ARI0801I DBS Utility started: 11/13/89 17:42:51

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

-----—> COMMENT ’***********************************************

-----—>

***

BLOCK FORMAT PRINTOUT EXAMPLE

***

-----—>

***********************************************’

-----—> CONNECT "MIKE

" IDENTIFIED BY ********;

ARI8004I User MIKE connected to database SQLDBA.

ARI0500I SQL processing was successful.

ARI0505I SQLCODE= 0

SQLSTATE = 00000

ROWCOUNT = 0

-----—> ALTER TABLE ACTIVITY ADD

-----—>

"FULL DESCRIPTION" VARCHAR(250);

ARI0500I SQL PROCESSING WAS SUCCESSFUL.

ARI0505I SQLCODE= 0

SQLSTATE = 00000

ROWCOUNT = 0

-----—> UPDATE ACTIVITY SET "FULL DESCRIPTION" = ’A FULL DESCRIPTION

-----—> OF ACTIVITIES WOULD BE DISPLAYED HERE. THE DESCRIPTION COU

-----—> LD OVERFLOW TO THE NEXT DISPLAY LINE FOR THE COLUMN BECAUSE

-----—> THE COLUMN CAN CONTAIN UP TO 250 DATA POSITIONS’;

ARI0500I SQL processing was successful.

ARI0505I SQLCODE= 0

SQLSTATE = 00000

ROWCOUNT = 0

-----—> SELECT * FROM ACTIVITY WHERE ACTNO < 30

SELECT * FROM ACTIVITY WHERE ACTNO < 30

PAGE 1

*****

ACTNO:

ACTKWD: MANAGE

ACTDESC: MANAGE/ADVISE

FULL DESCRIPTION: A FULL DESCRIPTION OF ACTIVITIES WOULD BE DISPLAY

ED HERE. THE DESCRIPTION COULD OVERFLOW TO THE N

EXT DISPLAY LINE FOR THE COLUMN BECAUSE THE COLUM

N CAN CONTAIN UP TO 250 DATA POSITIONS

*****

ACTNO:

ACTKWD: ECOST

ACTDESC: ESTIMATE COST

FULL DESCRIPTION: A FULL DESCRIPTION OF ACTIVITIES WOULD BE DISPLAY

ED HERE. THE DESCRIPTION COULD OVERFLOW TO THE N

EXT DISPLAY LINE FOR THE COLUMN BECAUSE THE COLUM

N CAN CONTAIN UP TO 250 DATA POSITIONS

ARI0850I SQL SELECT processing successful: Rowcount = 2

Figure 52. Sample Printout of Block Output Format

As in a tabular format query result, the block format has a heading and page

number; from there on, however, differences appear. Each row of the query result

is presented in a separate block of lines preceded by a subheading that identifies

the number of the row in the answer set. Individual fields of a row are preceded

by their column names and are to be read from left to right, and top to bottom.

The list form of output is similar to block form. Figure 53 on page 99 shows an

example of the list output format.

Database Services Utility

SELECT * FROM DEPARTMENT

PAGE 1

***ROW: 1

DEPTNO: A00

DEPTNAME: SPIFFY COMPUTER SERVICES DIV.

MGRNO:

000010

ADMRDEPT: A00

FULL DESCRIPTION: A FULL DESCRIPTION OF THE DEPARTMENT WOULD BE

DISPLAYED HERE. THE DESCRIPTION COULD OVERFLOW TO

THE NEXT DISPLAY LINE FOR THE COLUMN.

Figure 53. Sample Printout of List Output Format

The list output format resembles the block output format in that there is a heading

and page number. Each row of the query result is presented in a separate list of

records or lines preceded by a subheading that identifies the number of the row in

the answer set. Individual fields of a row are preceded by their column names and

are presented in separate records. The difference, however, is that with list output

format, the output for each selected row begins on a new page, and the column

name and data for each select-list column begins on a new output record or

display line.

You can specify the format used by the Database Services Utility for SQL SELECT

statement output by using either the SET FORMAT command or the FORMAT

control parameter. If you do not specify the format to be used, the Database

Services Utility uses column or block format as appropriate. For more information

on the SET FORMAT command, refer to “SET FORMAT” on page 217. For a

description of the control parameter FORMAT, see “Database Services Utility

Control Parameters” on page 115.

Using the LIST Parameter on a DATALOAD Command

The example in Figure 54 shows the output from a DATALOAD command that

was processed with the LIST(YES) option of the INFILE subcommand in effect.

———————> DATALOAD TABLE (SQLDBA.ACTIVITY) IF POS(1)=’Y’

———————> ACTNO

2—11

———————> ACTDESC

12—111

┌─────────┐

———————> INFILE (* LIST(YES) CONTINUED(YES))

│Record 1.│

ARI0852I DATALOAD PROCESSING STARTED.

└──┬──────┘

N2345678901THE DATA IN THIS RECORD IS NOT LOADED INTO THE TABLE.

◄───────────────┘

XY2345678902THIS DESCRIPTION OF AN ACTIVITY FILLS UP A WHOLE PHYSICAL INPUT

┌─────────┐

RECORD AND CONTINUES.

◄─────┤Record 2.│

XY2345678903THIS ACTIVITY DESCRIPTION DOES NOT FILL THE RECORD.

◄────────────┐ └─────────┘

◄────────────────────────┐

——————> ENDDATA

┌──┴───────────────┐

┌─┴───────┐

ARI0875I 2 row(s) loaded into table SQLDBA.ACTIVITY. │This blank line

│

│Record 3.│

ARI0855I DATALOAD processing successful.

│contains positions│

└─────────┘

│80-111 of data

│

│record 3.

│

└──────────────────┘

Figure 54. Using YES in the LIST Parameter

With continued record processing, each field of the records must contain the

maximum number of characters. The second and third records’ ACTDESC fields

Chapter 6. Interpreting the Output of the Database Services Utility

are 100 characters in length because they are to be loaded (position 1 is Y). The

system does not check the length of the first record’s ACTDESC field because this

record is not to be loaded (position 1 is N).

The example in Figure 55 shows output for a DATALOAD command that was

processed using the LIST(NO) option of the INFILE subcommand:

------> DATALOAD TABLE (SQLDBA.ACTIVITY) IF POS(1)=’Y’

------> ACTNO

2-11

------> ACTDESC

12-111

------> INFILE (* LIST(NO) CONTINUED(YES))

ARI0852I DATALOAD PROCESSING STARTED.

------> ENDDATA

ARI0875I 2 row(s) loaded into table SQLDBA.ACTIVITY.

ARI0855I DATALOAD processing successful.

Figure 55. Using NO in the LIST Parameter

Reading Report and Message-File Output in Error Recovery

Reading messages, command input, and data in output reports and message files

is an important task performed frequently by users of the Database Services Utility.

To read DB2 Server for VSE report output to recover from an error, proceed as

follows:

Check the messages at the end of the report to determine whether the utility

job ended without error. Message records begin with ARI.

If the job ran with errors, read all the messages, working backward from the

end until you reach the point of the (initial) error message. Note this spot in

the report so that you can easily return to it.

If data is included in the report, scan the query result to see how serious the

error is.

If you find the cause of the error, take corrective action and run the job again; if

you do not find the cause, inspect the command input for syntax errors.

Command-input lines begin with arrows (-----—>).

If the cause of the error is still unknown, determine whether it is a DB2 Server

for VSE error or a Database Services Utility error. Look up the error message in

the DB2 Server for VSE Messages and Codes manual and follow the

recommended recovery procedure, as applicable.

If the cause of the error appears to be related to the Database Services Utility,

review information in Chapter 9, “Error Handling and Debugging,” on page

223, and apply appropriate corrective action.

If the error persists, see your database administrator.

To read DB2 Server for VM message file output to recover from an error, proceed

as follows:

Print or display the message file to be read.

Check the messages at the end of the file to determine whether the utility job

ended without error. Message lines begin with ARI.

If the job did not run without errors, read all the message lines, working

backward from the end until you reach the point of the (initial) error message.

Note this spot in the message file so that you can easily return to it.

If data is included in the message file, scan the query result to see how serious

the error is.

100

Database Services Utility

5. If you find the cause of the error, take corrective action and run the job again; if

you do not find the cause, inspect the command input for syntax errors.

Command-input lines begin with arrows (-----—>).

6. If the cause of the error is still unknown, determine whether it is a DB2 Server

for VM error or a Database Services Utility error. Look up the error message in

the DB2 Server for VM Messages and Codes, and follow the recommended

recovery procedure, as applicable.

7. If the cause of the error appears to be related to the Database Services Utility,

review information in Chapter 9, “Error Handling and Debugging,” on page

223, and apply appropriate corrective action.

8. If the error persists, see your database administrator.

Chapter 6. Interpreting the Output of the Database Services Utility

101

Part 2. Reference

This part of the manual presents additional information on the calling and running

of the Database Services Utility. The material in this section is of primary interest

to database application programmers and system programmers; it includes the

following topics:

v Database Services Utility use from application programs

v Database Services Utility commands: reference

v Database Services Utility error handling and debugging

v Database Services Utility performance considerations.

For further reference material in the form of sample tables, see Appendix A,

“Sample Tables.” Refer to Appendix B, “FILEDEF Command Syntax and Notes,”

on page 249, for a syntax diagram and usage notes about the CMS FILEDEF

command.

103

Chapter 7. Using the Database Services Utility from

Application Programs

This chapter describes the procedures required to initiate Database Services Utility

processing from application programs and how to use the Database Services Utility

application program interface. Rules for naming objects and lists of reserved words

are also provided.

In DB2

Server for VSE

The Database Services Utility is an application program; like any other program, it

must be preprocessed before you can run it. Usually, the utility is preprocessed

during database installation. At that time, the RUN privilege to use the utility is

granted to prospective users; you must possess the RUN privilege to use the

utility. Your system programmer can tell whether the Database Services Utility is

properly installed and whether you are authorized to use it.

The ddname parameter of a Database Services Utility command identifies an

EBCDIC, standard-label sequential data file needed by that command for input or

output. Magnetic tape with a fixed, unblocked record format and a logical record

length and block size of 2 048 bytes is used as a default for these sequential files.

(The record format required varies for each command.)

As indicated in the command descriptions, you can override the defaults and

assign files to a direct access storage device (DASD). A sequential file allocated to

magnetic tape can reside on any device supported by the VSE DTFMT macro; files

allocated to direct access storage can reside on any device supported by the VSE

DTFSD macro. An exception to this is VSAM managed SAM files, which do not

support spanned records. Spanned records are used by UNLOAD

TABLE/DBSPACE and RELOAD TABLE/DBSPACE processing and, in some cases,

by DATALOAD and DATAUNLOAD.

You can invoke the Database Services Utility in a VSE batch partition or in a

VSE/ICCF interactive partition. The Database Services Utility does not use VSE

dynamic device assignment. Logical units SYS004 and SYS005, respectively, must

be used for input and output files allocated to magnetic tape: SYS006 and SYS007,

respectively, must be used for input and output files allocated to direct access

storage. Under VSE, all magnetic tape files processed by the Database Services

Utility must be EBCDIC standard-label files, and only magnetic tape input files are

rewound.

Special consideration should be given to the database log when using the Database

Services Utility to load large amounts of data. The log must be large enough to

contain all the log data generated during Database Services Utility RELOAD

DBSPACE, RELOAD TABLE, or DATALOAD command processing. Log space used

as a result of Database Services Utility processing is not freed until an SQL

COMMIT or ROLLBACK is executed. If the log space is filled by Database Services

Utility processing, a Database Services Utility processing error occurs. Your system

programmer can tell whether there is enough log space to contain all the log data

generated during Database Services Utility command processing.

105

Single User Mode Job Control

A minimum 2000K byte virtual partition is recommended to execute the Database

Services Utility with single user mode for VSE archive mode on. The sample VSE

job control statements in Figure 56 invoke the Database Services Utility in single

user mode with DB2 Server for VSE archive mode on:

▌1▐

// JOB

DBSUTIL

▌2▐

// EXEC

PROC=ARIS75PL

// EXEC

PROC=ARIS75DB

▌3▐

// TLBL

file name,

▌4▐

// DLBL

file name,

▌5▐

// ASSGN

SYS004,

▌6▐

// ASSGN

SYS005,

▌7▐

// ASSGN

SYS006,

▌8▐

// ASSGN

SYS007,

▌9▐

// EXEC

ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,LOGMODE=A,PROGNAME=ARIDBS’

▌10▐

Database Services Utility control commands and optional user data

▌11▐ /*

▌12▐ /&

Figure 56. Single User Mode Job Control

Each job control statement is described below:

▌1▐JOB Statement

Identifies and initiates the job control.

▌2▐EXEC PROC=ARIS75PL and EXEC PROC=ARIS75DB

When the database manager is installed, your installations have the option

of generating a starter database as described in the DB2 Server for VSE

Program Directory. The procedure ARIS75PL contains the job control

statements that identify the DB2 Server for VSE & VM library. Procedure

ARIS75DB contains the job control statements that are required to access

the starter database. You must execute a different procedure to access a

different database. Alternatively, you can code the actual DB2 Server for

VSE database and library definition job control statements in place of the

EXECUTE PROCEDURE statements.

To determine the database and library definition statements required,

contact the person who installed the database or refer to the DB2 Server for

VSE Program Directory, which contains a description of the starter database

and library definition job control statements and procedures.

▌3▐TLBL Statement

This job control statement is optional. It identifies a sequential (SAM)

magnetic tape file used for Database Services Utility input and/or output

data. The file can reside on any type of volume supported by the VSE

DTFMT macro.

Note: Tape files processed by the Database Services Utility under VSE

must be EBCDIC, standard-label files.

Any number of these commands (each having a unique file name) can be

included in the job control. Each file name defined is normally referenced

by a ddname parameter in a Database Services Utility command that is

contained in the SYSIPT control command input. Input magnetic tapes are

rewound by Database Services Utility OPEN processing, but output

106

Database Services Utility

magnetic tapes are not rewound. For input files other than the first file on

a tape volume, a file sequence number must be specified, corresponding to

the original position of that file on the tape.

▌4▐DLBL Statement

This job control statement is optional. It identifies a sequential (SAM)

DASD file used for Database Services Utility input or output data. The file

can reside on any type of volume supported by the VSE DTFSD macro.

Any number of these statements (each having a unique file name) can be

included in the job control. Each file name defined is normally referenced

by a ddname parameter in a Database Services Utility command contained

in the SYSIPT control command input. Job control EXTENT statements are

required to complete the description of the file identified by the DLBL

statement.

▌5▐ASSGN SYS004 (Tape Input File)

This job control statement is required if a Database Services Utility

sequential (SAM) input data file is allocated to a magnetic tape device. It

defines the logical unit SYS004 for a tape input file.

▌6▐ASSGN SYS005 (Tape Output File)

This job control statement is needed if a Database Services Utility

sequential (SAM) output data file is allocated to a magnetic tape device. It

defines the logical unit SYS005 for a tape output file. A large block size is

recommended for a tape output file to improve performance.

▌7▐ASSGN SYS006 (DASD Input File)

This job control statement is needed if a Database Services Utility

sequential (SAM) input data file is allocated to a direct access device. It

defines the logical unit SYS006 for a DASD input file.

▌8▐ASSGN SYS007 (DASD Output File)

This job control statement is needed if a Database Services Utility

sequential (SAM) output data file is allocated to a direct access device. It

defines the logical unit SYS007 for a DASD output file.

▌9▐EXEC Statement for Single User Mode

This statement identifies the database entry point (ARISQLDS), and

contains the required SIZE=AUTO specification and the job control

parameters to execute the Database Services Utility program with single

user mode.

The job control parameters that you must specify are:

v SYSMODE=S

v PROGNAME=ARIDBS

SYSMODE=S indicates that you want single user execution mode.

PROGNAME=ARIDBS identifies the Database Services Utility program

entry point. LOGMODE=A identifies that the database manager should

operate with archive and logging on.

All single user mode startup parameters and log mode considerations are

described in the DB2 Server for VSE System Administration manual. Consult

a system programmer about the startup parameters; your installation

might specify additional parameters for performance reasons.

Chapter 7. Using the Database Services Utility from Application Programs

107

▌10▐SYSIPT Control Statement and User Data Input

Database Services Utility control commands and user data input.

▌11▐End SYSIPT Control Statement Input Indicator

Indicates the end of Database Services Utility SYSIPT input when SYSIPT

is assigned to the reader file.

▌12▐End of Job Indicator

Indicates the end of the job.

Single User Mode Job Control Example

The sample job control and commands shown in Figure 57 run the Database

Services Utility with single user mode to perform the following functions:

v Unload the table SQLDBA.DEPARTMENT to the first file on a scratch tape.

v Unload the table SQLDBA.ACTIVITY to the second file on the tape.

// JOB DBS UTILITY EXAMPLE VSE SINGLE USER MODE JOB CONTROL

// EXEC PROC=ARIS75PL

<--DB2 Server for VSE Production Library Definition

// EXEC PROC=ARIS75DB

<--DB2 Server for VSE Starter Database Definition

// TLBL TAPE1,’DBSU-FILE1’,0,SQLDAT,1,1

<--Tape File#1

// TLBL TAPE2,’DBSU-FILE2’,0,SQLDAT,1,2

<--Tape File#2

// ASSGN SYS005,280

<--Tape output

// MTC REW,SYS005

<--Rewind tape

// EXEC ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,LOGMODE=Y,PROGNAME=ARIDBS’

CONNECT SQLDBA IDENTIFIED BY SQLDBAPW;

UNLOAD TABLE(DEPARTMENT) OUTFILE(TAPE1)

UNLOAD TABLE(ACTIVITY) OUTFILE(TAPE2)

Figure 57. Single User Mode Job Control Example

Multiple User Mode Job Control

The VSE job control statements in Figure 58 invokes the Database Services Utility

in multiple user mode:

// JOB

DBSUTIL

// EXEC PROC=ARIS75PL

<--DB2 Server for VSE Production Library Definition

// TLBL file name,

// DLBL file name,

// ASSGN SYS004,

// ASSGN SYS005,

// ASSGN SYS006,

// ASSGN SYS007,

// EXEC PGM=ARIDBS,SIZE=AUTO,PARM=’DBNAME(SQLDB1_TOR_INV)’

....DBS control commands and optional user data

Figure 58. Multiple User Mode Job Control

The job control statements in Figure 58 do the same things as the corresponding

statements in Figure 56 on page 106. The database manager must already be

running when you invoke the Database Services Utility (or any other application

program) with multiple user mode. To execute the Database Services Utility with

multiple user mode, at least a 200K byte virtual partition is recommended.

108

Database Services Utility

DBNAME=SQLDB1_TOR_INV identifies the application server on which to process

the Database Services Utility job. If the DBNAME parameter is not specified, the

default application server is accessed.

Multiple User Mode Job Control Example

The example job control and commands shown in Figure 59 run the Database

Services Utility with multiple user mode to perform the following functions:

v Unload the dbspace PUBLIC.SAMPLE to a DASD file.

v Reload the dbspace PUBLIC.SAMPLE from the same DASD file to reorganize

the data for all tables in the dbspace.

// JOB DBS UTILITY EXAMPLE VSE MULTIPLE USER MODE JOB CONTROL

// EXEC PROC=ARIS75PL

<--DB2 Server for VSE Production Library Definition

// DLBL DASDI,’DBSU-FILE’,0

<--DASD input file

// EXTENT SYS006,sqlwkl,1,0,57,76

<--DASD input file

// ASSGN SYS006,150

<--DASD input

// DLBL DASD0,’DBSU-FILE’,0

<--DASD output file

// EXTENT SYS007,sqlwkl,1,0,57,76

<--DASD output file

// ASSGN SYS007,150

<--DASD output

// EXEC PGM=ARIDBS,SIZE=AUTO,PARM=’DBNAME(SQLDB1_TOR_INV)’

CONNECT SQLDBA IDENTIFIED BY SQLDBAPW;

UNLOAD DBSPACE(PUBLIC.SAMPLE) OUTFILE(DASD0 PDEV(DASD))

RELOAD DBSPACE(PUBLIC.SAMPLE) PURGE INFILE(DASDI PDEV(DASD) BLKSZ(2048))

Figure 59. Multiple User Mode Job Control Example

In DB2 Server for VM

The Database Services Utility operates in the user’s virtual machine with the

application server in either single user mode or multiple user mode.

The IBM-supplied SQLDBSU EXEC invokes the utility. This EXEC accepts optional

parameters identifying the Database Services Utility input control file

(ddname=SYSIN) and the Database Services Utility output message file

(ddname=SYSPRINT). It also accepts other parameters necessary to run the database

system in single or multiple user mode.

If the optional parameters identifying the Database Services Utility SYSIN and

SYSPRINT files are not specified during startup of the SQLDBSU EXEC, the user

can either define these files by using the CMS FILEDEF commands or run the

utility with the SQLDBSU EXEC defaults, which assign the SYSIN and SYSPRINT

file to the terminal.

Other DASD or tape input or output data files referenced by the Database Services

Utility commands in the control file must be defined by the user with CMS

FILEDEF commands before the SQLDBSU EXEC command is issued. Tape file

processing and file definition restrictions apply to Database Services Utility input

and output data files. Refer to the DB2 Server for VM System Administration manual

for a description of tape file processing support. The VM/ESA: CMS Command

Reference manual describes the CMS FILEDEF command.

Chapter 7. Using the Database Services Utility from Application Programs

109

Notes:

1. VM/ESA system in ESA mode is supported in the Database Services Utility

only in XA-toleration mode. In this mode, the utility is always loaded and run

below 16MB.

2. CMS subset mode is not supported by the Database Services Utility.

Names and Identifiers

General Rules for Naming Data Objects

The DB2 Server for VSE & VM Application Programming manual contain the formal

definition of the SQL language and naming conventions. Briefly, the names of data

objects (such as tables, columns, indexes, synonyms, or dbspaces) must be a

particular kind of character string called an identifier. SQL identifiers must begin

with a letter or number. They can contain up to 18 uppercase and lowercase letters,

numbers, and underscores.

Note: If you need national language character translation for lowercase terminal

input, the CMS SET INPUT xx yy command can be used. Refer to the

VM/ESA: CMS Command Reference manual for more information.

The preprocessor used by the Database Services Utility for dynamic SQL statement

processing converts DB2 Server for VSE & VM identifiers to uppercase if they are

not in double quotation marks. For example, these two identifiers are identical to

the system:

department

DEPARTMENT

If you want the system to recognize the lowercase letters in the identifier, enclose

the identifier in double quotation marks. For example:

"department"

Qualifying Object Names

If a data object (such as a table, dbspace, or view) is owned by another user, you

need to qualify references to the object by concatenating the owner’s user identifier

as in the following figure:

SMITH.DEPARTMENT

──┬── ────┬─────

│

┌───────────┐

│

└───────►

│table name │

│

└───────────┘

│

┌───────────────────┐

└───────────────►

│owner of the table |

└───────────────────┘

Figure 60. Object Names

The period (.) is the concatenation symbol.

You can access another user’s table only if you know that person’s user identifier

and have the appropriate authorization to access that table.

110

Database Services Utility

When you concatenate a user ID to a table name, you fully qualify the table. That

is, owner.table-name uniquely identifies a table in the database. For example, there

can never be two SMITH.DEPARTMENT tables in the database at the same time.

Use fully qualified object names until you are an experienced DB2 Server for VSE

& VM user. By fully qualifying database object names, you avoid confusion and

errors.

Using Special Characters and Blanks within Identifiers

An identifier can contain blanks (but must not begin or end with blanks) or special

symbols if you enclose them in double quotation marks. For example:

"RESEARCH EMPLOYEES"

You should not, however, use double quotation marks within an SQL identifier.

The following is not a valid identifier:

"EMP"13"TABLE"

Reserved Words

SQL Reserved Words

A list of SQL reserved keywords can be found on “SQL Reserved Words” on page

xvii. Do not use these words in SQL statements except:

v With their defined meaning in the SQL syntax

v As host variables (preceded by a colon).

In particular, do not use them as names for tables, indexes, columns, views, or

dbspaces unless they are enclosed in double quotation marks (").

Database Services Utility Reserved Words

In addition to the SQL reserved keywords, do not use the following keywords in

Database Services Utility commands as the name for a table, view, column, or

dbspace unless you enclose the name in double quotation marks ("):

Table 6. Names to Avoid Using

DATALOAD

INMOD

RELOAD

SCHEMA

DATAUNLOAD

OUTFILE

REORGANIZE

UNLOAD

INFILE

REBIND

Using Reserved Words as Identifiers

If an identifier is the same as one of the SQL keywords listed in this chapter, you

must enclose the name in quotation marks. For example, you can use

"SELECT"

as a name, but if it is not delimited with quotation marks,

SELECT

is interpreted as a keyword.

Chapter 7. Using the Database Services Utility from Application Programs

111

Using the Database Services Utility from Programming Languages

You can invoke the Database Services Utility program from an assembler language,

PL/I, C, or COBOL program by using the Database Services Utility entry point

ARIDBS. (You cannot invoke the Database Services Utility from a Fortran

program.)

DB2 Server for VSE

If the Database Services Utility program is link-edited with a user program, you

must link-edit these modules in addition to those required for a normal DB2 Server

for VSE application program:

ARISYSDD

ARIDSQLA

ARIDDFP

If you use an assembler language CDLOAD instruction in the calling program, you

need not link-edit the above modules. (See the following section “Using the

Database Services Utility from an Assembler Program” on page 113.)

You need not have an SQL CONNECT statement in the input control card file if

the application that invokes the utility has already executed one. All authorization

checking is based on the user ID supplied in the last CONNECT statement that

was executed by the database manager.

ASSGN, TLBL, and DLBL commands required by the Database Services Utility

must be present in the job control, and SIZE=AUTO must be specified on the

EXEC command for the main program. The Database Services Utility processes all

input control card file records from SYSIPT before returning control to the routine

that invoked it.

DB2 Server for VM

The application program must be link-edited with ARIDBS, a member in the

ARISQLLD LOADLIB, along with any other modules required for a normal DB2

Server for VM application program.

The application program can execute a CONNECT statement, supply a CONNECT

statement in the Database Services Utility control file input, or take advantage of

the implicit CONNECT support. All authorization checking is based on the

connected user ID.

The FILEDEF commands for the Database Services Utility input control file, the

output message file, and any input/output data files referenced by Database

Services Utility commands must be executed before the utility is invoked. The

utility processes all control file records from SYSIN before returning control to the

program that invoked it.

Addressing Mode

Although the database manager can be run in 24-bit or 31-bit addressing mode,

you must run the Database Services Utility in 24-bit mode.

In single user mode, if the database manager is being run in 31-bit mode, the

addressing mode is switched to 24-bit mode before the Database Services Utility is

started. When you call the Database Services Utility from an application program,

the addressing mode is switched to 24-bit mode and the addressing mode of the

112

Database Services Utility

application program is restored upon return. You must, however, ensure that any

parameters passed by the application program to the Database Services Utility do

not reside above the 16MB (MB equals 1,048,576 bytes) line.

See the DB2 Server for VSE System Administration or the DB2 Server for VM System

Administration manuals for more information on addressing modes.

Startup

The Database Services Utility uses the following register content on entry:

v Register 0 is not used in DB2 Server for VSE; in DB2 Server for VM, it can

contain the same content as Register 1.

v Register 1 can contain the address of a standard parameter address list to pass

control parameters to the Database Services Utility program.

v Registers 2-12 are ignored.

v Register 13 contains the address of an area of 18 full-words to be used as a

v Register 14 contains the return address for the Database Services Utility

program.

v Register 15 contains the Database Services Utility entry point address.

When dynamically invoked, all registers except register 15 are restored by the

Database Services Utility before to returning by way of register 14 to the invoking

program. Register 15 contains the final return code from Database Services Utility

processing.

Using the Database Services Utility from an Assembler

Program

DB2 Server for VM

You can invoke the Database Services Utility program from an assembler language

program. You must include the Database Services Utility program in the load

module with the invoking program and follow the register conventions described

above. The format of the CALL to invoke the utility is:

CALL ARIDBS

DB2 Server for VSE

You can invoke the Database Services Utility program from an assembler program

in either of the ways described in the CALL macro description contained in the

VSE/Advanced Functions Macro Reference. If you include the Database Services

Utility program in the load module with the invoking program, the format of the

CALL statement is the same as in DB2 Server for VM.

If you do not include the Database Services Utility program in the load module

with the invoking program, use the following sequence of instructions to invoke

the Database Services Utility program:

CDLOAD ARIDBS

15,1

CALL

(15)

When using the above sequence of instructions, do not specify SIZE=AUTO on the

EXEC command for the main program.

Chapter 7. Using the Database Services Utility from Application Programs

113

Using the Database Services Utility from a C Program

You can invoke the Database Services Utility program from a C program. ARIDBS

must be declared to the compiler as an external entry point. ARIDBS must also be

defined as having OS linkage using #pragma linkage (ARIDBS, OS);. The format of

the C CALL command is:

ARIDBS(CLTYPEID,PARMSTR);

where CLTYPEID and PARMSTR can be declared as:

static char CLTYPEID[7]="DBSU01 ";

struct{short int

PARMLEN;

char

PARMDATA [80];

}PARMSTR;

Using the Database Services Utility from a COBOL Program

A main program written in COBOL can invoke the Database Services Utility

program by using the linkage conventions described for calling assembler

programs in the DOS Full American National Standard COBOL Compiler and Library,

Version 3, Programmer’s Guide. The Database Services Utility entry point name

ARIDBS must be used in the COBOL CALL command used to invoke the Database

Services Utility program. The format of the COBOL CALL command varies

depending on whether the COBOL compiler was generated with single (') or

double (") quotes as delineators:

CALL ’ARIDBS’ USING CALLTYPEID PARMSTRING.

CALL "ARIDBS" USING CALLTYPEID PARMSTRING.

where CALLTYPEID and PARMSTRING can be declared as:

01 CALLTYPEID

PIC X(6) VALUE’DBSU01’.

01 PARMSTRING.

49 PARMLEN

PIC S9(4) COMP.

49 PARMDATA

PIC X(80).

Using the Database Services Utility from a PL/I Program

You can invoke the Database Services Utility program from a PL/I program by

using the facilities of the IBM PL/I Optimizing Compiler Program Product.

ARIDBS must be declared to the compiler as an external entry point with the

ASSEMBLER and INTER options. The format of the PL/I CALL command is:

CALL ARIDBS(CLTYPEID,PARMSTR);

where CLTYPEID and PARMSTR can be declared as:

DCL 1 CLTYPEID

CHAR(6) INIT(’DBSU01’);

DCL 1 PARMSTR,

2 PARMLEN

BINARY FIXED(15),

2 PARMDATA

CHAR(80);

Using the Database Services Utility Application Program

Interface

The interface described in this section allows a calling program or EXEC (in VM)

to pass Database Services Utility control parameters or a single SQL statement or

both. These utility control parameters provide the caller with the means to:

114

Database Services Utility

v Suppress all or portions of the messages written by Database Services Utility

processing

v Identify the SQL SELECT statement output format

v Suppress SQL COMMIT and SQL ROLLBACK processing

v Determine the location where print data begins in the message file record

v Control the isolation level under which the Database Services Utility operates.

The calling program or EXEC can also pass a single SQL statement to the Database

Services Utility for immediate processing by means of the call parameter list. Only

SQL statements currently supported by Database Services Utility processing can be

supplied. If an invalid parameter or Database Services Utility command is passed

in the parameter list, it is processed as an SQL statement, and an error occurs.

Figure 61 shows the control parameters that can be used when invoking the

Database Services Utility.

LINEWIDTH(www) or LW(www)PROMPTS(NO)

MESSAGES(SQLONLY)

MESSAGES(NONE)

FORMAT(CL)

FORMAT(LO)

PAGECTL(NO)

ENDLUW(NO)

ISOL(CS)

ISOL(UR)

Figure 61. Control Parameters

Control Parameters

Database Services Utility Control Parameters: This section lists and describes the

Database Services Utility control parameters.

LINEWIDTH(www) or LW(www)

specifies the maximum number of print data positions used in a message file

record containing SQL SELECT statement output. The default value for www is

120. In DB2 Server for VM, if the Database Services Utility message file

(ddname=SYSPRINT) is assigned to the terminal, the number of print data

positions used for the SQL SELECT statement defaults to 80. The value www

can range from 60 to 256 but must be less than the logical record length of the

report or message file. For example, if the logical record length is 100, the

widest line you can set is LINEWIDTH(99).

Notes:

1. The utility always supplies an American Standards Association (ASA)

control character in the first position of the print record. The second

through nth positions of the print record are the print data positions. If the

value www+1 is less than the print record length, all unused print data

positions in the print record contain a blank (hex 40).

2. The Database Services Utility report record length is always 121.

3. The minimum message file record length is 81. If the control parameter

PAGECTL(NO) is specified, the minimum message file record length is 80.

4. If the value www is equal to or greater than the print record length, an

error occurs.

Chapter 7. Using the Database Services Utility from Application Programs

115

PROMPTS(NO)

suppresses Database Services Utility write-to-operator (WTO) messages. The

WTO messages appear on the user’s terminal or, in VSE, on the operator

console display.

MESSAGES(SQLONLY)

suppresses the messages normally generated by Database Services Utility

processing except for:

v SQL messages (ARI0500 through ARI0519)

v Message ARI0803E identifies an invalid command

v Message ARI0838E identifies an invalid CONNECT statement

v Message ARI0850I is generated after an SQL SELECT statement is

successfully processed

v Message ARI0856E is generated when an error occurs during the execution

of an SQL statement initiated by Database Services Utility processing

v Message ARI0884I indicates a command was processed

v Message ARI8999E: indicates an invalid control parameter or command was

passed by means of the Database Services Utility parameter list

v Other Database Services Utility messages normally written to the terminal,

or in VSE, to the operator console display device.

MESSAGES(NONE)

suppresses all Database Services Utility messages. Only the Database Services

Utility return codes indicate the status of the processing performed.

FORMAT(CB)

is not supported.

FORMAT(CL)

formats the output of an SQL SELECT statement in either column format or

list format.

FORMAT(LO)

formats the output of an SQL SELECT statement using only the list format.

PAGECTL(NO)

causes the Database Services Utility to:

v Use a default of 32767 lines per page for Database Services Utility report or

message file output instead of 60 lines per page

v Write display lines to the Database Services Utility report or message file

without a printer control character in position 1

v Suppress page number heading line(s) in SQL SELECT statement output.

The SET LINECOUNT command can override the default lines per page used

by Database Services Utility processing.

116

Database Services Utility

DB2 Server for VM Only

A user-supplied FILEDEF command defining SYSPRINT to the terminal

should specify RECFM F or RECFM FB. If RECFM F or RECFM FB is not

specified, the first character of each Database Services Utility message file

display line is truncated.

The default FILEDEF SYSPRINT command issued by the SQLDBSU

EXEC defines the Database Services Utility message file record without a

printer control character. This default command is:

FILEDEF SYSPRINT TERMINAL (RECFM F LRECL 120

ENDLUW(NO)

indicates that the Database Services Utility should not end the logical unit of

work before returning to the calling program or, in VM, EXEC. The Database

Services Utility does not issue an SQL COMMIT statement at the end of

Database Services Utility processing if this parameter is specified.

Only the end of Database Services Utility COMMIT processing is suppressed

by this control parameter. Other Database Services Utility COMMIT and

ROLLBACK processing is not suppressed. However, when the ENDLUW(NO)

control parameter is specified, and ERRORMODE CONTINUE is in effect, all

Database Services Utility COMMIT and ROLLBACK processing is suppressed.

In a VM system note that the SET ERRORMODE CONTINUE command is in

effect when the Database Services Utility input control file is assigned to a

terminal or a SET ERRORMODE CONTINUE command is processed. And, in a

VSE system, the SET ERRORMODE CONTINUE command is in effect when a

SET ERRORMODE CONTINUE command is processed.

Note: System-initiated COMMIT or ROLLBACK processing cannot be

suppressed by any means.

ISOL(CS), ISOL(UR)

indicates that the Database Services Utility should operate under cursor

stability or uncommitted read isolation level. The default mode of utility

processing is repeatable read isolation level; however, if you are accessing a

remote application server, the isolation level for the Database Services Utility is

always set to CS and the SET ISOLATION command has no effect.

SQL Statement Parameter: If an SQL statement is supplied by means of the call

parameter list, the Database Services Utility does not read the (input) control file

SYSIPT. Any SQL statement currently supported by Database Services Utility

processing can be supplied. This includes all SQL statements except those restricted

to use in SQL application programs. One or more of the utility control parameters

may precede the SQL statement. Utility commands are not supported in the call

parameter list.

If an invalid parameter or a Database Services Utility command is passed in the

parameter list, it is processed as an SQL statement, causing an error.

When an SQL statement is supplied in the Database Services Utility parameter list

and it is not preceded by the ENDLUW(NO) control parameter, Database Services

Utility processing ends the logical unit of work after the command is processed.

Chapter 7. Using the Database Services Utility from Application Programs

117

An SQL COMMIT statement is issued if the command is processed without errors.

An SQL ROLLBACK statement is issued if a command error occurs.

If the ENDLUW(NO) control parameter precedes the SQL statement, the Database

Services Utility issues neither an SQL COMMIT statement nor an SQL ROLLBACK

statement after the SQL statement is processed.

Using Control Parameters with DB2 Server for VM: Use control parameters in a

calling program or an EXEC when you want to set up the Database Services Utility

environment and execute all the commands from one file. Figure 62 shows a REXX

EXEC that directs the output messages to the terminal, executes the Database

Services Utility, and passes control parameters and an SQL statement to the utility.

You do not need to define the input requirements because the SQL statement is in

the EXEC.

/* Example DBS Utility Control Parameters in REXX EXEC */

ADDRESS CMS

’FILEDEF ARISQLLD DISK ARISQLLD LOADLIB Q (NOCHANGE’

’FILEDEF SYSPRINT TERMINAL (NOCHANGE RECFM F LRECL 120’

’NUCXLOAD ARIDBS ARIDBS ARISQLLD’

’ARIDBS PROMPTS(NO) FORMAT(LO) ENDLUW(NO) SELECT * FROM DEPARTMENT’

ADDRESS

EXIT RC

Figure 62. Using the Database Services Utility Control Parameters in DB2 Server for VM

Using the Database Services Utility Interface Conventions

Database Services Utility control parameters or an SQL statement or both can be

supplied using standard program (or in VM, EXEC interface) conventions.

Note: All system parameter string restrictions apply to Database Services Utility

processing. These restrictions are not overridden by Database Services

Utility parameter processing.

DB2 Server for VM Convention Formats: There are two format conventions; they

are:

Format 1 - EXEC Program Interface Conventions: Your EXEC or program must

follow these register conventions:

The address of the parameter address list

The address of the invoking program’s 18 full-word save area

The Database Services Utility return address

The Database Services Utility entry point address on entry; the

Database Services Utility processing return code on exit.

Your EXEC or program Database Services Utility parameter address list is to follow

these conventions:

Position (per Byte)

Contents

1-4

Address of command identifier (not

checked)

5-8

Address of PARAMETERSTRING

9-12

Address of PARAMETERSTRINGEND+1

118

Database Services Utility

Database Services Utility processing determines whether startup parameters are

identified by register 0 by interrogating the contents of register 0 on entry to the

Database Services Utility. Register 0 parameter processing is not performed if any

of the following conditions occurs:

v Register 0 contains the address of the ARIDBS module.

v Content of register 0 equals 0.

v Length of the parameter string is less than 1.

v Length of the parameter string is greater than 8192.

Note: EXEC parameter string restrictions must also be considered.

PARAMETERSTRING

identifies the start of the Database Services Utility parameter string. The

parameter string can contain Database Services Utility control parameters or an

SQL statement, or both. Blanks or commas can be used to separate Database

Services Utility control parameters from each other or from an SQL statement.

The first entry in the parameter can be the command name ARIDBS.

The parameter string format is:

PARAMETERSTRINGEND+1

identifies the position following the Database Services Utility parameter string.

Format 2 - Program Interface Conventions: Your program must follow these register

conventions:

The address of the Database Services Utility parameter address list

The address of the invoking program’s 18 full-word save area

The Database Services Utility return address

The Database Services Utility entry point address on entry; the

Database Services Utility processing return code on exit.

Your program Database Services Utility parameter address list must follow these

conventions:

Position (per Byte)

Contents

1-4

Address of CALLTYPEID

5-8

Address of PARAMETERSTRING

where:

CALLTYPEID

is the address of an area defined as CHAR(6) that contains the Database

Services Utility call type identifier. This area must contain the character string

value DBSU01.

PARAMETERSTRING

identifies the start of the Database Services Utility parameter string. The

parameter string can contain Database Services Utility control parameters or an

SQL statement, or both. Blanks or commas can be used to separate Database

Services Utility control parameters from each other or from an SQL statement.

The first entry in the parameter can be the command name ARIDBS.

Chapter 7. Using the Database Services Utility from Application Programs

119

The parameter string format is:

<optional control parameters> <optional SQL

statement>

where:

LL is defined as a FIXED(15) value representing the length of the following

parameter string. The maximum length of the parameter string passed to

the Database Services Utility is 8192 not including the length field.

Database Services Utility processing determines if startup parameters are identified

by register 1 by interrogating the contents of register 1 on entry to the Database

Services Utility. Register 1 parameter processing is not performed if any of the

following conditions occur:

v Register 1 contains the address of the ARIDBS module.

v Content of register 1 equals 0.

v A valid parameter list is passed by means of register 0.

v Content of register 1 addresses the character string value ARIDBS.

v First address in the Database Services Utility parameter address list equals 0.

v First address in the Database Services Utility parameter address list does not

address the character string value DBSU01.

v Length of the parameter string is less than 1 or greater than 8192.

DB2 Server for VSE Program Interface Conventions: Your program must follow

these register conventions:

The address of the Database Services Utility parameter address list

The address of the invoking program’s 18 full-word save area

The Database Services Utility return address

The Database Services Utility entry point address on entry; the

Database Services Utility processing return code on exit.

Your program Database Services Utility parameter address list must follow these

conventions:

Position (per Byte)

Contents

1-4

Address of CALLTYPEID

5-8

Address of PARAMETERSTRING

where:

CALLTYPEID

is the address of an area defined as CHAR(6) that contains the Database

Services Utility call type identifier. This area must contain the character string

value DBSU01.

PARAMETERSTRING

identifies the start of the Database Services Utility parameter string. The

parameter string can contain Database Services Utility control parameters or an

SQL statement, or both. Blanks or commas can be used to separate Database

Services Utility control parameters from each other or from an SQL statement.

120

Database Services Utility

The parameter string format is:

<optional control parameters> <optional SQL

statement>

where:

LL is defined as a FIXED(15) value representing the length of the following

parameter string. The maximum length of the parameter string passed to

the Database Services Utility is 8192 not including the length field but you

must also consider VSE job control restrictions.

determines if startup parameters are identified by register 1 by interrogating the

contents of register 1 on entry to the Database Services Utility. Register 1

parameter processing is not performed if any of the following conditions occur:

v Register 1 contains the address of the ARIDBS module.

v Content of register 1 equals 0.

v Content of register 1 addresses the character string value ARIDBS.

v First address in the Database Services Utility parameter address list equals 0.

v First address in the Database Services Utility parameter address list does not

address the character string value DBSU01.

v Length of the parameter string is less than 1 or greater than 8192.

Sample Programs

Sample DB2 Server for VM EXEC Procedure: Invoke the Database Services

Utility: The sample EXEC in Figure 63 invokes the Database Services Utility

against the application server in multiple user mode. The example is written in the

REXX language.

/* EXAMPLE DBS UTILITY REXX EXEC */

ARG PARMS

ADDRESS CMS

’FILEDEF ARISQLLD DISK ARISQLLD LOADLIB Q (NOCHANGE’

’FILEDEF SYSPRINT TERMINAL (NOCHANGE RECFM F LRECL 120’

’FILEDEF SYSIN TERMINAL (NOCHANGE’

’NUCXLOAD ARIDBS ARIDBS ARISQLLD’

’ARIDBS MESSAGES(SQLONLY) FORMAT(CL)’ PARMS

ADDRESS

EXIT RC

Figure 63. Sample REXX EXEC to Invoke the Database Services Utility

The EXEC performs the following functions:

v Unconditionally invokes the utility with the control parameters

MESSAGES(SQLONLY) and FORMAT(CL). These can be overridden by control

parameters specified as EXEC command parameters.

- If MESSAGES(NONE) is specified as an EXEC command parameter, it

overrides the MESSAGES(SQLONLY) parameter.

- If the FORMAT(LO) control parameter is specified as an EXEC command

parameter, it overrides the FORMAT(CL) parameter.

v Accepts optional Database Services Utility control parameters as EXEC

command parameters and passes them to the utility for processing. Database

Chapter 7. Using the Database Services Utility from Application Programs

121

Services Utility control parameters must be specified as EXEC command

parameters before any SQL statement is issued.

v Accepts an optional SQL statement as the last EXEC command parameter string

and passes it to the Database Services Utility for processing. Any Database

Services Utility parameters must be specified as EXEC command parameters

before the SQL statement.

- If no SQL statement is specified as an EXEC command parameter, the

Database Services Utility processing invoked by the example EXEC allows

you to enter one or more SQL or Database Services Utility commands from

the CMS command line. You are prompted to enter the first or next

command.

v Displays the results of Database Services Utility processing to the terminal.

If you create the CMS file SQL EXEC fm (where fm is the file mode) containing the

sample EXEC in Figure 63 on page 121, SQL statements can then be run from the

CMS command line. Some examples of running one sample EXEC are in Figure 64

on page 122.

Note: DB2 Server for VM user machine must identify the database to be accessed

by running the SQLINIT EXEC before running the sample EXEC or a similar

EXEC. Also, the VM terminal logical line-editing symbols (character delete,

line delete, line end, and escape) must not conflict with the SQL language

operators used in the SQL statements entered in the CMS command line.

Enter--> sql select creator,tname from system.sysaccess

(SELECT output will be displayed in column format)

Enter--> sql format(lo) select creator,tname from system.sysaccess

(SELECT output will be displayed in list format)

Enter--> sql

When prompted:

Enter--> select creator,tname from system.sysaccess

(SELECT output will be displayed in column format)

When prompted:

Enter--> exit or another SQL statement

Figure 64. CMS Command Line Entries to Run a Sample EXEC

DB2 Server for VM Sample User Program: Link-Edit User Programs and the

Database Services Utility: The following is a general example of the way to

link-edit and run a user-written program (VMUCALL) that invokes the Database

Services Utility. In Figure 65 on page 123 the example program is written in

COBOL. The user program is run from a user library (USERLOAD LOADLIB A).

This example assumes that the user program VMUCALL needs to be compiled first

and that the VMUCALL TEXT A file does not exist.

A sample link-edit REXX EXEC is shown in Figure 66 on page 123. The contents of

the user link-edit control file (VMULINK TEXT A) are shown in Figure 67 on page

123. Note that for the COBOL program, you must also link edit the TEXT file

ARIPADR4. Figure 68 on page 123 shows a sample REXX EXEC for running the

user program with multiple user mode.

122

Database Services Utility

***************************************************************

* Example COBOL Program Calling the Database Services Utility *

***************************************************************

IDENTIFICATION DIVISION.

PROGRAM-ID. VMUCALL

ENVIRONMENT DIVISION.

DATA DIVISION.

WORKING-STORAGE SECTION.

CALLTYPEID

PIC X(6) VALUE ’DBSU01’.

PARMSTRING.

49 PARMLEN

PIC S9(4) COMP VALUE 42.

49 PARMDATA

PIC X(42) VALUE

’FORMAT(LO) SELECT * FROM SYSTEM.SYSOPTIONS’.

PROCEDURE DIVISION.

CALL ’ARIDBS’ USING CALLTYPEID PARMSTRING.

FINIS.

STOP RUN.

Figure 65. Sample COBOL Program Calling the Database Services Utility

/* Example REXX EXEC to Link-Edit a COBOL program with DBS Utility */

ADDRESS ’COMMAND’

’COBOL2 VMUCALL (APOST’

’FILEDEF SYSLIB DISK VSC2LTXT TXTLIB Y’

’FILEDEF ARISQLLD DISK ARISQLLD LOADLIB Q (RECFM U’

’FILEDEF VMUCALL DISK VMUCALL TEXT A (RECFM F LRECL 80’

’FILEDEF ARIRVSTC DISK ARIRVSTC TEXT Q (RECFM F LRECL 80’

’FILEDEF ARIPADR4 DISK ARIPADR4 TEXT Q (RECFM F LRECL 80’

’FILEDEF SYSLMOD DISK USERLOAD LOADLIB A (RECFM U’

’LKED VMULINK (LET RENT NAME VMUMOD LIST TERM PRINT’

EXIT

Figure 66. Sample EXEC to Link-Edit a User Program with the Database Services Utility

INCLUDE VMUCALL

INCLUDE ARIRVSTC

INCLUDE ARIPADR4

<---- For user COBOL program only

INCLUDE ARISSQLD(ARIDBS)

ENTRY VMUCALL

Note: Position 1 of each record must be blank.

Figure 67. Sample User Link-Edit Control File

/* Example REXX EXEC to Run a User Program Calling DBS Utility */

ADDRESS ’COMMAND’

’FILEDEF USERLOAD DISK USERLOAD LOADLIB A’

’FILEDEF SYSIN

TERMINAL (RECFM F LRECL 120’

’FILEDEF SYSPRINT TERMINAL (RECFM F LRECL 120’

’NUCXLOAD VMUMOD VMUMOD USERLOAD’

’VMUMOD’

’NUCXDROP VMUMOD’

EXIT

Figure 68. Sample EXEC to Run a User Program Link-Edited with the Database Services

Utility

Chapter 7. Using the Database Services Utility from Application Programs

123

DB2 Server for VSE Sample COBOL Program: Call the Database Services

Utility: The following is a basic example of a user-written COBOL program and

the job control statements that call Database Services Utility to run SQL statements:

// JOB CONTROL TO RUN A USER PROGRAM THAT CALLS THE DBS UTILITY

// OPTION CATAL

PHASE COBDBSU,S

// EXEC IGYCRCTL

CBL TRUNC(BIN)

APOST

*********************************************

* Example COBOL program calling Database Services Utility *

*********************************************

IDENTIFICATION DIVISION.

PROGRAM-ID. COBDBSU

ENVIRONMENT DIVISION.

DATA DIVISION.

WORKING-STORAGE SECTION.

CALLTYPEID

PIC X(6) VALUE ’DBSU01’.

PARMSTRING.

PARMLEN

PIC S9(4) COMP.

PARMDATA

PIC X(80).

PROCEDURE DIVISION.

MOVE 49 TO PARMLEN.

MOVE ’ENDLUW(NO) CONNECT SQLDBA IDENTIFIED BY SQLDBAPW;’

TO PARMDATA.

CALL ’ARIDBS’ USING CALLTYPEID PARMSTRING.

MOVE 32 TO PARMLEN.

MOVE ’SELECT * FROM SYSTEM.SYSOPTIONS;’

TO PARMDATA.

CALL ’ARIDBS’ USING CALLTYPEID PARMSTRING.

FINIS.

STOP RUN.

INCLUDE ARIPRDID

INCLUDE ARIPADR4

INCLUDE ARISYSDD

INCLUDE ARIDSQLA

INCLUDE ARIDDFP

INCLUDE ARITDSSD

EXEC LNKEDT

EXEC PGM=COBDBSU

Figure 69. Sample COBOL Program to Call the Database Services Utility

Sample Assembler Program: Load and Invoke the Database Services Utility:

The following are basic examples of user-written assembler language programs

and the job control statements that invoke the Database Services Utility to run SQL

statements. In DB2 Server for VSE these statements run with single user mode.

124

Database Services Utility

// JOB CONTROL FOR USER PROGRAM THAT CDLOADS AND RUNS THE DBS UTILITY

// OPTION CATAL

PHASE VSELOAD,S

// EXEC ASSEMBLY

VSELOAD CSECT

EQU

R12

EQU

R13

EQU

R14

EQU

R15

EQU

STM

R14,R12,12(R13)

STORE THE CALLER’S REGISTERS

BALR

R12,0

ESTABLISH ADDRESSABILITY

USING

*,R12

R15,SAVE

GET ADDRESS OF MY SAVE AREA

R15,8(R13)

STORE FORWARD SAVE AREA POINTER

R13,4(R15)

STORE BACKWARD SAVE AREA POINTER

R13,R15

MAKE MY SAVE AREA CURRENT

CDLOAD ARIDBS

DBS ADDRESS RETURNED IN R1

R1,DBSADDR

SAVE DBS UTILITY ADDRESS

Figure 70. DB2 Server for VSE Sample Load-and-Invoke Assembler Program for the

Database Services Utility (Part 1 of 2)

MVI

PSTRINGT,C’ ’

CLEAR PARAMETER AREA

MVC

PSTRINGT+1(L’PSTRINGT-1),PSTRINGT CLEAR PARAMETER AREA

MVC

PSTRINGT(L’PARMDAT1),PARMDAT1

MOVE FIRST COMMAND

R0,L’PSTRINGT

LOAD PARAMETER STRING LENGTH

STH

R0,PSTRINGL

SET PARAMETER STRING LENGTH

R1,PARMLIST

LOAD PARAMETER LIST ADDRESS

R15,DBSADDR

LOAD DBS ADDRESS

BALR

R14,R15

CALL THE DBS UTILITY

MVI

PSTRINGT,C’ ’

CLEAR PARAMETER AREA

MVC

PSTRINGT+1(L’PSTRINGT-1),PSTRINGT CLEAR PARAMETER AREA

MVC

PSTRINGT(L’PARMDAT2),PARMDAT2

MOVE SECOND COMMAND

R1,PARMLIST

LOAD PARAMETER LIST ADDRESS

R15,DBSADDR

LOAD DBS ADDRESS

BALR

R14,R15

CALL THE DBS UTILITY

R13,4(R13)

GET ADDRESS OF CALLER’S SAVE AREA

R14,12(R13)

RESTORE CALLER’S R14

R0,R12,20(R13)

RESTORE CALLER’S R0-R12

R14

RETURN. R15=DBS RETURN CODE

SAVE

18F

DBSADDR

DBS ADDRESS SAVE AREA

PARMLIST DS

PARAMETER LIST

A(CTYPEID)

**ADDRESS OF CALL TYPE IDENTIFIER

A(PSTRING)

**ADDRESS OF PARAMETER STRING

CTYPEID DC

CL6’DBSU01’

PSTRING DS

PARAMETER LIST

PSTRINGL DS

** PARAMETER AREA LENGTH

PSTRINGT DS

CL250

** PARAMETER AREA

PARMDAT1 DC

C’CONNECT SQLDBS IDENTIFIED BY SQLDBAPW’

PARMDAT2 DC

C’FORMAT(LO) SELECT * FROM SYSTEM.SYSOPTIONS’

END

VSELOAD

// EXEC LNKEDT

// EXEC ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,LOGMODE=N,PROGNAME=VSELOAD’

Figure 70. DB2 Server for VSE Sample Load-and-Invoke Assembler Program for the

Database Services Utility (Part 2 of 2)

Chapter 7. Using the Database Services Utility from Application Programs

125

VMULOAD CSECT

EQU

R12

EQU

R13

EQU

R14

EQU

R15

EQU

STM

R14,R12,12(R13)

STORE THE CALLER’S REGISTERS

BALR

R12,0

ESTABLISH ADDRESSABILITY

USING

*,R12

R15,SAVE

GET ADDRESS OF MY SAVE AREA

R15,8(R13)

STORE FORWARD SAVE AREA POINTER

R13,4(R15)

STORE BACKWARD SAVE AREA POINTER

R13,R15

MAKE MY SAVE AREA CURRENT

LOAD

EP=ARIDBS

DBS ADDRESS RETURNED IN R0

R0,DBSADDR

SAVE DBS ADDRESS

MVI

PSTRINGT,C’ ’

CLEAR PARAMETER AREA

MVC

PSTRINGT+1(L’PSTRINGT-1),PSTRINGT CLEAR PARAMETER AREA

MVC

PSTRINGT(L’PARMDATA),PARMDATA

SET PARAMETER

R0,L’PSTRINGT

LOAD PARAMETER STRING LENGTH

STH

R0,PSTRINGL

SET PARAMETER STRING LENGTH

R0,R0

CLEAR REGISTER 0 (R1=PARM ADDRESS)

R1,PARMLIST

LOAD PARAMETER LIST ADDRESS

R15,DBSADDR

LOAD DBS ADDRESS

BALR

R14,R15

CALL THE DBS UTILITY

R13,4(R13)

GET ADDRESS OF CALLER’S SAVE AREA

R14,12(R13)

RESTORE CALLER’S R14

R0,R12,20(R13)

RESTORE CALLER’S R0-R12

R14

RETURN. R15=DBS RETURN CODE

SAVE

18F

DBSADDR

DBS ADDRESS SAVE AREA

PARMLIST DS

PARAMETER LIST

A(CTYPEID)

**ADDRESS OF CALL TYPE IDENTIFIER

A(PSTRING)

**ADDRESS OF PARAMETER STRING

CTYPEID

CL6’DBSU01’

PSTRING

PARAMETER LIST

PSTRINGL DS

** PARAMETER AREA LENGTH

PSTRINGT DS

CL250

** PARAMETER AREA

PARMDATA DC

C’FORMAT(LO) SELECT * FROM SYSTEM.SYSOPTIONS’

END

VMULOAD

Figure 71. DB2 Server for VM Sample Load-and-Invoke Assembler Program for the Database

Services Utility

Assuming that the DB2 Server for VM sample program is contained in the CMS

file VMULOAD ASSEMBLE A, you can run the program with multiple user mode

by entering the commands in Figure 72:

/* Example Database Services Utility to Run an ASSEMBLER Program Calling */

/* DBS Utility

ADDRESS ’COMMAND’

’GLOBAL MACLIB OSMACRO’

’GLOBAL LOADLIB ARISQLLD’

<---- Identifies DB2 Server for VM load library

’ASSEMBLE VMULOAD’

’LOAD VMULOAD’

’FILEDEF SYSPRINT TERMINAL (RECFM F LRECL 120’

’START’

EXIT

Figure 72. REXX EXEC to Run an Assembler Program That Loads the DBS Utility

126

Database Services Utility

Note: Before attempting to run the user program, identify the application server to

be accessed by using the SQLINIT EXEC.

Sample Assembler Program: Call the Database Services Utility: The following

are examples of user-written assembler language programs that invokes the

Database Services Utility. In DB2 Server for VSE, the Utility is invoked by means of

a CALL macro to process commands in a file defined as SYSIPT. The VSE job

control statements to assemble, link-edit, and run the user program with single

user mode are shown in the example. In DB2 Server for VM, the Utility in

invoked, by means of a CALL macro to process commands in a file defined as

SYSIN. All necessary CMS FILEDEF commands must be entered before this

program is executed.

// JOB CONTROL TO RUN A USER PROGRAM THAT CALLS THE DBS UTILITY

// OPTION CATAL

PHASE VSECALL,S

// EXEC ASSEMBLY

VSECALL CSECT

EQU

R12

EQU

R13

EQU

R14

EQU

R15

EQU

STM

R14,R12,12(R13)

STORE THE CALLER’S REGISTERS

BALR

R12,0

ESTABLISH ADDRESSABILITY

USING

*,R12

R15,SAVE

GET ADDRESS OF MY SAVE AREA

R15,8(R13)

STORE FORWARD SAVE AREA POINTER

R13,4(R15)

STORE BACKWARD SAVE AREA POINTER

R13,R15

MAKE MY SAVE AREA CURRENT

R0,0

CLEAR REGISTER 0

R1,0

INDICATE NO PARAMETER LIST PASSED

CALL

ARIDBS

R13,4(R13)

GET ADDRESS OF CALLER’S SAVE AREA

R14,12(R13)

RESTORE CALLER’S R14

R0,R12,20(R13)

RESTORE CALLER’S R0-R12

R14

RETURN. R15=DBS RETURN CODE

SAVE

18F

END

VSECALL

INCLUDE ARISYSDD

INCLUDE ARIDSQLA

INCLUDE ARIDDFP

INCLUDE ARIPRDID

INCLUDE ARITDSSD

// EXEC LNKEDT

// EXEC ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,LOGMODE=N,PROGNAME=VSECALL’

Figure 73. DB2 Server for VSE Sample Assembler Program to Call the Database Services

Utility

Chapter 7. Using the Database Services Utility from Application Programs

127

VMUCALL CSECT

EQU

R12

EQU

R13

EQU

R14

EQU

R15

EQU

STM

R14,R12,12(R13)

STORE THE CALLER’S REGISTERS

BALR

R12,0

ESTABLISH ADDRESSABILITY

USING

*,R12

R15,SAVE

GET ADDRESS OF MY SAVE AREA

R15,8(R13)

STORE FORWARD SAVE AREA POINTER

R13,4(R15)

STORE BACKWARD SAVE AREA POINTER

R13,R15

MAKE MY SAVE AREA CURRENT

R0,0

CLEAR REGISTER 0

R1,0

INDICATE NO PARAMETER LIST PASSED

CALL

ARIDBS

R13,4(R13)

GET ADDRESS OF CALLER’S SAVE AREA

R14,12(R13)

RESTORE CALLER’S R14

R0,R12,20(R13)

RESTORE CALLER’S R0-R12

R14

RETURN. R15=DBS RETURN CODE

SAVE

18F

END

VMUCALL

Figure 74. DB2 Server for VM Sample Assembler Program to Call the Database Services

Utility

Running the DB2 Server for VM Database Services Utility with

Multiple User Mode

With multiple user mode, the Database Services Utility runs as an application

program in the user’s virtual machine. It cannot run either in the CMS/DOS

environment or in CMS subset with multiple user mode.

Use the SQLINIT EXEC to specify the default database that you want to access. For

additional information on the SQLINIT EXEC, refer to the DB2 Server for VSE &

VM Database Administration manual.

Running the Database Services Utility with Single User Mode

When the Database Services Utility is run with single user mode, the database

manager is started by means of the SQLSTART EXEC, which is invoked by the

SQLDBSU EXEC. The database manager then loads the Database Services Utility

program and transfers control to the program ARIDBS. All startup and

initialization parameters cannot be directly supplied by means of the SQLDBSU

EXEC. The SQLDBSU EXEC parameters that can be supplied, however, and that

are applicable only to running the utility with single user mode are: DBNAME,

DCSSID, LOGMODE, and PARMID. These parameters are supplied to the

SQLSTART EXEC by the SQLDBSU EXEC when the database manager is started.

The SQLDBSU EXEC also supplies the initialization parameter,

PROGNAME(ARIDBS), to direct the database manager to execute the Database

Services Utility program ARIDBS. The IBM-supplied SQLSTART EXEC and the

startup and initialization parameters are described in the DB2 Server for VM System

Administration manual.

Single or Multiple User Mode: The sample commands shown below run the

Database Services Utility with single user mode and with multiple user mode to

perform the following functions:

v Unload all tables in the SQLDBA database dbspace PUBLIC.SAMPLE to a DASD

file

128

Database Services Utility

v Reload the dbspace PUBLIC.SAMPLE from the DASD file to reorganize the data

for all tables in the dbspace.

The CMS file DBSU COMMANDS A contains the following Database Services

Utility command input:

CONNECT SQLDBA IDENTIFIED BY SQLDBAPW;

UNLOAD DBSPACE(PUBLIC.SAMPLE) OUTFILE(DASD1)

RELOAD DBSPACE(PUBLIC.SAMPLE) PURGE INFILE(DASD1)

To run the utility with single user mode, enter the following commands:

FILEDEF DASD1 DISK DBSUFILE DATA A4 (RECFM VBS BLOCK 2048

SQLDBSU DBNAME(SQLDBA) SYSIN(DBSU COMMANDS A) SYSPRINT(TERMINAL)

To run the utility with multiple user mode, enter the following commands:

SQLINIT DBNAME(SQLDBA)

FILEDEF DASD1 DISK DBSUFILE DATA A4 (RECFM VBS BLOCK 2048

SQLDBSU SYSIN(DBSU COMMANDS A) SYSPRINT(TERMINAL)

Using the SQLDBSU EXEC

SQLDBSU EXEC Format: The following syntax diagrams show the format for

invoking the Database Services Utility with single or multiple user mode.

Format:

Multiple User Mode Parameters

►► SQLDBSU

►

sysIN

(

Reader

)

Terminal

file_name

file_type

file_mode

►

►◄

sysPRint

(

Printer

)

Terminal

file_name

file_type

file_mode

Multiple User Mode Examples:

SQLDBSU SYSIN(T) SYSPRINT(PR)

SQLDBSU

Notes:

1. When running the Database Services Utility in multiple user mode, you must

issue the SQLINIT EXEC before using the SQLDBSU EXEC. The SQLINIT

EXEC initializes the LASTING GLOBALV file and the database manager

Chapter 7. Using the Database Services Utility from Application Programs

129

bootstrap routines on your A-disk. These routines identify the application

server that you want to access and the method for loading the multiple user

mode support system routines.

The SQLINIT EXEC does not need to be run prior to each SQLDBSU command.

You need only to run the SQLINIT EXEC when you want to establish access to

a different application server, to vary the method of loading the multiple user

mode support system routines, or to change other characteristics of the

application requester.

An alternative method for connecting to another application server is to issue

the CONNECT command. See “CONNECT” on page 20, for more information

about using this command.

2. When the Database Services Utility (program ARIDBS) is run with multiple

user mode, it is loaded from load library ARISQLLD LOADLIB Q by using a

CMS NUCXLOAD command. Consequently, the SQLDBSU EXEC cannot be

run in the CMS/DOS environment with multiple user mode.

Format:

Single User Mode Parameters

►► SQLDBSU

►

sysIN

(

Reader

)

Terminal

file_name

file_type

file_mode

►

►◄

sysPRint

(

Printer

)

Terminal

file_name

file_type

file_mode

►► Dbname

(server_name)

►◄

dcssID

(dcss_id)

LOGmode

(

)

PARMID

(file_name)

Single User Mode Example: SQLDBSU IN(T) PR(DBSU LIST A) D(SQLDBA) ID(SUF1) LOG(Y) PARMID(SQL1)

Notes:

1. In single user mode, the console and program stack buffers are purged by the

SQLSTART EXEC. If you use multiple-volume tape files for Database Services

Utility processing with multiple user mode, the console and program stack

buffers should not contain any information. Empty buffers ensure that any

prompts issued by the multiple tape volume tape support can be properly

processed.

The following is a description of the parameters for the Database Services Utility

SQLDBSU EXEC.

sysIN (file_name file_type file_mode)

identifies the file name and optionally the file type and file mode of the CMS

file containing the Database Services Utility input commands. The file type

defaults to DBSINPUT and the file mode defaults to A.

130

Database Services Utility

If you supply this form of the SYSIN parameter, the SQLDBSU EXEC issues

the following CMS FILEDEF command for the Database Services Utility control

file:

FILEDEF SYSIN DISK file_name file_type file_mode . . .

(RECFM FB LRECL 80 BLOCK 800

sysIN (Reader)

specifies that the Database Services Utility input control file is a virtual reader

file. If you specify SYSIN(Reader), the SQLDBSU EXEC issues the following

CMS FILEDEF command for the Database Services Utility control file:

FILEDEF SYSIN READER (RECFM F LRECL 80

sysIN (Terminal)

specifies that the Database Services Utility input control file is the terminal. If

you specify SYSIN(Terminal), the SQLDBSU EXEC issues the following CMS

FILEDEF command for the Database Services Utility control file:

FILEDEF SYSIN TERMINAL (RECFM F LRECL 80

Notes:

The Database Services Utility control file is also assigned to the terminal if

you did not specify the SYSIN parameter, and you did not issue a CMS

FILEDEF command for the ddname=SYSIN before issuing the SQLDBSU

command.

If the Database Services Utility control file is assigned to the terminal:

Most Database Services Utility commands and all SQL statements must

be terminated by a semicolon. Database Services Utility commands

restricted to a single control file record (command line) do not require a

terminating semicolon. As a general rule, use a semicolon to terminate

all commands entered through the terminal.

The end of Database Services Utility input is indicated by entering a

null line. Prompts are issued to you after you use the ENTER key to

enter a null line. Your response depends on whether or not a command

has been partially entered and on the type of command entered. This

way, you cannot end Database Services Utility processing by mistakenly

using the ENTER key. If prompted to quit and you want to do so, enter

QUIT or HX.

Positions 1-80 of the input record are checked for command

information. Therefore, command records contained in files identified by

READ FILE commands entered through the terminal cannot contain

sequence numbers in positions 73-80. The READ FILE command has

the format:

READ FILE file_name file_type file_mode

If you use the READ FILE command, it must be the first command after

you issued the EXEC SQLDBSU command. It must not be preceded by

any other commands.

If Database Services Utility input entered from the terminal must

contain lowercase values, you must issue the following FILEDEF before

issuing the SQLDBSU EXEC without the SYSIN parameter specification:

FILEDEF SYSIN TERMINAL (RECFM F LRECL 80 LOWCASE

If you issue this FILEDEF command, all the Database Services Utility

command and SQL statement keywords must be entered in uppercase.

sysPRint (file_name file_type file_mode)

identifies the file name and optionally the file type and file mode of the CMS

Chapter 7. Using the Database Services Utility from Application Programs

131

file to be used for the Database Services Utility messages. The file type

specification defaults to DBSLIST and the file mode specification defaults to A.

If you specify this form of the SYSPRINT parameter, the SQLDBSU EXEC

issues the following CMS FILEDEF command for the Database Services Utility

message file:

FILEDEF SYSPRINT DISK file-name file-type file-mode . . .

(RECFM FBA LRECL 121 BLOCK 1210

Note: Position 1 of the Database Services Utility message file

(ddname=SYSPRINT) print records contains American Standards

Association (ASA) control characters. If the message file is a CMS file

and is printed with the CMS PRINT command, the option CC should be

specified in the CMS PRINT command. Refer to the VM/ESA: CMS

Command Reference manual for a description of the CMS PRINT

command.

sysPRint (Printer)

specifies that the Database Services Utility message file should be assigned to

the virtual printer.

If you specify SYSPRINT (Printer), the SQLDBSU EXEC issues the following

CMS FILEDEF command for the Database Services Utility message file:

FILEDEF SYSPRINT PRINTER (RECFM FA LRECL 121

sysPRint (Terminal)

specifies that the Database Services Utility message file should be assigned to

the terminal.

If your specify SYSPRINT (Terminal), the SQLDBSU EXEC issues the following

CMS FILEDEF command for the Database Services Utility message file:

FILEDEF SYSPRINT TERMINAL (RECFM F LRECL 120

Note: The Database Services Utility message file is also assigned to the

terminal if the SYSPRINT parameter is not specified, and you did not

issue a CMS FILEDEF command for the ddname=SYSPRINT before

issuing the SQLDBSU EXEC.

Dbname(server_name)

indicates that the Database Services Utility should be run with single user

mode. It also identifies the name of the database to be accessed by the

commands contained in the Database Services Utility control file.

If you specify this parameter, the SQLSTART EXEC parameters

DBNAME(server_name) are specified. The initialization parameters

SYSMODE=S, and PROGNAME=ARIDBS are also supplied in the SQLSTART

EXEC PARM parameter.

If you omit the DBNAME parameter, the Database Services Utility is run with

multiple user mode.

dcssID (dcss_id)

applies to running the Database Services Utility with single user mode. It

identifies the method by which all database manager modules are to be loaded

for execution. If you specify this parameter, you must also specify the

DBNAME parameter.

If you specify this parameter, it is supplied to the SQLSTART EXEC. The

SQLSTART EXEC then uses the database manager bootstrap routines with the

specified dcss-id to load the database manager code.

132

Database Services Utility

If you omit this parameter, it is not supplied as an SQLSTART EXEC

parameter.

LOGmode (A|L|N|Y)

applies only to running the Database Services Utility with single user mode.

This one-character field indicates how the logs are to be maintained:

A means maintain the logs and automatically archive the database.

L means maintain the logs and automatically archive the log when the

specified level has been reached.

N means do not maintain the logs for recovery.

Y means maintain the logs.

If you specify this parameter, you must also specify the DBNAME parameter.

It identifies the value to be used for the database initialization LOGMODE

parameter when the database manager is started in single user mode.

If you omit this parameter and you specify the DBNAME parameter, the

LOGMODE parameter is not supplied as an initialization parameter in the

SQLSTART EXEC.

PARMID (file_name)

applies only to running the Database Services Utility with single user mode. If

you specify this parameter, you must also specify the DBNAME parameter. It

identifies the file name of the CMS file that contains the database initialization

override parameters. The file type must be SQLPARM.

If you omit this parameter and you specify the DBNAME parameter, the

PARMID parameter is not supplied as an initialization parameter in the

SQLSTART EXEC.

For more information on the PARMID parameter, see the description of

SQLSTART in the DB2 Server for VM System Administration manual.

Notes:

1. If virtual console spooling is started and either SYSIN or SYSPRINT is

assigned to the terminal, the virtual console is spooled HOLD.

2. If the virtual printer is spooled NOHOLD, it is spooled HOLD, closed, and

then spooled NOHOLD.

3. When running the Database Services Utility, set the CP SET command EMSG

option to ON. The SQLDBSU EXEC checks the current EMSG option setting

and, if necessary, resets it to ON. If the EMSG option is reset, the original

setting is restored during the SQLDBSU EXEC termination processing. The

original EMSG setting is not restored if SQLDBSU EXEC execution is

abnormally terminated. Refer to the VM/ESA: CP Command and Utility

Reference for a description of the SET command’s EMSG option.

4. When running the Database Services Utility, the VM terminal logical

line-editing symbols (character delete, line delete, line end, and escape) must

be defined as follows:

LINEND # LINEDEL OFF CHARDEL OFF ESCAPE 1/2

The SQLDBSU EXEC checks the current settings for these symbols and, if

necessary, resets the symbols as described previously. If the symbols are reset,

the original symbols are restored during the SQLDBSU EXEC termination

processing. The symbols are not reset if SQLDBSU EXEC execution is

Chapter 7. Using the Database Services Utility from Application Programs

133

abnormally terminated. Refer to the VM/ESA: CP Command and Utility

Reference for a description of the TERMINAL command and the logical

line-editing symbols.

The Database Services Utility control file (ddname=SYSIN) logical record length

(LRECL) must be 80. The record format (RECFM) should be fixed or fixed

blocked.

The Database Services Utility message file (ddname=SYSPRINT) logical record

length (LRECL) must be at least 81. The record format (RECFM) should be

fixed or fixed blocked with ASA print control characters (F or FB).

If the Database Services Utility control parameter PAGECTL(NO) is specified,

the minimum message file record length is 80. The record format should be

fixed or fixed blocked (F or FB).

Database Services Utility and SQL statement information must be in positions

1-72 of the control file (ddname=SYSIN) records except when SYSIN defines the

input control file as the terminal. If the terminal is the control file, you can put

Database Services Utility and SQL statement information in positions 1-80 of a

command line that you enter from the terminal. If you enter a DB2 Server for

VM READ FILE file_name file_type file_mode command from the terminal, the

CMS file containing SQL statements or Database Services Utility commands

cannot have sequence numbers in positions 73-80 because the Database

Services Utility searches positions 1-80 for command information. For more

information on the READ FILE command, see the DB2 Server for VM Program

Directory.

You can always reference all 80 positions of data records contained in the

Database Services Utility control file as data field positions.

You must define all input or output data file ddnames referenced in the

Database Services Utility commands supplied in the Database Services Utility

control file through the CMS FILEDEF commands before issuing the

SQLDBSU command.

If you define DASD CMS files with variable-length spanned records for

Database Services Utility command input/output, you must use the file mode

number 4.

If you do not specify the SYSIN information in the EXEC parameters, and you

do not define the Database Services Utility control file (ddname=SYSIN) with

the CMS FILEDEF command before issuing the SQLDBSU command, the

SQLDBSU EXEC issues the following default FILEDEF command:

FILEDEF SYSIN TERMINAL (RECFM F LRECL 80

If you do not specify the SYSIN information in the EXEC parameters, but you

define the Database Services Utility control file (ddname=SYSIN) with a CMS

FILEDEF command before issuing the SQLDBSU command, the SQLDBSU

EXEC uses the user-defined Database Services Utility control file. Specify a

logical record length (LRECL) of 80 for a user-defined Database Services

Utility control file.

10.

If you do not specify SYSPRINT information, and you do not define the

Database Services Utility message file (ddname=SYSPRINT) with a CMS

FILEDEF command before issuing the SQLDBSU command, the SQLDBSU

EXEC issues this FILEDEF command:

FILEDEF SYSPRINT TERMINAL (RECFM F LRECL 120

If you define the Database Services Utility message file with a CMS FILEDEF

command, the minimum logical record length (LRECL) is 81. If you specify

the Database Services Utility control parameter as PAGECTL(NO), the

minimum message file record length is 80.

134

Database Services Utility

Chapter 8. Command Reference

The Database Services Utility can process commands that are unique to the

Database Services Utility and SQL statements that are not restricted to use in

user-written programs. This chapter provides descriptions of the Database Services

Utility commands and general rules governing how you type the commands. (SQL

statements are described in the DB2 Server for VSE & VM SQL Reference.)

Command Processing

Two kinds of commands that you can specify in the Database Services Utility are

Database Services Utility commands and SQL statements.

The difference between an SQL statement and a Database Services Utility

command is that a Database Services Utility command can only be issued within

the Database Services Utility. If you try to issue a Database Services Utility

command outside of the utility itself, it fails. On the other hand, an SQL statement

can be issued in both ISQL and the Database Services Utility.

Here is a summary of the Database Services Utility commands:

DATALOAD

DATAUNLOAD

RELOAD

UNLOAD

SET

COMMENT

REORGANIZE INDEX

SCHEMA

REBIND PACKAGE

Control commands are entered by means of one or more 80-byte input records in

the (input) control file. The utility usually reads only the first 72 positions of these

command records; you can use positions 73 through 80 for sequence numbers.

When control command input is being read directly from a DB2 Server for VM

terminal, all 80 positions of the command record can contain command

information. Some Database Services Utility commands allow you to place data

within the (input) control file; these data records are not restricted to the first 72

positions and can have information in all 80 positions.

In DB2 Server for VSE, lowercase information supplied in an input control card file

and read by the Database Services Utility is not converted to uppercase by

Database Services Utility processing. ISQL, on the other hand, converts lowercase

information to uppercase. Use uppercase in the input control card file to avoid a

case mismatch, especially for a table or dbspace name. In DB2 Server for VM,

lowercase information supplied in commands read by the utility is converted to

uppercase only when the control file (SYSIN) is assigned to the terminal. If you

require lowercase information and the utility reads commands from the terminal,

specify LOWCASE when you issue a CMS FILEDEF command to define the

control file (SYSIN). Alternatively, you can use the CMS SET INPUT xx yy

command to reset the hexadecimal code xx to the hexadecimal code yy. Refer to

the VM/ESA: CMS Command Reference manual for more information.

135

Except where noted, the control commands can span multiple 80-byte input

records. Individual keywords or parameter values must never span input records,

or a Database Services Utility processing error results. For example, these records

are correct:

┌──────────────────────────────────────────────────────────────────────────────┐

│ 1

┌───────────────┐

col 72

80 |

│ │────────────────────

| INPUT RECORDS |

─────────────────────────|

| |

│ │

└───────────────┘

│ │

│ ø

ø |

│

SELECT MFB001 |

│ EMPNO, LASTNAME FROM SQLDBA.EMPLOYEE;

MFB002 |

│

┌───────────┐

│

│ Correct.

│

└───────────┘

│

└──────────────────────────────────────────────────────────────────────────────┘

Figure 75. Example of Correct Records

MFB001 and MFB002 are sequence numbers that the Database Services Utility

ignores. Note that SELECT ends in position 72 in the above example. Conceptually,

the Database Services Utility inserts a single blank character between input records;

the above records are interpreted as:

SELECT EMPNO, LASTNAME FROM SQLDBA.EMPLOYEE;

The following input records are incorrect:

│ 1

┌───────────────┐

col 72

80 |

│ │────────────────────

| INPUT RECORDS |

─────────────────────────┤

│ |

│ │

└───────────────┘

│ │

│ ø

ø |

│

SELE MFB001 |

│ CT EMPNO, LASTNAME FROM SQLDBA.EMPLOYEE;

MFB002 |

│

┌──────────────────────┐

│

| Incorrect!

│

| Don’t split keywords |

│

└──────────────────────┘

│

Figure 76. Example of Incorrect Records

The Database Services Utility inserts a blank after column 72, and thus interprets

the input records as:

SELE CT EMPNO, LASTNAME FROM SQLDBA.EMPLOYEE;

The Database Services Utility does not recognize SELE as a Database Services

Utility command, and an error results.

There is an exception to the rule that individual keywords or parameter values

must not span input records. This exception occurs when a parameter is enclosed

in either single (') or double (") quotation marks. For these parameters, the

Database Services Utility does not insert a blank after position 72. Consider the

following example in which a character string constant spans multiple input

records. The character constant is delimited by a single quotation mark ('):

136

Database Services Utility

│ 1

┌───────────────┐

col 72

80 |

│ │────────────────────

| INPUT RECORDS |

─────────────────────────|

│ |

│ │

└───────────────┘

│ │

│ ø

ø |

│

SELECT ’AVERA MFB001 |

│ GE’, AVG(BONUS) FROM SQLDBA.EMPLOYEE;

MFB002 |

│

┌──────────────────────┐

│

| Correct.

│

| You can split

│

| quoted strings.

│

└──────────────────────┘

│

Figure 77. Example of a Character String Constant Spanning Multiple Input Records

The Database Services Utility interprets the above records as:

SELECT ’AVERAGE’, AVG(BONUS) FROM SQLDBA.EMPLOYEE;

Each Database Services Utility command or SQL statement must begin on a new

(input) control file input record.

DB2 Server for VM

Database Services Utility commands are terminated by a semicolon, by the

start of the next command, or by the end of the input control records.

Terminate Database Services Utility commands with a semicolon when

Database Services Utility control command input is being read directly from a

terminal.

In the Database Services Utility environment, SQL statements must be

terminated with a semicolon. Do not use the SQL continuation character

(required by ISQL) in an SQL statement that spans record boundaries in

either a batch or an interactive environment.

Database Services Utility processing ends when all the input records are processed.

You cannot reorganize a catalog index by using the REORGANIZE INDEX

command. To reorganize the catalog index in VM, use the SQLCIREO utility. In

VSE, set the STARTUP initialization parameter to one to reorganize the catalog

index.

Note: You can only reorganize a primary key index or a unique index by using the

ALTER TABLE ACTIVATE PRIMARY KEY and ALTER TABLE ACTIVATE

UNIQUE statements.

COMMENT

With the COMMENT command, you can document input by supplying Database

Services Utility COMMENT commands at appropriate points within the Database

Services Utility control command input stream. The utility displays the comments

in the report or message file listing. You cannot use SQL comments within

Database Services Utility COMMENT commands.

Chapter 8. Command Reference

137

DB2 Server for VSE. Operations Guide / Handbooks (2004-2007) - page 36
