Alfa Romeo Giulia (2023 year). Manual in english - page 3





83

A

FTER

 S

TARTING

 — W

ARMING

 U

P

 T

HE



E

NGINE

Proceed as follows:

Travel slowly, letting the engine run at a

reduced RPM, without accelerating suddenly.

It is recommended to wait until the digital

engine coolant temperature indicator starts to

rise for maximum performance.

S

TOPPING

 T

HE

 E

NGINE

To stop the engine, proceed as follows:
1. Park the vehicle in a position that is not

dangerous for oncoming traffic.

2. Engage the PARK (P) mode.
3. With engine idling, push the ENGINE START/

STOP button on the steering wheel to stop the

engine.

NOTE:

Do not leave the ignition in ACC position when the

engine is off.
To shut off the engine with vehicle speed greater

than 5 mph (8 km/h), you must push and hold

the ignition or push the ENGINE START/STOP

button three times consecutively within a few

seconds. The engine will shut down, and the

ignition will be placed in the ACC position.
With the keyless ignition system, it is possible to

leave the vehicle taking the key fob with you

without the engine switching off. The vehicle will

inform the absence of the key on board, only if the

doors are closed.

After stopping the engine (cycling from the ACC to

the OFF position), the accessories are still

powered for about three minutes, or until a door

is opened.
When the ignition is in the OFF position, the

window switches remain active for three minutes.

Opening a front door will cancel this function.
After severe driving, idle the engine to allow the

temperature inside the engine compartment to

cool before shutting off the engine.

T

URBOCHARGER

 C

OOL

 D

OWN

It is recommended before switching the vehicle

off, to keep the engine idling for a few minutes so

that the turbocharger can be suitably lubricated.

This procedure is particularly recommended after

severe driving.
After a full load operation, keep the engine idling

for three to five minutes before switching it off.
This time allows the lubricating oil and the engine

coolant to eliminate the excessive heat from

combustion chamber, bearings, inner

components and turbocharger.

ENGINE BLOCK HEATER —

IF EQUIPPED

The engine block heater warms the engine and

permits quicker starts in cold weather.
Connect the cord to a 110-115 Volt AC electrical

outlet with a grounded, three-wire extension cord.
For ambient temperatures below 0°F (-18°C),

the engine block heater is recommended. For

ambient temperatures below -20°F (-29°C), the

engine block heater is required.

See the following steps to properly use the engine

block heater:
1. Locate the engine block heater cord (access

door on the passenger side wiper cowl).

2. Pull the cord to the front of the vehicle and

plug it into a grounded, three-wire extension

cord.

3. After the vehicle is running, properly stow

away behind access door on the passenger

side wiper cowl.

NOTE:

The engine block heater cord is a factory

installed option. If your vehicle is not equipped,

heater cords are available from an authorized

dealer.

The engine block heater will require 110 Volts

AC and 6.5 Amps to activate the heater

element.

The engine block heater must be plugged in at

least one hour to have a warming effect on the

engine and at least four hours to have a

warming effect when ambient temperatures

are below -20°F (-29°C).

 WARNING!

Remember to disconnect the engine block

heater cord before driving. Damage to the

110-115 Volt electrical cord could cause

electrocution.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

84

ENGINE BREAK-IN

RECOMMENDATIONS

E

NGINE

 B

REAK

-I

N

For both engines, use the following engine

break-in recommendations:
NOTE:

A new engine may consume some oil during its

first few thousand miles (kilometers) of opera

-

tion. This should be considered a normal part of

the break-in period and not interpreted as an indi

-

cation of a problem. Please monitor your oil level

during the break-in period and add oil as

required.
It is recommended for the operator to observe the

following driving behaviors during the new vehicle

break-in period:
0 to 100 miles (0 to 160 km):

Do not allow the engine to operate at idle for

an extended period of time.

Press the accelerator pedal slowly and not

more than halfway to avoid rapid acceleration.

Avoid aggressive braking.

Drive with the engine speed less than

3,500 RPM.

Maintain vehicle speed below 55 mph

(88 km/h) and observe local speed limits.

100 to 300 miles (160 to 483 km):

Press the accelerator pedal slowly and not

more than halfway to avoid rapid acceleration

in lower gears (FIRST to THIRD gears).

Avoid aggressive braking.

Drive with the engine speed less than

5,000 RPM.

Maintain vehicle speed below 70 mph

(112 km/h) and observe local speed limits.

300 to 500 miles (483 to 805 km):

Exercise the full engine RPM range, shifting

manually (paddles or gear shift) at higher RPM

when possible.

Do not perform sustained operation with the

accelerator pedal at wide open throttle.

Maintain vehicle speed below 85 mph

(136 km/h) and observe local speed limits.

For the first 1,500 miles (2,414 km):

Do not participate in track events, sport driving

schools, or similar activities during the first

1,500 miles (2,414 km).

NOTE:

Monitor engine oil with every refueling and add if

necessary. Oil and fuel consumption may be

higher through the first oil change interval.

ELECTRIC PARK BRAKE

(EPB)

The EPB features a switch located on the center

console, a caliper with motor for each rear wheel,

and an electronic control module.

Electric Park Brake Switch

The EPB can be engaged in two ways:

Manually, by pulling the switch on the center

console.

Automatically, in “Safe Hold” or “Auto Park

Brake” conditions.

NOTE:

Normally, the EPB is engaged automatically when

the engine is stopped. This function can be deac

-

tivated/activated on the Information and Enter

-

tainment system by selecting the following items

in sequence on the main menu: “Settings”,

“Driver Assistance” and “Automatic Parking

Brake”.

CarManuals2.com

85

In addition to engaging the EPB, along with

steering and positioning chocks in front of the

wheels (when on a steep slope), you must always

place the vehicle in the PARK (P) mode before

leaving.
Should the vehicle battery be faulty, the battery

must be replaced in order to unlock the EPB.
Engaging The EPB Manually
Briefly pull the switch located on the center

console to manually engage the EPB when the

vehicle is stationary.
Noise may be heard from the rear of the vehicle

when engaging the EPB.
A slight movement of the brake pedal may be

detected when engaging the EPB with the brake

pedal pressed.
With the EPB engaged, the Brake Warning Light

on the instrument panel and the switch will

illuminate.

If, under exceptional circumstances, the use of

the brake is required with the vehicle in motion,

keep the switch on the center console pulled as

long as the brake action is necessary.
The Brake Warning Light may turn on with the

hydraulic system temporarily unavailable; in this

case braking is controlled by the motors.

The brake lights will also automatically turn on in

the same way as for normal braking with the use

of the brake pedal.
Release the switch on the center console to stop

the braking action with the vehicle in motion.
If, through this procedure, the vehicle is braked

until a speed below 1.9 mph (3 km/h) is reached

and the switch is kept pulled, the parking brake

will definitively engage.

Disengaging The EPB Manually
In order to manually release the parking brake,

the ignition should be in the ACC position. Press

the brake pedal, and then push the switch on the

center console briefly.
Noise may be heard from the rear of the vehicle,

and a slight movement of the brake pedal may be

detected during disengagement.
After disengaging the Electric Park Brake, the

Brake Warning Light on the instrument panel and

the light on the switch will turn off.
If the Brake Warning Light on the instrument

panel remains on with the EPB disengaged, this

indicates a fault: in this case, contact an

authorized dealer.

 CAUTION!

With the EPB failure warning light on, some

functions of the EPB are deactivated. In this

case the driver is responsible for engaging the

EPB manually to ensure the vehicle is safely

and properly parked.

 WARNING!

Driving the vehicle with the parking brake

engaged, or repeated use of the parking brake

to slow the vehicle may cause serious damage

to the brake system. Be sure the parking brake

is fully disengaged before driving; failure to do

so can lead to brake failure and a collision.

 WARNING!

Never use the PARK position as a substitute

for the parking brake. Always apply the

parking brake fully when parked to guard

against vehicle movement and possible

injury or damage.

When exiting the vehicle, always turn the

ignition OFF, secure the key fob, and lock

your vehicle.

Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing

children to be in a vehicle unattended is

dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.

Do not leave the key fob in or near the

vehicle, or in a location accessible to

children, and do not leave a vehicle

equipped with a keyless ignition system in

the ON/RUN position. A child could operate

power windows, other controls, or move the

vehicle.

Be sure the parking brake is fully disengaged

before driving; failure to do so can lead to

brake failure and a collision.

Always fully apply the parking brake when

leaving your vehicle, or it may roll and cause

damage or injury. Also be certain to leave the

transmission in PARK. Failure to do so may

allow the vehicle to roll and cause damage or

injury.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

86

(Continued)

E

LECTRIC

 P

ARK

 B

RAKE

 (EPB)

O

PERATING

 M

ODES

The EPB may operate as follows:

“Dynamic Operating Mode”: this mode is

activated by pulling the switch repeatedly

while driving.

“Static Engagement and Release Mode”: with

the vehicle stationary, the EPB can be

activated by pulling the switch on the center

console once. Push the switch and the brake

pedal at the same time to disengage the

brake.

“Drive Away Release”: the EPB will automat

-

ically disengage with the driver side seat belt

fastened and the detection of an action

performed by the driver to move the vehicle

(forward gear or reverse gear). This feature can

be turned on or off in the Information and

Entertainment System.

“Safe Hold”: engages if the gear selector is not

in PARK (P) position and the driver's intention

of leaving the vehicle is detected. The EPB will

automatically engage the EPB.

S

AFE

 H

OLD

Safe Hold is a safety function that automatically

engages the EPB if the driver attempts to leave

the vehicle while the ignition is in ON/RUN.
The EPB engages automatically to prevent

vehicle movement if:

The vehicle speed is below 2 mph (3 km/h).

A transmission operating mode different from

PARK (P) is activated.

The driver's seat belt is not fastened.

The driver side door is open.

No attempts to apply pressure on the brake

pedal have been detected.

The vehicle is parked on roads with a slope of

more than 4%.

The “Safe Hold” function can be temporarily

disabled by pushing the switch located on the

center console and the brake pedal at the same

time, with the vehicle stationary and the driver

side door open.
Once disabled, the function will activate again

when the vehicle speed reaches 12 mph (20 km/h)

or the ignition is cycled to OFF and then to ACC.

AUTOMATIC

TRANSMISSION

The vehicle is equipped with an electronically

controlled 8-speed automatic transmission

where gear shifting automatically takes place,

depending on the vehicle usage instantaneous

parameters (vehicle speed, grade, and

accelerator pedal position).
Manual gear shifting can still occur thanks to the

“sequential mode” position for the gear selector.

 WARNING!

It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than

idle speed. If your foot is not firmly pressing

the brake pedal, the vehicle could accelerate

quickly forward or in reverse. You could lose

control of the vehicle and hit someone or

something. Only shift into gear when the

engine is idling normally and your foot is

firmly pressing the brake pedal.

Unintended movement of a vehicle could

injure those in or near the vehicle. As with all

vehicles, you should never exit a vehicle

while the engine is running. Before exiting a

vehicle, always apply the parking brake, shift

the transmission into PARK, and turn the

ignition OFF. When the ignition is in the OFF

position, the transmission is locked in PARK,

securing the vehicle against unwanted

movement.

When leaving the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle, and lock the

vehicle.

Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing

children to be in a vehicle unattended is

dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the

transmission gear selector.

CarManuals2.com

87

D

ISPLAY

The following information is shown on the

dedicated area of the display:

In Automatic Mode: the active mode (P, R, N, D)

with "D" as the current gear number.

In Manual Drive Mode (Sequential): the mode

(M) with the current gear and the double or

single gear shift request, use both up and

down (single or double arrow).

Gear Display

G

EAR

 S

ELECTOR

The gear functioning is controlled by the gear

selector, which can assume the following

positions:

P = PARK

R = REVERSE

N = NEUTRAL

D = DRIVE (automatic forward speed)

AutoStick: using + manually shift to higher

gear; – to manually shift to lower gear

The positions diagram is illustrated on the top of

the gear selector.

Gear Selector Center Console

The letter corresponding to the mode selected on

the gear selector lights up and appears on the

instrument cluster display.
To select a mode, move the gear selector forward

or backwards, together with pressing the brake

pedal and gear selector button to engage

REVERSE (R).

Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and

do not leave the ignition in the ON/RUN or

ACC position. A child could operate power

windows, other controls, or move the vehicle.

 CAUTION!

Damage to the transmission may occur if the

following precautions are not observed:

Shift into or out of PARK or REVERSE only

after the vehicle has come to a complete

stop.

Do not shift between PARK, REVERSE,

NEUTRAL, or DRIVE when the engine is above

idle speed.

Before shifting into any gear, make sure your

foot is firmly pressing the brake pedal.

 WARNING!

1 — Gear Selector
2 — PARK (P) Button

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

88

(Continued)

(Continued)

Gear Selector

The gear selector is a joystick style shifting

mechanism which returns to the center position

automatically. It can be pushed forward twice and

rearward twice, based on the starting condition.
The PARK (P) mode can be enabled/disabled by

pushing the PARK (P) button.
To transition the vehicle into REVERSE (R) mode

from DRIVE (D) mode, or into DRIVE (D) mode

from REVERSE (R) mode, it is necessary to move

the gear selector by pushing the gear selector

button.
When using AutoStick to change gears, move the

gear selector left from DRIVE (D) and then

forward toward the - symbol or backward toward

the + symbol and the gear is changed.
To shift out of PARK (P), or to pass from position

NEUTRAL (N) to position DRIVE (D) or REVERSE

(R), the vehicle must be moving at a low speed or

stopped, and the brake pedal must also be

pressed.

NOTE:

DO NOT accelerate while shifting from position

PARK (P) or NEUTRAL (N) to another position.

After selecting a gear, wait a few seconds

before accelerating. This precaution is partic

-

ularly important with a cold engine.

T

RANSMISSION

 O

PERATING

 M

ODES

PARK (P)
The transmission is locked in this mode. The

engine can be started in this mode.
NOTE:

Never try to engage PARK (P) mode when the

vehicle is moving. Before leaving the vehicle,

make sure this mode is engaged (letter P shown

on the display and gear selector) and that the

parking brake is engaged.
When parking on a flat surface, first engage the

PARK (P) mode and then engage the Electric Park

Brake.
When parking uphill, before activating the PARK

(P) mode, engage the Electric Park Brake.

Otherwise, it could be difficult to engage the

PARK (P) mode.
To check that the PARK (P) mode is actually

engaged, make sure “P” is illuminated on the

display and on the gear selector.

3 — Gear Selector Button

 WARNING!

Never use the PARK position as a substitute

for the parking brake. Always apply the

parking brake fully when parked to guard

against vehicle movement and possible

injury or damage.

Your vehicle could move and injure you and

others if it is not in PARK. Check by trying to

move the gear selector out of PARK with the

brake pedal released. Make sure the

transmission is in PARK before leaving the

vehicle.

It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than

idle speed. If your foot is not firmly pressing

the brake pedal, the vehicle could accelerate

quickly forward or in reverse. You could lose

control of the vehicle and hit someone or

something. Only shift into gear when the

engine is idling normally and your foot is

firmly pressing the brake pedal.

Unintended movement of a vehicle could

injure those in or near the vehicle. As with all

vehicles, you should never exit a vehicle

while the engine is running. Before exiting a

vehicle, always apply the parking brake, shift

the transmission into PARK, and turn the

ignition STOP/OFF. When the ignition is in the

STOP/OFF position, the transmission is

locked in PARK, securing the vehicle against

unwanted movement.

When leaving the vehicle, always make sure

the ignition is in the STOP/OFF position,

remove the key fob from the vehicle, and lock

the vehicle.

 WARNING!

CarManuals2.com

89

REVERSE (R)
Select this mode only with the vehicle at a

standstill.
NEUTRAL (N)
Use this range when the vehicle is standing for

prolonged periods with the engine running. The

engine may be started in this range. Apply the

Electric Park Brake and shift the transmission

into PARK (P) if you must leave the vehicle.

DRIVE (D)
Use this mode in normal driving conditions.
Shifting from DRIVE (D) to PARK (P) or REVERSE

(R) modes must take place only after releasing

the accelerator pedal, with vehicle at a standstill

and brake pedal pressed.
This mode ensures automatic engagement of the

most suitable gears for driving needs and

maximum fuel economy in terms of consumption.
In this position, the transmission shifts the gears

automatically, selecting the most suitable for

forward driving among those available as you go.

This ensures the vehicle's optimal driving charac

-

teristics are provided for all conditions.
AutoStick
In the case of frequent shifting (e.g. for sport

driving, when the vehicle is driven with a heavy

load or on slopes), it is recommended to use the

AutoStick (sequential shifting) mode to select and

keep a lower fixed ratio.
In these conditions, the use of a lower gear

improves vehicle performance, preventing

overheating.

It is possible to shift from DRIVE (D) mode to

sequential mode regardless of vehicle speed.
Activation
Starting from DRIVE (D), move the selector to the

left (– and + indication of the trim) to activate the

sequential drive mode. The gear engaged will be

shown on the display.
Shifting is made by moving the gear selector

forwards, towards symbol – or backwards,

towards symbol +.
Steering Wheel Shift Paddles — If Equipped
The gear can also be manually shifted by using

the paddles behind the steering wheel. Pull the

right paddle (+) toward the steering wheel and

release it to engage a higher gear, and perform

the same operation with the left paddle (-) to

engage a lower gear.

Steering Wheel Shift Paddles

NOTE:

If only one manual shift is necessary, the letter

“D” will remain on the display with the engaged

gear next to it.

Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing

children to be in a vehicle unattended is

dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the

transmission gear selector.

Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and

do not leave the ignition in the ON position. A

child could operate power windows, other

controls, or move the vehicle.

 CAUTION!

Before moving the transmission gear

selector out of PARK, you must push the

ignition button to cycle from STOP/OFF

position to the ON position, and also press

the brake pedal. Otherwise, damage to the

gear selector could result.

DO NOT race the engine when shifting from

PARK or NEUTRAL into another gear range,

as this can damage the drivetrain.

 WARNING!

 WARNING!

Do not coast in NEUTRAL and never turn off

the ignition to coast down a hill. These are

unsafe practices that limit your response to

changing traffic or road conditions. You might

lose control of the vehicle and have a collision.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

90

Deactivation
To deactivate the sequential driving mode, bring

the gear selector back in position DRIVE (D)

(“automatic” driving mode).

NOTE:

To select the correct gear for maximum

deceleration (engine brake), just keep the gear

paddle pulled (–): the transmission goes to an

operating mode in which the vehicle can slow

down easily.

The vehicle will keep the gear selected by the

driver until the safety conditions allow it.

This means, for example, that the system will

try to prevent the engine from switching off,

automatically downshifting if the engine speed

is too low.

A

UTOMATIC

 T

RANSMISSION

 L

IMP

 H

OME



M

ODE

Transmission function is monitored electronically

for abnormal conditions. If a condition is detected

that could result in transmission damage,

Transmission Limp Home Mode is activated.
In this condition, the transmission stays in

FOURTH gear, regardless of the selected gear.

Positions PARK (P), REVERSE (R) and NEUTRAL

(N) still work.

The   symbol might light up in the instrument

cluster.
Temporary failure
In the event of a momentary problem, the

transmission can be reset to regain all forward

gears by performing the following steps:
1. Stop the vehicle.
2. Shift the transmission into PARK (P), if

possible. If not, shift the transmission to

NEUTRAL (N).

3. Push and hold the ignition until the engine

turns off.

4. Wait for about 10 seconds, then restart the

engine.

5. Shift into the desired gear range. If the

problem is no longer detected, the transmis

-

sion will return to normal operation.

NOTE:

Even if the transmission can be reset, we recom

-

mend that you visit an authorized dealer at your

earliest possible convenience. An authorized

dealer has diagnostic equipment to determine if

the problem could reoccur. If the transmission

cannot be reset, service is required at an autho

-

rized dealer.

B

RAKE

/T

RANSMISSION

 S

HIFT

 I

NTERLOCK



(BTSI) S

YSTEM

This vehicle is equipped with a BTSI system that

holds the gear selector in PARK (P) unless the

brakes are applied.
This system prevents you from moving the gear

selector from position PARK (P) unless the brakes

are applied.

To shift the transmission out of PARK (P), the

ignition must be placed in the ON/RUN position

(engine running or not) and the brake pedal must

be pressed.
Brake/Transmission Shift Interlock Disabling
Only if strictly necessary (e.g. pushing the vehicle,

conveyor vehicle washing systems), place the

vehicle in the NEUTRAL (N) position when

stopping the engine. See the following steps:
1. Vehicle at a standstill.
2. NEUTRAL (N) mode activated.
3. Push the ignition button for at least three

seconds.

The automatic parking brake engagement

function when the engine is stopped can also be

deactivated on the Information and

Entertainment system by selecting the following

functions on the main menu: “Settings”, “Driver

Assistance” and “Automatic Parking Brake”.

I

MPORTANT

 N

OTES

Failure to comply with the following may damage

the transmission:

Shift into PARK (P) mode only with the vehicle

at a standstill.

Select REVERSE (R) mode, or pass from

REVERSE to another mode only with the

vehicle at a standstill and engine idling.

Do not change between PARK (P), REVERSE

(R), NEUTRAL (N) or DRIVE (D) modes with

engine running at a speed above idling.

Before activating any transmission operating

mode, fully press the brake pedal.

 WARNING!

Do not downshift for additional engine braking

on a slippery surface. The drive wheels could

lose their grip and the vehicle could skid,

causing a collision or personal injury.

CarManuals2.com

91

(Continued)

ALFA DNA / PRO SELECTOR

A

LFA

 DNA S

YSTEM

This vehicle is equipped with an Alfa DNA system

selector (located on the center console). There

are four modes of operation to be selected

according to driving style and road conditions:

Alfa DNA System Selector

d = Dynamic (sports driving mode).

n = Natural (mode for driving in normal

conditions).

a = Advanced Efficiency (ECO driving mode for

maximum fuel savings).

RACE = track race driving mode (if equipped).

 = Adjusts the calibration of the active

suspension (Quadrifoglio only).

Unlike the other modes, there is no detent for the

RACE position. When the system selector is

rotated to the RACE position, it will return to its

initial position "d".

 WARNING!

It is dangerous to shift out of PARK or

NEUTRAL if the engine speed is higher than

idle speed. If your foot is not firmly pressing

the brake pedal, the vehicle could accelerate

quickly forward or in reverse. You could lose

control of the vehicle and hit someone or

something. Only shift into gear when the

engine is idling normally and your foot is

firmly pressing the brake pedal.

Unintended movement of a vehicle could

injure those in or near the vehicle. As with all

vehicles, you should never exit a vehicle

while the engine is running. Before exiting a

vehicle, always apply the parking brake, shift

the transmission into PARK, and turn the

ignition OFF. When the ignition is in the OFF

position, the transmission is locked in PARK,

securing the vehicle against unwanted

movement.

When leaving the vehicle, always make sure

the ignition is in the OFF position, remove the

key fob from the vehicle, and lock the

vehicle.

Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing

children to be in a vehicle unattended is

dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the

transmission gear selector.

Do not leave the key fob in or near the vehicle

(or in a location accessible to children), and

do not leave the ignition in the ON/RUN or

ACC position. A child could operate power

windows, other controls, or move the vehicle.

 CAUTION!

Only engage the gear with engine at idling

while fully pressing the brake pedal. If the

transmission temperature exceeds the

normal operating limits, the transmission

control unit may change the gear

engagement order and reduce the drive

torque. If the transmission overheats, it

could operate incorrectly until it cools down.

When using the vehicle with extremely low

external temperatures, the transmission

operation may change depending on the

engine and transmission temperature, as

well as vehicle speed. Activation of the

torque converter clutch and of the EIGHTH

gear is inhibited until the transmission oil is

correctly warmed up. Complete operation of

the transmission will be enabled as soon as

the fluid temperature reaches the

predefined value.

 WARNING!

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

92

When the engine is stopped, the selector returns

to “n” (Natural) mode.
The symbol of the active mode lights up in red on

the selector.
On the instrument panel display, the different

modes are characterized by different colors:

Natural - Blue

Dynamic - Red

Advanced Efficiency - Green

Mode Display

Each driving mode is graphically different on

color line and contents of each individual

“performance” screen.

D

RIVING

 M

ODES

“Dynamic” Mode
Activation
It is activated by rotating the selector to the letter

“d”; the displays light up in red.

Dynamic Mode

ESC and ASR systems: intervention thresholds

that ensure more enjoyable, sportier driving while

guaranteeing the stability of the vehicle.
“Electronic Q2” system: the system is calibrated

to increase traction while accelerating on turns,

improving the agility of the vehicle.
Engine and transmission: adoption of sports

mapping.

Dynamic Mode Performance Display

The “Performance” screen displays parameters

related to vehicle stability, the graphs illustrate

the trend of the longitudinal/lateral accelerations

(G-meter information), considering gravity

acceleration as a reference unit.
Lateral acceleration peaks are displayed on the

right.
“Natural” Mode
“Natural” Mode is the default mode when the

vehicle is started up.
Activation
It is activated by rotating the selector to the letter

“n”; the displays light up in blue.

 WARNING!

In “Dynamic”, the sensitivity of the accelerator

pedal increases considerably. Consequently,

driving is less fluid and comfortable. The driver

must ensure full control of the vehicle at all

times to avoid a collision.

CarManuals2.com

93

Natural Mode

Engine and transmission: standard response.
The “Performance” screen graphically

reproduces some parameters closely linked to

the efficiency of the driving style, with a view to

limiting consumption.

Natural Mode Performance Display

“Advanced Efficiency” Mode
Activation
It is activated by rotating the selector to the letter

“a”; the displays light up in green.

Advanced Efficiency Mode

ESC and ASR systems: intervention thresholds

aimed at ensuring maximum safety in low-grip

driving conditions. It is advisable to select

“Advanced Efficiency” mode in the presence of

low-grip road surfaces.
“Electronic Q2” system: the system is

deactivated.
There will be reduced engine performance.
“Advanced Efficiency” Mode is characterized by

reduced engine performance and ECO shifting

strategy for the automatic transmission.

The “Performance” screen graphically displays

some parameters closely related to the vehicle:

acceleration, deceleration, and gear selector.

Advanced Efficiency Mode Performance Display

NOTE:

The vehicle will always start up in NATURAL mode

as a default.

1 — Acceleration
2 — Deceleration
3 — Gear Selector

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

94

“RACE” Mode (Quadrifoglio Only)
Activation
It is activated by rotating the selector to position

“RACE”; the displays light up in yellow.

RACE Mode

Engine and transmission: adoption of sports

mapping.

The “Performance” screen displays parameters

related to vehicle stability, the graphs illustrate

the trend of the longitudinal/lateral accelerations

(G-meter information), considering gravity

acceleration as a reference unit.
The screen displays the lateral and longitudinal

acceleration peaks.

RACE Mode Performance Display

NOTE:

If the brake system overheats, this is communi

-

cated by the Information and Entertainment

system. In this case, allow the system to cool for

a few minutes by driving the vehicle normally

without operating the brakes.
Deactivation
To deactivate the RACE mode, rotate the selector

to the RACE position again and the system will be

set to “d” Dynamic mode.

ALFA ACTIVE SUSPENSION

(AAS) — IF EQUIPPED

The system continuously monitors the damping

of the suspension through the actuator installed

on each shock absorber. The calibration of the

shock absorbers can be adjusted to the

conditions of the road surface and to the dynamic

conditions of the vehicle, improving its comfort

and road handling.

The driver can choose, while driving (only in “d” or

“RACE” mode), between two types of suspension

calibration: a more sportier or a more

comfortable type.
By pushing the button, the system prepares the

shock absorber calibration in order to favor

driving comfort.

“Alfa DNA” System Selector

In case of a system failure, the symbol   and a

dedicated message will be shown on the

instrument cluster display.

STOP/START SYSTEM

The Stop/Start system automatically shuts off

the engine during a vehicle stop if the required

conditions are met. Releasing the brake pedal or

pressing the accelerator pedal will automatically

restart the engine.
The function was designed to increase vehicle

efficiency by reducing fuel consumption, gas

emissions, and sound pollution.
NOTE:

When the Stop/Start system stops the engine,

the power steering is also disabled.

 WARNING!

Only activate the RACE mode at the track.

In “RACE”, the sensitivity of the accelerator

pedal increases considerably. Consequently,

driving is less fluid and comfortable. The

driver must ensure full control of the vehicle

at all times to avoid a collision.

CarManuals2.com

95

O

PERATING

 M

ODE

Stopping the Engine
With the vehicle at a standstill and brake pedal

pressed, the Stop/Start system shuts off the

engine if the gear selector is in a position other

than REVERSE (R).
The system does not operate when the gear

selector is in REVERSE (R), in order to make

parking maneuvers easier.
In the event of uphill stops, the Stop/Start system

is disabled to make the “Hill Start Assist” function

available (works only with running engine).
NOTE:

The engine can only be automatically stopped

after having run at about 6 mph (10 km/h). After

an automatic restart, the vehicle only needs to

exceed a speed of 0.3 mph (0.5 km/h) to stop the

engine.
Engine stopping is signaled by the   symbol

lighting up on the instrument cluster display.
Restarting the Engine
To restart the engine, release the brake pedal or

turn the steering wheel slightly (if equipped).
With the brake pressed and the transmission in

automatic mode DRIVE (D), the engine will restart

by shifting to REVERSE (R), to PARK (P) or to

“AutoStick”.
With the brake pressed while the gear selector is

in “AutoStick” mode, the engine will restart by

shifting to PARK (P) or by moving the selector

to + or -.

S

YSTEM

 M

ANUAL

 A

CTIVATION

/

D

EACTIVATION

To manually activate/deactivate the system,

push the button located in the control panel on

the left of the steering wheel.

Stop/Start Button

System Activation
The activation of the system is indicated by the

 symbol lighting up on the display. In this

condition, the light on the button is off.
System Deactivation
A message will appear on the display when the

system is deactivated. In this condition, the light

on the button is on.
NOTE:

Each time the engine is started, the system is

activated regardless of where it was when it was

previously switched off.

P

OSSIBLE

 R

EASONS

 T

HE

 E

NGINE

 D

OES



N

OT

 A

UTOSTOP

For higher comfort and increased safety, and to

reduce emissions, there are certain conditions

where the engine will not autostop despite the

system being active, such as:

Engine still cold.

Especially cold outside temperature.

Battery not sufficiently charged.

Driver's door not shut.

Driver's seat belt not fastened.

Reverse gear engaged (e.g. for parking

maneuvers).

With the automatic climate control active, an

adequate cabin heating or cooling comfort has

not been reached or with MAX-DEF function

active.

During the first period of use, to initialize the

system.

Steering angle beyond threshold.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

96

E

NGINE

 R

ESTARTING

 C

ONDITIONS

Due to comfort, emission control and safety

reasons, the engine can restart automatically

without any action by the driver, under special

conditions, such as:

Battery not sufficiently charged.

Vehicle moving (e.g. when driving on roads

with a grade).

Engine stopping by the Stop/Start system for

more than approximately three minutes.

With the automatic climate control active, an

adjustment in cabin heating or cooling is made

or with MAX-DEF function active.

S

AFETY

 F

UNCTIONS

When the engine is stopped through the Stop/

Start system, if the driver releases their seat belt,

opens the driver's or passenger's door, or opens

the hood from inside the vehicle, the engine can

be restarted only by using the ignition.
This condition is indicated to the driver both

through a buzzer and a message on the

instrument cluster display.

I

RREGULAR

 O

PERATION

In the event of malfunction, the Stop/Start

system is deactivated.
For further information on failure indications

Ú

page 70.

V

EHICLE

 I

NACTIVITY

In the event of vehicle inactivity (or if the battery

is replaced), special attention must be paid to the

disconnection of the battery power supply.
Proceed as follows:
Remove connector from socket to disconnect

sensor (battery status monitoring) installed on

the negative pole of the battery. This sensor

should never be disconnected from the pole

except if the battery is replaced.

Battery Power Supply

NOTE:

After setting the ignition to OFF and having closed

the driver side door, wait at least one minute

before disconnecting the electrical supply from

the battery. When reconnecting the electrical

supply to the battery, make sure that the ignition

is in the OFF position and the driver side door is

closed.

SPEED LIMITER

D

ESCRIPTION

This feature allows the driver to program the

maximum speed of the vehicle.
NOTE:

The maximum set speed can be exceeded by

continuing to press the accelerator pedal.
The maximum speed can be set with the vehicle

stationary or in motion. The minimum speed that

can be set is 18 mph (30 km/h).
When this feature is active, the vehicle speed

depends on the pressing of the accelerator pedal

until the programmed speed limit is reached

Ú

page 97.

1 — Socket
2 — Sensor
3 — Connector

CarManuals2.com

97

A

CTIVATION

The feature can be activated/deactivated

through the radio system.
Activating The Device
To access this feature, select the “Driver

Assistance” widget in the radio system, then

select the following items in sequence:
1. Speed Limiter
2. ON
The activation of this feature is signaled by the

illumination of the green Speed Limiter icon,

along with the last speed set, in the instrument

cluster display. The Speed Limiter feature can

remain active concurrently with the Cruise

Control system. If a speed limit below the one

indicated in the Cruise Control is selected, the

Cruise Control speed will be lowered to that of the

Speed Limiter. This function remains available in

RACE mode.

Speed Limiter Display

S

PEED

 L

IMIT

 P

ROGRAMMING

The speed limit can be programmed through the

radio system.
To access the function on the main menu, select

the following items in sequence:
1. Driver Assistance
2. Speed Limiter - Set Speed
By turning the Rotary Pad, the speed increases by

5 mph (8 km/h), from a minimum of 18 mph

(30 km/h) to a maximum of 112 mph (180 km/h).

E

XCEEDING

 T

HE

 P

ROGRAMMED

 S

PEED

By fully pressing the accelerator pedal, the

programmed speed can be exceeded even with

the device active (e.g. in the event of overtaking).
The device is disabled until the speed drops

below the set limit, after which it reactivates

automatically.

P

ROGRAMMED

 S

PEED

 I

CON

 F

LASHING

The programmed speed will flash in the following

scenarios:

When the accelerator pedal has been fully

pressed and the vehicle has exceeded the

programmed speed.

Activating the system after setting a limit below

the effective speed of the vehicle.

In the event of overtake acceleration.

D

EACTIVATION

The feature can be activated/deactivated

through the radio system.
Deactivating The Device
To access this feature, select the “Driver

Assistance” widget in the radio system, then

select the following items in sequence:
1. Speed Limiter
2. OFF
Automatic Deactivation Of The Device
The device deactivates automatically in the event

of fault in the system. In this case, contact an

authorized dealer.
Temporary Signal Loss
When the device loses the signal, the white

symbol without the speed indication illuminates

on the display.
System Failure
If there is a system failure, the amber symbol

illuminates on the display.

CRUISE CONTROL

SYSTEMS — IF EQUIPPED

Your vehicle may be equipped with the Cruise

Control system, or the Adaptive Cruise Control

(ACC) system:

Cruise Control will keep your vehicle at a

constant preset speed.

Adaptive Cruise Control (ACC) will adjust the

vehicle speed up to the preset speed to

maintain a distance with the vehicle ahead.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

98

NOTE:

In vehicles equipped with ACC, if ACC is not

enabled, Fixed Speed Cruise Control will not

detect vehicles directly ahead of you. Always

be aware of the feature selected.

Only one Cruise Control feature can operate at

a time. For example, if Fixed Speed Cruise

Control is enabled, Adaptive Cruise Control will

be unavailable, and vice versa.

C

RUISE

 C

ONTROL

When engaged, the Cruise Control takes over

accelerator operations at speeds greater than

20 mph (32 km/h).

Cruise Control On/Off Switch

The Cruise Control buttons are located on the left

side of the steering wheel.
While driving downhill, the system could brake

the vehicle to keep the set speed the same.

To Activate

To activate the Cruise Control system, push the

on/off button located on the left side of the

steering wheel.
The activation of the system is signaled by the

illumination of the white indicator light on the

instrument cluster.

Cruise Control Indicator Light

The Cruise Control function can remain active at

the same time as the Speed Limiter system. If the

set speed is higher than the speed set with the

Speed Limiter, the set speed will be lowered to

that of the Speed Limiter.

For Quadrifoglio vehicles, this function remains

available in RACE mode.
NOTE:

The system cannot be engaged in FIRST or

REVERSE gear. It is advisable to engage it in

THIRD gear or higher if using the AutoStick

feature.

To Set A Desired Speed

To set a desired speed, proceed as follows:
1. Turn the Cruise Control on.
2. When the vehicle has reached the desired

speed, push the SET switch up or down and

release to activate. When the accelerator is

released, the vehicle will maintain the

selected speed automatically.

SET Switch Location

 WARNING!

Cruise Control can be dangerous where the

system cannot maintain a constant speed.

Your vehicle could go too fast for the

conditions, and you could lose control and

have an accident. Do not use Cruise Control in

heavy traffic or on roads that are winding, icy,

snow-covered or slippery.

 WARNING!

Leaving the Cruise Control system on when

not in use is dangerous. You could accidentally

set the system or cause it to go faster than you

want. You could lose control and have an

accident. Always ensure the system is OFF

when you are not using it.

CarManuals2.com

99

If needed (when overtaking for instance), you can

accelerate beyond the set speed by pressing the

accelerator. When you release the pedal, the

vehicle will return to the previously set speed.
When traveling downhill with the system active,

the vehicle speed may slightly exceed the set one.
NOTE:

Before pushing the SET switch, the vehicle must

be traveling at a constant speed on a flat surface.

To Vary The Speed Setting

To Increase Or Decrease The Set Speed
When the Cruise Control is set, you can increase

the speed by pushing the SET switch upward or

decrease the speed by pushing the SET switch

downward.
U.S. Speed (mph)

Pushing the SET switch once will result in a

1 mph speed adjustment. Each subsequent

movement of the switch results in an

adjustment of 1 mph.

If the switch is continually pushed, the set

speed will continue to adjust until the switch is

released, then the new set speed will be

established.

Metric Speed (km/h)

Pushing the SET switch once will result in a

1 km/h speed adjustment. Each subsequent

movement of the switch results in an

adjustment of 1 km/h.

If the switch is continually pushed, the set

speed will continue to adjust until the switch is

released, then the new set speed will be

established.

NOTE:

Moving the SET switch allows for adjusting of the

speed according to the selected unit of measure

-

ment set on the radio system. Refer to the Infor

-

mation and Entertainment System Owner’s

Manual for more information.

To Accelerate For Passing

While the Cruise Control is set, press the

accelerator to pass as you would normally. When

the pedal is released, the vehicle will return to the

set speed.

Using Cruise Control On Hills
The transmission may downshift on hills to

maintain the vehicle set speed.
The Cruise Control system maintains speed up

and down hills. A slight speed change on

moderate hills is normal. On steep hills, a greater

speed loss or gain may occur so it may be

preferable to drive without Cruise Control.

To Resume Speed

To resume a previously set speed, push the RES

button and release. Resume can be used at any

speed above 20 mph (32 km/h).

NOTE:

Before resuming the previously set speed, you

must accelerate to a speed close to that speed.

Resume Button Location

In AutoStick (sequential) mode, before resuming

the previously set speed, you should accelerate

until you are close to that speed. Then, push and

release the RES button.

To Deactivate

A tap on the brake pedal deactivates the Cruise

Control without deleting the set speed.
The Cruise Control may also be deactivated by

applying the Electric Park Brake or when the

braking system is operated (e.g. operation of the

Electronic Stability Control (ESC) system).
The set speed is deleted in the following cases:

Pushing the on/off button a second time

The ignition is placed in the OFF position

If there is a malfunction with the Cruise Control

 WARNING!

Cruise Control can be dangerous where the

system cannot maintain a constant speed.

Your vehicle could go too fast for the

conditions, and you could lose control and

have an accident. Do not use Cruise Control in

heavy traffic or on roads that are winding, icy,

snow-covered or slippery.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

100

(Continued)

A

DAPTIVE

 C

RUISE

 C

ONTROL

 (ACC)

The Adaptive Cruise Control (ACC) is a driver

assist system that combines the Cruise Control

functions with controlling the distance from the

vehicle ahead. ACC will adjust the vehicle speed

up to the preset speed to maintain a distance

with the vehicle ahead. ACC increases the driving

convenience provided by Cruise Control while

traveling on highways and major roadways.

However, it is not a safety system and not

designed to prevent collisions. The Cruise Control

function performs differently

Ú

page 98.

ACC will allow you to keep Cruise Control engaged

in light to moderate traffic conditions without the

constant need to reset your Cruise Control. ACC

uses a radar sensor located behind the front

bumper and a camera located in the center/

upper part of the windshield, to detect the

presence of a vehicle close ahead.
The system sets and holds the vehicle at the

desired speed without needing to press the

accelerator. It also sets and holds a distance

from the vehicle ahead (these settings are set by

the driver).

Front Bumper Radar Location

Windshield Camera Location

If the system detects a vehicle ahead, it will

automatically intervene by slightly braking or

accelerating in order to maintain the preset

distance. It will not exceed the original set speed

when adapting to the speed of the vehicle ahead.

NOTE:

Adaptive Cruise Control performance is not guar

-

anteed under the following circumstances. You

should not utilize the ACC system when:

Driving in fog, heavy rain, sleet, or snow.

Driving in heavy traffic and complex driving

situations (e.g., in construction zones).

Driving on icy, snowy, slippery roads, roads

with steep inclines or downhill slopes, or roads

with numerous turns and bends.

Entering a turn lane or highway off-ramp.

When circumstances do not allow safe driving

at a constant speed

Ú

page 239.

 WARNING!

Adaptive Cruise Control (ACC) is a

convenience system. It is not a substitute for

active driver involvement. It is always the

driver’s responsibility to be attentive of road,

traffic, and weather conditions, vehicle

speed, distance to the vehicle ahead and,

most importantly, brake operation to ensure

safe operation of the vehicle under all road

conditions. Your complete attention is

always required while driving to maintain

safe control of your vehicle. Failure to follow

these warnings can result in a collision and

death or serious personal injury.

The ACC system:

Does not react to pedestrians, oncoming

vehicles, and stationary objects (e.g., a

stopped vehicle in a traffic jam or a

disabled vehicle).

CarManuals2.com

101

Activating Adaptive Cruise Control (ACC)

The minimum set speed for the ACC system is

19 mph (30 km/h) and the maximum is 110 mph

(180 km/h).
The system cannot be activated:

When pressing the brake pedal.

When the brakes are overheated.

When the Electric Park Brake has been

operated.

When either PARK, REVERSE or NEUTRAL is

engaged.

When the engine RPM is above a maximum

threshold.

When the vehicle speed is not within the

operational speed range.

When the Electronic Stability Control (ESC) (or

Anti-Lock Brake System (ABS) or other stability

control systems) are operating or have just

operated.

When the ESC system is off.

When the Forward Collision Warning system (if

equipped) is braking automatically.

In the event of a system failure.

When the engine is off.

In case of obstruction of the radar sensor (in

this case the bumper area where it is located

must be cleaned).

If the system is set, the conditions described

above also cause a cancellation or deactivation

of the system. These situations may vary

according to the conditions.

NOTE:

The system will not be deactivated when speeds

higher than those set are reached by pressing the

accelerator pedal above 110 mph (180 km/h). In

these situations, the system may not work

correctly and it is recommended to deactivate it.
The driver should always obey traffic laws and

speed limits. Never drive above applicable speed

limit restrictions.

To Activate/Deactivate

The system has four operating states:

Enabled (speed not set)

Activated (speed set)

Paused

Deactivated

To Activate
To enable the system, push and release the on/

off button located on the left side on the steering

wheel.

On/Off Button

Cannot take street, traffic, and weather

conditions into account, and may be

limited upon adverse sight distance

conditions.

Does not always fully recognize complex

driving conditions, which can result in

wrong or missing distance warnings.

Will bring the vehicle to a complete stop

while following a vehicle ahead and hold

the vehicle for approximately two

minutes in the stop position. If the

vehicle ahead does not start moving

within two minutes, the parking brake

will be activated and the ACC system will

be canceled.

You should switch off the ACC system:

When driving in fog, heavy rain, heavy

snow, sleet, heavy traffic, and complex

driving situations (i.e., in highway

construction zones).

When entering a turn lane or highway

off-ramp; when driving on roads that are

winding, icy, snow-covered, slippery, or

have steep uphill or downhill slopes.

When circumstances do not allow safe

driving at a constant speed.

 WARNING!

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

102

When the system is enabled and ready to

operate, the display shows the white ACC icon

above dashes in place of the speed.

Enabled Icons

Setting a speed activates the system. The display

shows the icon in green with the set speed.

To Pause/Deactivate
With the feature enabled (speed not set), push

the on/off button to disable.
With the feature active (speed set), push the on/

off button to pause. The display will show the icon

in white with the speed in brackets. To deactivate

the feature, push the on/off button a second

time.

To Set A Desired Speed

When the vehicle reaches the desired speed,

push the RES/SET switch downward and release

it to activate the system. When the accelerator is

released, the vehicle will maintain the set speed

automatically.

SET Switch

While the accelerator pedal is pressed, the

system will not be able to control the distance

between the vehicle and the one ahead. In this

case, the speed will be determined only by the

position of the accelerator pedal.
The system will return to normal operation as

soon as the accelerator pedal is released.

To Vary The Speed Setting

To Increase Or Decrease The Set Speed
Once the system has been activated, you can

increase the speed by pushing the RES/SET

switch upward or decrease the speed by pushing

the RES/SET switch downward. Each time the

switch is pushed, the speed is adjusted by 1 mph.
Pushing and holding the switch upward or

downward will cause the set speed to adjust in

5 mph increments until the button is released.

The new set speed is reflected in the instrument

cluster display.
NOTE:

Moving the RES/SET switch downward allows

you to adjust the speed according to the

selected unit of measurement ("U.S." or

"Metric") set on the radio system. Refer to the

Information and Entertainment System

Owner’s Manual Supplement for further

information.

When the unit of measurement is set to Metric,

pushing and holding the RES/SET switch will

adjust the speed in 10 km/h increments.

By keeping the accelerator pedal pressed, the

vehicle can continue to accelerate beyond the

set speed. In this case, use the RES/SET

switch to set the speed to the vehicle’s current

speed.

When you push the RES/SET button to reduce

the speed, the braking system intervenes

automatically if the engine brake does not

slow the vehicle down sufficiently to reach the

set speed. The device holds the set speed

uphill and downhill; however a slight variation

is entirely normal, particularly on slight

inclines.

The transmission could shift to a lower gear

when driving downhill, or when accelerating.

This is normal and necessary to maintain the

set speed.

The system will disable while driving if the

brakes overheat.

 WARNING!

Leaving the Adaptive Cruise Control (ACC)

system on when not in use is dangerous. You

could accidentally set the system or cause it to

go faster than you want. You could lose control

and have a collision. Always leave the system

off when you are not using it.

CarManuals2.com

103

(Continued)

To Resume

Once the system has been canceled but not

deactivated, to resume a previously set speed,

simply push the RES/SET switch upward and

remove your foot from the accelerator to recall it.
The system will be set to the last stored speed.

Setting The Distance Between Vehicles

The distance between your vehicle and the

vehicle ahead may be set to one bar (short), two

bars (medium), three bars (long), or four bars

(maximum).

Distance Icons

The distances from the vehicle ahead are propor

-

tional to speed.
The interval of time with relation to the vehicle

ahead remains constant and varies from one

second (for the short distance one-bar setting) to

two seconds (for the maximum distance four-bar

setting).
The set distance is shown on the display by a

dedicated icon.
The setting is four bars (maximum) the first time

the system is used. After the distance has been

modified by the driver, the new distance will be

stored even if the system is deactivated and

reactivated.
To Decrease The Distance
Push and release the distance button to decrease

the distance setting. The distance setting

decreases by one bar (shorter) every time the

button is pushed.

Distance Button

The set speed is held if there are no vehicles

ahead. Once the shortest distance has been

selected, the next push of the button will set the

maximum distance.

If a slower vehicle is detected in the same lane,

the vehicle icon on the display illuminates from

grey to white. The system automatically adjusts

the vehicle’s speed to keep the set distance,

independently of the set speed.
The vehicle holds the set distance until:

The vehicle ahead accelerates to a speed

higher than the set speed.

The vehicle ahead leaves the lane or the

detection field of the Adaptive Cruise Control

system sensor.

The distance setting is changed.

The Adaptive Cruise Control system is

deactivated/paused.

 WARNING!

The Resume function should only be used if

traffic and road conditions permit. Resuming a

set speed that is too high or too low for

prevailing traffic and road conditions could

cause the vehicle to accelerate or decelerate

too sharply for safe operation. Failure to follow

these warnings can result in a collision and

death or serious personal injury.

 WARNING!

The maximum braking applied by the system

is limited. The driver may apply the brakes in

all cases if needed.

If the system predicts that the braking level is

insufficient to hold the set distance, either

“BRAKE!” or a dedicated message is

displayed to warn the driver of approaching

the vehicle ahead. An acoustic signal is also

emitted. In this case, it is advised to brake

immediately as necessary to hold a safe

distance from the vehicle ahead.

The driver is responsible for ensuring that

there are no pedestrians, other vehicles or

objects along the direction of the vehicle.

Failure to comply with these precautions may

cause serious accidents and injuries.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

104

Overtake Aid

When driving with ACC engaged and following a

vehicle at a speed greater than 45 mph (70 km/h),

the system will provide an additional acceleration

up to the ACC set speed to assist in passing the

vehicle. This additional acceleration is triggered

when the driver utilizes the left turn signal and will

only be active when passing on the left hand side.
The system detects the direction of traffic

automatically when the vehicle passes from left

hand traffic to right hand traffic. In this case, the

overtaking assist function is only active when the

reference vehicle is overtaken on the right. The

additional acceleration is deactivated when the

driver uses the right direction indicator and

returns to the original lane.

Stop And Go Function

The Stop and Go operating strategy allows you to

maintain a safe distance from the vehicle ahead

until the vehicle has completely stopped.
In the event that the ACC system brings your

vehicle to a standstill while following the vehicle

in front, if the vehicle in front starts moving within

two seconds of your vehicle coming to a

standstill, your vehicle will resume motion

without the need for any driver action.

If the vehicle in front does not start moving within

two seconds of your vehicle coming to a

standstill, the driver will have to push the RES/

SET switch upward to restart.

Deactivation

The system is deactivated and the set speed is

canceled if:

The on/off button is pushed (when the system

is on or paused)

The ignition is placed in the OFF position

RACE mode is activated (Quadrifoglio models)

The system is canceled (the set speed and

distance are stored):

When the system is paused

Ú

page 101

When the conditions shown in the “Activating

Adaptive Cruise Control (ACC)” section occur

Ú

page 101

Limited Operation Warning

If the dedicated message is shown on the display,

a condition limiting the Adaptive Cruise Control

operation may have occurred.

This could be due to an obstruction of the

vehicle’s sensor or camera. It could also be due

to a fault in the system. If an obstruction is

detected, clean the area of the windshield

opposite the interior rearview mirror, where the

camera is located, as well as the area of the front

bumper where the sensor is located. Then check

that the message has disappeared.
When the conditions limiting the system

functions end, normal operation will resume.
Should the fault persist, contact an authorized

dealer.

Precautions While Driving With ACC

In certain driving situations, ACC may have

detection issues. In these cases, ACC may brake

late or unexpectedly. The driver needs to stay

alert and may need to intervene. The following

are examples of these types of situations:

Offset Driving
ACC may not detect a vehicle in the same lane

that is offset from your direct line of travel, or a

vehicle merging in from a side lane. There may

not be sufficient distance to the vehicle ahead.

The offset vehicle may move in and out of the line

of travel, which can cause your vehicle to brake or

accelerate unexpectedly.

Turns And Bends
When driving on a curve with ACC engaged, the

system may increase or decrease the vehicle

speed for stability, with no vehicle ahead

detected. Once the vehicle is out of the curve the

system will resume your original set speed. This is

a part of normal ACC system functionality.

The driver is fully responsible for holding a

safe distance from the vehicle ahead

respecting the highway code in force in the

respective country.

 WARNING!

 WARNING!

When the ACC system is resumed, the driver

must ensure that there are no pedestrians,

vehicles or objects in the path of the vehicle.

Failure to follow these warnings can result in a

collision and death or serious personal injury.

CarManuals2.com

105

NOTE:

On tight turns ACC performance may be

limited. In this case, it is advisable to

deactivate the system.

The system only limits the speed DURING a

bend and not BEFORE it.

Turn Or Bend Example

Using ACC On Hills
When driving on hills, ACC may not detect a

vehicle in your lane. Depending on speed, vehicle

load, traffic conditions, and the steepness of the

hills, ACC performance may be limited.
NOTE:

The driver must maintain control of the vehicle,

remain alert, and be ready to apply the brakes if

needed.

Lane Changing
ACC may not detect a vehicle until it is completely

in the lane in which you are traveling. In the

following lane changing example, ACC has not yet

detected the vehicle changing lanes and it may

not detect the vehicle until it's too late for the ACC

system to take action. ACC may not detect a

vehicle until it is completely in the lane. There

may not be sufficient distance to the

lane-changing vehicle. Always be attentive and

ready to apply the brakes if necessary.

Lane Changing Example

Narrow Vehicles
Some narrow vehicles traveling near the outer

edges of the lane or edging into the lane are not

detected until they have moved fully into the lane.

There may not be sufficient distance to the

vehicle ahead.

Narrow Vehicle Example

Stationary Objects And Vehicles
The ACC system can detect stationary vehicles

when the vehicle is traveling at speeds between

2 mph and 35 mph (4 km/h and 60 km/h). The

driver should always be attentive and be ready to

press the brakes if necessary.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

106

Objects And Vehicles Moving In Opposite Or

Crosswise Direction
The system cannot detect the presence of

objects or vehicles traveling in opposite or

crosswise directions and consequently will not

activate

Ú

page 239.

Objects And Vehicles Moving In Opposite Or

Crosswise Direction

IFETEL: RCPBOMR 14-0766
La operación de este equipo está sujeta a las

siguientes dos condiciones:
1. es posible que este equipo o dispositivo no

cause interferencia perjudicial y

2. este equipo o dispositivo debe aceptar cual

-

quier interferencia, incluyendo la que pueda

causar su operación no deseada.

Changes or modifications made to this

equipment not expressly approved by Robert

BOSCH GmbH may void the FCC authorization to

operate this equipment.
This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not

installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area is likely to

cause harmful interference in which case the

user will be required to correct the interference at

his own expense.
Toutes modifications apportées à cet

équipement qui ne sont pas expressément

homologuées par Robert BOSCH GmbH peuvent

annuler l'autorisation de la FCC de faire

fonctionner cet équipement.
Cet appareil a été vérifié et s'est révélé conforme

aux normes applicables aux appareils

numériques de catégorie A, en vertu de la section

15 des règlements de la FCC. Ces normes sont

définies pour fournir une protection raisonnable

contre les interférences nuisibles lorsque

l'équipement est utilisé dans les installations

résidentielles. Cet appareil génère, utilise et peut

émettre des ondes radioélectriques et, s'il n'est

pas installé et utilisé conformément au manuel

d’instruction, peut causer un brouillage

radioélectrique nuisible aux communications

radio. Le fonctionnement de cet équipement

dans une zone résidentielle est susceptible de

causer des interférences nuisibles; dans ce cas,

l'usager doit corriger les interférences à ses

propres frais.
Radio Frequency Exposure Information
This equipment complies with FCC radiation

exposure limits set forth for an uncontrolled

environment. This equipment should be installed

and operated with minimum distance of 20 cm

between the radiator and your body.
This transmitter must not be co-located or

operating in conjunction with any other antenna

or transmitter.
Déclaration d’exposition aux radiations
Cet équipement est conforme aux limites

d'exposition aux rayonnements IC établies pour

un environnement non contrôlé. Cet équipement

doit être installé et utilisé avec un minimum de

20 cm de distance entre la source de

rayonnement et votre corps.
Ce transmetteur ne doit pas etre place au meme

endroit ou utilise simultanement avec un autre

transmetteur ou antenne.

HIGHWAY ASSIST SYSTEM

(HAS) — IF EQUIPPED

The Highway Assist System (HAS) is a driving

assistance system that is only available when

driving on highways. The system operates up to

speeds of 90 mph (145 km/h).
The system uses information from the front

camera and radar to help keep the vehicle in the

center of the lane and at a constant speed.
The HAS system combines Adaptive Cruise

Control (ACC) functions with lane centering logic

to control the trajectory of the vehicle. The HAS

system requires the driver’s hands to remain on

the steering wheel.
Once HAS is activated, a dedicated screen will

appear on the instrument cluster display.

CarManuals2.com

107

T

O

 A

CTIVATE

/D

EACTIVATE

To Activate
To activate the HAS system, push the button

located on the left side of the steering wheel.

Highway Assist Button

Suspension Conditions
The following operations will suspend the HAS

system:

Steer manually

Press the brake pedal

Disable the ACC device

Activate the turn signals

Push the ACC activation setting button for two

seconds to activate Cruise Control

Place the gear selector in PARK, REVERSE, or

NEUTRAL

Reactivating the ACC system will reactivate HAS

Ú

page 100.

Automatic Deactivation
The system can be deactivated in any of the

following situations:

If there are narrow bends

When hands are removed from the steering

wheel

If the left or right turn signal is activated

If the driver intentionally changes lanes

without using the turn signal

If the driver’s seat belt is released

If the gear selector is placed in DRIVE

If the “Active Braking” function is activated

Ú

page 138

If the vehicle exits the highway

If the lane markings are not detected by the

camera

If the ACC device is deactivated

If the vehicle speed exceeds 90 mph (145 km/h)

NOTE:

When the HAS system is turned off, the symbol

on the display turns red and then grey.

Hands on the steering wheel are detected by a

capacitive sensor within the steering wheel.

When the automatic suspension conditions are

over, HAS will be automatically reactivated.

O

PERATION

The HAS system only operates when the driver’s

hands are on the steering wheel.
If the system detects that the driver’s hands have

been removed from the steering wheel, the

system will alert the driver to place their hands

back on the steering wheel

Ú

page 108.

If the vehicle crosses the lane boundary, the

steering wheel will vibrate and the dedicated

screen will appear in the instrument cluster

display.
NOTE:

The HAS system may take up to five seconds to

turn on once all conditions are met. During this

time, a grey indicator light will appear on the

instrument cluster display and the system will

automatically activate as soon as all of the condi

-

tions are met with no intervention from the driver.
The following conditions must be met before the

HAS system turns on:

The HAS system must be enabled by pushing

the button on the steering wheel

The vehicle must be on a highway

ACC must be activated

The right and left lane boundaries must be

visible

The vehicle speed must be between 0 and

90 mph (0 and 145 km/h)

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

108

The camera, radar, and radio system must be

functioning properly

The road lane width must be between 8.5 ft

and 13.7 ft (2.6 m and 4.2 m)

The turn signals must not be activated

The HAS system must be functioning properly

Other operating limits:

If the speed of ACC can be set to a higher value

(top speed 110 mph (180 km/h), HAS is only

available as long as the vehicle speed is equal

to or less than 90 mph (145 km/h).

When the ACC speed is reduced and the

vehicle speed is less than 90 mph (145 km/h),

the system will automatically reactivate.

If the ACC speed is set to 90 mph (145 km/h),

traveling downhill may increase the vehicle

speed. The HAS system will deactivate until the

speed returns to 90 mph (145 km/h).

I

NDICATIONS

 O

N

 T

HE

 D

ISPLAY

The HAS system status can always be viewed in

the instrument cluster display.
The system status is indicated by the color of the

symbol on the display.
The HAS system uses sensors in the steering

wheel to detect if the driver’s hands are on it.
If the driver’s hands are not on the steering

wheel, a series of warnings will appear in the

instrument cluster display to alert the driver to

reposition their hands on the steering wheel. An

acoustic signal will also sound. After a period of

time, the HAS system will disable if the driver’s

hands do not return to the steering wheel.

After a period of time, the HAS system will disable

if the driver has not repositioned their hands on

the steering wheel.
When the system does not detect hands on the

steering wheel, it will warn the driver by displaying

a dedicated screen on the instrument cluster

display.

S

YSTEM

 S

TATUS

Active System
When the system is active, the following screen

will appear in the “Driver Assistance” menu on

the instrument cluster display.

HAS Active

If on a different menu screen, a symbol will

appear on the instrument cluster display

indicating that the system is active.
When the driver’s hands are removed from the

steering wheel, the system disables after a few

seconds. A screen will appear in the instrument

cluster display warning the driver to return their

hands to the steering wheel.

Active System (Hands Removed From The

Steering Wheel For A Short Time)
As soon as the driver removes their hands from

the steering wheel, the following screen will

appear in the instrument cluster display. The

system will remain active at this time.

Hands Removed Initial Warning

If the driver does not return their hands to the

steering wheel within a few seconds, the

following screen will appear in the instrument

cluster display.

Hands Removed Secondary Warning

CarManuals2.com

109

(Continued)

Active System (Hands Removed From The

Steering Wheel For A Long Time)
If the driver still has not returned their hands to

the steering wheel after the screen above is

displayed, the following screen will now appear in

the instrument cluster display, and an acoustic

signal will sound until the driver regains control of

the vehicle.

Hands Removed Final Warning

If the driver’s hands are not returned to the

steering wheel after an extended period of time,

a deactivation message will appear on the

instrument cluster display. The steering wheel

control will be deactivated.
This display will remain active even when the

driver’s hands are removed from the steering

wheel. The symbol on the display will turn grey.
The ACC system and Lane Departure Warning

systems will also be disabled.
When HAS is active, the Lane Keeping Assist

(LKA)/ Lane Departure Warning (LDW) systems (if

equipped), if previously activated, will remain

activated.

L

IMITED

 S

YSTEM

 A

VAILABILITY

/

O

PERATION

System Availability
External factors and conditions may affect the

proper operation of the HAS system, such as:

Narrow, winding, curvy streets

Poor visibility (due to heavy rain, snow, fog,

etc.)

Front lights of oncoming vehicles or direct

sunlight or shade

Damage or obstructions caused by mud, ice,

snow, etc.

Bumper damaged or not aligned

Interference with other equipment that causes

electromagnetic waves

Presence of roadwork/road construction sites

If the indications given by the navigation

system (if any) of the radio system are not yet

ready and/or if the navigation system is

recalculating the route

System Limited Operation
The HAS system may have limited or reduced

functionality when one of the following conditions

occur:

Lane markings are not clear or in conditions of

poor visibility (e.g. in heavy rain, snow, fog,

etc.)

Either the camera or radar are damaged,

covered, or obstructed (e.g. by mud, ice, snow,

etc.)

When driving on hills or roads with narrow

bends

Near highway toll booths

When the highway entrance or exit is wider

than 20 ft (6 m)

If the camera is exposed to glare caused by

reflections or direct sunlight

If the navigation system information is

unavailable or being recalculated

NOTE:

If the vehicle approaches a bend that is too

narrow with respect to the current speed, the

HAS system will disable.

If damage to the windshield occurs, have the

windshield replaced by an authorized dealer as

soon as possible.

 WARNING!

To prevent serious injury or death:

Always remain alert and be ready to take

control of the vehicle in the event that the

HAS system disables.

Always keep your hands on the steering

wheel when the HAS system is activated.

Maintain a safe distance from other vehicles

and pay attention to traffic conditions.

Do not place any objects on the steering

wheel (e.g. steering wheel covers) which

could interfere with the hand detection

sensor.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

110

TRAFFIC JAM ASSIST (TJA)

SYSTEM — IF EQUIPPED

The Traffic Jam Assist (TJA) system can be

activated on all road types. The system uses a

camera and radar sensors located on the front

fascia/bumper to detect lane markings and keep

the vehicle in the center of the lane.
When the system is unable to detect lane

markings, it will still operate using surrounding

traffic. This can occur in congested traffic

scenarios, when the vehicles ahead or

surrounding obstruct the visibility of the lane

markings. When the speed is below 12 mph

(20 km/h), the system can use a lock-on strategy

that allows the vehicle to automatically follow the

vehicle ahead.
The TJA system combines Adaptive Cruise Control

(ACC) functions with Lane Departure Warning

functions to maintain vehicle speed and steering

wheel behavior.

NOTE:

Do not use the TJA system while driving in urban

areas.

T

O

 A

CTIVATE

/D

EACTIVATE

To activate the system, push the button on the

left side of the steering wheel.
To deactivate the system, push the button again.

Traffic Jam Assist Button

Suspension Conditions
The following operations will suspend the TJA

system:

Pressing the brake pedal

Opening the driver’s door

Disabling ACC

If the vehicle speed exceeds 37 mph (60 km/h)

Releasing the driver’s seat belt

Placing the gear selector in PARK, REVERSE, or

NEUTRAL

If the Forward Collision Warning system or

“Active Braking” intervenes

Automatic Deactivation
System operation will be temporarily disabled

under the following conditions:

When traveling around narrow bends

If the lane boundaries are not detected

One of the two lines is interrupted

The sun is low and reflects on the radar

camera

If the turn signals are activated

If the driver intentionally changes lanes

without using the turn signal

If manual steering begins

If the driver’s hands are removed from the

steering wheel

When there is no surrounding traffic and there

are no horizontal lane boundaries

If the system is not functioning properly

If lateral acceleration is high

ALWAYS obey traffic laws and pay attention

to the road. ALWAYS drive safely with your

hands on the steering wheel. You have full

responsibility and assume all risks related to

the use of the features and applications in

this vehicle. Only use the features and

applications when it is safe to do so. Failure

to do so may result in an accident involving

serious injury or death.

 WARNING!

 WARNING!

You should switch off the TJA system:

When driving in fog, heavy rain, heavy snow,

sleet, heavy traffic, and complex driving

situations (i.e., in highway construction

zones).

When entering a turn lane or highway

off-ramp; when driving on roads that are

winding, icy, snow-covered, slippery, or have

steep uphill or downhill slopes.

When circumstances do not allow safe

driving at a constant speed.

CarManuals2.com

111

NOTE:

When TJA is turned off, the symbol in the

instrument cluster display will turn red, and

then grey.

A sensor in the steering wheel detects whether

the driver’s hands are placed on the steering

wheel.

When the automatic suspension conditions are

over, the TJA system will be automatically

reactivated.

O

PERATION

The TJA system can only operate when the

driver’s hands are on the steering wheel.
If the system detects that the driver’s hands have

been removed from the steering wheel, a

message will appear in the instrument cluster

display to alert the driver to place their hands

back on the wheel.
NOTE:

If the vehicle begins to cross the lane

boundary, the steering wheel will vibrate and a

dedicated screen will appear in the instrument

cluster display.

The TJA system may take up to five seconds to

become active once all conditions are met.

The following conditions must be met in order to

activate the system:

The TJA system must be enabled

The Adaptive Cruise Control (ACC) system must

be turned on

The right and left lane boundaries must be

recognized by the system

The vehicle must be traveling at a speed

between 0 and 37 mph (0 and 60 km/h)

The camera, radar, and radio system must be

functioning properly

The road lane width must be between 8.5 ft

and 13.7 ft (2.6 m and 4.2 m)

The turn signals must be turned off

The TJA system must be functioning properly

If the ACC speed is set to 37 mph (60 km/h) or

less, traveling downhill may increase the

vehicle speed. The system will remain inactive

until the speed returns to 37 mph (60 km/h) or

less.

I

NDICATIONS

 O

N

 T

HE

 D

ISPLAY

The TJA system status is indicated by the color of

the symbol in the instrument cluster display.
The system uses sensors in the steering wheel to

detect if the driver’s hands are present. If the

driver’s hands are removed, a series of warnings

will appear in the instrument cluster display to

alert the driver to reposition their hands on the

steering wheel. Acoustic signals will also be

emitted.
If the driver’s hands are not returned to the

steering wheel after a period of time, the system

will be disabled.

S

YSTEM

 S

TATUS

Active System
An active system is indicated by the following

screen in the “Driver Assistance” menu on the

instrument cluster display.

TJA System Active

Active System (Hands Removed From The

Steering Wheel For A Short Time)
The following screen will appear in the instrument

cluster display immediately after the driver’s

hands are removed from the steering wheel. The

system still remains active at this time.

Hands Removed Initial Warning

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

112

If the driver does not return their hands to the

steering wheel within a few seconds, the

following screen will appear in the instrument

cluster display.

Hands Removed Secondary Warning

Active System (Hands Removed From The

Steering Wheel For A Long Time)
If the driver’s hands have still not been returned

to the steering wheel, the following screen will

appear in the instrument cluster display.

Hands Removed Final Warning

An acoustic signal will sound until the driver

regains control of the vehicle (hands on steering

wheel). The system is still active at this time.

If the driver’s hands are not returned to the

steering wheel after a period of time, a deacti

-

vation message will appear on the instrument

cluster display and the steering wheel control will

be deactivated.
Once the indicator light on the display turns grey,

the system is no longer active and the driver must

take control of the vehicle. At this time, the

Adaptive Cruise Control (ACC) system and Lane

Departure Warning system will also be disabled.
When the TJA system is active, the Lane Keeping

Assist (LKA)/Lane Departure Warning (LDW)

systems (if equipped) will be temporarily

disabled. When TJA is not active, the LKA system

Ú

page 120 and LDW system

Ú

page 118 will

remain active.

L

IMITED

 S

YSTEM

 A

VAILABILITY

/

O

PERATION

System Availability
Performance of the TJA system may be affected

by the following factors:

Narrow, winding, curvy streets

Lane boundaries that are not clear or in

conditions of poor visibility (e.g. heavy rain,

snow, fog, etc.)

If the camera is exposed to glare from direct

sunlight or headlights of an oncoming vehicle

If the camera or sensor is damaged, covered,

or obstructed (e.g. by mud, ice, snow, etc.)

The bumper is damaged or misaligned

Interference with other equipment causes

electromagnetic waves

Construction sites

If the indications given by the navigation

system of the radio system are not yet ready or

if the system is recalculating

System Limited Operation
The TJA system may have limited or reduced

functionality when one of the following conditions

occurs:

Lane boundaries are not clear or in conditions

of poor visibility (e.g. in heavy rain, snow, fog,

etc.)

Either the camera or radar are damaged,

covered, or obstructed (e.g. by mud, ice, snow,

etc.)

When driving on hills or narrow bends

Near highway toll booths

When the highway entrance or exit is more

than 20 ft (6 m) wide

If the camera is exposed to glare from

reflections or direct sunlight

NOTE:

If damage to the windshield occurs, have the

windshield replaced by an authorized dealer

as soon as possible.

If the vehicle approaches a bend that is too

narrow with respect to the current speed, the

TJA system will deactivate.

CarManuals2.com

113

TRAFFIC SIGN

RECOGNITION (TSR)

SYSTEM — IF EQUIPPED

The Traffic Sign Recognition (TSR) system uses a

camera mounted on the windshield to detect

recognizable road signs such as:

Speed limits

No passing zones

Signs indicating the end of the situations

indicated above

If the camera does not detect valid speed limits,

the radio system navigation system may suggest

unregulated speed limits.
The system always checks the traffic signs

indicating the current speed limit signs. The

system is able to recognize and display up to two

different road signs in the instrument cluster

display.
Depending on the unit of measurement (km/h or

mph) set through the “Unit of Measurement”

menu in the radio system, the TSR system will

automatically show the indication of the road sign

in the unit of measurements selected in the

instrument cluster display.

T

O

 A

CTIVATE

/D

EACTIVATE

The TSR System can be activated/deactivated in

the radio system in the “Driver Assistance” menu.

The system activation is signaled by road signs

shown on the instrument cluster display.
NOTE:

The TSR system will reset to the default setting

when the vehicle is restarted.
NOTE:

By selecting “Blinking”, the driver can activate

a warning to display when the speed exceeds

the limit indicated by the TSR System. The

speed road sign on the instrument cluster

display will blink until the vehicle speed drops

below the displayed limit.

Selecting “Offset” will set the speed at which

“Blinking” is activated up to a maximum of

6 mph (10 km/h) above the limit detected by

the system.

If no speed limit signs are found, the system

will revert to the speed limit signs that are

stored in the NAV system.

I

NDICATIONS

 O

N

 T

HE

 D

ISPLAY

The system status can always be viewed through

the instrument cluster display.
The instrument cluster display shows only the

speed limit indications and consists of the

following steps:

The new speed limit recognized by the system,

which is indicated by means of a

predetermined color. The road sign indicating

the end of the speed limit or a “Road Sign Not

Detected” message may appear in this zone.

After a predetermined distance, the previously

displayed road sign changes color to inform

the driver that the speed limit provided may no

longer be valid.

If the camera does not detect valid speed

limits, the navigation system may suggest

unregulated speed limits on the instrument

panel display.

 WARNING!

To prevent serious injury or death:

Always remain alert and be ready to take

control of the car in the event that the TJA

system disables.

Always keep your hands on the steering

wheel when the TJA system is activated.

Maintain a safe distance from other vehicles

and pay attention to traffic conditions.

The TJA system should only be used as a

driving aid. The driver must always pay

attention to their surroundings when the

system is operating and be ready to take

control of the vehicle at any time.

Do not place any objects on the steering

wheel (e.g. steering wheel covers) that could

interfere with the hand detection sensor on

the steering wheel.

CarManuals2.com

STARTING AN

D O

PERA

TIN

G

114

Traffic Signs Detected

INTELLIGENT SPEED

CONTROL (ISC) SYSTEM —

IF EQUIPPED

The Intelligent Speed Control (ISC) system is

always paired with the Adaptive Cruise Control

(ACC) system. The ISC system suggests an

automatic speed adjustment to the driver based

on the speed limit for the road being traveled. The

driver can decide whether to accept or reject the

automatic speed adjustment, using the switch on

the steering wheel.
If the speed limit is exceeded according to the

road signs or traffic conditions, a dedicated

graphic message is displayed on the instrument

panel display.
NOTE:

The driver should always obey traffic laws and

speed limits. Never drive above the applicable

speed limit restrictions.

RES/SET Switch

T

O

 A

CTIVATE

/D

EACTIVATE

To Activate
The system can be activated in the radio system

within the “Driver Assistance” menu. The symbol

illuminates in the instrument cluster display

when the system is active.

1 — ISC System Active

To Deactivate
The system is deactivated under the following

conditions:

When the Traffic Sign Recognition (TSR)

system is deactivated

When the Adaptive Cruise Control (ACC)

system is deactivated

NOTE:

Selecting “Speed Offset” allows the driver to set

the speed up to a maximum of 6 mph (10 km/h)

above or below the suggested speed set by the

ISC system. In this instance, the road sign infor

-

mation shown in the instrument cluster display

will continue to be detected by the TSR system.

1 — Speed Limit Recognized
2 — Traffic Sign Recognized

 CAUTION!

Functionality may be limited or the system

may not work if the sensor is obstructed.

The system may have limited operation or

not work at all in weather conditions such as

heavy rain, hail, thick fog, and low

temperatures. Strong light contrasts can

influence the recognition capability of the

sensor.

The area surrounding the sensor must not be

covered with stickers or any other object.

Do not tamper or perform any operations in

the area of the windshield glass directly

surrounding the sensor.

Clean foreign matters such as bird

droppings, insects, snow or ice on the

windshield. Use specific detergents and

clean cloths to avoid scratching the

windshield.

CarManuals2.com

















Content      ..     1      2      3      4      ..
