Infiniti Q50 (2023 year). Manual in english - page 12





5-138

Starting and driving

— When a sonar or the area around

the sensor is extremely hot or
cold.

.

The sonar system may unintention-
ally operate in the following condi-
tions:

— When there is overgrown grass in

the area around the vehicle.

— When there are bumps, protru-

sions or manhole covers on the
road surface.

— When the vehicle drives through

a draped flag or a curtain.

— When there is an accumulation of

snow or ice behind the vehicle.

— When driving on a steep hill.

SYSTEM TEMPORARILY UNA-
VAILABLE

When sonar blockage is detected, the sys-
tem will be deactivated automatically.
The system is not available until the condi-
tions no longer exist.
The sonar sensors may be blocked by
temporary ambient conditions such as
splashing water, mist or fog. The blocked
condition may also be caused by objects

such as ice, frost or dirt obstructing the
sonar sensors.

Action to take:

When the above conditions no longer exist,
the system will resume automatically.

WAF0918X

SYSTEM MAINTENANCE

The sonar sensors are located on the front
and rear

of the vehicle.

.

Always keep the area near the sonar

sensors clean.

.

If the sonar sensors are dirty, wipe them

off with a soft cloth while being careful

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

to not damage them.

.

The sonar sensors may be blocked by

temporary ambient conditions such as
splashing water, mist or fog. The blocked
condition may also be caused by objects
such as ice, frost or dirt obstructing the
sonar sensors. Check for and remove
objects obstructing the area around the
sonar sensors.

.

Do not subject the area around the sonar

sensors to strong impact. Also, do not
remove or disassemble the sonar sen-
sors. If the sonar sensors and peripheral
areas are deformed in an accident, etc.,
have the sonar sensors checked. It is
recommended you visit an INFINITI
retailer for this service.

.

Do not attach stickers (including trans-

parent material), install accessories or
apply additional paint on the sonar
sensors and their surrounding areas. This
may cause a malfunction or improper
operation.

.

When washing the vehicle using a high-

pressure washer, do not apply direct
washer pressure on the sonar sensors.
This may cause a malfunction of the
sonar sensors.

FREEING A FROZEN DOOR LOCK

To prevent a door lock from freezing, apply
deicer through the key hole. If the lock
becomes frozen, heat the key before insert-
ing it into the key hole or use the Intelligent
Key system.

ANTIFREEZE

In the winter when it is anticipated that the
outside temperature will drop below 32°F
(0°C), check antifreeze to assure proper
winter protection. For additional informa-
tion, see “Engine cooling system” (P.8-3) or
“Intercooler cooling system” (P.8-5).

BATTERY

If the battery is not fully charged during
extremely cold weather conditions, the bat-
tery fluid may freeze and damage the
battery. To maintain maximum efficiency,
the battery should be checked regularly. For
additional information, see “Battery” (P.8-
11).

DRAINING OF COOLANT WATER

If the vehicle is to be left outside without
antifreeze, drain the cooling system, includ-
ing the engine block. Refill before operating
the vehicle. For details, see “Engine cooling
system” (P.8-3).

TIRE EQUIPMENT

SUMMER tires have a tread designed to
provide superior performance on dry pave-
ment. However, the performance of these
tires will be substantially reduced in snowy
and icy conditions. If you operate your
vehicle on snowy or icy roads, INFINITI
recommends the use of MUD & SNOW or
ALL SEASON tires on all four wheels. It is
recommended you consult an INFINITI re-
tailer for the tire type, size, speed rating and
availability information.
For additional traction on icy roads, studded
tires may be used. However, some U.S.
states and Canadian provinces prohibit their
use. Check local, state and provincial laws
before installing studded tires.

Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow tires.

Tire chains may be used. For details, see
“Tire chains” (P.8-34) of this manual.

Intelligent All-Wheel Drive (AWD)
models

If you install snow tires, they must also be
the same size, brand, construction and tread
pattern on all four wheels.

Starting and driving

5-139

COLD WEATHER DRIVING

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-140

Starting and driving

SPECIAL WINTER EQUIPMENT

It is recommended that the following items
be carried in the vehicle during winter:

.

A scraper and stiff-bristled brush to

remove ice and snow from the windows
and wiper blades.

.

A sturdy, flat board to be placed under

the jack to give it firm support.

.

A shovel to dig the vehicle out of

snowdrifts.

.

Extra window washer fluid to refill the

reservoir tank.

DRIVING ON SNOW OR ICE

WARNING

.

Wet ice (32°F, 0°C and freezing rain),
very cold snow or ice can be slick and
very hard to drive on. The vehicle will
have much less traction or “grip”
under these conditions. Try to avoid
driving on wet ice until the road is
salted or sanded.

.

Whatever the condition, drive with
caution. Accelerate and slow down
with care. If accelerating or down-
shifting too fast, the drive wheels will
lose even more traction.

.

Allow more stopping distance under
these conditions. Braking should be
started sooner than on dry pave-
ment.

.

Allow greater following distances on
slippery roads.

.

Watch for slippery spots (glare ice).
These may appear on an otherwise
clear road in shaded areas. If a patch
of ice is seen ahead, brake before
reaching it. Try not to brake while on
the ice, and avoid any sudden steer-
ing maneuvers.

.

Do not use the cruise control on
slippery roads.

.

Snow can trap dangerous exhaust
gases under your vehicle. Keep snow
clear of the exhaust pipe and from
around your vehicle.

ENGINE BLOCK HEATER (if so
equipped)

Engine block heaters are used to assist in
cold temperature starting.
The engine block heater should be used
when the outside temperature is 20°F
(−7°C) or lower.

To use the engine block heater

1. Turn the engine off.
2. Open the hood and unwrap the engine

block heater cord.

3. Plug the engine block heater cord into a

grounded 3-wire, 3-pronged extension
cord.

4. Plug the extension cord into a Ground

F a u l t I n t e r r u p t ( G F I ) p r o t e c t e d ,
grounded 110-volt AC (VAC) outlet.

5. The engine block heater must be plugged

in for at least 2 - 4 hours, depending on
outside temperatures, to properly warm
the engine coolant. Use an appropriate
timer to turn the engine block heater on.

6. Before starting the engine, unplug and

properly store the cord to keep it away
from moving parts.

WARNING

.

Do not use your engine block heater
with an ungrounded electrical system
or a 2-pronged adapter. You can be
seriously injured by an electrical
shock if you use an ungrounded
connection.

.

Disconnect and properly store the
engine block heater cord before

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

starting the engine. Damage to the
cord could result in an electrical shock
and can cause serious injury.

.

Use a heavy-duty 3-wire, 3-pronged
extension cord rated for at least 10A.
Plug the extension cord into a Ground
Fault Interrupt (GFI) protected,
grounded 110-VAC outlet. Failure
to use the proper extension cord or
a grounded outlet can result in a fire
or electrical shock and cause serious
personal injury.

JVS0263X

NOTE:

To operate the active noise cancellation and
active sound enhancement system properly:

.

Do not cover the speakers or woofer.

.

Do not cover the microphones.

.

Do not change or modify speakers in-

cluding the woofer and any audio related
parts such as the amplifier.

.

Do not make any modification including

sound deadening or modifications
around the microphones, speakers or
woofer.

Starting and driving

5-141

ACTIVE NOISE CANCELLATION/
ACTIVE SOUND ENHANCEMENT

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-142

Starting and driving

ACTIVE NOISE CANCELLATION

The active noise cancellation uses micro-
phones

located inside the vehicle to detect

engine booming noises. The system then
automatically produces a muted engine
booming noise through the speakers

and

woofer

(if so equipped) to reduce engine

booming noise.
If the microphone

or the area around it is

tapped, abnormal noise may be output from
the speaker.

ACTIVE SOUND ENHANCEMENT

The active sound enhancement generates
sounds according to engine speed and
driving modes through the speakers

and

woofer

(if so equipped) to enhance the

quality of the engine sound.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6-2

In case of emergency

SIC2574

Push the switch on to warn other drivers
when you must stop or park under emer-
gency conditions. All turn signal lights will
flash.

WARNING

.

If stopping for an emergency, be sure
to move the vehicle well off the road.

.

Do not use the hazard warning
flashers while moving on the highway
unless unusual circumstances force
you to drive so slowly that your
vehicle might become a hazard to
other traffic.

.

Turn signals do not work when the
hazard warning flasher lights are on.

The flasher can be actuated with the ignition
switch in any position.
When an impact that could activate the
supplemental air bags is detected, the
hazard warning flasher lights blink automa-
tically. If the hazard warning flasher switch is
pushed, the hazard warning flashers will turn
off.

WARNING

Do not turn the hazard warning flasher
switch to off until you can make sure
that it is safe to do so. Also, the hazard
flasher warning may not blink automa-
tically depending on the force of impact.

Some state laws may prohibit the use of the
hazard warning flasher switch while driving.

In the event of a roadside emergency,
Roadside Assistance Service is available to
you. Please refer to your Warranty Informa-
tion Booklet (U.S.) or Warranty & Roadside
Assistance Information Booklet (Canada) for
details.

HAZARD WARNING FLASHER SWITCH

ROADSIDE ASSISTANCE PROGRAM

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

To shut off the engine in an emergency
situation while driving, perform the follow-
ing procedure:

.

Rapidly push the push-button ignition

switch 3 consecutive times in less than
1.5 seconds, or

.

Push and hold the push-button ignition

switch for more than 2 seconds.

If you have a flat tire, follow the instructions
in this section.
For models with run-flat tires, you can
continue driving to a safe location even if
they are punctured. (See “Run-flat tires”
(P.6-4) and “Run-flat tires” (P.8-33).)

TIRE PRESSURE MONITORING
SYSTEM (TPMS)

This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS). It
monitors tire pressure of all tires except the
spare. When the low tire pressure warning
light is lit and the “Tire Pressure Low - Add
Air” warning appears in the vehicle informa-
tion display, one or more of your tires is
significantly under-inflated. If the vehicle is
being driven with low tire pressure, the
TPMS will activate and warn you of it by
the low tire pressure warning light. This
system will activate only when the vehicle is
driven at speeds above 16 MPH (25 km/h).
For more details, see “Warning lights, in-
dicator lights and audible reminders” (P.2-
10) and “Tire Pressure Monitoring System
(TPMS)” (P.5-5).

WARNING

.

Radio waves could adversely affect
electric medical equipment. Those

who use a pacemaker should contact
the electric medical equipment man-
ufacturer for the possible influences
before use.

.

If the low tire pressure warning light
illuminates while driving, avoid sud-
den steering maneuvers or abrupt
braking, reduce vehicle speed, pull
off the road to a safe location and
stop the vehicle as soon as possible.
Driving with under-inflated tires may
permanently damage the tires and
increase the likelihood of tire failure.
Serious vehicle damage could occur
and may lead to an accident and
could result in serious personal injury.
Check the tire pressure for all four
tires. Adjust the tire pressure to the
recommended COLD tire pressure
shown on the Tire and Loading
Information label to turn the low tire
pressure warning light OFF. If the
light still illuminates while driving
after adjusting the tire pressure, a
tire may be flat. If you have a flat tire,
replace it with a spare tire (if so
equipped).

.

Since the spare tire is not equipped
with the TPMS, when a spare tire is
mounted or a wheel is replaced, the
TPMS will not function and the low
tire pressure warning light will flash

In case of emergency

6-3

EMERGENCY ENGINE SHUT OFF

FLAT TIRE

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6-4

In case of emergency

for approximately 1 minute. The light
will remain on after 1 minute. Have
your tires replaced and/or TPMS
system reset as soon as possible. It
is recommended you visit an INFINITI
retailer for these services.

.

Replacing tires with those not origin-
ally specified by INFINITI could affect
the proper operation of the TPMS.

.

Do not inject any tire liquid or aerosol
tire sealant into the tires, as this may
cause a malfunction of the tire pres-
sure sensors.

RUN-FLAT TIRES (if so equipped)

Run-flat tires are those tires that can be
used temporarily if they are punctured. See
“Run-flat tires” (P.8-33).
Also, refer to “Important Tire Safety Infor-
mation” (US) or “Tire Safety Information”
(Canada) in the INFINITI Warranty Informa-
tion Booklet.

WARNING

.

Although you can continue driving
with a punctured run-flat tire, re-
member that vehicle handling stabi-
lity is reduced, which could lead to an

accident and personal injury. Also,
driving a long distance at high speeds
may damage the tires.

.

Do not drive at speeds above 50
MPH (80 km/h) and do not drive
more than approximately 93 miles
(150 km) with a punctured run-flat
tire. The actual distance the vehicle
can be driven on a flat tire depends on
outside temperature, vehicle load,
road conditions and other factors.

.

Drive safely at reduced speeds. Avoid
hard cornering or braking, which may
cause you to lose control of the
vehicle.

.

If you detect any unusual sounds or
vibrations while driving with a punc-
tured run-flat tire, pull off the road
to a safe location and stop the vehicle
as soon as possible. The tire may be
seriously damaged and need to be
replaced.

CAUTION

.

Never install tire chains on a punctu-
red run-flat tire, as this could damage
your vehicle.

.

Avoid driving over any projection or
pothole, as the clearance between
the vehicle and the ground is smaller
than normal.

.

Do not enter an automated car wash
with a punctured run-flat tire.

.

It is recommended you have the
punctured tire inspected by an
INFINITI retailer or other authorized
repair shop. Replace the tire as soon
as possible if the tire is seriously
damaged.

If you have a flat tire and have to stop the
vehicle, follow the instructions below.
1. Safely move the vehicle off the road and

away from traffic.

2. Turn on the hazard warning flashers.
3. Park on a level surface and apply the

parking brake. Move the shift lever to the
P (Park) position.

4. Turn off the engine.
5. Raise the hood to warn other traffic, and

to signal professional road assistance
personnel that you need assistance.

6. Have all passengers get out of the

vehicle and stand in a safe place, away
from traffic and clear of the vehicle.

For the tire removing procedure, see “Jack-

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

ing up the vehicle and replacing tires” (P.8-
38).

To start your engine with a booster battery,
the instructions and precautions below must
be followed.

WARNING

.

If done incorrectly, jump starting can
lead to a battery explosion, resulting
in severe injury or death. It could also
damage your vehicle.

.

Explosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.

.

Do not allow battery fluid to come
into contact with eyes, skin, clothing
or painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.

.

Keep the battery out of the reach of
children.

.

The booster battery must be rated at
12 volts. Use of an improperly rated
battery can damage your vehicle.

.

Whenever working on or near a
battery, always wear suitable eye
protectors (for example, goggles or

industrial safety spectacles) and re-
move rings, metal bands, or any other
jewelry. Do not lean over the battery
when jump starting.

.

Do not attempt to jump start a
frozen battery. It could explode and
cause serious injury.

.

Your vehicle has an automatic engine
cooling fan. It could come on at any
time. Keep hands and other objects
away from it.

In case of emergency

6-5

JUMP STARTING

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6-6

In case of emergency

JVE0282X

WARNING

Always follow the instructions below.
Failure to do so could result in damage to
the charging system and cause personal
injury.

1. If the booster battery is in another

vehicle

, position the two vehicles

and

to bring the batteries into close

proximity to each other.

CAUTION

.

Do not allow the two vehicles to
touch.

2. Apply parking brake. Move the shift lever

to the P (Park) position. Switch off all
unnecessary electrical systems (light,
heater, air conditioner, etc.).

3. Remove vent caps on the battery (if so

equipped). Cover the battery with a
firmly wrung out moist cloth

to reduce

explosion hazard.

4. Connect jumper cables in the sequence

as illustrated (

?

?

?

).

CAUTION

.

Always connect positive (+) to posi-
tive (+) and negative (−) to body
ground (as illustrated) − not to the
battery.

.

Make sure the jumper cables do not
touch moving parts in the engine
compartment and that clamps do
not contact any other metal.

5. Start the engine of the booster vehicle

and let it run for a few minutes.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6. Keep the engine speed of the booster

vehicle

at about 2,000 rpm, and start

the engine of the vehicle being jump
started

.

CAUTION

Do not keep the starter motor engaged
for more than 10 seconds. If the engine
does not start right away, push the
ignition switch to the OFF position and
wait 10 seconds before trying again.

7. After starting your engine, carefully

disconnect the negative cable and then
the positive cable (

?

?

?

).

8. Replace the vent caps (if so equipped).

Be sure to dispose of the cloth used to
cover the vent holes as it may be
contaminated with corrosive acid.

9. Put the battery cover and the engine

cover back to the original location.

Do not attempt to start the engine by
pushing.

CAUTION

.

Automatic Transmission (AT) models
cannot be push-started or tow-
started. Attempting to do so may
cause transmission damage.

.

Three-way catalyst equipped models
should not be started by pushing
since the three-way catalyst may be
damaged.

.

Never try to start the vehicle by
towing it; when the engine starts,
the forward surge could cause the
vehicle to collide with the tow vehi-
cle.

CAUTION

.

Do not continue to drive if your
vehicle overheats. Doing so could
cause engine damage or a vehicle fire.

.

To avoid the danger of being scalded,
never remove the radiator cap while
the engine is still hot. When the
radiator cap is removed, pressurized
hot water will spurt out, possibly
causing serious injury.

.

Do not open the hood if steam is
coming out.

If your vehicle is overheating (indicated by an
extremely high temperature gauge reading),
or if you feel a lack of engine power, detect
abnormal noise, etc., take the following
steps:
1. Move the vehicle safely off the road,

apply the parking brake and move the
shift lever to the P (Park) position.

Do not stop the engine.

2. Turn off the climate control. Open all the

windows, move the heater or air condi-
tioner temperature control to maximum
hot and fan control to high speed.

3. If engine overheating is caused by climb-

ing a long hill on a hot day, run the engine

In case of emergency

6-7

PUSH STARTING

IF YOUR VEHICLE OVERHEATS

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6-8

In case of emergency

at a fast idle (approximately 1,500 rpm)
until the temperature gauge indication
returns to normal.

4. Get out of the vehicle. Look and listen for

steam or coolant escaping from the
radiator before opening the hood. (If
steam or coolant is escaping, turn off the
engine.) Do not open the hood further
until no steam or coolant can be seen.

5. Open the engine hood.

WARNING

If steam or water is coming from the
engine, stand clear to prevent getting
burned.

6. Visually check drive belts for damage or

looseness. Also check if the cooling fan is
running. The radiator hoses and radiator
should not leak water. If coolant is
leaking or the cooling fan does not run,
stop the engine.

WARNING

Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or get caught in, engine belts or the
engine cooling fan. The engine cooling

fan can start at any time.

7. After the engine cools down, check the

coolant level in the reservoir tank with
the engine running. Add coolant to the
reservoir tank if necessary. Have your
vehicle repaired. It is recommended you
visit an INFINITI retailer for this service.

When towing your vehicle, all State (Pro-
vincial in Canada) and local regulations for
towing must be followed. Incorrect towing
equipment could damage your vehicle. Tow-
ing instructions are available from an
INFINITI retailer. Local service operators
are familiar with the applicable laws and
procedures for towing. To assure proper
towing and to prevent accidental damage to
your vehicle, INFINITI recommends that you
have a service operator tow your vehicle. It is
advisable to have the service operator care-
fully read the following precautions.

WARNING

.

Never ride in a vehicle that is being
towed.

.

Never get under your vehicle after it
has been lifted by a tow truck.

CAUTION

.

When towing, make sure that the
transmission, axles, steering system
and powertrain are in working con-
dition. If any unit is damaged, dollies
must be used.

TOWING YOUR VEHICLE

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

.

Always attach safety chains before
towing.

For information about towing your vehicle
behind a recreational vehicle (RV), see “Flat
towing” (P.10-20) of this manual.

SCE0788

Two-Wheel Drive (2WD) models

TOWING RECOMMENDED BY
INFINITI

Two-Wheel Drive (2WD) models

INFINITI recommends that your vehicle be
towed with the driving (rear) wheels off the
ground or place the vehicle on a flat bed
truck as illustrated.

CAUTION

.

Never tow automatic transmission
models with the rear wheels on the
ground or four wheels on the ground

(forward or backward), as this may
cause serious and expensive damage
to the transmission. If it is necessary
to tow the vehicle with the front
wheels raised, always use towing
dollies under the rear wheels.

.

When towing rear wheel drive models
with the front wheels on the ground
or on towing dollies: Push the ignition
switch to the ACC or ON position,
and secure the steering wheel in a
straight-ahead position with a rope
or similar device.

In case of emergency

6-9

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

6-10

In case of emergency

SCE0488

All-Wheel Drive (AWD) models

Intelligent All-Wheel Drive (AWD)
models

INFINITI recommends that towing dollies be
used when towing your vehicle or the vehicle
be placed on a flat bed truck as illustrated.

CAUTION

Never tow Intelligent AWD models with
any of the wheels on the ground as this
may cause serious and expensive da-
mage to the powertrain.

VEHICLE RECOVERY (freeing a
stuck vehicle)

WARNING

To avoid vehicle damage, serious perso-
nal injury or death when recovering a
stuck vehicle:

.

Contact a professional towing ser-
vice to recover the vehicle if you have
any questions regarding the recovery
procedure.

.

Tow chains or cables must be at-
tached only to main structural mem-
bers of the vehicle.

.

Do not use the vehicle tie-downs to
tow or free a stuck vehicle.

.

Only use devices specifically designed
for vehicle recovery and follow the
manufacturer’s instructions.

.

Always pull the recovery device
straight out from the front of the
vehicle. Never pull at an angle.

.

Route recovery devices so they do
not touch any part of the vehicle
except the attachment point.

If your vehicle is stuck in sand, snow, mud,
etc., use a tow strap or other device

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

designed specifically for vehicle recovery.
Always follow the manufacturer’s instruc-
tions for the recovery device.

Rocking a stuck vehicle

If your vehicle is stuck in sand, snow, mud,
etc., use the following procedure:
1. Turn off the Vehicle Dynamic Control

(VDC) system.

2. Make sure the area in front and behind

the vehicle is clear of obstructions.

3. Turn the steering wheel right and left to

clear an area around the front tires.

4. Slowly rock the vehicle forward and

backward.

.

Shift back and forth between R (Re-

verse) and D (Drive).

.

Apply the accelerator as little as

possible to maintain the rocking mo-
tion.

.

Release the accelerator pedal before

shifting between R and D.

.

Do not spin the tires above 35 MPH

(55 km/h).

5. If the vehicle cannot be freed after a few

tries, contact a professional towing
service to remove the vehicle.

WARNING

.

Stand clear of a stuck vehicle.

.

Do not spin your tires at high speed.
This could cause them to explode and
result in serious injury. Parts of your
vehicle could also overheat and be
damaged.

In case of emergency

6-11

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

7 Appearance and care

Cleaning exterior ................................................................ 7-2

Washing .......................................................................... 7-2
Waxing ............................................................................ 7-2
Removing spots ............................................................ 7-3
Underbody ...................................................................... 7-3
Glass ................................................................................ 7-3
Wheels ............................................................................. 7-3
Chrome parts ................................................................ 7-4
Tire dressing ................................................................. 7-4

Cleaning interior ................................................................ 7-5

Air fresheners .............................................................. 7-5
Floor mats .................................................................... 7-6
Seat belts ...................................................................... 7-7

Corrosion protection ....................................................... 7-8

Most common factors contributing to
vehicle corrosion ........................................................ 7-8
Environmental factors influence the rate
of corrosion ................................................................. 7-8
To protect your vehicle from corrosion .............. 7-8

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

7-2

Appearance and care

In order to maintain the appearance of your
vehicle, it is important to take proper care of
it.
To protect the paint surface, wash your
vehicle as soon as you can:

.

after a rainfall to prevent possible da-

mage from acid rain

.

after driving on coastal roads

.

when contaminants such as soot, bird

droppings, tree sap, metal particles or
bugs get on the paint surface

.

when dust or mud builds up on the

surface

Whenever possible, store or park your
vehicle inside a garage or in a covered area.
When it is necessary to park outside, park in
a shady area or protect the vehicle with a
body cover.

Be careful not to scratch the paint surface
when putting on or removing the body
cover.

WASHING

Wash dirt off the vehicle with a wet sponge
and plenty of water. Clean the vehicle
thoroughly using a mild soap, a special
vehicle soap or general purpose dishwashing
liquid mixed with clean, lukewarm (never hot)
water.

CAUTION

.

Do not use car washes that use acid in
the detergent. Some car washes,
especially brushless ones, use some
acid for cleaning. The acid may react
with some plastic vehicle compo-
nents, causing them to crack. This
could affect their appearance, and
also could cause them not to function
properly. Always check with your car
wash to confirm that acid is not used.

.

Do not wash the vehicle with strong
household soap, strong chemical de-
tergents, gasoline or solvents.

.

Do not wash the vehicle in direct
sunlight or while the vehicle body is
hot, as the surface may become
water-spotted.

.

Avoid using tight-napped or rough
cloths, such as washing mitts. Care
must be taken when removing caked-

on dirt or other foreign substances so
the paint surface is not scratched or
damaged.

Rinse the vehicle again with plenty of clean
water.
Inside flanges, seams and folds on the doors,
hatches and hood are particularly vulnerable
to the effects of road salt. Therefore, these
areas must be regularly cleaned. Make sure
that the drain holes in the lower edge of the
door are open. Spray water under the body
and in the wheel wells to loosen the dirt and
wash away road salt.
Avoid leaving water spots on the paint
surface by using a damp chamois to dry the
vehicle.

WAXING

Regular waxing protects the paint surface
and helps retain new vehicle appearance.
Polishing is recommended to remove built-
up wax residue and to avoid a weathered
appearance before reapplying wax.
An INFINITI retailer can assist you in choos-
ing the proper product.

.

Wax your vehicle only after a thorough

washing. Follow the instructions sup-
plied with the wax.

CLEANING EXTERIOR

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

.

Do not use a wax containing any abra-

sives, cutting compounds or cleaners
that may damage the vehicle finish.

Machine compound or aggressive polishing
on a base coat/clear coat paint finish may
dull the finish or leave swirl marks.

REMOVING SPOTS

Remove tar and oil spots, industrial dust,
insects, and tree sap as quickly as possible
from the paint surface to avoid lasting
damage or staining. Special cleaning pro-
ducts are available at an INFINITI retailer or
any automotive accessory stores.

UNDERBODY

In areas where road salt is used in winter, the
underbody must be cleaned regularly. This
will prevent dirt and salt from building up
and causing the acceleration of corrosion on
the underbody and suspension. Before the
winter period and again in the spring, the
underseal must be checked and, if necessary,
re-treated.

GLASS

Use glass cleaner to remove smoke and dust
film from the glass surfaces. It is normal for
glass to become coated with a film after the
vehicle is parked in the hot sun. Glass cleaner
and a soft cloth will easily remove this film.

CAUTION

When cleaning the inside of the win-
dows, do not use sharp-edged tools,
abrasive cleaners or chlorine-based dis-
infectant cleaners. They could damage
the electrical conductors, radio antenna
elements or rear window defroster ele-
ments.

WHEELS

Wash the wheels when washing the vehicle
to maintain their appearance.

.

Clean the inner side of the wheels when

the wheel is changed or the underside of
the vehicle is washed.

.

Inspect wheel rims regularly for dents or

corrosion. Such damage may cause loss
of pressure or poor seal at the tire bead.

.

INFINITI recommends that the road

wheels be waxed to protect against road
salt in areas where it is used during

winter.

CAUTION

Do not use abrasive cleaners when
washing the wheels.

Aluminum alloy wheels

Wash regularly with a sponge dampened in a
mild soap solution, especially during winter
months in areas where road salt is used. Salt
could discolor the wheels if not removed.

CAUTION

Follow the directions below to avoid
staining or discoloring the wheels:

.

Do not use a cleaner that uses strong
acid or alkali contents to clean the
wheels.

.

Do not apply wheel cleaners to the
wheels when they are hot. The wheel
temperature should be the same as
ambient temperature.

.

Rinse the wheel to completely re-
move the cleaner within 15 minutes
after the cleaner is applied.

Appearance and care

7-3

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

7-4

Appearance and care

Bright wheels (if so equipped)

The bright wheels use a different coating
process than typical aluminum alloy wheel
and they are not plated wheels. These
wheels are clear-coated and require the
following special cleaning. They should be
regularly washed with a soft sponge soaked
in a lot of water. After washing with water,
wipe clean with a dry, soft cloth and dry
completely. When there is chemical or tire
wax, or dirt such as an antifreeze agent on
the surface, wash them with water as soon
as possible.

CAUTION

.

The surfaces of the wheels use a
different coating process than typical
aluminum alloy wheels. Do not use
aluminum alloy wheel cleaners or
abrasive cleaners to clean the wheels.
Using such cleaners could damage the
wheel surfaces.

.

Do not use an automatic car wash if
the vehicle is equipped with bright
wheels. The wheel coating may be
damaged.

.

Do not use a brush to wash the
wheels if the vehicle is equipped with
bright wheels. The wheel coating may

be damaged.

CHROME PARTS

Clean chrome parts regularly with a non-
abrasive chrome polish to maintain the
finish.

TIRE DRESSING

INFINITI does not recommend the use of tire
dressings. Tire manufacturers apply a coat-
ing to the tires to help reduce discoloration
of the rubber. If a tire dressing is applied to
the tires, it may react with the coating and
form a compound. This compound may come
off the tire while driving and stain the vehicle
paint.
If you choose to use a tire dressing, take the
following precautions:

.

Use a water-based tire dressing. The

coating on the tire dissolves more easily
with an oil-based tire dressing.

.

Apply a light coat of tire dressing to help

prevent it from entering the tire tread/
grooves (where it would be difficult to
remove).

.

Wipe off excess tire dressing using a dry

towel. Make sure the tire dressing is
completely removed from the tire tread/
grooves.

.

Allow the tire dressing to dry as recom-

mended by tire dressing manufacturer.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Occasionally remove loose dust from the
interior trim, plastic parts and seats using a
vacuum cleaner or soft bristled brush. Wipe
the vinyl and leather surfaces with a clean,
soft cloth dampened in mild soap solution,
then wipe clean with a dry soft cloth.
Regular care and cleaning is required in order
to maintain the appearance of the leather.
Before using any fabric protector, read the
manufacturer’s recommendations. Some
fabric protectors contain chemicals that
may stain or bleach the seat material.
Use a cloth dampened only with water, to
clean the meter and gauge lens.

WARNING

Do not use water or acidic cleaners (hot
steam cleaners) on the seat. This can
damage the seat or occupant classifica-
tion sensors. This can also affect the
operation of the air bag system and
result in serious personal injury.

CAUTION

.

Never use benzine, thinner, or any
similar material.

.

For cleaning, use a soft cloth, dam-
pened with water. Never use a rough
cloth, alcohol, benzine, thinner or any
kind of solvent or paper towel with a
chemical cleaning agent. They will
scratch or cause discoloration to the
lens.

.

Do not spray any liquid such as water
on the meter lens. Spraying liquid
may cause the system to malfunction.

.

Small dirt particles can be abrasive
and damaging to the leather surfaces
and should be removed promptly. Do
not use saddle soap, car waxes,
polishes, oils, cleaning fluids, sol-
vents, detergents or ammonia-based
cleaners as they may damage the
leather’s natural finish.

.

Only use fabric protectors approved
by INFINITI.

.

Do not use glass or plastic cleaner on
meter or gauge lens covers. It may
damage the lens cover.

.

Do not spill on or make contact with
interior surfaces while handling air
fresheners, aroma agents, cosmetics,
sunscreen, etc. They may cause per-
manent discoloration, stain, crack,
paint peeling, etc. depending on the
ingredients. If they contact the inter-
ior surface, wipe them off immedi-

ately using a soft cloth.

.

Do not use the chlorine-based clean-
ing liquid such as chlorine dioxide and
hypochlorous acid, which may cause
the paint peeling, corrosion, etc. If it
is unavoidable to clean or sterilize
interior surfaces, use less than 75%
ethanol. Wipe the interior parts with
a dry cloth dampened with ethanol.
Wipe off ethanol completely. If you
leave it uncleaned, it may cause paint
peeling, discoloration, etc. Since
ethanol is flammable, be careful of
fire.

AIR FRESHENERS

Most air fresheners use a solvent that could
affect the vehicle interior. If you use an air
freshener, take the following precautions:

.

Hanging-type air fresheners can cause

permanent discoloration when they con-
tact vehicle interior surfaces. Place the
air freshener in a location that allows it
to hang free and not contact an interior
surface.

.

Liquid-type air fresheners typically clip

on the vents. These products can cause
immediate damage and discoloration
when spilled on interior surfaces.

Carefully read and follow the manufac-

Appearance and care

7-5

CLEANING INTERIOR

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

7-6

Appearance and care

turer’s instructions before using air fresh-
eners.

FLOOR MATS

WARNING

To avoid potential pedal interference
that may result in a collision, injury or
death:

.

NEVER place a floor mat on top of
another floor mat in the driver front
position or install them upside down
or backwards.

.

Use only genuine INFINITI floor mats
or equivalent floor mats that are
specifically designed for use in your
vehicle model and model year.

.

Properly position the mats in the
floorwell using the floor mat posi-
tioning hook. See “Floor mat installa-
tion” (P.7-6).

.

Make sure the floor mat does not
interfere with pedal operation.

.

Periodically check the floor mats to
make sure they are properly installed.

.

After cleaning the vehicle interior,
check the floor mats to make sure
they are properly installed.

The use of genuine INFINITI floor mats can
extend the life of your vehicle carpet and
make it easier to clean the interior. Mats
should be maintained with regular cleaning
and replaced if they become excessively
worn.

JVA0032X

Floor mat installation

Your vehicle is equipped with floor mat
positioning hook(s). The number and shape
of the floor mat positioning hook(s) for each
seating position varies depending on the
vehicle.
When installing genuine INFINITI floor mats,
follow the installation instructions provided
with the floor mat and the following:
1. Position the floor mat in the floorwell so

that the mat grommet holes are aligned
with the hook(s).

2. Push the grommet holes into the hook(s)

firmly and secure them. Ensure that the
floor mat is properly positioned.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3. Make sure the floor mat does not

interfere with pedal operation. With the
ignition in the OFF position and the shift
lever in the P (Park) position, fully apply
and release all pedals. The floor mat
must not interfere with pedal operation
or prevent the pedal from returning to its
normal position. It is recommended you
see an INFINITI retailer for details about
installing the floor mats in your vehicle.

SAI0051

Positioning hooks

The illustration shows the location of the
floor mat positioning hooks.

SEAT BELTS

The seat belts can be cleaned by wiping
them with a sponge dampened in a mild soap
solution. Allow the belts to dry completely
before using them.
See “Seat belts” (P.1-12).

WARNING

Do not allow wet seat belts to roll up in
the retractor. NEVER use bleach, dye, or
chemical solvents to clean the seat belts,

since these materials may severely
weaken the seat belt webbing.

Appearance and care

7-7

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

7-8

Appearance and care

MOST COMMON FACTORS
CONTRIBUTING TO VEHICLE
CORROSION

.

The accumulation of moisture-retaining

dirt and debris in body panel sections,
cavities, and other areas.

.

Damage to paint and other protective

coatings caused by gravel and stone
chips or minor traffic accidents.

ENVIRONMENTAL FACTORS IN-
FLUENCE THE RATE OF COR-
ROSION

Moisture

Accumulation of sand, dirt and water on the
vehicle body underside can accelerate corro-
sion. Wet floor coverings will not dry
completely inside the vehicle, and should be
removed for drying to avoid floor panel
corrosion.

Relative humidity

Corrosion will be accelerated in areas of high
relative humidity, especially those areas
where the temperatures stay above freezing
where atmospheric pollution exists, or where
road salt is used.

Temperature

A temperature increase will accelerate the
rate of corrosion to those parts which are
not well ventilated.

Air pollution

Industrial pollution, the presence of salt in
the air in coastal areas, or heavy road salt
use will accelerate the corrosion process.
Road salt will also accelerate the disintegra-
tion of paint surfaces.

TO PROTECT YOUR VEHICLE
FROM CORROSION

.

Wash and wax your vehicle often to keep

the vehicle clean.

.

Always check for minor damage to the

paint and repair it as soon as possible.

.

Keep drain holes at the bottom of the

doors open to avoid water accumulation.

.

Check the underbody for accumulation of

sand, dirt or salt. If present, wash with
water as soon as possible.

CAUTION

.

NEVER remove dirt, sand or other
debris from the passenger compart-
ment by washing it out with a hose.
Remove dirt with a vacuum cleaner.

.

Never allow water or other liquids to
come in contact with electronic com-
ponents inside the vehicle as this may
damage them.

Chemicals used for road surface deicing are
extremely corrosive. They accelerate corro-
sion and deterioration of underbody compo-
nents such as the exhaust system, fuel and
brake lines, brake cables, floor pan and
fenders.

In winter, the underbody must be cleaned
periodically.

For additional protection against rust and
corrosion, which may be required in some
areas, it is recommended you consult an
INFINITI retailer.

CORROSION PROTECTION

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

8 Do-it-yourself

Maintenance precautions ............................................... 8-2
Engine compartment check locations ......................... 8-3

VR30DDTT engine ..................................................... 8-3

Engine cooling system ..................................................... 8-3

Checking engine coolant level ................................ 8-4
Changing engine coolant .......................................... 8-5

Intercooler cooling system ............................................. 8-5

Checking intercooler coolant level ......................... 8-6
Changing intercooler coolant .................................. 8-6

Engine oil ............................................................................. 8-7

Checking engine oil level ........................................... 8-7
Changing engine oil and filter .................................. 8-7

Automatic Transmission Fluid (ATF) .......................... 8-9
Brake fluid ........................................................................ 8-10
Window washer fluid ................................................... 8-10
Battery ............................................................................... 8-11

Checking battery fluid level .................................... 8-12
Jump starting ............................................................. 8-13

Variable voltage control system ................................. 8-13
Drive belts ......................................................................... 8-13
Spark plugs ....................................................................... 8-14

Replacing spark plugs .............................................. 8-14

Air cleaner ........................................................................ 8-15
Windshield wiper blades .............................................. 8-15

Cleaning ..................................................................... 8-15
Replacing ................................................................... 8-16

Brakes ................................................................................ 8-16

Self-adjusting brakes ............................................. 8-16
Brake pad wear warning ....................................... 8-16

Fuses .................................................................................. 8-17

Engine compartment .............................................. 8-17
Passenger compartment ....................................... 8-18

Intelligent Key battery replacement ......................... 8-19
Lights ................................................................................. 8-22

Headlights ................................................................. 8-22
Exterior and interior lights .................................... 8-23

Wheels and tires ............................................................. 8-26

Tire pressure ............................................................. 8-26
Tire labeling ............................................................. 8-30
Types of tires ........................................................... 8-32
Tire chains ................................................................ 8-34
Changing wheels and tires ................................... 8-35
Jacking up the vehicle and replacing tires ...... 8-38

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

8-2

Do-it-yourself

When performing any inspection or main-
tenance work on your vehicle, always take
care to prevent serious accidental injury to
yourself or damage to the vehicle. The
following are general precautions which
should be closely observed.

WARNING

.

Park the vehicle on a level surface,
apply the parking brake securely and
block the wheels to prevent the
vehicle from moving. Move the shift
lever to P (Park).

.

Be sure the ignition switch is in the
OFF or LOCK position when per-
forming any parts replacement or
repairs.

.

Never connect or disconnect the
battery or any transistorized compo-
nent while the ignition switch is in the
ON position.

.

Never leave the engine or automatic
transmission related component har-
nesses disconnected while the igni-
tion switch is in the ON position.

.

If you must work with the engine
running, keep your hands, clothing,
hair and tools away from moving
fans, belts and any other moving

parts.

.

It is advisable to secure or remove
any loose clothing and remove any
jewelry, such as rings, watches, etc.
before working on your vehicle.

.

Always wear eye protection when-
ever you work on your vehicle.

.

If you must run the engine in an
enclosed space such as a garage, be
sure there is proper ventilation for
exhaust gases to escape.

.

Never get under the vehicle while it is
supported only by a jack. If it is
necessary to work under the vehicle,
support it with safety stands.

.

Keep smoking materials, flame and
sparks away from fuel tank and the
battery.

.

Your vehicle is equipped with an
automatic engine cooling fan. It may
come on at any time without warn-
ing, even if the ignition key is in the
OFF position and the engine is not
running. To avoid injury, always dis-
connect the negative battery cable
before working near the fan.

.

Because the fuel lines are under high
pressure even when the engine is off,
it is recommended you visit an
INFINITI retailer for service of the

fuel filter or fuel lines.

CAUTION

.

Do not work under the hood while the
engine is hot. Turn the engine off and
wait until it cools down.

.

Avoid direct contact with used en-
gine oil and coolant. Improperly dis-
posed engine oil, coolant, and/or
other vehicle fluids can damage the
environment. Always conform to lo-
cal regulations for disposal of vehicle
fluid.

This “8. Do-it-yourself” section gives in-
structions regarding only those items which
are relatively easy for an owner to perform.
A genuine INFINITI Service Manual is also
available. (See “Owner’s Manual/Service
Manual order information” (P.10-24).)
You should be aware that incomplete or
improper servicing may result in operating
difficulties or excessive emissions, and could
affect your warranty coverage.

If in doubt

about any servicing, it is recommended you
have it done by an INFINITI retailer.

MAINTENANCE PRECAUTIONS

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVC0968X

VR30DDTT ENGINE

1.

Battery

2.

Engine oil dipstick

3.

Engine oil filler cap

4.

Brake fluid reservoir

5.

Fuse/fusible link holder

6.

Air cleaner

7.

Engine drive belt location

8.

Radiator filler cap

9

Intercooler cooling reservoir

10. Engine coolant reservoir
11. Window washer fluid reservoir

The engine cooling system is filled at the
factory with a pre-diluted mixture of 50%
Genuine NISSAN Long Life Antifreeze/
Coolant (blue) and 50% water to provide
year-round anti-freeze and coolant protec-
tion. The anti-freeze solution contains rust
and corrosion inhibitors. Additional engine
cooling system additives are not necessary.

WARNING

.

Never remove the radiator cap when
the engine is hot. Wait until the
engine and radiator cool down. Ser-
ious burns could be caused by high
pressure fluid escaping from the
radiator. See precautions in “If your
vehicle overheats” (P.6-7) of this
manual.

.

The radiator is equipped with a
pressure type radiator cap. To pre-
vent engine damage, use only a
genuine NISSAN radiator cap.

CAUTION

.

Never use any cooling system addi-
tives such as radiator sealer. Addi-
tives may clog the cooling system and
cause damage to the engine, trans-

Do-it-yourself

8-3

ENGINE COMPARTMENT CHECK
LOCATIONS

ENGINE COOLING SYSTEM

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

8-4

Do-it-yourself

mission and/or cooling system.

.

When adding or replacing coolant, be
sure to use only Genuine NISSAN
Long Life Antifreeze/Coolant (blue)
or equivalent. Genuine NISSAN Long
Life Antifreeze/Coolant (blue) is pre-
diluted to provide antifreeze protec-
tion to −34°F (−37°C). If additional
freeze protection is needed due to
weather where you operate your
vehicle, add Genuine NISSAN Long
Life Antifreeze/Coolant (blue) con-
centrate following the directions on
the container. If an equivalent cool-
ant other than Genuine NISSAN Long
Life Antifreeze/Coolant (blue) is
used, follow the coolant manufac-
ture’s instructions to maintain mini-
mum antifreeze protection to −34°F
(−37°C). The use of other types of
coolant solutions other than Genuine
NISSAN Long Life Antifreeze/Cool-
ant (blue) or equivalent may damage
the engine cooling system.

.

The life expectancy of the factory-fill
coolant is 105,000 miles (168,000
km) or 7 years. Mixing any other type
of coolant other than Genuine
NISSAN Long Life Antifreeze/Cool-
ant (blue) (or equivalent coolant),
including Genuine NISSAN Long Life
Antifreeze/ Coolant (green), or the

use of non-distilled water will reduce
the life expectancy of the factory-fill
coolant. Refer to the “9. Mainte-
nance and schedules” section of this
manual for more details.

JVM0652X

CHECKING ENGINE COOLANT
LEVEL

Check the coolant level in the reservoir tank
when the engine is running and after it
reaches normal operating temperature. If
the coolant level is below MIN level

, add

coolant up to the MAX level

. If the

reservoir tank is empty, check the coolant
level in the radiator

when the engine is cold

.

If there is insufficient coolant in the radiator,
fill the radiator with coolant up to the filler
cap above the radiator upper hose opening
and also add it to the reservoir tank up to the
MAX level

. Put on the filler cap above the

radiator upper hose and with the reservoir
cap open, start the engine. Run the engine

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

until it reaches normal operating tempera-
ture. Add coolant up to the MAX level

.

Tighten the cap securely after adding engine
coolant.

If the cooling system requires coolant fre-
quently, have it checked. It is recommended
you visit an INFINITI retailer for this
service.

CHANGING ENGINE COOLANT

It is recommended that major cooling system
repairs be performed by an INFINITI retailer.
The service procedures can be found in the
appropriate INFINITI Service Manual.

Improper servicing can result in reduced
heater performance and engine overheat-
ing.

WARNING

.

To avoid the danger of being scalded,
never change the coolant when the
engine is hot.

.

Never remove the radiator cap when
the engine is hot. Serious burns could
be caused by high pressure fluid
escaping from the radiator.

.

Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner

as soon as possible.

.

Keep coolant out of reach of children
and pets.

Engine coolant must be disposed of prop-
erly. Check your local regulations.

The intercooler cooling system is filled at the
factory with a pre-diluted mixture of 50%
Genuine NISSAN Long Life Antifreeze/
Coolant (blue) and 50% water to provide
year-round anti-freeze and coolant protec-
tion. The antifreeze solution contains rust
and corrosion inhibitors. Additional inter-
cooler cooling system additives are not
necessary.

WARNING

.

Never remove the coolant reservoir
cap when the engine is hot. Wait until
the engine cools down. Serious burns
could be caused by high pressure fluid
escaping from the coolant reservoir.

.

The intercooler reservoir is equipped
with a pressure type cap. To prevent
engine and intercooler damage, use
only a genuine NISSAN intercooler
reservoir cap.

CAUTION

.

Never use any additives in the cool-
ant such as radiator sealer in the
cooling system. This may cause da-
mage to the intercooler.

Do-it-yourself

8-5

INTERCOOLER COOLING SYSTEM

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

8-6

Do-it-yourself

.

When adding or replacing coolant, be
sure to use only Genuine NISSAN
Long Life Antifreeze/Coolant (blue)
or equivalent. Genuine NISSAN Long
Life Antifreeze/Coolant (blue) is pre-
diluted to provide antifreeze protec-
tion to −34°F(−37°C). If additional
freeze protection is needed due to
weather where you operate your
vehicle, add Genuine NISSAN Long
Life Antifreeze/Coolant (blue) con-
centrate following the directions on
the container. If an equivalent cool-
ant other than Genuine NISSAN Long
Life Antifreeze/Coolant (blue) is
used, follow the coolant manufac-
ture’s instructions to maintain mini-
mum antifreeze protection to −34°F
(−37°C). The use of other types of
coolant solutions other than Genuine
NISSAN Long Life Antifreeze/Cool-
ant (blue) or equivalent may damage
the Intercooler cooling system.

JVM0653X

CHECKING INTERCOOLER
COOLANT LEVEL

Check the coolant level in the reservoir when
the engine is cold. If the coolant level is
below the MIN level

, add coolant to the

MAX level

.

If the intercooler cooling system frequently
requires coolant, have it checked. It is
recommended you visit an INFINITI retailer
for this service.

CHANGING INTERCOOLER
COOLANT

Intercooler coolant is maintenance-free.
If replacement is required, it is recommended
you visit an INFINITI retailer for this service.

Improper servicing can result in intercooler
overheating.

WARNING

.

To avoid the danger of being scalded,
never change the coolant when the
engine is hot.

.

Never remove the cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escap-
ing from the intercooler cooling re-
servoir.

.

Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner
as soon as possible.

.

Keep coolant out of the reach of
children and pets.

Intercooler coolant must be disposed of
properly. Check your local regulations.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVM0654X

CHECKING ENGINE OIL LEVEL

1. Park the vehicle on a level surface and

apply the parking brake.

2. Run the engine until it reaches operating

temperature.

3. Turn off the engine.

Wait more than 15

minutes for the oil to drain back into the
oil pan.

4. Remove the dipstick and wipe it clean.

Reinsert it all the way.

5. Remove the dipstick again and check the

oil level. It should be within the range

.

If the oil level is below

, remove the oil

filler cap and pour recommended oil
through the opening.

Do not overfill

.

6. Recheck oil level with the dipstick.

It is normal to add some oil between oil
maintenance intervals or during the break-
in period, depending on the severity of
operating conditions.

CAUTION

Oil level should be checked regularly.
Operating the engine with an insuffi-
cient amount of oil can damage the
engine, and such damage is not covered
by warranty.

CHANGING ENGINE OIL AND
FILTER

Vehicle set-up

1. Park the vehicle on a level surface and

apply the parking brake.

2. Run the engine until it reaches operating

temperature.

3. Turn the engine off and wait more than

15 minutes.

4. Raise and support the vehicle using a

suitable floor jack and safety jack stands.

.

Place the safety jack stands under the

vehicle jack-up points.

.

A suitable adapter should be attached

to the jack stand saddle.

5. Remove the plastic engine undercover.

.

Remove the small plastic clip at the

center point of the undercover.

.

Then remove the other bolts that hold

the undercover in place.

CAUTION

Make sure the correct lifting and sup-
port points are used to avoid vehicle
damage.

Do-it-yourself

8-7

ENGINE OIL

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

8-8

Do-it-yourself

JVM0668X

2WD models

JVM0669X

AWD models

Engine oil and filter

1. Place a large drain pan under the drain

plug.

2. Remove the oil filler cap.
3. Remove the drain plug

with a wrench

and completely drain the oil.

CAUTION

Be careful not to burn yourself, as the
engine oil is hot.

.

Waste oil must be disposed of prop-

erly.

.

Check your local regulations.

4. (Perform steps 4 to 7 only when the

engine oil filter change is needed.)
Loosen the oil filter

with an oil filter

wrench. Remove the oil filter by turning it
by hand.

5. Wipe the engine oil filter mounting sur-

face with a clean rag.

CAUTION

Be sure to remove any old rubber gasket
remaining on the mounting surface of
the engine. Failure to do so could lead to

engine damage.

6. Coat the gasket on the new filter with

clean engine oil.

7. Screw in the oil filter clockwise until a

slight resistance is felt, then tighten
additionally more than 2/3 turn.

Oil filter tightening torque:

11 to 15 ft-lb
(14.7 to 20.6 N·m)

8. Clean and re-install the drain plug with a

new washer. Securely tighten the drain
plug with a wrench.

Drain plug tightening torque:

22 to 29 ft-lb
(29.4 to 39.2 N·m)

Do not use excessive force.

9. Refill engine with recommended oil and

install the oil filler cap securely.
See “Capacities and recommended
fluids/lubricants” (P.10-2) for drain and
refill capacity. The drain and refill capa-
city depends on the oil temperature and
drain time. Use these specifications for
reference only. Always use the dipstick
to determine the proper amount of oil in
the engine.

10. Start the engine and check for leakage

around the drain plug and the oil filter.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     10      11      12      13     ..
