COMMENT Format

Format:

►► COMMENT

’string_constant’

►◄

COMMENT

identifies a Database Services Utility COMMENT command. At least one blank

must appear after the command identifier.

'string-constant'

is the comment text delimited by single quotation marks. The string-constant

can span control command input records, but must begin in the same record

that contains the command identifier. All positions of a control command

record containing comment text are displayed. A COMMENT command is

terminated when a control command input record containing comment text

ends with a single quotation mark or a single quotation mark immediately

followed by a semicolon. All control command input record positions

(normally positions 1-72) after the terminating single quotation mark or single

quotation mark and semicolon must be blank. Positions 73-80 of comment text

records can still contain sequence numbers (except in DB2 Server for VM when

Database Services Utility control command input is being read directly from a

terminal).

REORGANIZE INDEX

The REORGANIZE INDEX command allows you to correct index fragmentation,

and correct the skewing of index key values without having to drop the index and

then recreate it using the DROP INDEX and CREATE INDEX SQL statements.

REORGANIZE INDEX also revalidates an invalid index.

As with other Database Services Utility commands, you can use the REORGANIZE

INDEX command with both single user mode and multiple user mode.

Note: The REORGANIZE INDEX command is not supported if you are using

DRDA flow.

REORGANIZE INDEX Format

Format:

►► REORGANIZE INDEX

(index_name)

►◄

PCTFREE = integer

Example:

REORGANIZE INDEX(SMITH.INDEXINV) PCTFREE = 50

Authorization: You must own the index or have DBA authority.

Note: In DB2 Server for VSE, to reorganize a catalog index, you must start the database manager in single user

mode and specify STARTUP=I.

INDEX (index-name)

identifies the index to be reorganized. You can further identify the index by

specifying the owner and server-name of the index. For more information about

identifying the index, see “Qualifying Object Names” on page 110 for details.

138

Database Services Utility

When reorganizing an invalid index, the database manager uses a sort similar

to the one used for a CREATE INDEX statement.

PCTFREE = integer

allows you to control the amount of free space that REORGANIZE reserves in

the index for later insertions and updates.

integer

is a number from 0 to 99 representing a percentage of the total index space.

For practical purposes, it should not exceed 50.

If you do not specify PCTFREE, the amount of free space remains unchanged from

the previous PCTFREE value.

The REORGANIZE INDEX command consists of several separate internal steps.

Some steps might be completed even though the whole REORGANIZE INDEX

command is not completed successfully.

The following unusual situations can occur when rolling back or recovering from a

REORGANIZE INDEX command:

v Although a REORGANIZE INDEX command is successfully completed during

forward processing, it might not be completed during rollback or recovery

because the system has run out of physical or logical pages (or both).

Checkpoints for sufficient storage can interrupt only during forward processing.

As a result, the recovered index is marked invalid.

v If an index reorganization is rolled back or undone, the recovered index is

nevertheless reorganized. In REORGANIZE INDEX processing, the index is

effectively dropped and re-created, resulting in a reorganized index. If you

changed the PCTFREE value, however, that value is set back to the original

value defined before the REORGANIZE INDEX command.

v If the system ends abnormally after an index reorganization is interrupted by a

checkpoint and an attempt is made to restart the database manager without the

current log (because of a loss of the log or log reconfiguration), the reorganized

index will be marked as invalid. It must be recovered by dropping the dbspace

and re-creating it, or by restoring a previous database archive.

v The updating of index statistics is not supported during rollback or recovery.

The previous index statistics are recovered, but the recovered index (which is

nevertheless reorganized) may not match them.

DBSS prevents a REORGANIZE INDEX or CREATE INDEX command from

proceeding if the command can overflow the invalid index limit. During rollback

or recovery, if the maximum number of invalid indexes (30) is reached, the system

ends abnormally. When the system is brought up again for recovery, it is very

likely to end again for the same reason. If the large number of invalid indexes

exists because of a lack of physical pages, add a dbextent to the system before

attempting to recover again. If the large number of invalid indexes exists because

of a lack of logical index pages, use filtered log recovery to skip over the index

reorganizations that are causing the invalid indexes. For information about adding

a dbextent, see the DB2 Server for VM System Administration and DB2 Server for VSE

System Administration manuals. To find out more about using filtered log recovery,

see the DB2 Server for VSE & VM Diagnosis Guide and Reference manual. Additional

information on the REORGANIZE INDEX command is in the DB2 Server for VSE &

VM Database Administration manual.

Chapter 8. Command Reference

139

You cannot reorganize a catalog index by using the REORGANIZE INDEX

command. To reorganize the catalog index in VM, use the SQLCIREO utility. In

VSE, set the STARTUP initialization parameter to I to reorganize the catalog index.

Note: You can only reorganize a primary key index or a unique index by using the

ALTER TABLE ACTIVATE PRIMARY KEY and ALTER TABLE ACTIVATE

UNIQUE statements.

SCHEMA

A schema file specifies an authorization ID and a list of table, view, and privilege

definitions using the syntax of the CREATE TABLE, CREATE VIEW, and GRANT

statements. The SCHEMA command reads and processes the statements from a

schema file.

SCHEMA Format

Table 7. SCHEMA Command Syntax

Format:

(1)

►►

SCHEMA INFILE

( ddname

option-c

)

►◄

(dbspace_name)

Notes:

Option C is valid in DB2 Server for VSE only.

option-c:

2000

REWIND

BLKSZ

(

size

)

(TAPE)

NOREWIND

PDEV

(DASD)

Example:

SCHEMA INFILE(IN1 BLKSZ(800))

Authorization:

You must be connected as the AUTHORIZATION ID specified in the CREATE SCHEMA statement.

INFILE (ddname)

identifies the sequential input file containing the schema.

ddname

in DB2 Server for VSE: this is the TLBL or DLBL job control statement file

name for the sequential input file. The file must have a record format of

fixed-length blocked and a record length of 80.

Alternatively, SCHEMA can read its input from SYSIPT by using a READ

MEMBER. You use the READ MEMBER NOCONT option to properly close

the SYSIPT file. An example of using READ MEMBER with NOCONT is:

SCHEMA INFILE(SYSIPT)

READ MEMBER schema-member (NOCONT

140

Database Services Utility

If you do not specify the NOCONT option, the database manager reads in

the SYSIPT records following the READ MEMBER statement as part of the

SCHEMA file; then SYSIPT can provide additional input after the READ

MEMBER statement.

in DB2 Server for VM: this is the name of the sequential input file. It must

have records with a fixed length of 80 characters. The file characteristics

specified in the FILEDEF command or the default FILEDEF options are the

source of the input record definition information for the Database Services

Utility. Do not specify SYSIN or SYSPRINT as the ddname.

dbspace-name

specifies the name of the dbspace where the table is to be placed if no

dbspace-name is given in the CREATE TABLE statement. If the CREATE

TABLE statement in the SCHEMA input file specifies a dbspace-name then

this overrides the name of the dbspace given in the SCHEMA command.

BLKSZ (size) (DB2 Server for VSE Only)

is a parameter that specifies the block size of the sequential input file. The

default block size is 2 000 bytes per block.

PDEV (TAPE or DASD) (DB2 Server for VSE Only)

is an optional parameter that specifies the device type (DASD or TAPE) of the

sequential (SAM) input file. If PDEV(DASD) is specified, the file resides on any

device supported by the VSE DTFSD macro. VSAM-managed SAM does not

support spanned records. If PDEV(TAPE) is specified, the file resides on any

device supported by the VSE DTFMT macro. The default is PDEV(TAPE).

NOREWIND or REWIND

controls tape file rewind processing performed during OPEN processing.

This parameter is valid only if you specify TAPE for PDEV. The default

processing is REWIND.

NOREWIND

specifies that the tape file is not to be rewound by OPEN processing. If

NOREWIND is specified for input tape files referenced by a series of

SCHEMA commands, you must ensure that the tape files being

referenced are in ascending sequence. For example, if NOREWIND is

specified in a sequence of two SCHEMA commands and the first

command reads tape file 2, then the second command must reference

tape file 3 or a higher number. If it references tape file 1, an OPEN

error occurs.

REWIND

specifies OPEN processing to rewind the tape file.

Chapter 8. Command Reference

141

Table 8. Contents of the Schema (in a Sequential Input File)

Format:

;

▼

►► CREATE SCHEMA AUTHORIZATION authorization_id

►◄

;

schema_statement

Example:

-- create table TAB1 and give Jones SELECT privilege

CREATE SCHEMA AUTHORIZATION SMITH

CREATE TABLE SMITH.TAB1 (COL1 CHAR(4))

GRANT

SELECT ON

TAB1

TO JONES

The first line of the above example is a comment line. To insert comments within

the schema file:

v Mark the beginning of a comment with two consecutive hyphens (--)

v Begin the comment anywhere on a record or line

v End the comment with the end of the record or line.

The sequential input file must contain only one CREATE SCHEMA statement,

which must be the first statement in the file (unless the preceding lines are

comments); otherwise, the Database Services Utility issues an error message and

stops processing the SCHEMA command.

AUTHORIZATION authorization id

You must be connected as the authorization id in the AUTHORIZATION clause.

If a schema statement does not specify an owner, the statement is processed for

the authorization ID. For example, in Table 8 the SELECT privilege in the

GRANT statement is granted on SMITH.TAB1.

schema-statement

refers to every statement following the CREATE SCHEMA statement. Valid

schema statements are:

v CREATE TABLE

v CREATE VIEW

v GRANT (INSERT, SELECT, UPDATE, REFERENCES, ALL and DELETE

privileges).

The schema statements must be entered in uppercase. See the DB2 Server for

VSE & VM SQL Reference for the correct syntax of valid schema statements.

Successful statements are committed if the Database Services Utility

AUTOCOMMIT indicator is ON.

The Database Services Utility issues an error message if any invalid statement

is in the schema, and might or might not continue processing on the next

statement, depending on the setting of ERRORMODE.

142

Database Services Utility

You can change the setting of the ERRORMODE and AUTOCOMMIT indicators before the SCHEMA

command by issuing the Database Services Utility SET ERRORMODE and SET AUTOCOMMIT

commands. If ERRORMODE is set to CONTINUE, processing continues on the next statement

following a minor error on any sequential input file statement other than the CREATE SCHEMA

statement. If AUTOCOMMIT is ON, the work is committed after each successful statement. For a

complete description of these commands, see “SET ERRORMODE” on page 215 and “SET

AUTOCOMMIT” on page 214.

Using File Definitions with the DB2 Server for VM SCHEMA

Command

The schema file must have a fixed length of 80 characters. This format is used if

you do not specify any FILEDEF options when you define a schema file. For

example, you can create a FILEDEF such as this:

FILEDEF DBSFILE DISK DBSFILE SCHEMIN A

where DBSFILE is the name of the schema file as you refer to it in the SCHEMA

command.

For a procedure to construct a FILEDEF command, see “Using File Definitions” on

page 14. For more information about FILEDEF parameters and options, see

Appendix B, “FILEDEF Command Syntax and Notes,” on page 249.

SQL Statement Processing

The SQL statements that you can enter from the (input) control file are:

v SELECT statements (without an INTO clause or host variables)

v Data manipulation statements

v Data control statements

v Data definition statements

v Authorization statements.

You cannot enter some SQL statements in the Database Services Utility (input)

control file. You receive an error message if you attempt to use these statements:

v SELECT statements with an INTO clause or host variables

v Cursor management statements (DECLARE, OPEN, FETCH, CLOSE)

v Commands that support dynamic SQL statement execution (PREPARE,

DESCRIBE, EXECUTE, EXECUTE IMMEDIATE)

v Exception handling statements (WHENEVER statements)

v INCLUDE statements (INCLUDE SQLCA or INCLUDE SQLDA).

SQL statements entered from a Database Services Utility (input) control file must

not be prefixed by EXEC SQL (as they are when embedded within application

programs). In DB2 Server for VM, no information should be placed in the input

record after the semicolon. This restriction does not apply to positions 73 through

80 of a control-file record when the Database Services Utility control file is

assigned as a CMS file. In DB2 Server for VSE, use a semicolon to indicate the end

of each SQL statement. Do not use the continuation character required by ISQL for

SQL statements that span record boundaries. Except for positions 73 through 80, no

information should be placed in the input record after the semicolon.

SELECT and Arithmetic Exceptions

Database Services Utility flags arithmetic exceptions in outer select-lists by filling

the corresponding fields with number (or pound) signs (#). When one or more of

these exceptions occur, (for example, when a number is divided by zero) a

Chapter 8. Command Reference

143

Database Services Utility and an SQLCODE message are issued after the results are

retrieved. If more than one arithmetic exception occurs, only one

message—referring to the first exception—is issued. This is to alert you to any

warnings occurring during Database Services Utility (input) control file processing.

Processing Summary

Figure 78 summarizes the Database Services Utility processing that you can

perform on tables and views.

Table

View

Multiple

Tables

UNLOAD

DATAUNLOAD

TABLE

DBSPACE

(Note that the SAM

SAM File

files could also be

on magnetic tape.)

Table

User Program

RELOAD TABLE NEW

RELOAD TABLE PURGE

DATALOAD TABLE

View

RELOAD DBSPACE

NEW OR PURGE

One or

Tables

Figure 78. Database Services Utility Processing

Notes:

1. See Database Services Utility UNLOAD record format description in

“UNLOAD DBSPACE” on page 201 and “UNLOAD TABLE” on page 204.

2. View definitions must not violate any of the rules related to SQL INSERT

processing. In general, the view must be:

v Defined only on one table

v Defined to include all the NOT NULL columns of the underlying table

v Defined without using virtual column definitions.

3. If SAM files created by Database Services Utility UNLOAD processing are used

as input to Database Services Utility DATALOAD processing, the rules below

must be followed. (This description assumes that you are thoroughly familiar

with the Database Services Utility UNLOAD record formats and the contents of

each Database Services Utility UNLOAD record type.)

v All input data records selected for DATALOAD processing must contain data

fields in the same position in each data record up to the last position of a

data record type referenced by DATALOAD commands.

144

Database Services Utility

This rule implies that all input data record varying-length fields must have

the same length. Any fields that permit nulls must all be null or must all

contain data.

v The DATALOAD input-record-id-clause must be employed to select at least

the UNLOAD record type 60 for DATALOAD processing.

v The position of the column data in the input data record must be computed

from the following information:

- Order of column definition in source table or view

- Actual length of column data at time of UNLOAD

- Fixed “overhead” in data records created by Database Services Utility

UNLOAD processing.

Load-Data Commands

DATALOAD TABLE

The DATALOAD command and subcommands are contained on more than one

input record. If, for example, you want to load data into 10 columns of a table, the

first input record contains the DATALOAD command, and the next 10 input

records contain the Table Column Identification (TCI) subcommands.

The DATALOAD command cannot be continued onto a second input record; it

must be completed on a single record. The record immediately following the

DATALOAD command must contain a TCI subcommand.

DATALOAD TABLE Format

Format:

►► DATALOAD TABLE

(table_name)

►◄

input_record_id_clause

►► table_column_id_subcommand

►◄

►►

infile_subcommand

►◄

▼

user_data_record

ENDDATA

Note: Detailed syntax is shown in the following pages.

Example:

DATALOAD TABLE(SMITH.ACTIVITY)

ACTNO 1-3

ACTKWD 5-10

ACTDESC 12-21

INFILE(NEWACT)

<-------in DB2 Server for VM

INFILE(NEWACT BLKSZ (2048) PDEV (TAPE) NOREWIND RECFM(FB)) <-in DB2 Server for VSE

Chapter 8. Command Reference

145

Authorization: You must have the INSERT and SELECT privilege on the tables

affected by the command.

TABLE (table_name)

identifies the table (called table_name) to be loaded. (The table must already

exist.) You can further identify the table by specifying the owner of the table.

For more information about identifying tables see “Qualifying Object Names”

on page 110. A synonym cannot be used as table_name. You can specify a view

name instead of a table name if the view meets the following requirements:

v The view is defined on a single table.

v The view definition includes all NOT NULL columns in the table. That is, all

columns outside of the view definition must permit the insertion of nulls.

v The view does not contain a column that is a virtual column.

A virtual column is a column of a view that is not derived directly from a

column of a table. For example, view columns defined with expressions such

as BONUS+COMM, PRSTAFF*1.5, or AVG(BONUS) are virtual columns.

When loading data into a view that was created using the WITH CHECK

OPTION clause, the database manager checks all inserts and updates to the

view against the view definition and rejects them if the row to be inserted or

updated does not conform to the view definition.

table_name

identifies the table to be loaded.

input_record_id_clause

is optional; it allows you to selectively load records into the table. Records are

used for DATALOAD processing only if they contain the value specified in the

input_record_id_clause. All input data records are loaded into the table if you

omit this parameter.

If multiple DATALOAD commands are supplied before an INFILE command

and an input_record_id_clause appears on one of them, all the DATALOAD

commands must have the clause. Database Services Utility error messages are

generated and no DATALOAD processing is performed if you break this rule.

The parameters of input_record_id_clause are:

startpos

identifies the starting position in the input record of the identification value.

Position 1 of the input record is the first position of the logical record. If

variable-length input records are used, startpos 1 to 4 refers to the record length

control field. As a result, startpos 5 refers to the first data position.

endpos

identifies the last position of the identification value. If the value occupies only

one position, you need only specify startpos. Blanks are not allowed between

the starting position, hyphen, or ending position values.

constant

identifies the identification value. If an input record contains this value in the

specified location, it is used for loading the specified table.

The value cannot be continued onto a second input record. It can be one of the

following:

v A character-string constant that satisfies both of these requirements:

- Must be enclosed in single quotation marks (')

- Has a value of maximum length equal to endpos−startpos+1.

v A one-position unsigned integer constant (range is 0 to 255)

146

Database Services Utility

v A two-position optionally signed integer constant (default is a positive

value)

v A four-position optionally signed integer constant (default is a positive

value).

Notice that one-, two-, or four-position refers to the length the value occupies

in the input record, not the length it occupies in the clause itself. See Figure 79

through Figure 82 for examples to clarify this definition.

Examples of Input-Record-Id-Clause

IF POS (20-22) =

’RT1’

▌1▐

IF POS (20-21) ¬= ’01’

▌1▐

To be used for DATALOAD, positions 20 to 22 of the input data record

must contain the character string RT1.

Figure 79. Character-String Constant Value Used in the Input-Record-Id-Clause

IF POS (20)

= 255

▌1▐

IF POS (16)

¬= 25

IF POS (35)

▌1▐

To be used for DATALOAD, positions 20 of the input data record

must contain a hex FF value.

Figure 80. One-Position Integer Constant Value Used in the Input_Record_Id_Clause

IF POS (20-21)

= 1

▌1▐

IF POS (35-36)

<> 50

IF POS (5-6)

+32767

IF POS (3-4)

32767

▌1▐

To be used for DATALOAD, positions 20 through 21 of the input

record must contain a hex 0001 value.

Figure 81. Two-Position Integer Constant Value Used in the Input_Record_Id_Clause

IF POS (20-23)

= 15

▌1▐

IF POS (16-19)

¬= 50

IF POS (21-24)

+2000123563

IF POS (20-23)

1839107489

▌1▐

To be used for DATALOAD, positions 20 through 23 of the input

record must contain a hex 0000000F value.

Figure 82. Four-Position Integer Constant Value Used in the Input_Record_Id_Clause

Chapter 8. Command Reference

147

Table_Column_Id Subcommand

Format:

►► column_name startpos

options

null_current_clause

►◄

options

CHARacter

▼

-endpos

data_type

The next record following the DATALOAD command must contain a Table

Column Identification (TCI) subcommand. If it does not, the Database Services

Utility issues an error message. TCI subcommands identify the location in the

input records of the data for a table column. Only one TCI subcommand can

appear in an input record. The command parameters must not span input records,

and the column_name, startpos, and endpos parameters must be specified first in the

command and in that order.

The data must be in the same record positions in all records that relate to the table.

column_name

specifies the name of the table column where the input data is to be stored.

startpos

identifies the starting position of the data in each input data record. Position 1

of the input record corresponds to the first position of the logical input record.

If variable-length input records are used, startpos 1 to 4 will refer to the record

length control information. As a result, startpos 5 refers to the first data

position.

endpos

identifies the end position of the data in each input data record. You can omit

this parameter if the data occupies only one position in the input record. If you

specify this parameter, do not place blanks between the starting position and

the hyphen, or between the hyphen and the ending position.

data-type

identifies whether character, fixed-binary, floating-point, zoned, packed

decimal, or graphic data values are contained in the record positions specified.

The data type specification can appear either before or after null or current if

both parameters are entered. The data type parameter is optional, and the

default data type is character. The valid data type identifiers that you can

specify are:

CHAR or CHARACTER

If the column-type is CHAR, an all-blank input record data field results in

a sequence of blanks being inserted in the table.

If the table column is defined with a column-type of VARCHAR, trailing

blanks are removed from the input record data field before the length of

the field is established. An all-blank input record data field targeted for a

148

Database Services Utility

varying-length character column results in a length of 0. (A sequence of

blanks is not inserted in the database.)

If extended DBCS is in effect for a database, character input data can

contain DBCS characters with shift-in and shift-out delimiters, but the

Database Services Utility does not ensure that shift-in and shift-out

delimiters are balanced.

If the table column is defined as numeric (SMALLINT, INTEGER,

DECIMAL, or FLOAT), character (EBCDIC) input data must be in the form

of an SQL INTEGER, DECIMAL, or FLOAT constant. The character input

data is then converted by Database Services Utility processing.

Note: If a data field contains an EBCDIC numeric value that is not in the

form of an SQL INTEGER, DECIMAL, or FLOAT constant, (or if it

contains an implied decimal point), the data field can meet the

requirements of a DATALOAD ZONED input data field.

The type of representation allowed for numeric values in character (CHAR

or CHARACTER) input data fields depends on the data type of the target

numeric column:

v A value in an SQL INTEGER constant format is valid for a SMALLINT

or INTEGER column.

v A value in an SQL INTEGER or DECIMAL constant format is valid for a

DECIMAL column.

v A value in an SQL INTEGER, DECIMAL, or FLOAT constant format is

valid for a FLOAT column.

The number is converted regardless of its position in the field, but leading

and trailing blanks are ignored. If you specify a data field in positions 1 to

5 and type a 2-character number in positions 4 and 5, the number is

recognized. In the example below, the TCI subcommand says that data for

ACTNO (which has a SMALLINT data type) is in record positions 1

through 5. Additionally, it identifies that the data within those record

positions is character. Thus, the Database Services Utility must convert the

character data on the input record to a SMALLINT value before it can

insert it into the ACTNO column shown in Figure 83.

DATALOAD TABLE(ACTIVITY)

ACTNO 1-5 CHAR

Input Record:

In both of these cases, the utility

recognizes 45 and ignores the leading

or trailing blanks when performing

data conversion.

Figure 83. Character Input Data Used in Data type-n

Chapter 8. Command Reference

149

The precision and scale represented in the CHAR field targeted for a table

column with a data type of DECIMAL must be less than or equal to the

precision and scale defined for the column. Leading zeros after the

optional sign are ignored; thus, you can code:

+000000011.1

on an input data record, and it fits into a column with a data type of

DECIMAL(3,1).

Character is the default data type for input records.

DATE

If the table column is defined with a column type of DATE, input data can

be in one of the following formats:

yyyy-mm-dd

(ISO, JIS format)

dd.mm.yyyy

(EUR format)

mm/dd/yyyy

(USA format)

installation defined

(Local format)

where:

yyyy is the year

mm is the month

dd is the day

Local Date Format

A database administrator can change the date default format, which is

defined in the SYSTEM.SYSOPTIONS table, from ISO (which is the

system-supplied database default form) to any installation-defined

format. See the DB2 Server for VSE System Administration, or DB2 Server

for VM System Administration manuals for information about

installation-defined formats and their interface.

Note: You can omit leading zeros from months and days, but do not

replace them with blanks. For example, 2000-1-1 is valid while

2000-1-1 is not.

TIME

If the table column is defined with a column type of TIME, input data can

be in one of the following formats:

hh:mm AM or hh:mm PM

(USA format)

hh.mm[.ss]

(ISO, EUR format)

hh:mm[:ss]

(JIS format)

installation defined

(Local format)

where:

hh is the hour

0 <= hh <= 12

for USA format

0 <= hh <= 24

for ISO, EUR, JIS format

mm is the minutes

ss is the seconds

In the USA time format, you can specify zero in the hh field only for 00:00

a.m.

Local Time Format

A database administrator can change the time default format, which is

defined in the SYSTEM.SYSOPTIONS table, from ISO (which is the

system-supplied database default form) to any installation-defined

format. See the DB2 Server for VSE System Administration or the DB2

150

Database Services Utility

Server for VM System Administration manual for information about

installation-defined formats and their interface.

Note: Leading zeros can be omitted from hours. The specification of

seconds is optional.

TIMESTAMP

If the table column is defined with a column type of TIMESTAMP, input

data must be in the following format:

yyyy-mm-dd-hh.mm.ss[.[nnnnnn]]

where

yyyy-mm-dd is the date (see ISO DATE format)

hh.mm.ss is the time (see ISO TIME format)

nnnnnn is the microseconds

Notes:

1. Leading zeros can be omitted from the month, day, and hour.

2. The microsecond format is optional.

FIXED or INT or INTEGER

If the table column is defined with a data type of SMALLINT, the input

can be in a 1-byte or 2-byte binary data field. Table columns defined with a

data type of INTEGER can be loaded from a 1-byte, 2-byte, or 4-byte

binary input data field.

The value ranges for binary input data fields are:

v A 1-byte binary data field can contain an 8-bit binary integer with a

value range of 0 to 255.

v A 2-byte binary data field can contain a 15-bit binary integer with the

value range described for a table column defined with the data type

SMALLINT.

v A 4-byte binary data field can contain a 31-bit binary integer with the

value range described for a table column defined with the data type

INTEGER.

FLOAT or REAL

If FLOAT is specified for 4-byte floating-point binary input data, set

startpos and endpos so that (endpos−startpos+1) = 4. The table column

identified must be defined with a data type of REAL or FLOAT(n) where n

is from 1 to 21.

FLOAT or DOUBLE PRECISION

If FLOAT is specified for 8-byte floating-point binary input data, set

startpos and endpos so that (endpos−startpos+1) = 8. The table column

identified must be defined with a data type of FLOAT, DOUBLE

PRECISION, or FLOAT(n) where n is from 22 to 53.

Note: If 8-byte floating-point binary data is loaded into a 4-byte

floating-point table column, a number of digits of precision are lost.

DECIMAL or DEC (scalevalue)

If you have packed decimal input data, the table column must be defined

with a DECIMAL data type. The precision of the input decimal data field

value must be equal to or less than the precision of the target decimal

column. The Database Services Utility takes the scale (number of positions

to the right of the implied decimal point) of an input record decimal data

value from the scale of the target column unless you specify the optional

DECIMAL(scalevalue) form of the command parameter.

Chapter 8. Command Reference

151

The optional scalevalue is an integer value (0 through 31) identifying the

number of scale positions in the input record decimal data value. A

scalevalue equal to or less than the scale of the target DECIMAL column is

allowed. A Database Services Utility processing error occurs if the scalevalue

is greater than the scale of the target DECIMAL column.

If the DECIMAL(scalevalue) form of the parameter is used, no blanks are

allowed within the parameter specification.

Columns defined as NUMERIC are treated as DECIMAL data types.

ZONED (scalevalue)

If the input record data field has a zoned value, the target table column

must be defined as numeric (SMALLINT, INTEGER, DECIMAL, FLOAT).

See Figure 84 on page 154 for examples.

Three variations or types of zoned data input are supported (see

description below). The type of zoned data is identified by Database

Services Utility processing. Database Services Utility processing converts

the zoned data to the data type of the target numeric column.

Note: If a data field contains an EBCDIC numeric value with an explicit

decimal point, or otherwise does not meet the requirements of a

zoned input data field, the data field can meet the requirements of a

DATALOAD character (CHAR) input data field. DATALOAD

character input data is described in this section.

If the zoned field is for a DECIMAL column, it must contain a value with a

precision less than or equal to the precision of the target DECIMAL

column. The Database Services Utility uses the scale (number of positions

to the right of the implied decimal point) of the target DECIMAL column

for the scale of a zoned value in the input record unless the optional

ZONED(scalevalue) form of the command parameter is specified.

The optional scalevalue is an integer value (0 through 31) identifying the

number of scale positions in each input record zoned data field value. A

scalevalue equal to or less than the scale of the target DECIMAL column is

allowed. A Database Services Utility processing error occurs if scalevalue is

greater than the scale of the target DECIMAL column.

If the ZONED(scalevalue) form of the parameter is used, no blanks are

allowed within the parameter specification. Also, scalevalue is ignored if the

target column is defined as a SMALLINT, INTEGER, or FLOAT column.

The Database Services Utility zoned data support is based on the definition

of a zoned field that is described in the publication IBM System/370

Principles of Operation manual. It includes support for standard and

extended decimal items (zoned decimal items).

The following three variations of a zoned input data field are supported:

1. A standard zoned data field.

A numeric value within a standard zoned data field has the following

format:

v Each digit of a number is represented by a single byte.

v The 4 high-order bits of each byte are zone bits except for the 4

high-order bits of the low-order byte, which represent the sign of the

number.

v The 4 low-order bits of each byte contain the value of the digit.

The valid zone bit configuration for a standard zoned data field is:

152

Database Services Utility

1111

(hex F)

The valid plus-sign bit configurations for a standard zoned data field

are:

1010

(hex A)

1100

(hex C)

1110

(hex E)

1111

(hex F)

The valid minus-sign bit configurations for a standard zoned data field

are:

1011

(hex B)

1101

(hex D)

A zoned field with a leading sign.

A zoned data field value with a leading sign has a format identical to

the zoned data format described above except that the 4 high-order bits

of the high-order byte represent the sign of the number. The 4

high-order bits of the low-order bytes contain zone bits.

The valid plus-sign bit configuration for a zoned data field with a

leading sign is:

1100

(hex C)

The valid minus-sign bit configuration for a zoned data field with a

leading sign is:

1101

(hex D)

The valid zone bit configurations for a zoned data field with a leading

sign is:

1111

(hex F)

A zoned field with a trailing sign in a separate position.

A numeric value within a zoned data field with a trailing sign in a

separate position has a format similar to the zoned data format

described above except that the high-order 4 bits of the high-order and

low-order numeric value bytes contain zone bits. The sign of the

numeric data value is contained in a separate low-order data value

byte.

The valid zone bit configuration for the numeric value bytes in a zoned

data field with a trailing sign in a separate position is:

1111

(hex F)

A plus-sign is represented in the separate low-order data field position

by an EBCDIC plus (+) sign (hex 4E) or by a blank (hex 40). A

minus-sign is represented in the low-order data field position by an

EBCDIC minus (−) sign (hex 60).

Chapter 8. Command Reference

153

┌────────────────┬─────────────────────────────────────────────────────┐

│ HEXADECIMAL

│ DESCRIPTION OF VALUE LOADED INTO NUMERIC COLUMN

│

│ CONTENTS OF

├─────────────────────────────────────────────────────┤

│FIVE(5) POSITION├───────────┬───────────┬────────────────┬────────────┤

│ZONED DATA FIELD│ SMALLINT

│ INTEGER

│ DECIMAL(5,2)

│ FLOAT

│

├────────────────┼───────────┼───────────┼────────────────┼────────────┤

│

│ (...System/370* Zoned Data Formats...) │

│

│ F1F1F1F1A1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ F1F1F1F1B1

│

─11111

│

─11111

│

─111.11 │─1.1111E+04

│

│ F1F1F1F1C1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ F1F1F1F1D1

│

─11111

│

─11111

│

─111.11 │─1.1111E+04

│

│ F1F1F1F1E1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ F1F1F1F1F1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ (...COBOL Standard Zoned Data...)

│

│ F1F1F1F1F1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ F1F1F1F1C1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ F1F1F1F1D1

│

─11111

│

─11111

│

─111.11 │─1.1111E+04

│

│ (...COBOL Zoned Data with Leading Sign...)

│

│ F1F1F1F1F1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ C1F1F1F1F1

│

11111

│

11111

│

111.11 │ 1.1111E+04

│

│ D1F1F1F1F1

│

─11111

│

─11111

│

─111.11 │─1.1111E+04

│

│ (...COBOL Zoned Data with Trailing Sign in Separate Position...)

│

│ F1F1F1F140

│

1111

│

1111

│

11.11 │

1.111E+03

│

│ F1F1F1F14E

│

1111

│

1111

│

11.11 │

1.111E+03

│

│ F1F1F1F160

│

─1111

│

─1111

│

─11.11 │ ─1.111E+03

│

│ (...Miscellaneous Other Formats Accepted...)

│

4040404040

│

0 │

0.0E0

│

404040F0F2

│

.02 │

2.0E+00

│

4040F24040

│

.02 │

2.0E+00

│

40C1F1F1F1

│

1111

│

1111

│

11.11 │

1.111E+03

│

40D1F1F1F1

│

─1111

│

─1111

│

─11.11 │ ─1.111E+03

│

404040F24E

│

.02 │

2.0E+00

│

│ F24E404040

│

.02 │

2.0E+00

│

404040F260

│

─2

│

─2

│

─.02 │

─2.0E+00

│

│ F260404040

│

─2

│

─2

│

─.02 │

─2.0E+00

│

└────────────────┴───────────┴───────────┴────────────────┴────────────┘

Figure 84. Examples of Valid Zoned Data Input

GRAPHIC or GR or G

If the input field contains double-byte character set (DBCS) data, the table

columns must be defined with a data type of GRAPHIC, VARGRAPHIC,

or long fields.

One DBCS character is contained in 2 data-field bytes. The input data field

must be an even number (2, 4, 6...100, and so forth) of positions (bytes) in

length, or a Database Services Utility processing error occurs.

The shift-out and shift-in delimiters are optional in the input data field.

If the first position of the input data field contains a shift-out delimiter

(hex 0E), the last position of the data field must contain a shift-in delimiter

(hex 0F); if it does not, a Database Services Utility processing error occurs.

If the first position of the input data field does not contain a shift-out

delimiter, no shift-in delimiter is expected.

See Table 9 on page 165 for a summary of data type conversions.

154

Database Services Utility

null-current-clause

allows you to specify that a NULL, CURRENT DATE, CURRENT TIME, or

CURRENT TIMESTAMP is to be loaded in place of the input record data for a

table column. To determine when a null or current value is to be loaded, a

comparison is done between two values. The first value is taken from the input

record; you specify the positions of the input record that contain this value.

The second value is specified in the null or current clause.

No embedded blanks are allowed in the null or current clause within the left

and right parentheses enclosing the startpos and endpos values. The format of

the null or current clause is:

null-current-clause

►►

NULL

►◄

CURRENT DATE

CURRENT TIME

POS

( startpos

)

constant

CURRENT TIMESTAMP

-endpos

where the following is true, as appropriate:

v NULL IF POS is for null columns.

v CURRENT DATE IF POS is for date columns.

v CURRENT TIME IF POS is for time columns.

v CURRENT TIMESTAMP IF POS is for timestamp columns.

These special registers identify the start of a null or current clause. Note that IF

is optional; for example, you can specify the keyword phrase NULL IF POS or

NULL POS.

Note: CURRENT TIMEZONE is not supported.

When CURRENT DATE, CURRENT TIME, or CURRENT TIMESTAMP is to be

loaded, you must provide a value for the endpos parameter of the TCI

subcommand so that the correct length of the data field can be loaded. You

need a minimum of 10 bytes for CURRENT DATE, a minimum of 5 bytes for

CURRENT TIME, and a minimum of 19 bytes for CURRENT TIMESTAMP.

These values follow the rules for ISO formats. To ensure that each data field is

sufficiently large to accommodate the maximum value that can be entered for

the field, you should define 10 bytes for CURRENT DATE, 8 bytes for

CURRENT TIME, and 26 bytes for CURRENT TIMESTAMP. Refer to the input

data formats required for date, time, and timestamp.

startpos

identifies the starting position in the input data record of the value that

identifies a null or current table-column value. Position 1 of the input data

record is the first position of the logical record. If variable-length input records

are used, startpos 1 to 4 will refer to the record length control information. As a

Chapter 8. Command Reference

155

result, startpos 5 refers to the first data position. The null or current identifier

value positions can be the same as, or different from, those specified for the

associated data field.

endpos

identifies the last input data record position of the null or current table column

identification value. If the value occupies only one input data record position,

this parameter is not required.

constant

specifies the null or current table column identification value. The value cannot

be continued to a second input record but can be one of the following:

v A character-string constant that:

- Must be enclosed in single quotation marks (')

- Has a value of maximum length equal to endpos−startpos+1.

See Figure 85 on page 158 for examples.

v A one-position unsigned integer constant (range 0 to 255). See Figure 86 on

page 158 for examples.

v A two-position optionally signed integer constant (default is a positive

value). See Figure 87 on page 158 for examples.

v A four-position optionally signed integer constant (default is a positive

value). See Figure 88 on page 158 for examples.

156

Database Services Utility

Overlapping Column Position Specifications

The startpos and endpos in the null-current-clause need not depend on the

positions occupied by data fields in the sequential input file specified in the

INFILE subcommand; however, if the positions of the data fields and the

positions specified by startpos and endpos in the null-current-clause overlap,

data can be overlaid.

During DATALOAD processing, the database manager generates an input

buffer to hold one row of data for the table. When a TCI subcommand is

encountered, one row of the data, either embedded or in the specified input

file, is written to the input buffer. The TCI subcommand then writes the

CURRENT DATE, CURRENT TIME or NULL characters to the buffer as

required. The data from the specified positions in the input buffer is then

written to the table. This process is performed for every row in the table. If

the positions of the data fields and the positions specified by startpos and

endpos in the null-current-clause overlap, the data in the buffer may be overlaid

and cause unexpected results or errors. The following example illustrates how

data may be overlaid.

CREATE TABLE TIMING

( START_DATE

DATE,

START_TIME

TIME);

DATALOAD TABLE(TIMING)

START_DATE 3-12 CURRENT DATE IF POS(1-10) = ’

’

START_TIME 5-12 CURRENT TIME IF POS(4-11) = ’

’

INFILE(*)

-- FIRST 12 COLUMNS ARE BLANK

ENDDATA;

In this example, the START_DATE, START_TIME and the startpos and endpos

of the IF POS clause overlap. The first row of the embedded data is loaded

into the input buffer. The first TCI subcommand in the DATALOAD

command checks column 1 to 10 in the buffer and determines that POS(1-10)

' is true. The CURRENT DATE is then written into positions 3

to 12 in the input buffer. The second TCI subcommand checks positions 4 to

11 of the input buffer; however, positions 3 to 12 contain part of CURRENT

DATE; therefore the IF POS(4-11) '

' clause is not true. The data for

START_TIME is then taken from column 5 to 12 in the input buffer when the

START_TIME column is written to the TIMING table. Because positions 5 to

12 in the input buffer were already overwritten by the first TCI command,

those positions now contain part of CURRENT DATE and the data for

START_TIME is not in the correct time format. A syntax error therefore

occurs.

Chapter 8. Command Reference

157

Examples of Null-Current-Clause

NULL IF POS(20-23) = ’SKIP’

CURRENT DATE IF POS(20-21) ¬= ’

’

CURRENT TIME IF POS(20-21) >= ’01’

CURRENT TIMESTAMP IF POS(20-21) <> ’XX’

Figure 85. Character-String Constant Value Used in the Null-Current-Clause

NULL IF POS(20) = 255

CURRENT DATE IF POS(16) ¬= 25

CURRENT TIME IF POS(35) < 3

CURRENT TIMESTAMP IF POS(50) > 16

Figure 86. One-Position Integer Constant Value Used in the Null-Current-Clause

NULL IF POS (20-21) = 1

CURRENT DATE IF POS (35-36) ¬= 50

CURRENT TIME IF POS (5-6)

<= +32767

CURRENT TIMESTAMP IF POS(9-10) >= 116

NULL IF POS (3-4)

> -32768

Figure 87. Two-Position Integer Constant Value Used in the Null-Current-Clause

NULL IF POS (20-23) = 1

CURRENT DATE IF POS (16-19) ¬= 50

CURRENT TIME IF POS (21-24) <= +2000123563

CURRENT TIMESTAMP IF POS (20-23) >= -1839107489

Figure 88. Four-Position Integer Constant Value Used in the Null-Current-Clause

158

Database Services Utility

INFILE Subcommand

(1)

►►

INFILE

►

(

)

►

Yes

CONTINUED

(

)

LIST

(

)

Yes

( ddname

option_b

)

►

►◄

COMMITCOUNT

(ccount)

RESTARTCOUNT

(rcount)

Notes:

Option B is valid in DB2 Server for VSE only.

option-b:

tape/disk options for DB2 Server for VSE:

►

2048

REWIND

BLKSZ

(

size

)

(TAPE)

NOREWIND

PDEV

(DASD)

►

RECFM

(format)

RECSZ

(size)

The INFILE subcommand identifies the sequential input file containing the data

referenced by the preceding DATALOAD and Table Column Identification

subcommands.

This INFILE subcommand not only tells the utility the file the data is in, but also

tells it to read that file and load the data into the table(s) identified by the previous

DATALOAD TABLE command(s).

The sequential input file can contain fixed, variable, or variable-length spanned

records. The records can be blocked or unblocked.

* identifies that input data is embedded within the control statements

immediately following this control statement. Subsequent records are processed

as user data records until an ENDDATA statement is encountered. If the

(input) control file is exhausted before an ENDDATA statement is encountered,

a Database Services Utility processing error occurs, and the current logical unit

of work is rolled back.

Note: The CONTINUED and LIST parameters are applicable only if the *

parameter has been specified.

CONTINUED (No or Yes)

indicates whether or not the input data that is embedded within the

control statements can span more than one (input) control file record.

Chapter 8. Command Reference

159

Continued record processing is supported only for data records embedded

within the (input) control file because data records in sequential tape or

DASD are not restricted to a maximum length of 80 positions. No blanks

are allowed between or within this parameter keyword and value

specification.

indicates that the input data does not span (input) control file records.

Specify either NO or N. This is the default.

Yes

indicates that the input data can span (input) control file records.

Specify either YES or Y.

If you specify CONTINUED(YES), the actual input data is constructed from

one or more (input) control file data records. An input data record with a

nonblank value in position 1 indicates that the input data is continued in the

next (input) control file data record. An input data record with a blank (hex 40)

in position 1 indicates that the input data is not continued in the next (input)

control file data record. The first position (position 1) of each (input) control

file data record is not included in the actual input data. Data for a column can

then be contained in more than one (input) control file data record.

For example, if 10 input control card file data records are required to contain

the data for each row of a table, DATALOAD processing constructs a single

input data record from 10 consecutive input control card file data records. The

relationship between the positions of each of the 10 input control card file data

records and the positions of the actual input data record is:

Control File

Actual Input

Data

Data Record

Record

Positions

2-80

1-79

2-80

80-158

2-80

159-237

2-80

238-316

2-80

317-395

2-80

396-474

2-80

475-553

2-80

554-632

2-80

633-711

2-80

712-790

Figure 89. Relationship of Data Records

The maximum possible length of the input data is calculated from the highest

endpos value specified in any DATALOAD command or TCI subcommand

comprising the DATALOAD command set. The endpos value specified for an

input record data field or the endpos value specified in an input-record-id-clause

or null or current clause is included in this consideration. The maximum

length of the actual input data (rounded to the next multiple of 80) is

computed by the following formula:

160

Database Services Utility

Maximum Length

highest endpos value + 80

Actual Input

-------------------------------- X

Data Record

Figure 90. Formula

Notes:

1. Any continuation records that would cause the actual input data record

length to exceed the length computed by this formula are read and ignored

by DATALOAD processing.

2. Actual input data records containing data to be loaded into a table must be

at least as long as the highest endpos value specified in a TCI subcommand.

LIST (Yes or No)

indicates whether or not the input data that is embedded within the

control statements should be displayed in the report or message file. The

LIST parameter is applicable only if the data records are embedded within

the (input) control file. No blanks are allowed between or within this

parameter keyword and value specification.

Yes

indicates that the embedded data records should be displayed in the

report or message file. Specify either YES or Y as the parameter value.

The default is LIST(YES).

indicates that the embedded data records should not be displayed in

the report or message file. Specify either NO or N as the parameter

value.

If a data field error is detected in an input data record while the LIST(NO)

and CONTINUED(NO) are in effect, the input data record is displayed in

the report or message file before the message describing the error.

If LIST(NO) and CONTINUED(YES) are in effect, no input data is

displayed in the report or message file if a data field error occurs. A

meaningful display of the input data record might not be possible because

the data for a record might span multiple 80-byte data records or the data

field in error might span input data records. Also, it is likely that

continued records contain unprintable data. The commands and input data

can be rerun with LIST(YES) specified if the problem cannot be identified.

ddname

in DB2 Server for VM is the name of the sequential input file defined with

a CMS FILEDEF command. The file characteristics specified in the

FILEDEF command or the default FILEDEF specifications are the source of

the input record definition information for the Database Services Utility.

Input files with RECFM U, A, or M are not supported.

If you define DATALOAD CMS input files with variable-length spanned

records (RECFM=VS or RECFM=VBS), you must use the file-mode number

4. DATALOAD processing changes the record format from VS or VBS to

VB.

Note: The RECFM, RECSZ and BLKSIZE information displayed in the

message ARI0868I depends on the CMS FILEDEF command

specifications for the DATALOAD input file. If you define

DATALOAD input files as VS or VBS, DATALOAD processing

Chapter 8. Command Reference

161

changes the record format to VB and the RECFM, RECSZ and

BLKSIZE information displayed in the message ARI0868I will

indicate this change.

If variable-length input records are used, the data fields referenced by the

TCI subcommands must be in the same position for each occurrence of the

data record type.

Do not specify SYSIN or SYSPRINT as the ddname.

in DB2 Server for VSE: is the TLBL or DLBL job control statement file

name for the sequential (SAM) input file or for SYSIPT if you are using the

READ member statement. For more information, refer to the DB2 Server for

VSE Program Directory manual.

You must specify the ddname parameter first; that is, you cannot specify

BLKSZ, PDEV, RECFM, and RECSZ before the ddname. You can specify the

other keyword parameters in any order.

BLKSZ (size) (DB2 Server for VSE Only)

is a parameter that specifies the block size of the sequential input file. The

default block size is 2048 bytes per block.

PDEV (TAPE or DASD) (DB2 Server for VSE Only)

is an optional parameter that specifies the device type (DASD or TAPE) of

the sequential (SAM) input file. If PDEV(DASD) is specified, the file

resides on any device supported by the VSE DTFSD macro. Managed SAM

does not support spanned records. If PDEV(TAPE) is specified, the file

resides on any device supported by the VSE DTFMT macro. The default is

PDEV(TAPE).

NOREWIND or REWIND (DB2 Server for VSE Only)

controls tape file rewind processing performed during OPEN

processing. This parameter is valid only if you specify TAPE for PDEV.

The default processing is REWIND.

NOREWIND (DB2 Server for VSE Only)

specifies that the tape file will not be rewound by OPEN

processing. If NOREWIND is specified for input tape files

referenced by a series of DATALOAD commands, you must ensure

that the tape files being referenced are in ascending sequence. For

example, if NOREWIND is specified in a sequence of two

DATALOAD commands and the first command reads tape file 2,

then the second command must reference tape file 3 or a higher

number. If it references tape file 1, an OPEN error occurs.

REWIND (DB2 Server for VSE Only)

specifies OPEN processing to rewind the tape file.

RECFM (format) (DB2 Server for VSE Only)

is an optional parameter that specifies the format of the records in the

input data file. For format, substitute one of the following values:

162

Database Services Utility

Value

Meaning

fixed, unblocked

fixed, blocked

variable, unblocked

variable, blocked

variable spanned, unblocked

variable spanned, blocked

The default is RECFM(F).

If variable-length input records are used, the data fields referenced by the

TCI subcommands must be in the same position for each occurrence of the

data record type.

RECSZ(size) (DB2 Server for VSE Only)

is a parameter that specifies the length of a logical record for the input

data file.

Default record size values are specified as follows:

v If RECFM = F or FB, the default record size is the block size.

v If RECFM = V or VB, the default record size is the block size minus four.

v If RECFM = S or SB, the default record size is the block size minus four

or the highest input record position referenced, whichever is greater.

COMMITCOUNT (ccount)

identifies the frequency of COMMIT action during DATALOAD

processing.

ccount

is a number from 1 to 2,147,483,647 indicating that a COMMIT

statement should be executed after the number of input data records

equal to ccount are processed by DATALOAD.

Database Services Utility AUTOCOMMIT ON processing must be in effect

when you use DATALOAD COMMITCOUNT processing. If

AUTOCOMMIT is OFF and the COMMITCOUNT parameter is used, an

error message is written. DATALOAD command processing is not

performed.

If a SET ERRORMODE CONTINUE command is in effect during

DATALOAD COMMITCOUNT processing, input data records with

incorrect data fields might not be used. The incorrect input records are

skipped if:

v Multiple DATALOAD commands were used preceding an INFILE

subcommand and the records were not used for successful inserts by

any other DATALOAD commands.

v An SQL insert error occurs identified by SQLCODE -405, -424, -530, -802,

or -803, followed by message ARI0862E, and insert blocking is not in

effect.

Insert blocking is not in effect under the following conditions:

v Database Services Utility is running with single user mode.

v Database Services Utility is running with multiple user mode, but was

preprocessed with the NOBLOCK option.

v Insert blocking is suppressed by the database manager.

Chapter 8. Command Reference

163

Note: For more information, refer to “Skipping Bad Records” on page 45.

If an invalid ccount value is specified, an error message is written, and

DATALOAD command processing is not performed.

For DATALOAD CONTINUED record processing, the ccount value refers to

the number of physical input data records, not the number of logical

records constructed from input records. A COMMIT statement is

performed when the number of physical input data records processed

equals or exceeds the ccount value.

RESTARTCOUNT (rcount)

identifies the restart point for DATALOAD processing.

rcount

is a number from 1 to 2147483647 that indicates the number of input

data records to be skipped before DATALOAD record processing

begins.

If this parameter is omitted, no records are skipped and DATALOAD

processing begins with the first input data record.

If an invalid rcount value is specified, an error message is written and

DATALOAD processing is not performed.

If an end-of-file condition occurs before the number of records specified by

the rcount value are read, an error condition exists. Error message

ARI0844E is written to the message file before DATALOAD processing

ends.

For DATALOAD CONTINUED processing, the rcount value refers to the

number of physical input data records, not the number of logical records

constructed from input records. If the rcount+1 input record is not the first

physical record of a set of physical records comprising a logical record,

error message ARI0887E is issued.

ENDDATA Subcommand

Format:

►► ENDDATA

►◄

The ENDDATA subcommand identifies the end of user data embedded within the

(input) control file. This command is valid only if the previous Database Services

Utility command processed was an INFILE(*) subcommand.

No other information is allowed in this subcommand. If ENDDATA is not alone on

the input record, the utility reads it as data. If ENDDATA is terminated by a

semicolon (;), no blanks are permitted between the keyword and the semicolon.

SQL comments are not allowed on the ENDDATA subcommand.

During CONTINUED(YES) processing, an ENDDATA command is recognized only

if the previous (input) control file data record contains a blank (hex 40) in position

164

Database Services Utility

1. If the previous (input) control file data record contains a nonblank in position 1,

the ENDDATA command is processed as a continuation data record.

DATALOAD Data Conversion Summary

Table 9 summarizes the data conversion performed by DATALOAD processing.

YES means that the utility performs the conversion; NO means that the utility

cannot convert the input data into the data type of the target column. The numbers

in the chart refer to the notes below.

Table 9. DATALOAD Data Conversion Table

Target Column Data Type

DBCS

CHAR,

GRAPHIC,

VAR-

CHAR, or

DATE,

GRAPHIC,

LONG

DOUBLE

TIME or

or LONG

Input Field Data

VAR-

SMALL-

PRECI-

TIME-

VAR-

Type

CHAR

DECIMAL

INT

INTEGER

REAL¹¹

SION¹²

STAMP¹³

GRAPHIC

CHAR

Yes^1,4

Yes²

Yes

1-Byte FIXED

Yes

2-Byte FIXED

Yes

4-Byte FIXED

Yes

4-Byte FLOAT

Yes

Yes¹⁰

8-Byte FLOAT

Yes⁹

Yes

DECIMAL

Yes³

ZONED

Yes^5,6

Yes⁵

GRAPHIC (G)

Yes⁷

DATE, TIME, or

Yes⁸

TIME-STAMP

Chapter 8. Command Reference

165

Notes for Table 9:

Character (CHAR) input data fields for VARCHAR or long field columns have

trailing (low-order) blanks truncated before the length of the varying column

is established. All-blank CHAR input data fields result in a length of 0.

The first trailing blank after the number within a character (CHAR) input data

field terminates the character string used for character-to-numeric data

conversion. An all-blank CHAR field or a CHAR field with only a sign (+ or

-) results in a numeric value of 0. The data can be in the form of an integer,

decimal, or float constant.

Decimal (DECIMAL) input data fields should contain data with a precision

less than or equal to the precision of the target DECIMAL column. The

Database Services Utility uses the scale defined for the target column for the

input data unless a scale value equal to or less than that defined for the target

column is specified. A Database Services Utility processing error occurs if the

scale specified for the input data field is greater than that of the target

column.

Character (CHAR) input data fields for CHAR columns are padded with

trailing blanks if they are less than the length of the target column. CHAR

input data fields with a length greater than the length of the target CHAR,

VARCHAR, or long field columns are not allowed.

Leading and trailing blank positions within a zoned input data field are

ignored. An all-blank zoned input data field results in a numeric (SMALLINT,

INTEGER, DECIMAL, or FLOAT) column value of 0. A zoned data input field

containing only an EBCDIC plus (+) sign or minus (-) sign is not valid.

A zoned (ZONED) data input field should contain a value with a precision

less than or equal to the precision of the target DECIMAL column. The

Database Services Utility uses the scale defined for the target column as the

scale for the zoned data value unless a scale value equal to or less than the

scale of the target column is specified. A Database Services Utility processing

error occurs if the scale specified for the input data field is greater than that of

the target column.

A DBCS input data field must be an even number (2, 4, 6,...100, and so forth)

of positions (bytes) in length. The shift-out (hex 0E) and shift-in (hex 0F)

delimiters can be in the first position (startpos) and last position ( endpos) of

the data field. A two-position DBCS data field containing only the shift-out

and shift-in delimiter values is treated as a blank input data field.

If the shift-out and shift-in delimiters are present in the data field, the

Database Services Utility treats data field positions startpos+1 to endpos−1 as

DBCS data. The hex value 4040 is treated as a blank DBCS character.

A DBCS input data field for VARGRAPHIC or a long field has trailing

(low-order) DBCS blank characters truncated before the length of the varying

column is established. An all-blank DBCS input data field results in a column

value with a length = 0 for columns defined with the data type

VARGRAPHIC or long field.

The datetime data type input and target type must match; for example, the

input data type of TIME is valid only for the target column data type of

TIME.

When 8-byte floating-point data is loaded into a 4-byte floating-point table

column, a number of digits of precision are lost. The fraction (mantissa) is

reduced from 14 to 6 digits of precision. If an error occurs during the

conversion process, the message ARI0864E is generated, and processing of the

DATALOAD command stops.

10.

4-byte floating-point data is padded with hex 0000 0000.

166

Database Services Utility

11. The REAL input data field represents single-precision floating-point data and

is synonymous with FLOAT(N), where 1 is less than or equal to N, and N is

less than or equal to 21.

12. DOUBLE PRECISION represents double-precision floating-point data and is

synonymous with FLOAT or FLOAT(N), where 22 is less than or equal to N,

and N is less than or equal to 53.

13. When a current date, current time, or current timestamp value is to be loaded,

you must provide a value for the endpos parameter of the TCI subcommand so

that the correct length of the data field can be loaded. You need a minimum of

10 bytes for current date, a minimum of 5 bytes for current time, and a

minimum of 19 bytes for current timestamp. These values follow the rules for

ISO formats. To ensure that each data field is sufficiently large to

accommodate the maximum value that can be entered for the field, you

should define 10 bytes for current date, 8 bytes for current time, and 26 bytes

for current timestamp. Refer to the input data formats required for date, time,

and timestamp.

Chapter 8. Command Reference

167

Example 1:

DATAUNLOAD

SELECT AVG(BONUS) FROM EMPLOYEE;

OUTFILE(EXTRA)

Example 2:

DATAUNLOAD

SELECT SALARY FROM EMPLOYEE;

SALARY 1-10 CHAR

OUTFILE(REGULAR)

Authorization:

All normal SELECT privilege ground rules apply.

DATAUNLOAD

identifies the start of the DATAUNLOAD command sequence. A Database

Services Utility processing error occurs if other information is present in the

(input) control file record after the command identifier DATAUNLOAD.

select-statement

is any valid SQL SELECT statement without host variables. The SQL SELECT

statement must begin in the next (input) control file record following the one

containing the DATAUNLOAD command. A semicolon must be used to

terminate the SQL SELECT statement.

The results of the SQL SELECT statement supplied after a DATAUNLOAD

command are not written to the Database Services Utility report or message

file. An output file data record is written for each row (except those containing

data values that exceed the capacity of numeric output record data fields)

returned as a result of executing the SQL SELECT statement.

If the user-supplied SQL SELECT statement is not valid, or is not terminated

by a semicolon, a Database Services Utility processing error occurs.

If an arithmetic exception occurs, the DATAUNLOAD command handles it in a

way similar to arithmetic exceptions under the SELECT statement. (See “SELECT

and Arithmetic Exceptions” on page 143 for a description of the way arithmetic

exceptions are handled under the SELECT statement.) If an arithmetic exception

occurs when the data is to be placed into an output numeric data type field

(FIXED, FLOAT, DECIMAL, or ZONED), an error message is issued and

processing is terminated because the DB2 Server for VSE & VM system incorrectly

reads the number (or pound) symbols (#) used under SELECT as real data.

Stopping the processing prevents the arithmetic exception from generating

incorrect output.

Chapter 8. Command Reference

169

Data_Field_Id Subcommand

Format:

CHARacter

►►

column_reference

startpos

►◄

integer

-endpos

data_type

set_null_clause

The next record following the end of the SQL SELECT statement can contain one

or more Data Field Identification (DFI) subcommands or an OUTFILE

subcommand. If the OUTFILE subcommand is missing, a Database Services Utility

processing error occurs. If DFI subcommands are omitted, the default output

record format described in the section “DATAUNLOAD Output Data Field

Defaults” on page 179 is used.

A DFI subcommand identifies the location in the output record where the data for

a column in the select-list should be placed. The subcommand also identifies the

output record data-field data type. If the output record data-field data type is

different from the select-list column data type, the Database Services Utility

converts the column data. The data conversions performed by DATAUNLOAD

processing are described in Table 13 on page 187.

Only one DFI subcommand can appear in an input record. The command

parameters must not span input records, and the column_reference, startpos, and

endpos parameters must be specified first in the command and in that order.

If DFI subcommands are specified, only the data for the select-list columns

referenced by these subcommands is unloaded to the output data record. The data

for a column in the select-list (explicitly specified, or implicitly specified by the *

specification in the SQL SELECT) not referenced by a DFI subcommand is not

unloaded. A Database Services Utility warning message identifies each select-list

column that is ignored by DATAUNLOAD processing.

The data for the same column in the select-list can be unloaded to more than one

output record data field by specifying two or more DFI subcommands that

reference the column.

column_reference

identifies the select-list column to be used as the source of the output data

field value. Column_reference can be any valid form of a table column name or

integer that refers to a select-list column. For example, the integer value 1 (hex

F1) refers to the first item in the select-list; the integer value 10 (hex F1F0)

refers to the 10th item in the select-list.

A Database Services Utility processing error occurs if:

v The column name specified in the DFI subcommand is not in the select-list.

v The integer value identifying the column name exceeds the number of

columns in the select-list.

Use the integer notation for column_reference to identify the column if:

v The select-list contains columns from different tables with the same column

name. For example:

170

Database Services Utility

SELECT...,EMPLOYEE.EMPNO,EMP_ACT.EMPNO,

...FROM EMPLOYEE,EMPLOYEE.ACTIVITY...;

v The select-list contains a column that is a constant or is derived from an

expression or function:

SELECT...,’SALARY(+6%)=’,SALARY*1.06,MAX(SALARY)

...FROM EMPLOYEE...;

startpos

identifies the starting position (byte) of the data in each output data record.

Position 1 of the output record corresponds to the first position of the logical

output record. If variable-length input records are used, startpos 1 to 4 refers to

the record length control field. As a result, startpos 5 refers to the first data

position.

endpos

identifies the end position (byte) of the data in each output data record. You

can omit this parameter if the data occupies only one position in the output

record. If you specify this parameter, do not place blanks between the starting

position and the hyphen, or between the hyphen and the ending position.

To unload a column defined with a double-byte character set (DBCS) data

type, the length of the output data field must be an even number (4, 6, ..., 100,

...) of positions (bytes) other than 2. A Database Services Utility processing

error occurs if DBCS data is identified for an output record data field with an

odd number of positions, or with only two positions.

data-type

identifies whether character, graphic, fixed-binary, floating-point, packed

decimal, or zoned data values should be placed in the output data record

positions specified. The data type specification must appear after the

startpos-endpos values in the subcommand. The default data type is character.

The valid data type identifiers that you can specify are:

CHAR or CHARACTER

If the table column data type is anything but GRAPHIC, you can create a

CHAR output data field.

CHAR output data derived from a CHAR, VARCHAR, DATE, TIME,

TIMESTAMP, or long field select-list column is left-justified and padded on

the right with blanks (hex 40). Trailing (low-order) data is truncated if the

output data field length is less than the length of the column data except

for TIME, DATE, and TIMESTAMP. For TIME and DATE, an error occurs if

the output data field length is less than the length of the column data. For

TIMESTAMP, if the output data field length is less than 19 bytes, an error

occurs; if the output data field length is less than 26 but greater than or

equal to 19 bytes, trailing digits of the MICROSECONDS part of the

timestamp are truncated.

The CHAR output data can also be derived from select-list columns with

data type SMALLINT, INTEGER, DECIMAL, and FLOAT. See the section,

“DATAUNLOAD Data Conversion Summary” on page 187, for a

description of the content of CHAR output data fields derived from

numeric column data types.

If extended DBCS processing is in effect, character data can contain

DBCS/EBCDIC mixed data. See page 231 for a discussion of extended

DBCS support.

When an arithmetic exception occurs and the data is to be placed into an

output data type field, no error message is issued and processing

Chapter 8. Command Reference

171

continues. Number (or pound) symbols (#) are used, as under SELECT, to

fill the data type field and to indicate that an exception occurred during

processing.

CHAR is the default data type specification.

GRAPHIC or GR or G

If the table column is defined with the data type GRAPHIC,

VARGRAPHIC, or long field, you can create a DBCS output data field.

The startpos and endpos for a DBCS output record data field reflect the

number of bytes the data field occupies in the data record; they do not

reflect the number of DBCS characters that the data field contains.

The startpos of the output data field contains a shift-out (hex 0E) delimiter.

The endpos of the output data field contains a shift-in (hex 0F) delimiter.

Two intervening positions are required for each DBCS character.

The DBCS output record data field must occupy an even number of bytes

in the data record, or a Database Services Utility processing error occurs.

DBCS column data is truncated if the length of the output record data field

is less than the column data length plus 2. For a DBCS column, the column

data length equals the number of DBCS characters times 2.

A blank DBCS output data field contains the hex 40 value in all positions

except for the first and the last. A null source column value also results in

a blank output record data field.

DATE

If the table column is defined with a column type of DATE, output data is

in one of the following formats:

yyyy-mm-dd

(ISO, JIS format)

dd.mm.yyyy

(EUR format)

mm/dd/yyyy

(USA format)

installation defined

(Local format)

where:

yyyy is the year

mm is the month

dd is the day

The format is dependent on the SYSOPTIONS default format value or is

specified by the CHAR function in the SELECT statement.

Local Date Format

A database administrator can change the date default format, which is

defined in the SYSTEM.SYSOPTIONS table, from ISO (which is the

system-supplied database default form) to any installation-defined

format. See the DB2 Server for VM System Administration and DB2

Server for VSE System Administration manuals for information about

installation-defined formats and their interface.

Note: See page 169 for information on arithmetic error handling.

TIME

If the table column is defined with a column type of TIME, output data is

in one of the following formats:

hh:mm AM or hh:mm PM

(USA format)

hh.mm[.ss]

(ISO, EUR format)

hh:mm[:ss]

(JIS format)

installation defined

(Local format)

172

Database Services Utility

where:

hh is the hour

0 <= hh <= 12

for USA format

0 <= hh <= 24

for ISO, EUR, JIS format

mm is the minutes

ss is the seconds

The format is dependent on the SYSOPTIONS default format value or is

specified by the CHAR function in the SELECT statement.

Local Time Format

A database administrator can change the time default format, which is

defined in the SYSTEM.SYSOPTIONS table, from ISO (which is the

system-supplied database default form) to any installation-defined

format. See the DB2 Server for VSE System Administration, or DB2 Server

for VM System Administration manual for information about

installation-defined formats and their interface.

Note: See page 169 for information on arithmetic error handling.

TIMESTAMP

If the table column is defined with a column type of TIMESTAMP, output

data is in the following format:

yyyy-mm-dd-hh.mm.ss[.[nnnnnn]]

where

yyyy-mm-dd is the date (see ISO DATE format)

hh.mm.ss is the time (see ISO TIME format)

nnnnnn is microseconds

If the output data field length is less than 19 bytes long, an error occurs. If

the output data field is less than 26 bytes, but greater than or equal to 19

bytes, trailing digits of the microseconds part of the timestamp are

truncated.

FIXED or INT or INTEGER

If the table column is defined with a data type of SMALLINT or INTEGER,

you can define a fixed-point binary-output data field. If a row selected

from the database by the SQL SELECT statement supplied for

DATAUNLOAD processing contains a column value that exceeds the

capacity of a 1-byte or 2-byte FIXED output data field, an error message is

issued, and no output data file record is written for the row.

The value ranges for binary-output data fields are:

v A 1-byte binary data field can contain an 8-bit binary integer with a

value range of 0 to 255.

v A 2-byte binary data field can contain a 15-bit binary integer with the

value range described for a table column defined with the data type

SMALLINT.

v A 4-byte binary data field can contain a 31-bit binary integer with the

value range described for a table column defined with the data type

INTEGER.

Note: See page 169 for information on arithmetic error handling.

FLOAT or REAL

If the table column is defined with a data type of REAL or FLOAT(n),

Chapter 8. Command Reference

173

where n is from 1 to 21, you can define 4-byte floating-point binary-output

data, where (endpos−startpos+1) = 4. If a row selected from the database

by the SQL SELECT statement supplied for DATAUNLOAD processing

contains a column value that exceeds the capacity of the FLOAT output

data field, an error message is issued, and no output data file record is

written for the row.

Note: See page 169 for information on arithmetic error handling.

FLOAT or DOUBLE PRECISION

If the table column is defined with a data type of FLOAT, DOUBLE

PRECISION, or FLOAT(n), where n is from 22 to 53, you can define 8-byte

floating-point binary-output data, where (endpos−startpos+1) = 8.

Note: If 8-byte floating-point binary data is unloaded into a 4-byte

floating-point output data field, a number of digits of precision is

lost. If a row selected from the database by the SQL SELECT

statement supplied for DATAUNLOAD processing contains a

column value that exceeds the capacity of the FLOAT output data

field, an error message is issued, and no output data file record is

written for the row.

See page 169 for information on arithmetic error handling.

DECIMAL or DEC

If the table column is defined with a DECIMAL data type, you can specify

DECIMAL or DEC for packed decimal output data.

The length of the output data field must be large enough to accommodate

all significant digits of the column data value. The minimum length of an

output field derived from DECIMAL column data is (column scale/2)+1.

The implied scale of the output data field value is the same as that defined

for column.

If a row selected from the database by the SQL SELECT statement supplied

for DATAUNLOAD processing contains a column value that exceeds the

capacity of a decimal output data field, an error message is issued, and no

output data file record is written for the row.

Columns defined as NUMERIC are treated as DECIMAL data types.

Note: See page 169 for information on arithmetic error handling.

ZONED

If the table column is defined with a data type of SMALLINT, INTEGER,

or DECIMAL, you can specify ZONED for zoned output data. The length

of a zoned output record data field derived from a DECIMAL column

must be equal to or greater than the column scale.

Each digit of the table column value is represented by a single byte in the

zoned output data field. The 4 high-order bits of each byte are the zone

bits. The 4 high-order bits of the low-order byte are the sign of the value.

The 4 low-order bits of each byte contain the value of the digit.

The zone bits are 1111 (hex F). A plus-sign is represented by the bits 1100

(hex C), and a minus-sign is represented by the bits 1101 (hex D).

The output data field value is right-justified. Leading (high-order) zeros are

either added to, or truncated from, the column value depending on the

length of the output data field.

174

Database Services Utility

If a row selected from the database by the SQL SELECT statement supplied

for DATAUNLOAD processing contains a column value that exceeds the

capacity of a zoned output data field, an error message is issued, and no

output data file record is written for the row.

Examples of zoned output data fields:

The hexadecimal content of a 5-position zoned data field containing the

value +00011 is:

Hexadecimal Value

Field Position

Note: See page 169 for information on arithmetic error handling.

The hexadecimal content of a 5-position zoned data field containing the

value -00011 is:

Hexadecimal Value

Field Position

See Table 13 on page 187 for a table summarizing the data conversion performed

by Database Services Utility DATAUNLOAD processing.

set_null_clause

specifies the output data record position and value that identifies a null table

column value. The null identifier value can be a character or an integer value

(see below); it does not assume the data type specified for the output record

data field.

The set_null_clause must appear after the startpos-endpos values in the

subcommand. No embedded blanks are allowed in the set_null_clause within

the left and right parentheses enclosing the startpos and endpos values.

set_null_clause:

SET

►►

NULL

POS

( startpos

)

= value

►◄

-endpos

The parameters are:

IF NULL SET POS

identifies the start of the set_null_clause. You can use either the keyword phrase

IF NULL SET POS or NULL POS.

startpos

identifies the starting position (byte) in the output data record of the value that

identifies a null table column value. The null identifier value positions can

overlap the positions assigned to an output record data field.

Position 1 of the output data record is the first position of the logical record. If

variable-length output records are used, startpos 1 to 4 refer to the record

length control information and the data begins at startpos 5.

Chapter 8. Command Reference

175

endpos

identifies the last output data record position (byte) of the null table column

identification value. If the value occupies only one output data record position,

this parameter is not required.

value

specifies the null table column identification value. If an occurrence of the

column value is null, the value specified is placed in the output data record

positions specified after the data field value for the default output record is set.

If an occurrence of the column value is not null, no value is placed in the

output data record positions specified in the set_null_clause. These positions

contain blanks (hex 40) if they do not contain a default output record data field

value for null column data.

The set_null_clause value cannot be continued to a second output record. It can

be one of the following:

v A character-string constant that:

- Must be enclosed in single quotation marks (')

- Has a maximum length equal to endpos −startpos+1.

v A one-position unsigned integer constant (0 to 255)

v A two-position optionally signed integer constant (default is a positive

value)

v A four-position optionally signed integer constant (default is a positive

value).

Examples of Set-Null-Clause:

v Character-string constant:

IF NULL SET POS(20-23) = ’NULL’

IF NULL SET POS(20-22) = ’ ? ’

v One-position integer constant:

IF NULL SET POS(20) = 255

v Two-position integer constant:

IF NULL SET POS(20-21) = 32767

v Four-position integer constant:

IF NULL SET POS(20-23) = -1839107489

176

Database Services Utility

OUTFILE Subcommand

VSE Format:

►► OUTFILE

( ddname

►

BLKSZ

(size)

NOREWIND

(TAPE)

REWIND

PDEV

(DASD)

►

)

►◄

RECFM

(format)

RECSZ

(size)

VM Format:

►► OUTFILE

(ddname)

►◄

The OUTFILE subcommand identifies the sequential output file that contains the

data referenced by the preceding DATAUNLOAD commands and subcommands. It

tells the utility the file in which to put the data and to begin to unload the data.

The sequential output file can contain fixed, variable-length, or variable-length

spanned records. The records can be blocked or unblocked. If you want variable

length records to be generated, variable-length spanned records must be used if the

total length of the column values to be unloaded exceeds 32752 bytes.

A blank (hex 40) is placed in all positions (bytes) of the output data record before

the data record field values are inserted.

ddname

in DB2 Server for VM: this is the name of the sequential output file defined

with a CMS FILEDEF command. If you define DATAUNLOAD CMS output

files with variable-length spanned records (RECFM=VS or RECFM=VBS), you

must use file-mode number 4. DATAUNLOAD processing changes the record

format from VS or VBS to U. See Appendix B, “FILEDEF Command Syntax

and Notes,” on page 249 for more information about undefined (U) record

format usage. If a tape output file is used, performance can be improved by

using a large block size value (greater than 8244) on the FILEDEF.

The file characteristics specified in the FILEDEF command or the default

FILEDEF specifications are the source of the output record definition

information for the Database Services Utility. Output files with RECFM U, A,

or M are not supported.

Note: The RECFM, RECSZ and BLKSIZE information displayed in the message

ARI0868I depends on the CMS FILEDEF command specifications for the

DATAUNLOAD output file. If you define DATAUNLOAD output files

on CMS as VS or VBS, DATAUNLOAD processing changes the record

format to U and the RECFM, RECSZ and BLKSIZE information

displayed in message ARI0868I will reflect this change. However, the

CMS FILEDEF command that defines the DATALOAD input data file

must still specify RECFM=VBS or VS accordingly. Except for the

Chapter 8. Command Reference

177

DB2 Server for VSE. Operations Guide / Handbooks (2004-2007) - page 37
