When a wheel is off the ground due to an
unlevel surface, do not spin the wheel
excessively.

Accelerating quickly, sharp steering ma-
neuvers or sudden braking may cause
loss of control.

If at all possible, avoid sharp turning ma-
neuvers, particularly at high speeds.
Your INFINITI vehicle has a higher center
of gravity than a passenger car. The ve-
hicle is not designed for cornering at the
same speeds as passenger cars. Failure
to operate this vehicle correctly could re-
sult in loss of control and/or a rollover
accident.

Always use tires of the same type, size,
brand, construction (bias, bias-belted, or
radial), and tread pattern on all four
wheels. Install tire chains on the front
wheels when driving on slippery roads
and drive carefully.

Be sure to check the brakes immediately
after driving in mud or water. For addi-
tional information, see “Brake precau-
tions” (P. 5-139).

Avoid parking your vehicle on steep hills.
If you get out of the vehicle and it rolls
forward, backward or sideways, you
could be injured.

Whenever you drive off-road through
sand, mud or water as deep as the wheel
hub, more frequent maintenance may be
required. For additional information, see
“Additional maintenance items for se-
vere operating conditions” (P. 9-7).

INTELLIGENT ALL-WHEEL
DRIVE (AWD) DRIVING SAFETY
PRECAUTIONS (if so equipped)

WARNING

Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.

Always use tires of the same type, size,
brand, construction (bias, bias-belted or
radial), and tread pattern on all four
wheels. Install tire chains on the front
wheels when driving on slippery roads
and drive carefully.

This vehicle is not designed for off-road
(rough road) use. Do not drive on sandy
or muddy roads that tires may get stuck
in.

For AWD equipped vehicles, do not at-
tempt to raise two wheels off the ground
and shift the transmission to any D
(Drive) or R (Reverse) position with the
engine running. Doing so may result in
drivetrain damage or unexpected vehicle
movement which could result in serious
vehicle damage or personal injury.

Do not attempt to test an AWD
equipped vehicle on a 2-wheel dyna-
mometer (such as the dynamometers
used by some states for emissions test-
ing) or similar equipment even if the
other two wheels are raised off the
ground. Make sure you inform test facil-
ity

personnel

that

your

vehicle

is

equipped with AWD before it is placed
on a dynamometer. Using the wrong test
equipment may result in drivetrain dam-
age or unexpected vehicle movement
which could result in serious vehicle dam-
age or personal injury.

When a wheel is off the ground due to an
unlevel surface, do not spin the wheel
excessively.

5-12

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

Do not operate the push-button ignition
switch while driving the vehicle except in
an emergency. (The engine will stop when
the ignition switch is pushed three con-
secutive times in quick succession or the
ignition switch is pushed and held for more
than 2 seconds.) If the engine stops while
the vehicle is being driven, this could lead
to a crash and serious injury.

When the ignition switch is pushed without
depressing the brake pedal, the ignition
switch will change as follows:

Push the ignition switch center:
• Once to change to ON.
• Two times to change to OFF.

The ignition switch will automatically return
to the LOCK position when any door is either
opened or closed with the switch in the OFF
position.

The ignition lock is designed so that the igni-
tion switch cannot be placed in the OFF po-
sition until the shift position is in the P (Park)
position.

When the ignition switch cannot be placed in
the OFF position, proceed as follows:

1. Press the Park button to place the vehicle

in the P (Park) position.

2. Push the ignition switch. The ignition

switch position will change to the ON
position.

3. Push the ignition switch again to the OFF

position.

The shift position can be shifted from the P
(Park) position if the ignition switch is in the
ON

position

and

the

brake

pedal

is

depressed.

If the battery of the vehicle is discharged, the
ignition switch cannot be moved from the
LOCK position.

Some indicators and warnings for operation
are displayed on the vehicle information dis-
play. For additional information, see “Vehicle
information display” (P. 2-19).

LSD2911

PUSH-BUTTON IGNITION SWITCH

Starting and driving

5-13

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

OPERATING RANGE

The Intelligent Key functions can only be used
when the Intelligent Key is within the speci-
fied operating range.

When the Intelligent Key battery is almost
discharged or strong radio waves are present
near the operating location, the Intelligent
Key system’s operating range becomes nar-
rower and may not function properly.

If the Intelligent Key is within the operating
range, it is possible for anyone, even some-
one who does not carry the Intelligent Key, to
push the ignition switch to start the engine.

The operating range of the engine start func-
tion is inside of the vehicle

O

1

.

• The luggage area is not included in the

operating range, but the Intelligent Key
may function.

• If the Intelligent Key is placed on the instru-

ment panel or inside the glove box, storage
bin or door pocket, the Intelligent Key may
not function.

• If the Intelligent Key is placed near the door

or window outside the vehicle, the Intelli-
gent Key may function.

PUSH-BUTTON IGNITION
SWITCH POSITIONS

LOCK (Normal parking position)

The ignition switch can only be locked in this
position.

The ignition switch will be unlocked when it is
placed in the ON position while carrying the
Intelligent Key.

The ignition switch will lock when any door is
opened or closed with the ignition switched
off.

ON (Normal operating position)

This position turns on the ignition system and
electrical accessories.

ON has a battery saver feature that will place
the ignition switch in the OFF position, if the
vehicle is not running, after some time under
the following conditions:
• All doors are closed.
• The vehicle is in the P (Park) position.

The battery saver feature will be canceled if
any of the following occur:
• Any door is opened.
• The shift position is shifted out of the P

(Park) position.

• The ignition switch changes position.

CAUTION

Do not leave the vehicle with the ignition
switch in the ON position when the engine
is not running for an extended period. This
can discharge the battery.

OFF

The ignition switch is in the OFF position
when the engine is turned off using the igni-
tion switch. No lights will illuminate on the
ignition switch.

LSD2020

5-14

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

AUTO ACC

With the vehicle in the P (Park) position, the
Intelligent Key with you and the ignition
switch placed from the ON position to the
OFF position, the radio can still be used for a
period of time, or until the driver’s door is
opened.

After a period of time, functions such as ra-
dio, navigation, and Bluetooth® Hands-Free
Phone System may be restarted by pressing
the POWER button/VOLUME control knob
or the key fob unlock button. For additional
information, see the “Monitor, climate, audio,
phone

and

voice

recognition

systems”

(P. 4-2).

EMERGENCY ENGINE SHUT OFF

To shut off the engine in an emergency situ-
ation while driving, perform the following
procedure:
• Rapidly push the ignition switch three con-

secutive times in less than 1.5 seconds, or

• Push and hold the ignition switch for more

than 2 seconds.

INFINITI INTELLIGENT KEY
BATTERY DISCHARGE

If the battery of the Intelligent Key is dis-
charged or environmental conditions inter-
fere with the Intelligent Key operation, start
the engine according to the following proce-
dure:

1. Press the Park button to place the vehicle

in the P (Park) position.

2. Firmly apply the foot brake.

3. Touch the ignition switch with the Intelli-

gent Key as illustrated. (A chime will
sound.)

4. Push the ignition switch while depressing

the brake pedal within 10 seconds after
the chime sounds. The engine will start.

After step 3 is performed, when the ignition
switch is pushed without depressing the
brake pedal, the ignition switch position will
change to ON.

NOTE:

• When the ignition switch is placed in the

ON position or the engine is started by the
above procedure, the Intelligent Key bat-
tery discharge indicator may appear in the
vehicle information display even when the
Intelligent Key is inside the vehicle. This is
not a malfunction. To turn off the Intelli-
gent Key battery discharge indicator,
touch the ignition switch with the Intelli-
gent Key again.

• If the Intelligent Key battery discharge in-

dicator appears, replace the battery as
soon as possible. For additional informa-
tion, see “Battery replacement” (P. 8-22).

LSD3572

Starting and driving

5-15

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INFINITI VEHICLE IMMOBILIZER
SYSTEM

The INFINITI Vehicle Immobilizer System will
not allow the engine to start without the use
of the registered key.

If the engine fails to start using the registered
key, it may be due to interference caused by
another registered key, an automated toll
road device or automated payment device on
the key ring. Restart the engine using the
following procedures:

1. Leave the ignition switch in the ON posi-

tion for approximately 5 seconds.

2. Place the ignition switch in the OFF or

LOCK position and wait approximately 5
seconds.

3. Repeat steps 1 and 2.

4. Restart the engine while holding the de-

vice (which may have caused the interfer-
ence) separate from the registered key.

If the no start condition re-occurs, INFINITI
recommends placing the registered key on a
separate key ring to avoid interference from
other devices.

• Make sure the area around the vehicle is

clear.

• Check fluid levels such as engine oil, cool-

ant, brake fluid, and windshield-washer
fluid as frequently as possible, or at least
whenever you refuel.

• Check that all windows and lights are clean.
• Visually inspect tires for their appearance

and condition. Also check tires for proper
inflation.

• Check that all doors are closed.
• Position

seat

and

adjust

head

restraints/headrests.

• Adjust inside and outside mirrors.
• Fasten seat belts and ask all passengers to

do likewise.

• Check the operation of warning lights

when the ignition switch is placed in the ON
position. For additional information, see
“Warning lights, indicator lights and audible
reminders” (P. 2-9)

1. Apply the parking brake.

2. Press the Park button to place the vehicle

in P (Park) or move the shift lever to N
(Neutral). P (Park) is recommended.

The starter is designed not to operate if
the shift lever is in any of the driving
positions.

3. Push the ignition switch to the ON posi-

tion. Depress the brake pedal and push
the ignition switch to start the engine.

To start the engine immediately, push and
release the ignition switch while depress-
ing the brake pedal with the ignition
switch in any position.

• If the engine is very hard to start in

extremely cold weather or when re-
starting, depress the accelerator pedal a
little (approximately 1/3 to the floor)
and while holding, crank the engine. Re-
lease the accelerator pedal when the
engine starts.

• If the engine is very hard to start be-

cause it is flooded, depress the accel-
erator pedal all the way to the floor and
hold it. Push the ignition switch to the
ON position to start cranking the en-
gine. After 5 or 6 seconds, stop cranking
by pushing the ignition switch to the

BEFORE STARTING THE ENGINE

STARTING THE ENGINE

5-16

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCK position. After cranking the en-
gine, release the accelerator pedal.
Crank the engine with your foot off the
accelerator pedal by depressing the
brake pedal and pushing the ignition
switch to start the engine. If the engine
starts, but fails to run, repeat the above
procedure.

CAUTION

Do not operate the starter for more than
15 seconds at a time. If the engine does not
start, push the ignition switch to the OFF
position and wait 10 seconds before crank-
ing again, otherwise the starter could be
damaged.

4.

Warm-up:

Allow the engine to idle for at least 30
seconds after starting. Do not race the
engine while warming it up. Drive at a
moderate speed for a short distance first,
especially

in

cold

weather.

In

cold

weather, keep the engine running for a
minimum of 2 - 3 minutes before shutting
it off. Starting and stopping the engine
over a short period of time may make the
vehicle more difficult to start.

5. To stop the engine, place the vehicle in the

P (Park) position and push the ignition
switch to the OFF position.

NOTE:
Care should be taken to avoid situations
that can lead to potential battery dis-
charge and potential no-start conditions
such as:

1. Installation or extended use of electronic

accessories that consume battery power
when the engine is not running (phone
chargers, GPS, DVD players, etc.).

2. The vehicle is not driven regularly and/or

only driven short distances.

In these cases, the battery may need to be
charged to maintain battery health.

REMOTE ENGINE START

Vehicles started with the Remote Engine
Start require the ignition switch to be placed
in the ON position before the shift position
can be shifted from the P (Park) position. To
place the ignition switch in the ON position,
follow these steps:

1. Make sure that the Intelligent Key is on

you.

2. Apply the brake.

3. Push the ignition switch once to the ON

position.

For additional information, see “INFINITI In-
telligent Key” (P. 3-2).

Starting and driving

5-17

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONTINUOUSLY VARIABLE
TRANSMISSION (CVT)

WARNING

Do not depress the accelerator pedal
while shifting from P (Park) or N (Neu-
tral) to R (Reverse), D (Drive), or M
(Manual shift mode). Always depress the
brake pedal until shifting is completed.
Failure to do so could cause you to lose
control and have an accident.

Cold engine idle speed is high, so use
caution when shifting into a forward or
reverse gear before the engine has
warmed up.

Do not downshift abruptly on slippery
roads. This may cause a loss of control.

Never shift to either the P (Park) or R
(Reverse) position while the vehicle is
moving forward and P (Park) or D (Drive)
position while the vehicle is reversing.
This could cause an accident or damage
the transmission.

Except in an emergency, do not shift to
the N (Neutral) position while driving.
Coasting with the transmission in the N
(Neutral) position may cause serious
damage to the transmission.

CAUTION

To avoid possible damage to your ve-
hicle, when stopping the vehicle on an
uphill grade, do not hold the vehicle by
depressing the accelerator pedal. The
foot brake should be used for this
purpose.

Do not hang items on the shift lever. This
may cause an accident due to a sudden
start.

The CVT in your vehicle is electronically con-
trolled to produce maximum power and
smooth operation.

The recommended operating procedures for
this transmission are shown on the following
pages. Follow these procedures for maxi-
mum

vehicle

performance

and

driving

enjoyment.

Engine power may be automatically reduced
to protect the CVT if the engine speed in-
creases quickly when driving on slippery
roads or while being tested on some
dynamometers.

Starting the vehicle

1. After starting the engine, fully depress the

foot brake pedal before shifting the shift
position out of the P (Park) position.

This Continuously Variable Transmission
is designed so that the foot brake pedal
must be depressed before shifting from P
(Park) to any driving position while the
ignition switch is in the ON position.
The shift position cannot be shifted out of
the P (Park) position and into any of the
other positions if the ignition switch is
placed in the OFF position.

2. Keep the foot brake pedal depressed and

move the shift lever to a driving position.

3. Release the parking brake and foot brake

pedal and then gradually start the vehicle
in motion.

WARNING

Do not depress the accelerator pedal
while shifting from P (Park) or N (Neu-
tral) to R (Reverse), D (Drive), or M
(Manual shift mode). Always depress the
brake pedal until shifting is completed.
Failure to do so could cause you to lose
control and have an accident.

DRIVING THE VEHICLE

5-18

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cold engine idle speed is high, so use
caution when shifting into a forward or
reverse gear before the engine has
warmed up.

Do not downshift abruptly on slippery
roads. This may cause a loss of control.

Never shift to either the P (Park) or R
(Reverse) position while the vehicle is
moving forward and P (Park) or D (Drive)
position while the vehicle is reversing.
This could cause an accident or damage
the transmission.

CAUTION

To avoid possible damage to your ve-
hicle, when stopping the vehicle on an
uphill grade, do not hold the vehicle by
depressing the accelerator pedal. The
foot brake should be used for this
purpose.

Except in an emergency, do not shift to
the N (Neutral) position while driving.
Coasting with the transmission in the N
(Neutral) position may cause serious
damage to the transmission.

Do not hang items on the shift lever. This
may cause an accident due to a sudden
start.

Shifting

Press the shift lever button to shift

Shift without pressing the shift lever
button

After starting the engine, fully depress the
brake pedal, press the shift lever button and
shift the shift position from the P (Park) po-
sition to any of the desired shift positions.
Confirm that the vehicle is in the desired shift

position by checking the shift indicator lo-
cated near the shift lever or the vehicle infor-
mation display.

WARNING

Apply the electronic parking brake if the
shift lever is in any position while the en-
gine is not running. Failure to do so could
cause the vehicle to move unexpectedly or
roll away and result in serious personal in-
jury or property damage.

CAUTION

Use the P (Park), R (Reverse) or D (Drive)
position only when the vehicle is com-
pletely stopped.

After switching to the desired shift posi-
tion, release your hand from shift lever to
let it return to the home position.

Do not operate the shift lever while the
accelerator pedal is depressed. This may
cause a sudden start which could result in
an accident.

The following operations are not allowed
because excessive force would be ap-
plied to the transmission and this may
result in damage to the vehicle:

LSD4196

Starting and driving

5-19

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Moving the shift lever to the R (Re-
verse) position when driving forward.

Moving the shift lever to the D (Drive)
position when reversing.

If these operations are attempted, a chime
sounds and the vehicle shifts to the N (Neu-
tral) position.

P (Park)

CAUTION

To prevent transmission damage, use the
P (Park) position only when the vehicle is
completely stopped.

Do not slide the shift lever while pressing
the Park button. This may damage the
shift control system.

Use this position when the vehicle is parked
or starting the engine. Always make sure that
the vehicle is completely stopped before
pressing the Park button

O

1

to engage the P

(Park) position. For maximum safety, the
brake pedal must be depressed before en-
gaging the P (Park) position. Use this position
together with the parking brake. When park-
ing on a hill, first depress the brake pedal,
apply the parking brake and then engage the
P (Park) position. The parking lock should not
be used as a brake when parking. In order to

secure the vehicle, always apply the elec-
tronic parking brake in addition to the parking
lock.

In the event of a malfunction of the vehicle’s
electronics, the transmission may lock in the
P (Park) position. Have the vehicle’s electron-
ics checked immediately. It is recommended
that you visit an INFINITI retailer for this
service.

The P (Park) position is automatically en-
gaged if:
• You switch off the ignition switch.
• You unfasten the driver’s seat belt and

open the driver’s door when the vehicle is
stationary or driving at a very low speed
and the transmission is in the D (Drive) po-
sition or R (Reverse) position.

R (Reverse)

CAUTION

To prevent transmission damage, use the R
(Reverse) position only when the vehicle is
completely stopped.

Use the R (Reverse) position to back up. Make
sure the vehicle is completely stopped before
selecting the R (Reverse) position.

The brake

pedal must be depressed and the shift lever
button pressed to move the shift lever from
the home position to R (Reverse).

If the vehicle is placed in the R (Reverse)
position while forwarding, the chime will
sound and the vehicle will switch into the N
(Neutral) position.

N (Neutral)

Neither forward nor reverse gear is engaged.
The engine can be started in this position. You
may shift to N (Neutral) and restart a stalled
engine while the vehicle is moving. You can
select this position by holding the shift lever
at this position for 0.5 seconds.

D (Drive)

Use this position for all normal forward driv-
ing. The CVT changes gears automatically. All
forward gears are available. If the vehicle is
placed in the D (Drive) position while revers-
ing, the chime will sound and the vehicle will
switch into the N (Neutral) position.

5-20

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Neutral hold mode function (if so
equipped)

This function enables you to get out of the
vehicle when it is in the N (Neutral) position,
while the engine is running. While this func-
tion is activated, the vehicle can be moved by
pushing with hand (when car washing). When
using this function, release the electronic
parking brake.

WARNING

Use this function on a level surface only.
Failure to do so may cause the vehicle to
move accidentally and could result in a
collision or serious personal injury.

Do not use this function for a purpose
other than car washing.

Do not turn the engine off after neutral
hold mode function is activated, other-
wise the N (Neutral) position will not be
kept and the vehicle will automatically
be placed in the P (Park) position.

If this function is not activated regard-
less of proper operation, transmission
may malfunction. It is recommended that
you visit an INFINITI retailer for this
service.

To activate the Neutral hold mode, perform
the following operations:

1. Push the ignition switch to start the

engine.

2. Release the electronic parking brake.

3. Depress and hold the brake pedal.

4. Push the P (Park) button.

5. Slide the shift lever to the N (Neutral)

position, and hold it for 0.5 second until
“N” appears in the vehicle information
display.

6. Slide the shift lever to the N (Neutral)

position again, and hold it for 0.5 seconds,
until a message “Neutral Hold Mode has
been activated” appears in the vehicle in-
formation display. For additional informa-
tion, see “Neutral Hold Mode activated”
(P. 2-27).

7. The ignition switch has to be kept in the

ON position. Otherwise Neutral hold
mode is canceled and the P (Park) position
is engaged automatically.

To exit the Neutral hold mode, place the shift
lever in any position other than the N (Neu-
tral) position.

NOTE:

It is necessary to perform the steps 4
through 6 within approximately 5 seconds
to prevent incorrect operation.

When the shifter is changed to the N (Neu-
tral) position, approximately 5 seconds
later, a message will appear in the vehicle
information display. For additional infor-
mation, see “Neutral Hold Mode guidance”
(P. 2-27).

If the Neutral hold mode is unavailable, a
message will appear in the vehicle infor-
mation display. For additional informa-
tion, see “Neutral Hold Mode was not ac-
tivated” (P. 2-27).
To activate the Neutral
hold mode, wait for a while without shift-
ing operation and then perform the opera-
tions again.

Starting and driving

5-21

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Manual shift mode

The transmission enters the manual shift
mode by moving the shift lever again to the D
(Drive) position when the vehicle is in the D
range.

You can select the manual shift range by
pulling the left side or right side paddle shifter

O

A

and

O

B

. To cancel the manual shift mode,

move the shift lever to the D (Drive) position
again. The transmission returns to the auto-
matic drive mode.

When the shift lever is shifted from D (Drive)
to the manual shift mode with the vehicle

stopped or while driving, the transmission
enters the manual shift mode. Shift ranges
can be selected manually. Shift ranges can
also be selected using the paddle shifters on
the steering wheel. When you pull the paddle
shifter while in the D (Drive) position, the
transmission will shift to the upper or lower
range temporarily. If the paddle shifters are
not used for about 5–10 seconds, the trans-
mission will automatically return to the D
(Drive) position. If you want to return to the D
(Drive) position manually, pull and hold either
paddle shifter for about 1.5 seconds.

In the manual shift mode, the shift range is
displayed on the position indicator in the me-
ter. When moving the shift lever to the
manual shift mode, the position indicator dis-
plays 1 (1st) up to 8 (8th) depending on ve-
hicle speed.

Shift ranges up or down one by one as
follows:

1

2

3

4

5

6

7

8

8 (8th)

Use this position for all normal forward driv-
ing at highway speeds.

7 (7th), 6 (6th) and 5 (5th)

Use this position when driving up long slopes,
or for engine braking when driving down long
slopes.

4 (4th), 3 (3rd) and 2 (2nd)

Use these positions for hill climbing or engine
braking on downhill grades.

1 (1st)

Use this position when climbing steep hills
slowly or when driving slowly, or for maxi-
mum engine braking on steep downhill
grades.

LSD4197

Manual shift gate

LSD2914

Paddle shifters

5-22

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

• Remember not to drive at high speeds for

extended periods of time in lower than 8th
gear. This reduces fuel economy.

When shifting up

Use the + (up) side paddle shifter

O

B

. (Shifts to

higher range.)

When shifting down

Use the − (down) side paddle shifter

O

A

.

(Shifts to lower range.)
• The transmission will automatically down-

shift the gears. (For example, if you select
the 3rd range, the transmission will shift
down between the 3rd and 1st gears.)

• Moving the shift lever rapidly to the same

side

twice

will

shift

the

ranges

in

succession.

When canceling the manual shift mode

Move the shift lever to the D (Drive) position
to return the transmission to the normal driv-
ing mode.

In the manual shift mode, the transmission
may not shift to the selected gear. This
helps maintain driving performance and
reduces the chance of vehicle damage or
loss of control.

When this situation occurs, the Continu-
ously Variable Transmission (CVT) posi-
tion indicator will blink and the chime will
sound.

In the manual shift mode, the transmission
may shift up automatically to a higher
range than selected if the engine speed is
too high. When the vehicle speed de-
creases, the transmission automatically
shifts down and shifts to 1st gear before
the vehicle comes to a stop.

• CVT operation is limited to automatic drive

mode when CVT fluid temperature is ex-
tremely low even if manual shift mode is
selected. This is not a malfunction. When
CVT fluid warms up, manual mode can be
selected.

• When the CVT fluid temperature is high,

the shift range may upshift in lower rpm
than usual. This is not a malfunction.

Accelerator downshift
— in D (Drive) position —

For passing or hill climbing, depress the ac-
celerator pedal to the floor. This shifts the
transmission down into a lower gear, de-
pending on the vehicle speed.

High fluid temperature protection
mode

This transmission has a high fluid tempera-
ture protection mode. If the fluid temperature
becomes too high (for example, when climb-
ing steep grades in high temperatures with
heavy loads), engine power and, under some
conditions, vehicle speed will be decreased
automatically to reduce the chance of trans-
mission damage. Vehicle speed can be con-
trolled with the accelerator pedal, but the
engine and vehicle speed may be limited.

Fail-safe

When the fail-safe operation occurs, the
Continuously Variable Transmission will not
be shifted into the selected driving position.

If the vehicle is driven under extreme condi-
tions, such as excessive wheel spinning and
subsequent hard braking, the fail-safe sys-
tem may be activated. The Malfunction Indi-
cator Light (MIL) may come on to indicate
the fail-safe mode is activated. For addi-
tional information, see “Malfunction Indica-
tor Light (MIL)” (P. 2-15).
This will occur
even if all electrical circuits are functioning
properly. In this case, place the ignition
switch in the OFF position and wait for 10
seconds. Then place the ignition switch back

Starting and driving

5-23

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

in the ON position. The vehicle should return
to its normal operating condition. If it does
not return to its normal operating condition,
have the transmission checked and repaired,
if necessary. It is recommended that you visit
an INFINITI retailer for this service.

WARNING

When the high fluid temperature protec-
tion mode or fail-safe operation occurs, ve-
hicle speed may be gradually reduced. The
reduced speed may be lower than other
traffic, which could increase the chance of
a collision. Be especially careful when driv-
ing. If necessary, pull to the side of the road
at a safe place and allow the transmission
to return to normal operation, or have it
repaired if necessary.

WARNING

Be sure the parking brake is fully re-
leased before driving. Failure to do so
can cause brake failure and lead to an
accident.

Do not release the parking brake from
outside the vehicle.

Do not use the shift lever in place of the
parking brake. When parking, be sure the
parking brake is fully engaged.

To help avoid risk of injury or death
through unintended operation of the ve-
hicle and/or its systems, do not leave
children, people who require the assis-
tance of others or pets unattended in
your vehicle. Additionally, the tempera-
ture inside a closed vehicle on a warm day
can quickly become high enough to cause
a significant risk of injury or death to
people and pets.

The electronic parking brake can be applied
or released automatically or by operating the
parking brake switch.

AUTOMATIC OPERATION

The electronic parking brake will apply auto-
matically if the ignition switch is placed in the
OFF position when the brake force is main-
tained by the automatic brake hold function.

The electronic parking brake is automatically
released as soon as the vehicle starts and the
accelerator pedal is depressed.

The driver’s seat belt needs to be fastened.

LSD2915

ELECTRONIC PARKING BRAKE

5-24

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

The electronic parking brake will not be
automatically applied when the engine is
stopped without using the ignition
switch (for example, by engine stalling).
Without the vehicle stationary, the elec-
tronic parking brake will not be auto-
matically applied even if the engine is
turned off with the ignition switch.

Before leaving the vehicle, press the Park
button to place the vehicle in the P (Park)
position and check that the electronic
parking brake indicator light (red) is illu-
minated to confirm that the electronic
parking brake is applied. The electronic
parking brake indicator light (red) will
remain on for a period of time after the
driver’s door is locked.

CAUTION

When parking in an area where the outside
temperature is below 32°F (0°C), the park-
ing brake, if applied, may freeze in place
and may be difficult to release.

For safe parking, it is recommended that
you place the shift position in the P (Park)
position and securely block the wheels.

NOTE:

• If a malfunction occurs in the electronic

parking brake system (for example, due to
battery discharge), it is recommended that
you visit an INFINITI retailer.

• If the shift position is shifted to the P

(Park) position when the brake force is
maintained by the automatic brake hold
function, the electronic parking brake will
apply automatically.

• If the driver’s seat belt is unfastened when

the brake force is maintained by the auto-
matic brake hold function, the electronic
parking brake will apply automatically.

• If the ignition switch is placed in the OFF

position when the brake force is main-
tained by the automatic brake hold func-
tion, the electronic parking brake will ap-
ply automatically.

• Under the following conditions, the elec-

tronic parking brake will automatically be
applied and the brake force of the auto-
matic brake hold will be released:
– The brake force is applied by the auto-

matic brake hold function for 3 minutes
or longer.

– The vehicle is in the P (Park) position.
– The electronic parking brake is applied

manually.

– The driver’s seat belt is unfastened.

– The ignition switch is placed in the OFF

position.

– A malfunction occurs in the automatic

brake hold function.

MANUAL OPERATION

The electronic parking brake will not be auto-
matically applied if the engine is stopped
without using the ignition switch (for ex-
ample, by engine stalling). In such a case, you
have to apply the parking brake manually.

To apply:

Pull the switch up

O

1

. The indicator

light

O

A

will illuminate.

To release:

With the ignition switch in the ON

position, depress the brake pedal and push
the switch down

O

2

. The indicator light

O

A

will turn off.

Before driving, check that the electronic
parking brake indicator light (red) (if so
equipped)

or

goes out. For addi-

tional information, see “Warning lights, indi-
cator lights and audible reminders” (P. 2-9).

NOTE:

• A buzzer will sound if the vehicle is driven

without releasing the parking brake. For
additional information, see “Warning
lights, indicator lights and audible remind-
ers” (P. 2-9).

Starting and driving

5-25

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

• While the electronic parking brake is ap-

plied or released, an operating sound is
heard from the lower side of the rear seat.
This is normal and does not indicate a
malfunction.

• When the electronic parking brake is fre-

quently applied and released in a short pe-
riod of time, the parking brake may not op-
erate in order to prevent the parking brake
system from overheating. If this occurs, op-
erate the electronic parking brake switch
again after waiting approximately 1 minute.

• If the electronic parking brake must be ap-

plied while driving in an emergency, pull up
and hold the parking brake switch. When
you release the parking brake switch, the
parking brake will be released.

• While pulling up the electronic parking brake

switch during driving, the parking brake is ap-
plied and a chime sounds. The electronic park-
ing brake indicator light (red) in the meter and
in the parking brake switch illuminates. This
does not indicate a malfunction. The elec-
tronic parking brake indicator light (red) in
the meter and in the parking brake switch
turns off when the parking brake is released.

• When pulling the electronic parking brake

switch up with the ignition switch in the
OFF or AUTO ACC position, the parking
brake switch indicator light will continue
to illuminate for a short period of time.

The automatic brake hold function maintains
the braking force without the driver having to
depress the brake pedal when the vehicle is
stopped at a traffic light or intersection. As
soon as the driver depresses the accelerator
pedal again, the automatic brake hold func-
tion is deactivated and the braking force is
released. The operating status of the auto-
matic brake hold can be displayed.

To use the automatic brake hold function, the
following conditions need to be met:
• The driver’s seat belt is fastened.
• The electronic parking brake is released.
• The vehicle is not in the P (Park) position.
• The vehicle is not parked on a steep hill.

WARNING

The automatic brake hold function is not
designed to hold the vehicle on a steep
hill or slippery road. Never use the auto-
matic brake hold when the vehicle is
stopped on a steep hill or slippery road.
Failure to do so may cause the vehicle to
move.

The automatic brake hold warning may
appear to request that the driver retake
control by depressing the brake pedal.

When the automatic brake hold function
is activated but fails to maintain the ve-
hicle at a standstill, depress the brake
pedal to stop the vehicle. If the vehicle
unexpectedly moves due to outside con-
ditions, the chime may sound and auto-
matic

brake

hold

warning

may

illuminate.

Be sure to deactivate the automatic
brake hold function when using a car
wash or towing your vehicle.

Make sure to place the shift position in
the P (Park) position and apply the park-
ing brake when parking your vehicle, en-
tering or exiting the vehicle, or loading
luggage. Failure to do so could cause the
vehicle to move or roll away unexpect-
edly and result in serious personal injury
or property damage.

AUTOMATIC BRAKE HOLD

5-26

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

If any of the following conditions occur,
the automatic brake hold function may
not function. Have the system checked
promptly. It is recommended that you
visit an INFINITI retailer for this service.
Failure to operate the vehicle in accor-
dance with these conditions could cause
the vehicle to move or roll away unex-
pectedly and result in serious personal
injury or property damage.

A warning message appears.

The indicator light on the automatic

brake hold switch does not illuminate
when the switch is pushed.

The automatic brake hold function will
not be activated if the Slip indicator
light, electronic parking brake warning
light or master warning light illuminate
and the chassis control system fault
message appears in the vehicle informa-
tion display.

To maintain the braking force to keep
the vehicle to a standstill, a noise may be
heard. This is not a malfunction.

HOW TO ACTIVATE/
DEACTIVATE THE AUTOMATIC
BRAKE HOLD FUNCTION

For additional information on activating and
deactivating the automatic brake hold func-
tion, refer to the instructions outlined in this
section.

How to activate the automatic
brake hold function

1. With the ignition switch in the ON posi-

tion, push the automatic brake hold switch

O

1

. The indicator light on the automatic

brake hold switch

O

2

illuminates.

2. When the automatic brake hold function

goes into standby, the automatic brake
hold indicator light (white) illuminates.

To use the automatic brake hold function, the
following conditions need to be met:
• The driver’s seat belt is fastened.
• The electronic parking brake is released.
• The vehicle is not in the P (Park) position.
• The vehicle is not parked on a steep hill.

NOTE:

The automatic brake hold function retains
the last state even if the engine is restarted.

How to deactivate the automatic
brake hold function

While the automatic brake hold function is
activated, push the automatic brake hold
switch to turn off the automatic brake hold
indicator light and deactivate the automatic
brake hold function. To deactivate the auto-
matic brake hold function while the brake
force has been maintained by the automatic
brake hold function, depress the brake pedal
and push the automatic brake hold switch.

LSD2916

Starting and driving

5-27

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

Make sure to firmly depress and hold the
brake pedal when turning off the auto-
matic brake hold function while the brake
force is applied. When the automatic brake
hold function is deactivated, the brake
force will be released. This could cause the
vehicle to move or roll away unexpectedly.
Failure to prevent the vehicle from rolling
may result in serious personal injury or
property damage.

HOW TO USE THE AUTOMATIC
BRAKE HOLD FUNCTION

For additional information on using the auto-
matic brake hold function, refer to the in-
structions outlined in this section.

To maintain braking force
automatically

With the automatic brake hold function acti-
vated and the automatic brake hold indicator
light (white) illuminated on the meter, depress
the braking pedal to stop the vehicle. The
automatic brake hold indicator illuminates
green on the meter, and the brake force is
automatically applied without your foot de-
pressed on the brake pedal. While the brake

hold is maintained, the automatic brake hold
indicator light (green) illuminates on the
meter.

To start the vehicle from a standstill

With the vehicle not in the P (Park) or N
(Neutral) position, depress the accelerator
pedal while the brake force is maintained. The
brake force will automatically be released to
restart the vehicle.

The automatic brake hold indicator light
(white) illuminates and the automatic brake
hold returns to standby.

Parking

When the vehicle is in the P (Park) position
with the brake force maintained by the auto-
matic brake hold function, the parking brake
will automatically be applied and the brake
force of the automatic brake hold will be
released. The automatic brake hold indicator
light turns off. When the parking brake is
applied with the brake force maintained by
the automatic brake hold function, the brake
force of the automatic brake hold will be
released. The automatic brake hold indicator
light turns off.

NOTE:

• Under the following conditions, the elec-

tronic parking brake will automatically be
applied and the brake force of the auto-
matic brake hold will be released. The au-
tomatic brake hold indicator light turns
off.

– The brake force is applied by the auto-

matic brake hold function for 3 minutes
or longer.

– The vehicle is in the P (Park) position.
– The electronic parking brake is applied

manually.

– The driver's seat belt is unfastened.
– The ignition switch is placed in the OFF

position.

– A malfunction occurs in the automatic

brake hold function.

• When the vehicle stops, but the brake

force is not automatically applied, depress
the brake pedal firmly until the automatic
brake

hold

indicator

light

(green)

illuminates.

5-28

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Automatic brake hold function
display

The automatic brake hold function status is
shown by color in the “Chassis Control” mode
in the vehicle information display. For addi-
tional information, see “Vehicle information
display” (P. 2-19).

Also depending on the driving situations,
some warnings or indicators may be dis-
played in the vehicle information display. For
additional information, see “Vehicle informa-
tion

display

warnings

and

indicators”

(P. 2-25)

Multiple driving modes can be selected by
using the INFINITI Drive Mode Selector
switch: STANDARD, SPORT, ECO and
PERSONAL.

When the INFINITI Drive Mode Selector se-
lects a mode, the mode may not switch
quickly. This is not a malfunction.

NOTE:

• The mode list will be turned off in approxi-

mately 5 seconds after the mode is
selected.

• Select the STANDARD mode for normal

driving.

If the driving mode cannot be switched using
the INFINITI Drive Mode Selector when the
ignition switch is in the ON position, have the
system checked by an INFINITI retailer.

STANDARD MODE

STANDARD mode is recommended for nor-
mal driving. Push the INFINITI Drive Mode
Selector switch until “STANDARD” appears
in the vehicle information display. STAN-
DARD mode will also be displayed in the
upper display.

This mode will be selected first each time the
engine is started.

SPORT MODE

The SPORT mode adjusts the engine and
transmission to enhance performance. Push
the INFINITI Drive Mode Selector switch to
the SPORT position. “SPORT” appears in the
vehicle information display. SPORT mode will
also be displayed in the upper display.

NOTE:

In the SPORT mode, fuel economy may be
reduced.

LSD3922

LSD2917

INFINITI Drive Mode Selector switch

INFINITI DRIVE MODE SELECTOR

Starting and driving

5-29

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PERSONAL MODE

PERSONAL mode is used for adjusting the
steering mode and drive modes. Turn the
PERSONAL mode off for normal driving.
Push the Drive Mode Selector switch until
“PERSONAL” appears in the vehicle informa-
tion display. PERSONAL mode will also be
displayed in the upper display.

How to set the PERSONAL mode

Perform the following steps to set the PER-
SONAL mode:

1. Press the MENU button

O

1

and select

“INFINITI Drive Mode Selector” on the
lower display.

2. Select “Engine/Transmission,” “Steering,”

“Active Trace Control” or “Active Engine
Brake” and select each item. (See later
about the feature of each item.)

3. Select “Back” or press the MENU button

O

1

to finish the PERSONAL mode setting.

Engine/Transmission:

“Engine/Transmission” can be set to “Stan-
dard,” “Sport” or “Eco.”

Steering (models with Direct Adaptive
Steering®):

Multiple combinations of steering mode and
steering response can be set.

Mode

Response

Sport

Dynamic+

Dynamic

Default

Standard

Default

Steering (models without Direct Adaptive
Steering®):

“Steering” can be set to “Sport” or “Standard.”

Active Trace Control:

“Active Trace Control” can be set to ON (en-
abled) or OFF (disabled). For additional infor-
mation, see “Active Trace Control” (P. 5-144).

Active Engine Brake:

“Active Engine Brake” can be set to ON (en-
abled) or OFF (disabled). For additional infor-
mation, see “Active Engine Brake” (P. 5-145).

LSD2982

5-30

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Reset Drive Mode Settings to Default:

Touch to restore all the PERSONAL mode
settings to default. For additional informa-
tion, refer to the separate INFINITI InTouch™
Owner’s Manual.

ECO MODE

The ECO mode adjusts the engine and trans-
mission to enhance fuel economy.

NOTE:

Selecting this drive mode will not necessarily
improve fuel economy as many driving fac-
tors influence its effectiveness.

Operation

Push the Drive Mode Selector switch to the
ECO position. “ECO” appears in the vehicle
information display and the ECO drive indi-
cator light illuminates on the instrument
panel. ECO mode will also be displayed in the
upper display.

When the accelerator pedal is depressed
within the range of economy drive, the ECO
drive indicator light illuminates in green.
When the accelerator pedal is depressed
above the range of economy drive, the ECO
drive indicator light turns off.

The ECO drive indicator light will not illumi-
nate in the following cases:
• When the shift lever is in the R (Reverse)

position.

• When the vehicle speed is below 3 mph (4.8

km/h) or over 90 mph (144 km/h).

• When the Intelligent Cruise Control system

(if so equipped) is operated.

The TSR system provides the driver with in-
formation about the most recently detected
speed limit. The system captures the road
sign information with the multi-sensing front
camera unit

O

1

located on the windshield in

front of the inside rearview mirror and dis-
plays the detected signs in the vehicle infor-
mation display. For vehicles equipped with a
navigation system, the speed limit displayed
is based on a combination of navigation sys-
tem data and live camera recognition. TSR
information is always displayed at the top of
the vehicle information display, and option-
ally in the main central area of the display
screen.

LSD4091

TRAFFIC SIGN RECOGNITION (TSR)
(if so equipped)

Starting and driving

5-31

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

The TSR system is only intended to be a
support device to help provide the driver
with information. It is not a replacement
for the driver’s attention to traffic condi-
tions or responsibility to drive safely. It
cannot prevent accidents due to careless-
ness. It is the driver’s responsibility to stay
alert and drive safely at all times.

SYSTEM OPERATION

The Traffic Sign Recognition (TSR) system
displays the following types of road signs:

O

A

Speed sign detected (in Canada)

O

B

Speed sign detected (in USA)

O

C

Speed sign detected (no speed limit

detected)

O

D

“Do not pass” sign detected

CAUTION

The TSR system is intended as an aid to
careful driving. It is the driver’s responsi-
bility to stay alert, drive safely, and ob-
serve all road regulations that currently
apply, including looking out for road
signs.

The TSR system may not function prop-
erly under the following conditions:

When the road sign is not clearly vis-
ible, for example, due to damage or
weather conditions.

LSD3330

LSD3378

5-32

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When rain, snow or dirt adheres to
the windshield in front of the multi-
sensing camera unit.

When the headlights are not bright,
for example, due to dirt on the lens or
if the aiming is not adjusted properly.

When strong light enters the camera
unit. (For example, the light directly
shines on the front of the vehicle at
sunrise or sunset.)

When a sudden change in brightness
occurs. (For example, when the ve-
hicle enters or exits a tunnel or under
a bridge.)

If there are deviations in relation to
the navigation, for example due to
changes in the road routing.

When overtaking buses or trucks
with speed stickers.

TURNING THE TRAFFIC SIGN
RECOGNITION (TSR) SYSTEM ON
AND OFF

Perform the following steps to enable or dis-
able the TSR system.

1. Press the MENU button

O

1

below the

lower display screen.

2. Select “Driver Assistance.”

3. Select “Traffic Sign Assist.”

4. Select “ON” to turn the “Traffic Sign Rec-

ognition” system on or off.

SYSTEM TEMPORARILY
UNAVAILABLE

If the vehicle is parked in direct sunlight under
high temperature conditions (over approxi-
mately 104°F [40°C]) and then started, the
TSR system may be deactivated automati-
cally. The “Not Available: High Camera
Temp.” warning message will appear in the
vehicle information display.

Action to take:

When the interior temperature is reduced, the
TSR

system

will

resume

operating

automatically.

SYSTEM MALFUNCTION

If the TSR system malfunctions, it will be
turned off automatically and the system
“Malfunction” warning message will appear
in the vehicle information display.

Action to take:

If the TSR “Malfunction” message appears,
pull off the road at a safe location and stop
the vehicle. Turn the engine off and restart
the engine. If the TSR “Malfunction” message
continues to appear, have the system
checked. It is recommended that you visit an
INFINITI retailer for this service.

LSD2965

Starting and driving

5-33

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SYSTEM MAINTENANCE

The TSR system uses the same multi-sensing
front camera unit that is used by the Lane
Departure Warning (LDW) system, located in
front of the interior rearview mirror. For ad-
ditional information, see ”System mainte-
nance” (P. 5-38).

WARNING

Failure to follow the warnings and instruc-
tions for proper use of the LDW system
could result in serious injury or death.

This system is only a warning device to
inform the driver of a potential unin-
tended lane departure. It will not steer
the vehicle or prevent loss of control. It is
the driver’s responsibility to stay alert,
drive safely, keep the vehicle in the trav-
eling lane, and be in control of the vehicle
at all times.

The LDW system will operate when the ve-
hicle is driven at speeds of approximately 37
mph (60 km/h) and above, and only when the
lane markings are clearly visible on the road.

The LDW system monitors the lane markers
on the traveling lane using the camera unit

O

1

located above the inside mirror.

The LDW system warns the driver with an
indicator in the vehicle information display
and the steering wheel will vibrate, indicating
that the vehicle is beginning to leave the driv-
ing lane. For additional information, see
“LDW system operation” (P. 5-35).

LSD4091

LANE DEPARTURE WARNING (LDW)

5-34

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LDW SYSTEM OPERATION

The LDW system provides a lane departure
warning function when the vehicle is driven at
speeds of approximately 37 mph (60 km/h)
and above and the lane markings are clear.
When the vehicle approaches either the left
or the right side of the traveling lane, the
steering wheel will vibrate and the LDW indi-
cator on the instrument panel will blink to
alert the driver.

The warning function will stop when the ve-
hicle returns inside of the lane markers.

LSD3040

Starting and driving

5-35

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

HOW TO ENABLE/DISABLE THE

LDW SYSTEM

Perform the following steps to enable or dis-
able the LDW system:

1. Press the MENU button below the lower

display screen.

2. Select “Driver Assistance.”

3. Select “Lane Assist.”

4. Select “ON” to turn the “Lane Departure

Warning” system on or off.

LDW SYSTEM LIMITATIONS

WARNING

Listed below are the system limitations for
the LDW system. Failure to follow the
warnings and instructions for proper use of
the LDW system could result in serious in-
jury or death.

This system is only a warning device to
inform the driver of a potential unin-
tended lane departure. It will not steer
the vehicle or prevent loss of control. It is
the driver’s responsibility to stay alert,
drive safely, keep the vehicle in the trav-
eling lane, and be in control of the vehicle
at all times.

The system will not operate at speeds
below approximately 37 mph (60 km/h)
or if it cannot detect lane markers.

LSD4240

5-36

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Do not use the LDW system under the
following conditions as it may not func-
tion properly:

During bad weather (rain, fog, snow,

etc.).

When driving on slippery roads, such

as on ice or snow.

When driving on winding or uneven

roads.

When there is a lane closure due to

road repairs.

When driving in a makeshift or tem-

porary lane.

When driving on roads where the lane

width is too narrow.

When driving without normal tire

conditions (for example, tire wear,
low tire pressure, installation of
spare tire, tire chains, nonstandard
wheels).

When the vehicle is equipped with

non-original brake parts or suspen-
sion parts.

The system may not function properly
under the following conditions:

On roads where there are multiple
parallel lane markers; lane markers
that are faded or not painted clearly;
yellow painted lane markers; non-
standard lane markers; or lane mark-
ers covered with water, dirt, snow,
etc.

On roads where the discontinued
lane markers are still detectable.

On roads where there are sharp
curves.

On roads where there are sharply
contrasting objects, such as shad-
ows, snow, water, wheel ruts, seams
or lines remaining after road repairs.
(The LDW system could detect these
items as lane markers.)

On roads where the traveling lane
merges or separates.

When the vehicle’s traveling direc-
tion does not align with the lane
marker.

When traveling close to the vehicle in
front of you, which obstructs the lane
camera unit detection range.

When rain, snow, dirt or an object ad-
heres to the windshield in front of the
lane camera unit.

When the headlights are not bright
due to dirt on the lens or if the aiming
is not adjusted properly.

When strong light enters the lane
camera unit. (For example, the light
directly shines on the front of the ve-
hicle at sunrise or sunset.)

When a sudden change in brightness
occurs. (For example, when the ve-
hicle enters or exits a tunnel or under
a bridge.)

SYSTEM TEMPORARILY
UNAVAILABLE

If the vehicle is parked in direct sunlight under
high temperature conditions (over approxi-
mately 104°F [40°C]) and then started, the
LDW system may be deactivated automati-
cally and the following message will appear in
the vehicle information display: “Not avail-
able: High Camera Temp.”

When the interior temperature is reduced, the
LDW

system

will

resume

operating

automatically.

Starting and driving

5-37

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The LDW system is not designed to warn
under the following conditions:
• When you operate the lane change signal

and change traveling lanes in the direction
of the signal. (The LDW system will become
operable again approximately 2 seconds
after the lane change signal is turned off.)

• When the vehicle speed lowers to less than

approximately 37 mph (60 km/h).

After the above conditions have finished and
the necessary operating conditions are satis-
fied, the LDW functions will resume.

SYSTEM MALFUNCTION

If the LDW system malfunctions, it will cancel
automatically and “Malfunction” will appear
in the vehicle information display. If “Mal-
function” appears in vehicle information dis-
play, pull off the road to a safe location and
stop the vehicle. Place the shift position in the
P (Park) position and ignition switch in the
OFF position and restart the engine. If “Mal-
function” continues to appear in vehicle infor-
mation display, have the system checked. It is
recommended that you visit an INFINITI re-
tailer for this service.

SYSTEM MAINTENANCE

The lane camera unit

O

1

for the LDW system

is located above the inside mirror. To keep the
proper operation of the LDW system and
prevent a system malfunction, be sure to ob-
serve the following:
• Always keep the windshield clean.
• Do not attach a sticker (including transpar-

ent material) or install an accessory near
the camera unit.

• Do not place reflective materials, such as

white paper or a mirror, on the instrument
panel. The reflection of sunlight may ad-
versely affect the camera unit’s capability
of detecting the lane markers.

• Do not strike or damage the areas around

the camera unit. Do not touch the camera
lens or remove the screw located on the
camera unit. If the camera unit is damaged
due to an accident, it is recommended that
you visit an INFINITI retailer.

LSD3075

5-38

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

Failure to follow the warnings and instruc-
tions for proper use of the LDP system
could result in serious injury or death.

The LDP system will not steer the vehicle
or prevent loss of control. It is the driv-
er’s responsibility to stay alert, drive
safely, keep the vehicle in the traveling
lane, and be in control of the vehicle at all
times.

The LDP system is primarily intended for
use on well-developed freeways or high-
ways. It may not detect the lane markers
in certain road, weather, or driving
conditions.

The LDP system must be turned on with the
ProPILOT Assist switch on the steering
wheel, every time the ignition is placed in the
ON position.

The LDP system will operate when the ve-
hicle is driven at speeds of approximately 37
mph (60 km/h) and above, and only when the
lane markings are clearly visible on the road.

The LDP system warns the driver when the
vehicle has left the center of the traveling
lane with an indicator and steering wheel
vibration.

The system helps assist the driver to return
the vehicle to the center of the traveling lane
by applying the brakes to the left or right
wheels individually (for a short period of
time).

The LDP system monitors the lane markers
on the traveling lane using the camera unit

O

1

located above the inside mirror.

LSD4091

LANE DEPARTURE PREVENTION
(LDP)

Starting and driving

5-39

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LDP SYSTEM OPERATION

1. LDP indicator

2. Lower display buttons

3. ProPILOT Assist switch

4. LDP ON indicator

The LDP system operates above approxi-
mately 37 mph (60 km/h). When the vehicle
approaches either the left or the right side of
the traveling lane, the steering wheel will vi-
brate and the LDP indicator (orange) on the
instrument panel will blink to alert the driver.
Then, the LDP system will automatically ap-
ply the brakes for a short period of time to
help assist the driver to return the vehicle to
the center of the traveling lane.

To turn on the LDP system, push the ProPI-
LOT Assist switch on the steering wheel af-
ter starting the engine. The LDP ON indicator
on the instrument panel will illuminate. Push
the ProPILOT Assist switch on the steering
wheel again to turn off the LDP system. The
LDP ON indicator will turn off.

LSD3896

5-40

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

HOW TO ENABLE/DISABLE THE

LDP SYSTEM

When the LDP system is enabled in the lower
display, the system can be turned off tempo-
rarily by pushing the ProPILOT Assist switch
on the steering wheel.

Perform the following steps to enable or dis-
able the LDP system.

1. Press the MENU button below the lower

display screen.

2. Select “Driver Assistance.”

3. Select “Lane Assist.”

4. Select “ON” to turn the “Lane Interven-

tion” system on or off.

NOTE:

Turning on the ProPILOT Assist system will
turn on the LDP and BSI systems at the same
time. If the LDP system is disabled in the
settings menu, the LDP will automatically be
turned on when the Steering Assist system is
active. For additional information, see “Pro-
PILOT Assist” (P. 5-73).

LSD4240

Starting and driving

5-41

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LDP SYSTEM LIMITATIONS

WARNING

Listed below are the system limitations for
the LDP system. Failure to follow the
warnings and instructions for proper use of
the LDP system could result in serious in-
jury or death.

The LDP system may activate if you
change lanes without first activating
your turn signal or, for example, if a con-
struction zone directs traffic to cross an
existing lane marker. If this occurs you
may need to apply corrective steering to
complete your lane change.

Because the LDP may not activate under
the road, weather, and lane marker con-
ditions described in this section, it may
not activate every time your vehicle be-
gins to leave its lane and you will need to
apply corrective steering.

The LDP system will not operate at
speeds below approximately 37 mph (60
km/h) or if it cannot detect lane markers.

When the LDP system is operating,
avoid excessive or sudden steering ma-
neuvers. Otherwise, you could lose con-
trol of the vehicle.

Do not use the LDP system under the
following conditions as it may not func-
tion properly:

During bad weather (rain, fog, snow,

etc.).

When driving on slippery roads, such

as on ice or snow.

When driving on winding or uneven

roads.

When there is a lane closure due to

road repairs.

When driving in a makeshift or tem-

porary lane.

When driving on roads where the lane

width is too narrow.

When driving without normal tire

conditions (for example, tire wear,
low tire pressure, installation of
spare tire, tire chains, non-standard
wheels).

When the vehicle is equipped with

non-original brake parts or suspen-
sion parts.

The system may not function properly
under the following conditions:

On roads where there are multiple
parallel lane markers; lane markers
that are faded or not painted clearly;
yellow painted lane markers; non-
standard lane markers; or lane mark-
ers covered with water, dirt, snow,
etc.

On roads where discontinued lane
markers are still detectable.

On roads where there are sharp
curves.

On roads where there are sharply
contrasting objects, such as shad-
ows, snow, water, wheel ruts, seams
or lines remaining after road repairs.
(The LDP system could detect these
items as lane markers.)

On roads where the traveling lane
merges or separates.

When the vehicle’s traveling direc-
tion does not align with the lane
marker.

When traveling close to the vehicle in
front of you, which obstructs the lane
camera unit detection range.

When rain, snow or dirt adheres to
the windshield in front of the lane
camera unit.

When the headlights are not bright
due to dirt on the lens or if the aiming
is not adjusted properly.

5-42

Starting and driving

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When strong light enters the lane
camera unit. (For example, the light
directly shines on the front of the ve-
hicle at sunrise or sunset.)

When a sudden change in brightness
occurs. (For example, when the ve-
hicle enters or exits a tunnel or under
a bridge.)

While the LDP system is operating, you may
hear a sound of brake operation. This is nor-
mal and indicates that the LDP system is
operating properly.

SYSTEM TEMPORARILY
UNAVAILABLE

Condition A:

The warning and assist functions of the LDP
system are not designed to work under the
following conditions:
• When you operate the lane change signal

and change the traveling lanes in the direc-
tion of the signal. (The LDP system will be
deactivated for approximately 2 seconds
after the lane change signal is turned off.)

• When the vehicle speed lowers to less than

approximately 37 mph (60 km/h).

After the above conditions have finished and
the necessary operating conditions are satis-
fied, the warning and assist functions will
resume.

Condition B:

The assist function of the LDP system is not
designed to work under the following condi-
tions (warning is still functional):
• When the brake pedal is depressed.
• When the steering wheel is turned as far as

necessary for the vehicle to change lanes.

• When the vehicle is accelerated during LDP

system operation.

• When the Intelligent Cruise Control (ICC)

approach warning occurs.

• When the hazard warning flashers are

operated.

• When driving on a curve at high speed.

After the above conditions have finished and
the necessary operating conditions are satis-
fied, the LDP system application of the
brakes will resume.

Condition C:

If the following messages appear in the ve-
hicle information display the LDP system will
be turned off automatically:
• “Not Available Poor Road Conditions”:

When the VDC system (except Traction
Control System [TCS] function) or ABS
operates.

• “Currently not available”:

When the VDC system is turned off.

Action to take:

When the above conditions no longer exist,
turn off the LDP system. Push the ProPILOT
Assist switch on the steering wheel again to
turn the LDP system back on.

Temporary

disabled

status

at

high

temperature:

If the vehicle is parked in direct sunlight under
high temperature conditions (over approxi-
mately 104°F [40°C]) and then the LDP sys-
tem is turned on, the LDP system may be
deactivated automatically and the following
message will appear on the vehicle informa-
tion display: “Not available: High Camera
Temp.” When the interior temperature is re-
duced, the system will resume operating
automatically.

Starting and driving

5-43

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     7      8      9      10     ..
