Infiniti Q50 (2023 year). Manual in english - page 8





5-10

Starting and driving

damage. See “Wheels and tires” (P.8-26) of
this manual.
If a tire rapidly loses air pressure or “blows-
out” while driving maintain control of the
vehicle by following the procedure below.
Please note that this procedure is only a
general guide. The vehicle must be driven as
appropriate based on the conditions of the
vehicle, road and traffic.

WARNING

The following actions can increase the
chance of losing control of the vehicle if
there is a sudden loss of tire air pressure.
Losing control of the vehicle may cause a
collision and result in personal injury.

.

The vehicle generally moves or pulls
in the direction of the flat tire.

.

Do not rapidly apply the brakes.

.

Do not rapidly release the accelerator
pedal.

.

Do not rapidly turn the steering
wheel.

1. Remain calm and do not overreact.
2. Maintain a firm grip on the steering

wheel with both hands and try to hold
a straight course.

3. When appropriate, slowly release the

accelerator pedal to gradually slow the
vehicle.

4. Gradually steer the vehicle to a safe

location off the road and away from
traffic if possible.

5. Lightly apply the brake pedal to gradu-

ally stop the vehicle.

6. Turn on the hazard warning flashers and

either contact a roadside emergency
service to change the tire or see “Jacking
up the vehicle and replacing tires” (P.8-
38) of this Owner’s Manual.

DRINKING ALCOHOL/DRUGS
AND DRIVING

WARNING

Never drive under the influence of alco-
hol or drugs. Alcohol in the bloodstream
reduces coordination, delays reaction
time and impairs judgement. Driving
after drinking alcohol increases the like-
lihood of being involved in an accident
injuring yourself and others. Addition-
ally, if you are injured in an accident,
alcohol can increase the severity of the
injury.

INFINITI is committed to safe driving. How-
ever, you must choose not to drive under the
influence of alcohol. Every year thousands of
people are injured or killed in alcohol-related
accidents. Although the local laws vary on
what is considered to be legally intoxicated,
the fact is that alcohol affects all people
differently and most people underestimate
the effects of alcohol.
Remember, drinking and driving don’t mix!
And that is true for drugs, too (over-the-
counter, prescription, and illegal drugs).
Don’t drive if your ability to operate your
vehicle is impaired by alcohol, drugs, or some
other physical condition.

INTELLIGENT ALL-WHEEL
DRIVE (AWD) DRIVING SAFETY
PRECAUTIONS (AWD models)

WARNING

.

Do not drive beyond the performance
capability of the tires, even with
Intelligent AWD engaged. Accelerat-
ing quickly, sharp steering maneuvers
or sudden braking may cause loss of
control.

.

Always use tires of the same type,
size, brand, construction (bias, bias-

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

belted or radial), and tread pattern
on all four wheels. Install tire chains
on the rear wheels when driving on
slippery roads and drive carefully.

.

This vehicle is not designed for off-
road (rough road) use. Do not drive
on sandy or muddy roads that tires
may get stuck in.

.

For AWD equipped vehicles, do not
attempt to raise two wheels off the
ground and shift the transmission to
any D (Drive) or R (Reverse) position
with the engine running. Doing so
may result in drivetrain damage or
unexpected vehicle movement which
could result in serious vehicle damage
or personal injury.

.

Do not attempt to test an AWD
equipped vehicle on a 2-wheel dy-
namometer (such as the dynam-
ometers used by some states for
emissions testing), or similar equip-
ment even if the other two wheels are
raised off the ground. Make sure you
inform test facility personnel that
your vehicle is equipped with AWD
before it is placed on a dynamometer.
Using the wrong test equipment may
result in drivetrain damage or unex-
pected vehicle movement which could
result in serious vehicle damage or

personal injury.

.

When a wheel is off the ground due
to an unlevel surface, do not spin the
wheel excessively.

WARNING

Do not operate the push-button ignition
switch while driving the vehicle except in
an emergency. (The engine will stop
when the ignition switch is pushed 3
consecutive times or the ignition switch
is pushed and held for more than 2
seconds.) If the engine stops while the
vehicle is being driven, this could lead to
a crash and serious injury.

Before operating the push-button ignition
switch, be sure to move the shift lever to the
P (Park) position.

Starting and driving

5-11

PUSH-BUTTON IGNITION SWITCH

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-12

Starting and driving

SSD0659

OPERATING RANGE FOR EN-
GINE START FUNCTION

The Intelligent Key can only be used for
starting the engine when the Intelligent Key
is within the specified operating range.
When the Intelligent Key battery is almost
discharged or strong radio waves are pre-
sent near the operating location, the Intelli-
gent Key system’s operating range becomes
narrower and may not function properly.
If the Intelligent Key is within the operating
range, it is possible for anyone, even some-
one who does not carry the Intelligent Key,
to push the ignition switch to start the
engine.

.

The trunk area is not included in the

operating range but the Intelligent Key
may function.

.

If the Intelligent Key is placed on the

instrument panel, rear parcel shelf, inside
the glove box or door pocket, the
Intelligent Key may not function.

.

If the Intelligent Key is placed near the

door or window outside the vehicle, the
Intelligent Key may function.

JVS0241X

PUSH-BUTTON IGNITION
SWITCH OPERATION

When the ignition switch is pushed without
depressing the brake pedal, the ignition
switch position will change as follows:

.

Push center once to change to ACC.

.

Push center two times to change to ON.

.

Push center three times to change to

OFF. (No position illuminates.)

.

Push center four times to return to ACC.

.

Open or close any door to return to

LOCK during the OFF position.

If the battery of the vehicle is discharged,
the push-button ignition switch cannot be
turned from the LOCK position.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Some indicators and warnings for operation
are displayed in the vehicle information
display between the speedometer and tach-
ometer. (See “Vehicle information display”
(P.2-19).)
The ignition lock is designed so that the
ignition switch position cannot be switched
to LOCK until the shift lever is moved to the
P (Park) position.
When the ignition switch cannot be pushed
toward the LOCK position, proceed as
follows:
1. Move the shift lever into the P (Park)

position.

2. Push the ignition switch to the OFF

position. The ignition switch position
indicator will not illuminate.

3. Open the door. The ignition switch will

change to the LOCK position.

The shift lever can be moved from the P
(Park) position if the ignition switch is in the
ON position and the brake pedal is de-
pressed.

PUSH-BUTTON IGNITION
SWITCH POSITIONS

LOCK (Normal parking position)

The ignition switch can only be locked in this
position.
The ignition switch will be unlocked when it
is pushed to the ACC position while carrying
the Intelligent Key.

ACC (Accessories)

This position activates electrical accessories
such as the radio, when the engine is not
running.

ON (Normal operating position)

This position turns on the ignition system
and electrical accessories.

OFF

The engine can be turned off in this position.
The ignition lock is designed so that the
ignition switch cannot be switched to the
LOCK position until the shift lever is moved
to the P (Park) position.

CAUTION

Do not leave the vehicle with the push-
button ignition switch in ACC or ON
positions when the engine is not running
for an extended period. This can dis-
charge the battery.

EMERGENCY ENGINE SHUT OFF

To shut off the engine in an emergency
situation while driving, perform the follow-
ing procedure:

.

Rapidly push the push-button ignition

switch 3 consecutive times in less than
1.5 seconds, or

.

Push and hold the push-button ignition

switch for more than 2 seconds.

Starting and driving

5-13

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-14

Starting and driving

WAF0237X

INTELLIGENT KEY BATTERY DIS-
CHARGE

If the battery of the Intelligent Key is
discharged, or environmental conditions in-
terfere with the Intelligent Key operation,
start the engine according to the following
procedure:
1. Move the shift lever to the P (Park)

position.

2. Firmly apply the foot brake.
3. Touch the ignition switch with the

Intelligent Key as illustrated. (A chime
will sound.)

4. Push the ignition switch while depressing

the brake pedal within 10 seconds after
the chime sounds. The engine will start.

After step 3 is performed, when the ignition
switch is pushed without depressing the
brake pedal, the ignition switch position will
change to ACC.

NOTE:

.

When the ignition switch is pushed to

the ACC or ON position or the engine is
started by the above procedures, the
Intelligent Key battery discharge indi-
cator appears in the vehicle information
display even if the Intelligent Key is
inside the vehicle. This is not a malfunc-
tion. To turn off the Intelligent Key
battery discharge indicator, touch the
ignition switch with the Intelligent Key
again.

.

If the Intelligent Key battery discharge

indicator appears, replace the battery as
soon as possible. (See “Intelligent Key
battery replacement” (P.8-19).)

.

Make sure the area around the vehicle is

clear.

.

Check fluid levels such as engine oil,

coolant, brake fluid and window washer
fluid as frequently as possible, or at least
whenever you refuel.

.

Check that all windows and lights are

clean.

.

Visually inspect tires for their appearance

and condition. Also check tires for proper
inflation.

.

Lock all doors.

.

Position seat and adjust head restraints.

.

Adjust inside and outside mirrors.

.

Fasten seat belts and ask all passengers

to do likewise.

.

Check the operation of warning lights

when the ignition switch is pushed to the
ON position. (See “Warning lights, in-
dicator lights and audible reminders”
(P.2-10).)

BEFORE STARTING THE ENGINE

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

1. Apply the parking brake.
2. Move the shift lever to the P (Park) or N

(Neutral) position. (P is recommended.)
The starter is designed not to operate
unless the shift lever is in either of the
above positions.

3. Push the ignition switch to the ON

position. Firmly depress the brake pedal
and push the ignition switch to start the
engine.
To start the engine immediately, push
and release the ignition switch while
depressing the brake pedal with the
ignition switch in any position.

.

If the engine is very hard to start in

extremely cold weather or when re-
starting, depress the accelerator ped-
al a little (approximately 1/3 to the
floor) and while holding, crank the
engine. Release the accelerator pedal
when the engine starts.

.

If the engine is very hard to start

because it is flooded, depress the
accelerator pedal all the way to the
floor and hold it. Push the ignition
switch to the ON position to start
cranking the engine. After 5 or 6
seconds, stop cranking by pushing
the ignition switch to OFF. After
cranking the engine, release the accel-
erator pedal. Crank the engine

with

your foot off the accelerator pedal

by

depressing the brake pedal and push-
ing the push-button ignition switch to
start the engine. If the engine starts,
but fails to run, repeat the above
procedure.

CAUTION

Do not operate the starter for more than
15 seconds at a time. If the engine does
not start, push the ignition switch to
OFF and wait 10 seconds before crank-
ing again, otherwise the starter could be
damaged.

4.

Warm-up

Allow the engine to idle for at least 30
seconds after starting. Do not race the
engine while warming it up. Drive at
moderate speed for a short distance
first, especially in cold weather. In cold
weather, keep the engine running for a
minimum of 2 - 3 minutes before shut-
ting it off. Starting and stopping the
engine over a short period of time may
make the vehicle more difficult to start.
When racing the engine up to 4,500 rpm
or more under no load condition, the
engine will enter the fuel cut mode.

5. To stop the engine, shift the shift lever to

the P (Park) position and push the
ignition switch to the OFF position.

NOTE:

Care should be taken to avoid situations
that can lead to potential battery discharge
and potential no-start conditions such as:

1.

Installation or extended use of electro-
nic accessories that consume battery
power when the engine is not running
(Phone chargers, GPS, DVD players,
etc.)

2.

Vehicle is not driven regularly and/or
only driven short distances.

In these cases, the battery may need to be
charged to maintain battery health.

REMOTE ENGINE START (if so
equipped)

Vehicles started with the remote engine
start function require the ignition switch to
be placed in the ON position before the shift
lever can be moved from the P (Park)
position. To place the ignition switch in the
ON position, perform the following steps:
1. Make sure that the Intelligent Key is on

you.

2. Depress the brake pedal.
3. Push the ignition switch once to the ON

position.

Starting and driving

5-15

STARTING THE ENGINE

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-16

Starting and driving

For additional information about the remote
engine start function, see “Remote engine
start” (P.3-19).

AUTOMATIC TRANSMISSION

The automatic transmission in your vehicle is
electronically controlled by a transmission
control module to produce maximum effi-
ciency and smooth operation.
Shown on the following pages are the
recommended operating procedures for this
transmission. Follow these procedures for
maximum vehicle performance and driving
enjoyment.

Starting the vehicle

After starting the engine, fully depress the
foot brake pedal and push the shift lever
button before shifting the shift lever to the R
(Reverse), N (Neutral), D (Drive) or Manual
shift mode position. Be sure the vehicle is
fully stopped before attempting to shift the
shift lever.

This Automatic Transmission (AT) model is
designed so that the foot brake pedal must
be depressed before shifting from P (Park)
to any drive position while the ignition
switch is in the ON position.

The shift lever cannot be moved out of the P
(Park) position and into any of the other
gear positions if the ignition switch is placed
in the LOCK, OFF or ACC position.

1. Keep the foot brake pedal depressed and

push the shift lever button to shift into a
driving gear.

2. Release the parking brake and foot

brake, then gradually start the vehicle in
motion.

WARNING

.

Do not depress the accelerator pedal
while shifting from P (Park) or N
(Neutral) to R (Reverse), D (Drive) or
manual shift mode. Always depress
the brake pedal until shifting is
completed. Failure to do so could
cause you to lose control and have
an accident.

.

Cold engine idle speed is high, so use
caution when shifting into a forward
or reverse gear before the engine has
warmed up.

.

Never shift to either P (Park) or R
(Reverse) position while the vehicle is
moving forward and P (Park) or D
(Drive) position while the vehicle is
moving reversing. This could cause an
accident or damage the transmission.

.

Do not downshift abruptly on slip-
pery roads. This may cause a loss of
control.

DRIVING THE VEHICLE

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

.

To avoid possible damage to your
vehicle; when stopping the vehicle on
an uphill grade, do not hold the
vehicle by depressing the accelerator
pedal. The foot brake should be used
for this purpose.

.

Except in an emergency, do not shift
to the N (Neutral) position while
driving. Coasting with the transmis-
sion in the N (Neutral) position may
cause serious damage to the trans-
mission.

JVS0186X

Shift lever

To move the shift lever,

:

Push the button while depressing the
brake pedal,

:

Push the button,

:

Just move the shift lever.

Shifting

After starting the engine, fully depress the
brake pedal and shift the shift lever from P
(Park) to R (Reverse), N (Neutral), D (Drive)
or Manual shift mode position.
Push the button to shift into P (Park) or R
(Reverse). All other positions can be selected
without pushing the button.

WARNING

Apply the parking brake if the shift lever
is in any position while the engine is not
running. Failure to do so could cause the
vehicle to move unexpectedly or roll
away and result in serious personal
injury or property damage.

CAUTION

Make sure the vehicle is completely
stopped and the transmission is in the
P (Park) position.

P (Park) position:

Use this position when the vehicle is parked
or when starting the engine. Make sure the
vehicle is completely stopped.

The brake

pedal must be depressed and the shift lever
button pushed in to move the shift lever
from the N (Neutral) position or any drive
position to the P (Park) position.

Apply the

parking brake. When parking on a hill, apply
the parking brake first, then move the shift
lever to the P (Park) position.

Starting and driving

5-17

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-18

Starting and driving

CAUTION

Use this position only when the vehicle is
completely stopped.

R (Reverse):

Use this position to back up. Always be sure
the vehicle is completely stopped before
selecting the R (Reverse) position.

The brake

pedal must be depressed and the shift lever
button pushed in to move the shift lever
from the P (Park) position, the N (Neutral)
position or any drive position to the R
(Reverse) position.

N (Neutral):

Neither forward nor reverse gear is engaged.
The engine can be started in this position.
You may shift to the N (Neutral) position and
restart a stalled engine while the vehicle is
moving.

D (Drive):

Use this position for all normal forward
driving.

JVS0903X

Paddle shifters (if so equipped)

Manual shift mode

When the shift lever is in the manual shift
gate, the transmission is ready for the
manual shift mode. Shift ranges can be
selected manually by moving the shift lever
up or down, or pulling the right-side or left-
side paddle shifter (if so equipped).
When shifting up, move the shift lever to the
+ (up) side or pull the right-side paddle
shifter (+)

(if so equipped). The transmis-

sion shifts to the higher range.
When shifting down, move the shift lever to
the − (down) side or pull the left-side paddle
shifter (−)

(if so equipped). The transmis-

sion shifts to the lower range.
When canceling the manual shift mode,
return the shift lever to the D (Drive)
position. The transmission returns to the
normal driving mode.
When you pull the paddle shifter (if so
equipped) while in the D (Drive) position,
the transmission will shift to the upper or
lower range temporarily. The transmission
will automatically return to the D (Drive)
position after a short period of time. If you
want to return to the D (Drive) position
manually, pull and hold the paddle shifter for
about 1.5 seconds.
In the manual shift mode, the shift range is
displayed in the vehicle information display.
Shift ranges up or down one by one as
follows:

1

M

?

/

2

M

?

/

3

M

?

/

4

M

?

/

5

M

?

/

6

M

?

/

7

M

7

M

(7th):

Use this position for all normal forward
driving at highway speeds.

6

M

(6th) and 5

M

(5th):

Use these positions when driving up long
slopes, or for engine braking when driving
down long slopes.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

4

M

(4th), 3

M

(3rd) and 2

M

(2nd):

Use these positions for hill climbing or engine
braking on downhill grades.

1

M

(1st):

Use this position when climbing steep hills
slowly or driving slowly through deep snow,
or for maximum engine braking on steep
downhill grades.

.

Remember not to drive at high speeds for

extended periods of time in lower than
7th gear. This reduces fuel economy.

.

Moving the shift lever rapidly to the same

side twice will shift the ranges in succes-
sion.

.

In the manual shift mode, the transmis-

sion may not shift to the selected gear
or may automatically shift to the other
gear. This helps maintain driving per-
formance and reduces the chance of
vehicle damage or loss of control.

.

When the transmission does not shift to

the selected gear, the Automatic Trans-
mission (AT) position indicator (in the
vehicle information display) will blink
and the buzzer will sound.

.

In the manual shift mode, the transmis-

sion automatically shifts down to 1st
gear before the vehicle comes to a stop.
When accelerating again, it is necessary
to shift up to the desired range.

Accelerator downshift — In D (Drive)
position —

For passing or hill climbing, fully depress the
accelerator pedal to the floor. This shifts the
transmission down into the lower gear,
depending on the vehicle speed.

Fail-safe

When the fail-safe operation occurs, note
that the transmission will be locked in any of
the forward gears according to the condi-
tion.

If the vehicle is driven under extreme
conditions, such as excessive wheel spinning
and subsequent hard braking, the fail-safe
system may be activated. This will occur
even if all electrical circuits are functioning
properly. In this case, push the ignition
switch to the OFF position and wait for 3
seconds. Then push the ignition switch back
to the ON position. The vehicle should
return to its normal operating condition. If
it does not return to its normal operating
condition, have the transmission checked
and repaired, if necessary. It is recom-
mended you visit an INFINITI retailer for
this service.

JVS0188X

Shift lock release

If the battery charge is low or discharged,
the shift lever may not be moved from the P
(Park) position even with the brake pedal
depressed and the shift lever button pushed.
To move the shift lever, perform the follow-
ing procedure:
1. Push the ignition switch to the OFF or

LOCK position.

2. Apply the parking brake.
3. Remove the shift lock cover

using a

suitable tool.

4. Push down the shift lock

using

mechanical key as illustrated.

Starting and driving

5-19

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-20

Starting and driving

5. Push the shift lever button

and move

the shift lever to N (Neutral) position
while holding down the shift lock.

If the lever cannot be moved out of P (Park),
have the automatic transmission system
checked as soon as possible. It is recom-
mended you visit an INFINITI retailer for this
service.

Adaptive Shift Control (ASC)

The adaptive shift control system automati-
cally operates when the transmission is in
the D (Drive) position and selects an appro-
priate gear depending on the road conditions
such as uphill, downhill or curving roads.

Control on uphill and curving roads:

A low gear is maintained that suits the
degree of the slope or curve to allow smooth
driving with a small number of shifts.

Control on downhill roads:

The adaptive shift control system shifts to a
low gear that suits the degree of the slope,
and uses the engine braking to reduce the
number of times that the brake must be
used.

Control on winding roads:

A low gear is maintained on continuous
curves that involve repeated acceleration
and deceleration, so that smooth accelera-
tion is available instantly when the accel-

erator pedal is depressed.

NOTE:

.

Adaptive shift control may not operate

when the transmission oil temperature
is low immediately after the start of
driving or when it is very hot.

.

During some driving situations, hard

braking for example, the adaptive shift
control may automatically operate. The
transmission may automatically shift to
a lower gear for engine braking. This
increases engine speed but not vehicle
speed. Vehicle speed is controlled by the
accelerator pedal when the vehicle is in
the Adaptive shift control mode.

.

When the adaptive shift control oper-

ates, the transmission sometimes main-
tains a lower gear for a longer period of
time than when adaptive shift control is
not operating. Engine speed will be
higher for a specific vehicle speed while
ASC system is operating than when ASC
is not operating.

WARNING

.

Be sure the parking brake is fully
released before driving. Failure to do
so can cause brake failure and lead to
an accident.

.

Do not release the parking brake
from outside the vehicle.

.

Do not use the gear shift in place of
the parking brake. When parking, be
sure the parking brake is fully en-
gaged.

.

To help avoid risk of injury or death
through unintended operation of the
vehicle and/or its systems, do not
leave children, people who require the
assistance of others or pets unat-
tended in your vehicle. Additionally,
the temperature inside a closed ve-
hicle on a warm day can quickly
become high enough to cause a sig-
nificant risk of injury or death to
people and pets.

PARKING BRAKE

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SPA2331

To apply:

Fully depress the parking brake

pedal

.

To release:

1. Firmly apply the foot brake

.

2. Depress the parking brake pedal

and

the parking brake will be released.

3. Before driving, be sure the brake warning

light goes out.

JVS0189X

INFINITI Drive Mode Selector

JVS0191M

Multiple driving modes can be selected by
using the INFINITI Drive Mode Selector
(PERSONAL, SPORT+ (if so equipped),
SPORT, STANDARD, ECO and SNOW).

NOTE:

When the INFINITI Drive Mode Selector
selects a mode, the mode may not switch
immediately. This is not a malfunction.

The current mode is displayed in the vehicle
information display.
To change the mode, push the INFINITI
Drive Mode Selector up or down. The mode
list will appear on the upper display and you
can select the mode.
PERSONAL

œ

SPORT+ (if so equipped)

œ

SPORT

œ

STANDARD

œ

ECO

œ

SNOW

NOTE:

The mode list will be turned off in approxi-
mately 5 seconds after the mode is selected.

If the driving mode cannot be switched using
the INFINITI Drive Mode Selector when the
ignition switch is in the ON position, have
the system checked. It is recommended you
visit an INFINITI retailer for this service.

Starting and driving

5-21

INFINITI DRIVE MODE SELECTOR

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-22

Starting and driving

STANDARD MODE

Allows for optimum driving according to the
driving conditions.
This mode will be selected first each time the
engine is started.

SPORT+ MODE (if so equipped)

In addition to the characteristics of the
SPORT mode, this mode heightens steering
response and changes the setting of VDC
(Vehicle Dynamic Control) for a more sporty
driving experience.

NOTE:

.

VDC operation is reduced when the

INFINITI Drive Mode Selector is used
to select the SPORT+ mode. The VDC
system may not operate in the same
circumstances when compared to op-
eration in the standard mode. To help
prevent accidents drive carefully, avoid
careless or dangerous driving techniques
and be especially careful when driving
and cornering on slippery surfaces.

.

In the SPORT+ mode, fuel economy may

be reduced.

SPORT MODE

.

Adjusts the engine and transmission

points for a higher response.

.

The setting of the steering system is

adjusted to provide a quick steering
response and a heavy steering effort.

.

The setting of the suspension system is

adjusted to increase the damping force
(if so equipped).

NOTE:

In the SPORT mode, fuel economy may be
reduced.

SNOW MODE

Changes the engine characteristics to aid
driving on slippery roads.

ECO MODE

Assists the driver’s eco-driving. The engine
and transmission points are adjusted for
improved fuel economy, providing such a
driving features as smooth starting or con-
stant cruising.

NOTE:

Selecting the ECO mode will not necessarily
improve fuel economy as many driving
factors influence its effectiveness.

Operation

Select the ECO mode using the INFINITI
Drive Mode Selector. The ECO drive indica-
tor light on the instrument panel illuminates.
When the accelerator pedal is depressed
within the range of economy drive, the ECO
drive indicator light illuminates in green.
When the accelerator pedal is depressed
above the range of economy drive, the ECO
drive indicator light turns off. For ECO pedal
system equipped models, see “ECO pedal
system” (P.5-22).
The ECO drive indicator light will not
illuminate in the following cases:

.

When the shift lever is in the R (Reverse)

position.

.

When the vehicle speed is below 2 MPH

(3.2 km/h) or over 90 MPH (144 km/h).

.

When the cruise control (if so equipped)

or the Intelligent Cruise Control (ICC)
system (if so equipped) is operated.

ECO pedal system (if so equipped)

The ECO pedal system helps assist the driver
to improve fuel economy by increasing the
reaction force of the accelerator pedal.
When the ECO drive indicator light is
blinking or remains off, the ECO pedal
system increases the reaction force of the
accelerator pedal.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVS0934X

When the ECO drive indicator illuminates in
green, the accelerator reaction force is
normal. When the ECO drive indicator light
is blinking or remains off, the ECO pedal
system increases the reaction force of the
accelerator pedal.
The ECO pedal system may not vary accel-
erator reaction force under the following
conditions:

.

When the shift lever is in the N (Neutral)

or R (Reverse) position.

.

When Intelligent Cruise Control (ICC) is

being operated.

If the ECO pedal system malfunctions, it will
cancel automatically. The ECO pedal system
will not vary the reaction force of the

accelerator pedal.
When the INFINITI Drive Mode Selector is
rotated from the ECO mode to another
m o d e ( S T A N D A R D , S P O R T + ( i f s o
equipped), SPORT, SNOW or PERSONAL)
while the ECO pedal system is operating, the
ECO pedal system continues to operate until
the accelerator pedal is released.
If the accelerator pedal is depressed quickly,
the ECO pedal system will not increase the
reaction force of the acceleration pedal. The
ECO pedal system is not designed to prevent
the vehicle from accelerating.

Adjusting the ECO pedal system reaction
force:

The ECO pedal system reaction force can be
adjusted. The reaction force setting will be
maintained until the setting is changed even
if the engine is turned off.

JVS0246X

Setting ECO pedal reaction force:

1. Push the MENU button

and touch

[Settings] on the lower display.

2. Touch [Drive Mode Enhancement].
3. Touch [ECO Pedal].
4. To set the reaction force of the ECO

pedal system, touch [Standard] or [Soft].

5. To turn off the ECO pedal system, touch

[Off].

When the ECO pedal system is turned off,
the accelerator will operate normally.
The displayed keys on the lower display may
vary depending on models, specifications
and software versions.

Starting and driving

5-23

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-24

Starting and driving

PERSONAL MODE

When the PERSONAL mode is selected, the
following functions can be adjusted indivi-
dually.

.

Engine/Transmission

.

Steering

.

Suspension (if so equipped)

.

Active Trace Control

.

Active Lane Control (if so equipped)

JVS0246X

How to set the PERSONAL mode

Perform the following steps to set the
PERSONAL mode.
1. Push the MENU button

and touch

[INFINITI Drive Mode Selector] on the
lower display.

2. Touch [Engine/Transmission], [Steer-

ing], [Suspension] (if so equipped), [Ac-
tive Trace Control] or [Active Lane
Control] (if so equipped) and select each
item. (See “Engine/Transmission”,
“Steering”, “Suspension”, “Active Trace
Control” and “Active Lane Control”
about the feature of each item.)

3. Touch [Back] or [Home] to finish the

PERSONAL mode setting.

The displayed keys on the lower display may
vary depending on models, specifications
and software versions.

Engine/Transmission:

“Engine/Transmission” can be set to [Sport],
[Eco], [Standard] or [Snow].

Steering (models with Direct Adaptive
Steering):

Multiple combinations of steering mode and
steering response can be set.

Mode

Response

Sport+ (if so equipped)

Dynamic+

Dynamic

Default

Sport

Dynamic+

Dynamic

Default

Standard

Default

Steering (models without Direct Adaptive
Steering):

“Steering” can be set to [Sport] or [Stan-
dard].

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Suspension (if so equipped):

“Suspension” can be set to [Sport] or
[Standard].

Active Trace Control:

“Active Trace Control” can be set to ON
(enabled) or OFF (disabled).
For details about the Active Trace Control,
see “Active trace control” (P.5-132).

Active Lane Control (if so equipped):

“Active Lane Control” can be set to [High] or
[Low].
Before setting this mode, Active Lane Con-
trol needs to be enabled. (See “How to
enable/disable Active Lane Control” (P.5-
29).)
For details about Active Lane Control, see
“Active Lane Control” (P.5-25).

Reset Drive Mode Settings to Default:

Touch [Reset Drive Mode Settings to De-
fault] and touch [OK] to restore all the
PERSONAL mode settings to default.

WARNING

Failure to follow the warnings and
instructions for proper use of Active
Lane Control could result in serious
injury or death.

.

Active Lane Control will not always
steer the vehicle to keep it in the lane.
It is not designed to prevent loss of
control. It is the driver’s responsibility
to stay alert, drive safely, keep the
vehicle in the traveling lane, and be in
control of vehicle at all times.

Active Lane Control enables the driver to
make fewer steering corrections on free-
ways.

Starting and driving

5-25

ACTIVE LANE CONTROL (if so equipped)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-26

Starting and driving

WAF0324X

/OK

switch

Vehicle information display
Dynamic driver assistance switch
Upper display
Lower display

JVS1124X

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVS0251X

ACTIVE LANE CONTROL OP-
ERATION

Active Lane Control slightly corrects front
tire angles and steering wheel torque to help
reduce the difference between the vehicle’s
direction and the lane direction

which is

detected by using the camera unit

located

above the inside mirror.
Active Lane Control operates under the
following conditions:

.

When the vehicle is driven at speeds of

approximately 45 MPH (70 km/h) and
above.

.

When the Lane Departure Prevention

(LDP) system is enabled in the settings

menu on the lower display. To turn on
the LDP system, see “Lane Departure
Warning (LDW)/Lane Departure Pre-
vention (LDP)” (P.5-33).

.

When Active Lane Control is enabled in

the settings menu on the display.

Starting and driving

5-27

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-28

Starting and driving

WAF0324X

/OK

switch

Vehicle information display
Dynamic driver assistance switch
Upper display
Lower display

TURNING ACTIVE LANE CON-
TROL ON/OFF

To turn on Active Lane Control, push the
dynamic driver assistance switch on the
steering wheel after starting the engine.
Push the dynamic driver assistance switch

again to turn off Active Lane Control.
The dynamic driver assistance switch is used
for the LDP, Blind Spot Intervention

®

(BSI)

and Distance Control Assist (DCA) systems.
When the dynamic driver assistance switch
is pushed, the LDP, BSI and DCA systems
will also turn on or off simultaneously. These
systems can be individually set to on or off
on the lower display.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVS0248X

The status of Active Lane Control can be
checked in the chassis control display in the
vehicle information display

.

.

When Active Lane Control is turned on,

the chassis control

is displayed.

.

When Active Lane Control is operating,

the chassis control

is displayed.

For setting of the chassis control display, see
the INFINITI InTouch

TM

Owner’s Manual.

HOW TO ENABLE/DISABLE AC-
TIVE LANE CONTROL

Perform the following steps to enable or
disable Active Lane Control. If Type A
setting is not available, perform Type B
setting.

Type A (if so equipped):

1. Push the

/OK

switch on the steering

wheel.

2. Touch [TURN ALC ON] or [TURN ALC

OFF] on the upper display to enable or
disable Active Lane Control.

Type B (if so equipped):

1. Push the MENU button and touch

[Driver Assistance] on the lower display.

2. Touch [Lane Assist].
3. Touch [Active Lane Control] to enable or

disable Active Lane Control.

The displayed keys on the display may vary
depending on models, specifications and
software version.

NOTE:

If the Lane Departure Prevention (LDP)
system setting is OFF, Active Lane Control
cannot be operated. To use Active Lane
Control, set the LDP system to ON. See
“How to enable/disable the LDP system”
(P.5-37).

Starting and driving

5-29

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-30

Starting and driving

Active Lane Control settings

Perform the following steps to set Active
Lane Control.

Type A (if so equipped):

1. Push the MENU button and touch

[INFINITI Drive Mode Selector] on the
lower display.

2. Touch [Active Lane Control] and select

[Low] or [High] to change the setting of
Active Lane Control.

Type B (if so equipped):

1. Push the MENU button and touch

[Driver Assistance] on the lower display.

2. Touch [Lane Assist].
3. Enable [Active Lane Control].
4. Touch [Active Lane Control Setting] and

select [Low] or [High] to change the
setting of Active Lane Control.

The displayed keys on the lower display may
vary depending on models, specifications
and software versions.

ACTIVE LANE CONTROL LIM-
ITATIONS

WARNING

Listed below are the limitations for
Active Lane Control. Failure to operate
the vehicle in accordance with these
limitations could result in serious injury
or death.

.

Active Lane Control is primarily in-
tended for use on well-developed
freeways or highways. It may not
detect the lane markers for certain
roads, weather or driving conditions.

.

Using Active Lane Control under
some conditions of road, lane marker
or weather, or if you attempt to
change lanes without using the lane
change signal could lead to an un-
expected system operation. In such
conditions, you need to correct the
vehicle’s direction with your steering
operation to avoid accidents.

.

Active Lane Control will not operate
at speeds below approximately 45
MPH (70 km/h) or if it cannot detect
lane markers.

.

Active Lane Control may not operate

properly and should not be used
under the following conditions:

— During bad weather (rain, fog,

snow, etc.).

— When driving on slippery roads,

such as on ice or snow, etc.

— When driving on winding or un-

even roads.

— When there is a lane closure due

to road repairs.

— When driving in a makeshift lane.

— When driving on roads where the

lane width is too narrow.

— When driving with a tire that is

not within normal tire conditions
(for example, tire wear, low tire
pressure, installation of spare tire,
tire chains, non-standard wheels).

— When the vehicle is equipped with

non-original steering parts or sus-
pension parts.

.

Active Lane Control may or may not
operate properly under the following
conditions:

— On roads where there are multi-

ple parallel lane markers; lane
markers that are faded or not
painted clearly; yellow painted

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

lane markers; non-standard lane
markers; or lane markers covered
with water, dirt, snow, etc.

— On roads where discontinued lane

markers are still detectable.

— On roads where there are sharp

curves.

— On roads where there are sharply

contrasting objects, such as sha-
dows, snow, water, wheel ruts,
seams or lines remaining after
road repairs. (Active Lane Control
could detect these items as lane
markers.)

— On roads where the traveling lane

merges or separates.

— When the vehicle’s traveling di-

rection does not align with the
lane marker.

— When traveling close to the ve-

hicle in front of you, which ob-
structs the lane camera unit
detection range.

— When rain, snow, dirt or object

adheres to the windshield in front
of the lane camera unit.

— When the headlights are not

bright due to dirt on the lens or
if the aiming is not adjusted

properly.

— When strong light enters the lane

camera unit. (For example, the
light directly shines on the front
of the vehicle at sunrise or sun-
set.)

— When a sudden change in bright-

ness occurs. (For example, when
the vehicle enters or exits a tunnel
or under a bridge.)

— When entering or exiting toll-

gates.

— When driving on roads with a

widening or narrowing lane width.

JVS0824X

Vehicle information display

SYSTEM TEMPORARILY UNA-
VAILABLE

Automatic deactivation

Active Lane Control is not designed to
operate under the following conditions:

.

When the Vehicle Dynamic Control

(VDC) system (except TCS function) or
ABS operates.

.

When you operate the lane change signal

and change the traveling lanes in the
direction of the signal. (Active Lane
Control is deactivated for approximately
2 seconds after the lane change signal is

Starting and driving

5-31

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-32

Starting and driving

turned off.)

.

When the vehicle speed lowers to less

than approximately 45 MPH (70 km/h).

.

When the hazard warning flashers are

operated.

After the above conditions have finished and
the operating conditions are satisfied again,
Active Lane Control will resume operation.

Temporary disabled status at high
temperature

If the vehicle is parked in direct sunlight
under high temperature conditions (over
approximately 104°F (40°C)) and then Ac-
tive Lane Control is turned on, Active Lane
Control may be deactivated automatically.
The high cabin temperature message will
appear in the vehicle information display

.

Action to take:

When the interior temperature is reduced,
push the dynamic driver assistance switch
again to turn Active Lane Control back on.

SYSTEM MALFUNCTION

If Active Lane Control malfunctions, it will
cancel automatically. The chassis control
warning will appear in the vehicle informa-
tion display.

Action to take:

If the chassis control warning appears, pull
off the road to a safe location and stop the
vehicle. Turn the engine off and restart the
engine. If the chassis control warning con-
tinues to illuminate, have the system
checked. It is recommended you visit an
INFINITI retailer for this service.

SSD0453

SYSTEM MAINTENANCE

The lane camera unit

for Active Lane

Control is located above the inside mirror. To
keep the proper operation of Active Lane
Control and prevent a system malfunction,
be sure to observe the following:

.

Always keep the windshield clean.

.

Do not attach a sticker (including trans-

parent material) or install an accessory
near the camera unit.

.

Do not place reflective materials, such as

white paper or a mirror, on the instru-
ment panel. The reflection of sunlight
may adversely affect the camera unit’s
capability of detecting the lane markers.

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

.

Do not strike or damage the areas around

the camera unit. Do not touch the
camera lens or remove the screw located
on the camera unit. It is recommended
you contact an INFINITI retailer if the
camera unit is damaged due to an
accident.

WARNING

Failure to follow the warnings and
instructions for proper use of the LDW
and LDP systems could result in serious
personal injury or death.

.

The LDW and LDP systems will not
prevent loss of control. It is the
driver’s responsibility to stay alert,
drive safely, keep the vehicle in the
traveling lane, and be in control of
the vehicle at all times.

.

The LDP system may activate if you
change lanes without first activating
your turn signal or, for example, if a
construction zone directs traffic to
cross an existing lane marker. If this
occurs, you may need to apply cor-
rective steering to complete your lane
change.

.

Because the LDP system may not
activate under the road, weather,
and lane marker conditions described
in this section, it may not activate
every time your vehicle begins to
leave its lane and you will need to
apply corrective steering.

.

Lane Departure Warning (LDW) system

— warns the driver with an indicator in

the vehicle information display and
vibrations of the steering wheel that
the vehicle is beginning to leave the
driving lane.

.

Lane Departure Prevention (LDP) system

(if so equipped)
— warns the driver with an indicator in

the vehicle information display and
vibrations of the steering wheel, and
helps the driver to return the vehicle
to the center of the traveling lane.

Starting and driving

5-33

LANE DEPARTURE WARNING
(LDW)/LANE DEPARTURE
PREVENTION (LDP) (if so equipped)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-34

Starting and driving

JVS1124X

The LDW and LDP systems use a camera
installed behind the windshield to monitor
the lane markers of your traveling lane.

JVS0825X

Dynamic driver assistance switch
Driver assist system lane indicator
(green) (on the vehicle information dis-
play)
Lower display

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LDW SYSTEM OPERATION

The LDW system operates above approxi-
mately 45 MPH (70 km/h) and when the
lane markings are clear.
If the vehicle approaches either the left or
the right side of the traveling lane, the driver
assist system lane indicator (orange) in the
vehicle information display will blink and the
steering wheel will vibrate.

NOTE:

The LDW system is not designed to warn
when you operate the lane change signal
and change traveling lanes in the direction
of the signal. (The LDW system will become
operable again approximately 2 seconds
after the lane change signal is turned off.)

JVS0246X

HOW TO ENABLE/DISABLE THE
LDW SYSTEM

Perform the following steps to enable or
disable the LDW system.
1. Push the MENU button

and touch

[Driver Assistance] on the lower display.

2. Touch [Lane Assist].
3. Touch [Lane Departure Warning] to

enable or disable the system.

The displayed keys on the lower display may
vary depending on models, specifications
and software versions.

LDP SYSTEM OPERATION (if so
equipped)

The LDP system operates above approxi-
mately 45 MPH (70 km/h) and when the
lane markings are clear.
If the vehicle approaches either the left or
right side of the traveling lane, the driver
assist system lane indicator (orange) in the
vehicle information display will blink and the
steering wheel will vibrate. Then, the LDP
system will automatically assist the driver to
return the vehicle to the center of the
traveling lane.

NOTE:

.

The LDP system is not designed to work

when you operate the lane change signal
and change traveling lanes in the direc-
tion of the signal. (The LDP system will
become operable again approximately 2
seconds after the lane change signal is
turned off.)

.

The LDP will not operate or will stop

operating and only the steering wheel
will vibrate under the following condi-
tions.

When the steering wheel is turned as
far as necessary for the vehicle to
change lanes.

When the accelerator pedal is de-
pressed.

Starting and driving

5-35

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-36

Starting and driving

When the Intelligent Cruise Control
(ICC), Distance Control Assist (DCA),
Blind Spot Intervention (BSI), Blind
Spot Warning (BSW), Predictive For-
ward Collision Warning (PFCW) or
Forward Emergency Braking (FEB)
approach warning occurs.

When the BSI system activates.

When the hazard warning flashers
are operated.

When driving on a curve at a high
speed.

JVS0825X

Dynamic driver assistance switch
Driver assist system lane indicator
(green) (on the vehicle information dis-
play)
Lower display

TURNING THE LDP SYSTEM ON/
OFF (if so equipped)

To turn on the LDP system, push the
dynamic driver assistance switch

on the

steering wheel after starting the engine. The
driver assist system lane indicator (green)
in the vehicle information display will illumi-

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

nate.
Push the dynamic driver assistance switch
again to turn off the LDP system. The driver
assist system lane indicator

will turn off.

The dynamic driver assistance switch

is

used for Active Lane Control, LDP, Blind
Spot Intervention (BSI) and Distance Control
Assist (DCA) systems. When the dynamic
driver assistance switch

is pushed, Active

Lane Control, BSI and DCA systems will also
turn on or off simultaneously. The LDP
system can be individually set to on or off
on the lower display

.

If the system is set to off, the system will not
turn on even if the dynamic driver assistance
switch

is pushed to on. To set the system

to on or off on the lower display, see “How
to enable/disable the LDP system” (P.5-37).

JVS0246X

HOW TO ENABLE/DISABLE THE
LDP SYSTEM (if so equipped)

Perform the following steps to enable or
disable the LDP system.
1. Push the MENU button

and touch

[Driver Assistance] on the lower display.

2. Touch [Lane Assist].
3. Touch [Lane Departure Prevention] to

enable or disable the system.

The displayed keys on the lower display may
vary depending on models, specifications
and software versions.

LDW/LDP SYSTEM LIMITATIONS

WARNING

Listed below are the system limitations
for the LDW and LDP systems. Failure to
operate the vehicle in accordance with
these system limitations could result in
serious injury or death.

.

The system will not operate at speeds
below 45 MPH (70 km/h) or if it
cannot detect lane markers.

.

The LDP system is primarily intended
for use on well-developed freeways
or highways. It may not detect the
lane markers in certain roads, weath-
er or driving conditions.

.

Do not use the LDP system under the
following conditions as it may not
function properly:

— During bad weather (rain, fog,

snow, etc.).

— When driving on slippery roads,

such as on ice or snow, etc.

— When driving on winding or un-

even roads.

— When there is a lane closure due

to road repairs.

Starting and driving

5-37

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-38

Starting and driving

— When driving in a makeshift or

temporary lane.

— When driving on roads where the

lane width is too narrow.

— When driving without normal tire

conditions (for example, tire wear,
low tire pressure, installation of
spare tire, tire chains, non-stan-
dard wheels).

— When the vehicle is equipped with

non-original steering parts, brake
parts or suspension parts.

.

The camera may not detect lane
markers in the following situations
and the LDW and LDP systems may
not operate properly.

— On roads where there are multi-

ple parallel lane markers; lane
markers that are faded or not
painted clearly; yellow painted
lane markers; non-standard lane
markers; or lane markers covered
with water, dirt, snow, etc.

— On roads where discontinued lane

markers are still detectable.

— On roads where there are sharp

curves.

— On roads where there are sharply

contrasting objects, such as sha-

dows, snow, water, wheel ruts,
seams or lines remaining after
road repairs. (The LDW and LDP
systems could detect these items
as lane markers.)

— On roads where the traveling lane

merges or separates.

— When the vehicle’s traveling di-

rection does not align with the
lane marker.

— When traveling close to the ve-

hicle in front of you, which ob-
structs the lane camera unit
detection range.

— When rain, snow or dirt adheres

to the windshield in front of the
lane camera unit.

— When the headlights are not

bright due to dirt on the lens or
if the aiming is not adjusted
properly.

— When strong light enters the lane

camera unit. (For example, the
light directly shines on the front
of the vehicle at sunrise or sun-
set.)

— When a sudden change in bright-

ness occurs. (For example, when
the vehicle enters or exits a tunnel

or under a bridge.)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVS0826X

Warnings and indicators (on the vehicle
information display)
Dynamic driver assistance switch

SYSTEM TEMPORARILY UNA-
VAILABLE

Condition A

Under the following conditions, If the “LDP
currently unavailable” message appears in
the vehicle information display, a chime will
sound and the LDP system will be turned off
automatically.

.

When the VDC system (except TCS

function) or ABS operates.

.

When the VDC system is turned off.

.

When the INFINITI Drive Mode Selector

is turned to the SNOW mode.

Action to take:

When the above conditions no longer exist,
push the dynamic driver assistance switch
again to turn the LDP system back on.

Condition B

LDW system:

If the vehicle is parked in direct

sunlight under high temperature conditions
(over approximately 104°F (40°C)) and then
started, the LDW system may be deacti-
vated automatically. The “high cabin tem-
perature” warning message will appear in
the vehicle information display.

LDP system:

If the vehicle is parked in direct

sunlight under high temperature conditions
(over approximately 104°F (40°C)) and then
the LDP system is turned on, the LDP
system may be deactivated automatically.
The “high cabin temperature” message will
appear in the vehicle information display.
The LDW and LDP systems are not available
until the conditions no longer exist.

Action to take:

When the above conditions no longer exist,
the LDW system will resume automatically.
For the LDP system, push the dynamic driver
assistance switch

again to turn the LDP

system back on.

SYSTEM MALFUNCTION

LDW system:

If the LDW system malfunc-

tions, it will cancel automatically, and the
LDW “malfunction” message will appear in
the vehicle information display.

LDP system:

If the LDP system malfunc-

tions, it will cancel automatically. The LDP
“malfunction” message will appear in the
vehicle information display.

Action to take:

Stop the vehicle in a safe location, place the
vehicle in the P (Park) position, turn the
engine off and restart the engine. If the
“malfunction” message continues to appear,
have the system checked. It is recommended
you visit an INFINITI retailer for this service.

Starting and driving

5-39

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5-40

Starting and driving

SSD0453

SYSTEM MAINTENANCE

The lane camera unit

for LDW/LDP

systems is located above the inside mirror.
To keep the proper operation of LDW/LDP
systems and prevent a system malfunction,
be sure to observe the following:

.

Always keep the windshield clean.

.

Do not attach a sticker (including trans-

parent material) or install an accessory
near the camera unit.

.

Do not place reflective materials, such as

white paper or a mirror, on the instru-
ment panel. The reflection of sunlight
may adversely affect the camera unit’s
capability of detecting the lane markers.

.

Do not strike or damage the areas around

the camera unit. Do not touch the
camera lens or remove the screw located
on the camera unit. It is recommended
you contact an INFINITI retailer if the
camera unit is damaged due to an
accident.

WARNING

Failure to follow the warnings and
instructions for proper use of the BSW
system could result in serious injury or
death.

.

The BSW system is not a replacement
for proper driving procedure and is
not designed to prevent contact with
vehicles or objects. When changing
lanes, always use the side and rear
mirrors and turn and look in the
direction your vehicle will move to
ensure it is safe to change lanes.
Never rely solely on the BSW system.

.

There is a limitation to the detection
capability of the radar. Not every
moving object or vehicle will be
detected. Using the BSW system
under some road, ground, lane mar-
ker, traffic or weather conditions
could lead to improper system opera-
tion. Always rely on your own opera-
tion to avoid accidents.

The BSW system helps alert the driver of
other vehicles in adjacent lanes when chan-
ging lanes.

BLIND SPOT WARNING (BSW) (if
so equipped)

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------

JVS1122X

The BSW system uses radar sensors
installed near the rear bumper to detect
other vehicles in an adjacent lane.

SSD1030

Detection zone

The radar sensors can detect vehicles on
either side of your vehicle within the detec-
tion zone shown as illustrated. This detec-
tion zone starts from the outside mirror of
your vehicle and extends approximately 10
ft (3.0 m) behind the rear bumper, and
approximately 10 ft (3.0 m) sideways.

Starting and driving

5-41

CarManuals2.com

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     6      7      8      9     ..
