogram a HomeLink

®

button, com-

plete the following.
1. Press and hold the desired HomeLink

®

button.

DO NOT

release the button.

2. The indicator light will illuminate in

green, and after 20 seconds it will begin
to flash in orange and “TRAINING” is
displayed on the mirror.

3. Release the HomeLink

®

button and

p r o c e e d

w i t h

“ P r o g r a m m i n g

HomeLink

®

” — Step 3.

For questions or comments, contact
HomeLink

®

at: www.homelink.com/infiniti

or 1-800-355-3515.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The HomeLink

®

button has now been re-

programmed. The new device can be acti-
vated by pressing the HomeLink

®

button

that was just programmed. This procedure
will not affect any other programmed
HomeLink

®

buttons.

If a new device is not programmed to the
HomeLink

®

button, it will revert to the

previously stored programming.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change
the codes of any non-rolling code device that
has been programmed into HomeLink

®

.

Consult the Owner’s Manual of each device
or call the manufacturer or retailer of those
devices for additional information.

When your vehicle is recovered, you will
need to reprogram the HomeLink

®

Univer-

sal Transceiver with your new transmitter
information.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.

For Canada:

This device contains licence-exempt trans-
mitter(s)/receiver(s) that comply with In-
n o v a t i o n , S c i e n c e a n d E c o n o m i c
Development Canada’s licence-exempt
RSS(s). Operation is subject to the follow-
ing two conditions: (1) This device may not
cause interference. (2) This device must
accept any interference, including interfer-
ence that may cause undesired operation of
the device.

Instruments and controls

2-91

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

2-92

Instruments and controls

MEMO

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3 Pre-driving checks and adjustments

Keys ...................................................................................... 3-2

Intelligent Key .............................................................. 3-2
Valet hand-off ............................................................. 3-4

Doors .................................................................................... 3-4

Locking with mechanical key ................................... 3-4
Opening and closing windows with the
mechanical key ............................................................. 3-5
Locking with inside lock knob ................................. 3-5
Locking with power door lock switch ................... 3-5
Automatic door locks ................................................. 3-6
Child safety rear door lock ...................................... 3-6

Intelligent Key system ...................................................... 3-7

Intelligent Key operating range ............................... 3-9
Door locks/unlocks precaution ............................... 3-9
Intelligent Key operation ......................................... 3-10
Battery saver system ............................................... 3-12
Warning signals ......................................................... 3-12
Troubleshooting guide ............................................. 3-13

Remote keyless entry system ...................................... 3-15

How to use remote keyless entry system .......... 3-16

Remote engine start (if so equipped) ........................ 3-19

Remote engine start operating range ................. 3-19
Remote starting the engine ................................... 3-19
Extending engine run time ..................................... 3-20

Canceling a remote engine start ........................ 3-20
Conditions the remote engine start will
not work ................................................................... 3-20

Hood .................................................................................. 3-21
Liftgate ............................................................................. 3-22

Operating manual liftgate .................................... 3-22
Operating power liftgate ...................................... 3-22
Auto closure ............................................................ 3-25
Liftgate release lever ............................................. 3-26

Fuel-filler door ................................................................ 3-26

Opening the fuel-filler door ................................. 3-26
Fuel-filler cap ........................................................... 3-26

Tilt/telescopic steering ................................................. 3-29

Electric operation .................................................... 3-29

Sun visors ......................................................................... 3-29
Mirrors ............................................................................. 3-30

Inside mirror ............................................................. 3-30
Outside mirrors ........................................................ 3-37
Vanity mirror ............................................................ 3-39

Memory seat ................................................................... 3-39

Entry/exit function ................................................. 3-39
Memory storage ..................................................... 3-40
Setting memory function ...................................... 3-41
System operation .................................................... 3-41

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-2

Pre-driving checks and adjustments

A key number plate is supplied with your
keys. Record the key number and keep it in a
safe place (such as your wallet), not in the
vehicle. If you lose your keys, it is recom-
mended you visit an INFINITI retailer for
duplicates by using the key number. INFINITI
does not record any key numbers so it is very
important to keep track of your key number
plate.
A key number is only necessary when you
have lost all keys and do not have one to
duplicate from. If you still have a key, it can
be duplicated without knowing the key
number.

SPA2717

Type A

JVP0155X

Type B

1.

Intelligent Key (2)

2.

Mechanical key (inside Intelligent Key)
(2)

3.

Key number plate (1)

INTELLIGENT KEY

Your vehicle can only be driven with the
Intelligent Keys which are registered to your
vehicle’s Intelligent Key system components
and INFINITI Vehicle Immobilizer System
components. As many as 4 Intelligent Keys
can be registered and used with one vehicle.
The new keys must be registered by an
INFINITI retailer prior to use with the
Intelligent Key system and INFINITI Vehicle
Immobilizer System of your vehicle. Since the
registration process requires erasing all
memory in the Intelligent Key components
when registering new keys, be sure to take
all Intelligent Keys that you have to the
INFINITI retailer.

CAUTION

.

Be sure to carry the Intelligent Key
with you when driving. The Intelli-
gent Key is a precision device with a
built-in transmitter. To avoid dama-
ging it, please note the following.

— The Intelligent Key is water re-

sistant; however, wetting may

KEYS

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

damage the Intelligent Key. If the
Intelligent Key gets wet, immedi-
ately wipe until it is completely
dry.

— Do not bend, drop or strike it

against another object.

— If the outside temperature is

below 14°F (−10°C), the battery
of the Intelligent Key may not
function properly.

— Do not place the Intelligent Key

for an extended period in a place
where temperatures exceed
140°F (60°C).

— Do not change or modify the

Intelligent Key.

— Do not use a magnet key holder.

— Do not place the Intelligent Key

near an electric appliance such as
a television set or personal com-
puter.

— Do not allow the Intelligent Key

to come into contact with water
or salt water, and do not wash it
in a washing machine. This could
affect the system function.

.

If an Intelligent Key is lost or stolen,
INFINITI recommends erasing the ID
code of that Intelligent Key. This will

prevent the Intelligent Key from un-
authorized use to unlock the vehicle.
For information regarding the eras-
ing procedure, it is recommended you
visit an INFINITI retailer.

SPA2033

Mechanical key

To remove the mechanical key, release the
lock knob at the back of the Intelligent Key.
To install the mechanical key, firmly insert it
into the Intelligent Key until the lock knob
returns to the lock position.
Use the mechanical key to lock or unlock the
doors and the glove box.
See “Doors” (P.3-4), “Storage” (P.2-66).

CAUTION

Always carry the mechanical key in-
stalled in the Intelligent Key.

Pre-driving checks and adjustments

3-3

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-4

Pre-driving checks and adjustments

VALET HAND-OFF

When you have to leave a key with a valet,
give them the Intelligent Key itself and keep
the mechanical key with you to protect your
belongings.
To prevent the glove box from being opened
during valet hand-off, follow the procedures
below.
1. Remove the mechanical key from the

Intelligent Key.

2. Lock the glove box with the mechanical

key.

3. Hand the Intelligent Key to the valet,

keeping the mechanical key in your
pocket or bag for insertion into the
Intelligent Key when you retrieve your
vehicle.

See “Storage” (P.2-66).

WARNING

.

Always have the doors locked while
driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from unintention-
ally opening the doors, and will help
keep out intruders.

.

Before opening any door, always look
for and avoid oncoming traffic.

.

To help avoid risk of injury or death
through unintended operation of the
vehicle and or its systems, including
entrapment in windows or inadver-
tent door lock activation, do not
leave children, people who require
the assistance of others or pets
unattended in your vehicle. Addition-
ally, the temperature inside a closed
vehicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.

SPA2457B

LOCKING WITH MECHANICAL
KEY

The power door lock system allows you to
lock or unlock all doors simultaneously using
the mechanical key.

.

Turning the driver’s door key cylinder to

the front of the vehicle

will lock all

doors.

.

Turning the driver’s door key cylinder

once to the rear of the vehicle

will

unlock the driver’s door. After returning
the key to the neutral position

, turning

it to the rear again within 5 seconds will
unlock all doors.

DOORS

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

.

You can switch the lock system to the

mode that allows you to open all the
doors when the key is turned once. (See
“Vehicle settings” (P.2-23).)

OPENING AND CLOSING WIN-
DOWS WITH THE MECHANICAL
KEY

The driver’s door key operation also allows
you to open and close all door windows.
To open the windows, turn the driver’s door
key cylinder to the rear of the vehicle for

longer than 1 second

. The door is unlocked

and the window keeps opening while turning
the key.
This function can also be performed by
pushing and holding the door UNLOCK
button of the Intelligent Key. (See “Remote
keyless entry system” (P.3-15).)
To close the windows, turn the driver’s door
key cylinder to the front of the vehicle for

longer than 1 second

. The door is locked and

the window keeps closing while turning the
key.

SPA2744

LOCKING WITH INSIDE LOCK
KNOB

To lock the door individually, move the inside
lock knob to the lock position

.

To unlock, move the inside lock knob to the
unlock position

.

Be sure not to leave the Intelligent Key
inside the vehicle.

JVP0319X

LOCKING WITH POWER DOOR
LOCK SWITCH

Operating the power door lock switch will
lock or unlock all the doors. The switches are
located on the driver’s and front passenger’s
door armrests.
To lock the doors, push the power door lock
switch to the lock position

.

Be sure not to leave the Intelligent Key
inside the vehicle.

To unlock the doors, push the power door
lock switch to the unlock position

.

Pre-driving checks and adjustments

3-5

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-6

Pre-driving checks and adjustments

Lockout protection

When the power door lock switch (driver or
front passenger) is moved to the lock
position with any door open, all doors will
lock and unlock automatically. With the
Intelligent Key left in the vehicle and any
door open, all doors will unlock automati-
cally and a chime will sound after the door is
closed.
These functions help to prevent the Intelli-
gent Key from being accidentally locked
inside the vehicle.

AUTOMATIC DOOR LOCKS

.

All doors lock automatically when the

vehicle speed reaches 15 MPH (24
km/h).

.

All doors unlock automatically when the

ignition switch is placed in the OFF
position.

The automatic unlock function can be
deactivated or activated.

To deactivate or

activate the automatic door unlock system,
perform the following procedure:
1. Close all doors.
2. Place the ignition switch in the ON

position.

3. Within 20 seconds of performing Step 2,

push and hold the power door lock
switch to the

position (UNLOCK)

for more than 5 seconds.

4. When activated, the hazard indicator will

flash twice. When deactivated, the ha-
zard indicator will flash once.

5. The ignition switch must be placed in the

OFF and ON position again between
each setting change.

When the automatic door unlock system is
deactivated, the doors do not unlock when
the ignition switch is placed in the OFF
position. To unlock the door manually, use
the inside lock knob or the power door lock
switch (driver’s or front passenger’s side).

SPA2536

CHILD SAFETY REAR DOOR
LOCK

Child safety rear door locks help prevent
doors from being opened accidentally, espe-
cially when small children are in the vehicle.

When the levers are in the lock position

,

the rear doors can be opened only from the
outside.

To disengage, move the levers to the unlock
position

.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

.

Radio waves could adversely affect
electric medical equipment. Those
who use a pacemaker should contact
the electric medical equipment man-
ufacturer for the possible influences
before use.

.

The Intelligent Key transmits radio
waves when the buttons are pushed.
The FAA advises that the radio
waves may affect aircraft navigation
and communication systems. Do not
operate the Intelligent Key while on
an airplane. Make sure the buttons
are not operated unintentionally
when the unit is stored during a
flight.

The Intelligent Key system can operate all
the door locks using the remote controller
function or pushing the request switch on
the vehicle without taking the key out from a
pocket or purse. The operating environment
and/or conditions may affect the Intelligent
Key system operation.
Be sure to read the following before using
the Intelligent Key system.

CAUTION

.

Be sure to carry the Intelligent Key
with you when operating the vehicle.

.

Never leave the Intelligent Key in the
vehicle when you leave the vehicle.

The Intelligent Key is always communicating
with the vehicle as it receives radio waves.
The Intelligent Key system transmits weak
radio waves. Environmental conditions may
interfere with the operation of the Intelligent
Key system under the following operating
conditions.

.

When operating near a location where

strong radio waves are transmitted, such
as a TV tower, power station and broad-
casting station.

.

When in possession of wireless equip-

ment, such as a cellular telephone,
transceiver, and CB radio.

.

When the Intelligent Key is in contact

with or covered by metallic materials.

.

When any type of radio wave remote

control is used nearby.

.

When the Intelligent Key is placed near

an electric appliance such as a personal
computer.

.

When the vehicle is parked near a parking

meter.

In such cases, correct the operating condi-
tions before using the Intelligent Key func-
tion or use the mechanical key.
Although the life of the battery varies
depending on the operating conditions, the
battery’s life is approximately 2 years. If the
battery is discharged, replace it with a new
one.
Since the Intelligent Key is continuously
receiving radio waves, if the key is left near
equipment which transmits strong radio
waves, such as signals from a TV and
personal computer, the battery life may
become shorter.
For information regarding replacement of a
battery, see “Intelligent Key battery replace-
ment” (P.8-21).
As many as 4 Intelligent Keys can be
registered and used with one vehicle. For
information about the purchase and use of
additional Intelligent Keys, contact an
INFINITI retailer.

CAUTION

.

Do not allow the Intelligent Key,
which contains electrical compo-
nents, to come into contact with

Pre-driving checks and adjustments

3-7

INTELLIGENT KEY SYSTEM

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3-8

Pre-driving checks and adjustments

water or salt water. This could affect
the system function.

.

Do not drop the Intelligent Key.

.

Do not strike the Intelligent Key
sharply against another object.

.

Do not change or modify the Intelli-
gent Key.

.

Wetting may damage the Intelligent
Key. If the Intelligent Key gets wet,
immediately wipe until it is comple-
tely dry.

.

If the outside temperature is below
14°F (−10°C), the battery of the
Intelligent Key may not function
properly.

.

Do not place the Intelligent Key for
an extended period in an area where
temperatures exceed 140°F (60°C).

.

Do not attach the Intelligent Key
with a key holder that contains a
magnet.

.

Do not place the Intelligent Key near
equipment that produces a magnetic
field, such as a TV, audio equipment
and personal computers.

If an Intelligent Key is lost or stolen, INFINITI
recommends erasing the ID code of that
Intelligent Key from the vehicle. This may
prevent the unauthorized use of the Intelli-

gent Key to operate the vehicle. For infor-
mation regarding the erasing procedure, it is
recommended that you contact an INFINITI
retailer.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SPA2074

INTELLIGENT KEY OPERATING
RANGE

The Intelligent Key functions can only be
used when the Intelligent Key is within the
specified operating range from the request
switch

.

When the Intelligent Key battery is dis-
charged or strong radio waves are present
near the operating location, the Intelligent
Key system’s operating range becomes nar-
rower, and the Intelligent Key may not
function properly.
The operating range is within 31.50 in (80
cm) from each request switch

.

If the Intelligent Key is too close to the door

glass, handle or rear bumper the request
switches may not function.
When the Intelligent Key is within the
operating range, it is possible for anyone
who does not carry the Intelligent Key to
push the request switch to lock/unlock the
doors.

SPA2326

DOOR LOCKS/UNLOCKS PRE-
CAUTION

.

Do not push the door handle request

switch with the Intelligent Key held in
your hand as illustrated. The close dis-
tance to the door handle will cause the
Intelligent Key system to have difficulty
recognizing that the Intelligent Key is
outside the vehicle.

.

After locking with the door handle re-

quest switch, verify the doors are se-
curely locked by testing them.

.

To prevent the Intelligent Key from being

left inside the vehicle, make sure you
carry the key with you and then lock the

Pre-driving checks and adjustments

3-9

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     4      5      6      7     ..
