clarity, but this is not mandatory. Do not, however, use character positions 1

through 4 for output data if you have specified variable-length output records for

the output file. Record positions 1-4 are reserved for the record length control

field.

Figure 36 shows a DATAUNLOAD command sequence using DFI subcommands.

The EMPNO field is to occupy positions 1 through 6 in the output records. The

PROJNO field goes in positions 8 through 13. The EMPTIME field is to take

positions 15 through 21 as data type DECIMAL.

DATAUNLOAD

SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME,JOB

FROM EMP_ACT,EMPLOYEE

WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

ORDER BY EMP_ACT.EMPNO;

EMPNO

1-6

PROJNO

8-13

EMPTIME

15-21

DECIMAL

OUTFILE(OUTPUT1)

Figure 36. DATAUNLOAD Command with DFI Subcommands

To unload data in user-specified output-file format, supply DFI subcommands. Use

the standard method for unloading data in “Unloading Data in System-Defined

Format” on page 63, but supply a DFI subcommand for each column that you

want to unload. To construct a DFI subcommand, use the following format:

column-reference startpos-endpos data-type set-null-clause

v column-reference is usually the name of the table column in the select-list

parameter, but it might be an integer. For more information, see “Data_Field_Id

Subcommand” on page 170.

v startpos-endpos gives the first and last positions of the named table-column data

in the output record. You can omit endpos if the output data is one character

long.

v data-type is the data format to be used in the data field of the output record. For

more information, refer to the sections starting on page 171 in Chapter 8,

“Command Reference,” on page 135.

v set-null-clause is a conditional expression that tells the Database Services Utility

to provide a particular flag, control character, or string in the output record if

the value of the output data is null. The set-null-clause also specifies the start and

end positions in the output record for the flag or string.

Unloading NULL Values

You can use the set-null-clause to instruct the utility to insert a particular value

whenever a null value occurs in a table that you are unloading. In the following

example, you instruct the Database Services Utility to write a question mark in

position 22 of the output record whenever a null field occurs in the table that is

being unloaded.

Database Services Utility

DATAUNLOAD

SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME,JOB

FROM EMP_ACT,EMPLOYEE

WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

ORDER BY EMP_ACT.EMPNO;

EMPNO

1-6

PROJNO

8-13

EMPTIME

15-21

DECIMAL

IF NULL SET POS(22) = ’?’

OUTFILE(OUTPUT1)

Figure 37. Unloading NULL Values with DATAUNLOAD Command

As is shown in Figure 37 on page 59, if the value of an EMPTIME column is null,

the utility puts a ? value in output record position 22. For more information about

using the set-null-clause, see page 175 under “Data_Field_Id Subcommand” on

page 170 in Chapter 8, “Command Reference,” on page 135.

Periodic Reports during the Processing of Long Jobs

During DATAUNLOAD processing of a file containing more than 15,000 data

records, the message ARI8995I is written every 15,000 records to inform you

that the job is running normally and that n records have been unloaded. In a

VM system, these messages are written to your workstation, and in a VSE

system, they are written to the system operator’s console. If the number of

records being read from the database is less than 15,000, you do not receive

message ARI8995I.

As the DATAUNLOAD command is executed, the actual command sequence and

messages are written to the report or message file. Figure 38 on page 60 and

Figure 39 on page 60 show report results from running the DATAUNLOAD

command as shown in Figure 36 on page 58.

Chapter 3. Unloading Data with the Database Services Utility

1ARI0801I DBS Utility started: 10/05/89 14:54:41.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

1ARI0803I ...Extended DBCS (DBCS=YES) processing now in effect.

0-------> DATAUNLOAD

-------> SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME,JOB

-------> FROM EMP_ACT,EMPLOYEE

-------> WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

-------> ORDER BY EMP_ACT.EMPNO;

-------> EMPNO

1-6

-------> PROJNO

8-13

-------> EMPTIME

15-21

DECIMAL

IF NULL SET POS(22) = ’?’

-------> OUTFILE(OUTPUT1)

ARI0852I DATAUNLOAD processing started.

ARI0831I Column JOB data will not be unloaded.

ARI0868I DNAME=OUTPUT1 RECFM=F RECSZ=80 BLKSIZE=80

<— See Note

ARI0835I 74 record(s) written to the output data file.

ARI0855I DATAUNLOAD processing successful.

ARI0802I End of command file input.

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes successful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 10/05/89 10:54:44.

Figure 38. Database Services Utility Report Output with User-Specified Data Fields

ARI0801I DBS Utility started: 10/05/89 14:54:41.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

-------> CONNECT "SQLDBA " IDENTIFIED BY ********;

ARI8004I User SQLDBA connected to database SQLDBA.

ARI0500I SQL processing was successful.

ARI0505I SQLCODE = 0

SQLSTATE = 00000

ROWCOUNT = 0

------->

ARI8003I ...Extended DBCS (DBCS=YES) processing now in effect.

-------> DATAUNLOAD

-------> SELECT EMP_ACT.EMPNO,PROJNO,EMPTIME,JOB

-------> FROM EMP_ACT,EMPLOYEE

-------> WHERE EMP_ACT.EMPNO=EMPLOYEE.EMPNO

-------> ORDER BY EMP_ACT.EMPNO;

-------> EMPNO

1-6

-------> PROJNO

8-13

-------> EMPTIME

15-21

DECIMAL

IF NULL SET POS(22)

= ’?’

-------> OUTFILE(OUTPUT1)

ARI0831I Column JOB data will not be unloaded.

ARI0868I DNAME=OUTPUT1 RECFM=F RECSZ=80 BLKSIZE=80

ARI0835I 74 record(s) written to the output data file.

ARI0855I DATAUNLOAD processing successful.

ARI0802I End of command file input.

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes successful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 10/05/89 14:54:44.

Figure 39. Database Services Utility Message File Output with User-Specified Data Fields

Note: The RECFM, RECSZ, and BLKSIZE information displayed in the message

ARI0868I depends on the CMS FILEDEF command specifications for the

output file OUTPUT1.

Database Services Utility

The Database Services Utility does not unload data for which no DFI subcommand

exists (unless all DFIs are omitted), but the report or message file does show you

the columns that are not unloaded.

The records in the output data file are formatted according to your specifications.

Table 2 shows the data field format resulting from the DATAUNLOAD command

specification shown in Figure 36 on page 58.

Table 2. Output Record Format That is User Determined

Data Value Source

(Column or

Record Position

Other)

Output Record Field Data Type

1-6

EMPNO

CHAR

(blank)

CHAR

8-13

PROJNO

CHAR

(blank)

CHAR

15-21

EMPTIME

DECIMAL

EMPTIME

CHAR

(null indicator)

Unloading a View

A view is a virtual table that is derived from one or more tables, from other views,

or from combinations of views and tables. When views are processed and

displayed or printed, they are indistinguishable from tables; they have rows and

columns and, like tables, views have no inherent order of rows.

You can use the DATAUNLOAD command to unload views as if they were tables.

Once unloaded, the output data of a view is the same as the data from a table.

To use the DATAUNLOAD command to unload a view, use the same procedure

that you use to unload a table, but specify a view name instead of a table name in

the SQL SELECT statement. You can select all the columns of the view (SELECT *),

or use the select-list parameter. If you use this parameter, specify the names of

view columns.

Suppose you create a view such as this:

CREATE VIEW TOSPIFFY (NUMBER,NAME,MANAGER)

AS SELECT DEPTNO,DEPTNAME,MGRNO

FROM DEPARTMENT

WHERE ADMRDEPT = ’A00’

To unload the view, construct a DATAUNLOAD command like this:

DATAUNLOAD

SELECT * FROM TOSPIFFY;

NUMBER

1-3

NAME

6-42

MANAGER

45-50 IF NULL SET POS (45-50) = ’

’

OUTFILE(SUBSPIF)

The DATAUNLOAD command uses the view column names, not the column

names of the founding table, and null entries in the MANAGER column are

represented by 6 blanks in the output data file.

Chapter 3. Unloading Data with the Database Services Utility

Using File Definitions with the DB2 Server for VM

DATAUNLOAD Command

The DATAUNLOAD command uses three files: the control file, the message file,

and the data output file. You must define all three files, either with the SQLDBSU

EXEC or a FILEDEF command. Figure 40 on page 62 shows the relationship of the

three files and the appropriate definition facility (FILEDEF or SQLDBSU) for each.

Message

Control File

DATAUNLOAD

File Output

Input (Use the

(Use the SQLDBSU

SQLDBSU EXEC)

Processing

EXEC)

Data File Output

(Use a CMS

FILEDEF Command)

Figure 40. DATAUNLOAD Files

For more information on FILEDEF parameters and options, see Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249.

FILEDEFs Supporting DATAUNLOAD Command Processing

In the FILEDEF command defining the Database Services Utility DATAUNLOAD

command output data file, all record format (RECFM) values are supported except

for undefined (U) or carriage controls (A or M). If you define CMS output files

with variable-length spanned records (RECFM=VS or VBS), you must use the

file-mode number 4. In this case, DATAUNLOAD processing changes the record

format to U. See Appendix B, “FILEDEF Command Syntax and Notes,” on page

249 for more information about undefined (U) record format usage.

Note: If the message ARI0868I, generated using DATAUNLOAD command

processing, identified RECFM=U for an output file defined with

RECFM=VBS or VS, the CMS FILEDEF command that defines the

DATALOAD input data files must still specify RECFM=VBS or VS

accordingly. CMS FILEDEF command information for DATALOAD

command processing must be identical to the information in the FILEDEF

command that was used when DATAUNLOAD command processing

created the file.

A sample CMS FILEDEF command defining a CMS file for DATAUNLOAD

command processing is:

FILEDEF DBSFILE DISK DBSFILE DATA A (RECFM FB LRECL 800 BLOCK 1600

where DBSFILE is the ddname used in the DATAUNLOAD command, and it refers

to the output file DBSFILE DATA A.

If you want to print some of the data in a table, use the FILEDEF statement to

specify the printer as the output device:

FILEDEF PRINTOUT PRINTER

Database Services Utility

where PRINTOUT is the ddname that you use in the DATAUNLOAD command.

UNLOAD Procedures

This section describes the UNLOAD commands provided by the Database Services

Utility.

Unloading Data in System-Defined Format

Database Services Utility UNLOAD TABLE and UNLOAD DBSPACE processing

allows you to unload tables and views to a sequential file. You can later use this

file as input to Database Services Utility RELOAD TABLE and RELOAD DBSPACE

processing (described in Chapter 4, “Reloading Data with the Database Services

Utility,” on page 71). With the UNLOAD commands, you cannot unload data in a

user-defined format.

Note: You cannot use the UNLOAD DBSPACE and UNLOAD TABLE commands

if you are using DRDA flow.

The following is a brief description of the two UNLOAD commands:

v UNLOAD DBSPACE unloads all tables in a particular dbspace to an output file.

v UNLOAD TABLE is more specific than UNLOAD DBSPACE; it unloads a

specific table into an output file.

Unloading a Dbspace or Table That You Do Not Own

To unload dbspaces and tables that you do not own, concatenate the owner’s

user ID to the dbspace name (for example, SMITH.PERSONNEL). You must

have the SELECT privilege on all tables in the dbspace you want to unload.

Figure 41 on page 64 shows how the parts of an UNLOAD DBSPACE command

relate to the dbspace and output file. In the figure, the command:

UNLOAD DBSPACE (SMITH.PERSONNEL) OUTFILE (SAVE)

unloads the dbspace called SMITH.PERSONNEL to the file SAVE.

Chapter 3. Unloading Data with the Database Services Utility

UNLOAD DBSPACE

(SMITH.PERSONNEL)

OUTFILE (SAVE)

SMITH.PERSONNEL

EMPLOYEE

DEPARTMENT

SAVE

PROJECT

(DBSPACE)

Figure 41. Diagram of the UNLOAD DBSPACE Command

The format of the UNLOAD TABLE command is the same as UNLOAD DBSPACE,

but instead of a dbspace, specify a table name. In Figure 42, the UNLOAD TABLE

command unloads a single table called SMITH.DEPARTMENT to the output file

SAVE.

UNLOAD TABLE

(SMITH.DEPARTMENT)

OUTFILE (SAVE)

SMITH.PERSONNEL

SAVE

EMPLOYEE

DEPARTMENT

PROJECT

(DBSPACE)

Figure 42. Diagram of the UNLOAD TABLE Command

The Database Services Utility UNLOAD processing writes all rows from a table or

all rows from all tables in a dbspace as individual records to the sequential output

file. Before producing these records, the utility writes records that contain

information supporting the RELOAD function. The Database Services Utility

RELOAD processing with the NEW parameter uses this information for creating

the table(s).

Database Services Utility

Attention:

In RELOAD processing with the parameter NEW, the Database Services Utility

must create the table. The table is not created if the CREATE TABLE statement

used by the Database Services Utility is greater than 8192 bytes. If the statement is

greater than 8192 bytes, you can use the RELOAD command only with the PURGE

parameter and only if the table already exists.

The CREATE TABLE statement used by the Database Services Utility will be longer

than the statement that you initially issue if:

v You do not specify the column clauses in the column definition of the table.

v You use the ALTER TABLE statement to add columns to the table.

UNLOAD Processing Uses Indexes

The Database Services Utility unloads table data in the sequence identified by

the first index created for the table. This first index is also known as the

clustering index. The CLUSTER column of the SYSINDEXES catalog table

indicates the index for a given table that is the first, or clustering, index. (The

CLUSTER column contains an F or W value. See DB2 Server for VSE & VM

Database Administration for more information on SYSINDEX and clustering

indexes.) The data is ordered by the clustering index before it is selected for

unloading.

If a table has no indexes, the data is not put in order before it is unloaded;

table rows are unloaded in a system-determined order.

The UNLOAD command does not unload any indexes, primary or foreign keys, or

constraint definitions. Additionally, a package (preprocessed program) that depends

on the unique constraint indexes is invalidated when unique constraints are

dropped. All packages dependent on the table are invalidated when a unique

constraint is added to the table because they might have UPDATE statements that

cause multiple-row updates. Packages are also invalidated when unique constraints

are activated or deactivated. When using the Database Services Utility RELOAD

command with PURGE OPTION, however, you should ACTIVATE the unique

constraints (in the ALTER TABLE statement) rather than re-create them because it

is more efficient.

Furthermore, the Database Services Utility is sensitive to the tagging of character

and graphic data (single byte, double byte, and mixed), which identify the format

of the data, such as US or Kanji. The tags are maintained when you use the

UNLOAD and RELOAD commands.

Attention:

Operate under isolation level repeatable read (the default Database Services Utility

processing mode) when you use the UNLOAD command to ensure a consistent

state of the database during backup or migration.

Chapter 3. Unloading Data with the Database Services Utility

Using the UNLOAD DBSPACE Command

The command statements UNLOAD DBSPACE and UNLOAD TABLE are much

simpler than the DATAUNLOAD statement because the UNLOAD commands do

not specify the output fields. The lack of specifications leads to very long output

records.

Such long output records make it difficult to locate specific data or to edit the

output file. The UNLOAD commands are designed to provide output files for

backup or subsequent reloading at remote sites (or locally, for purposes of

reorganizing DB2 Server for VSE & VM data structures). Consequently, unloaded

data should be used only for reloading purposes. The following UNLOAD

DBSPACE command unloads all tables in a dbspace named PERSONNEL. The

tables are placed in an output file called SAVE:

UNLOAD DBSPACE (PERSONNEL) OUTFILE (SAVE)

The syntax is simple, requiring only:

v The command name

v The name of the dbspace to be unloaded

v The name of the output file. (In VM this is specified in the FILEDEF command.)

To unload an entire dbspace for backup or subsequent reloading, follow the

procedure in “Unloading Data in System-Defined Format” on page 52, but use the

UNLOAD DBSPACE command instead of the DATAUNLOAD command. The

UNLOAD DBSPACE command uses the following structure:

UNLOAD DBSPACE (dbspace-name)

where dbspace-name is the name of the dbspace.

Using the UNLOAD TABLE Command

You can use UNLOAD TABLE to specify the table you want to unload. UNLOAD

DBSPACE unloads all the tables in a dbspace.

For example, if you make regular backups of the inventory table of a small

company, you unload the table frequently. The table is in a dbspace with other

tables that you do not need to backup as often. Use the UNLOAD TABLE

command to backup only the inventory table. If your system fails, you can reload

the table by using the RELOAD TABLE command, which is discussed in the next

chapter.

The syntax of the UNLOAD TABLE command is similar to that of the UNLOAD

DBSPACE command, requiring only:

v The command name

v The name of the table to be unloaded

v The name of the output file. (Specified in the FILEDEF command in VM.)

To unload a table for backup or subsequent reloading, use the same procedure

given in “Unloading Data in System-Defined Format” on page 52, but use the

UNLOAD TABLE command instead of the DATAUNLOAD command. The

UNLOAD TABLE command has the following structure:

UNLOAD TABLE (table-name)

where table-name is the name of the table.

Database Services Utility

Unloading Views

You can unload a view (virtual table) with UNLOAD TABLE processing. The

Database Services Utility processes views in the same manner as a table

without indexes.

In DB2 Server for VSE

Each file of a multiple-file tape volume must be identified with the correct file

name and file sequence number of the TLBL statement for each tape file. Tape

rewind processing is controlled by the VSE job control statements.

In DB2 Server for VM

If you want to do a simple Database Services Utility command, such as unload one

table to a DASD file, and you are not going to repeat this command regularly, use

the utility interactively to avoid creating a control file and specifying a message

file.

If you have to execute several UNLOAD TABLE commands or use the same

command again, use message and control files. For example, to unload the

organization tables that are in the same dbspace as personnel tables, you need

several UNLOAD TABLE commands to specify each organization table. To unload

project activity tables for managers who have different dbspaces, you again need

several UNLOAD TABLE commands. Putting the Database Services Utility

commands in a control file enables you to use the commands again. Also, if any

command fails, you can refer to the message file repeatedly to deal with each error

message and correct the mistake in the control file without retyping all of the

UNLOAD commands.

Using File Definitions with the DB2 Server for VM UNLOAD

DBSPACE and UNLOAD TABLE Commands

The UNLOAD DBSPACE and UNLOAD TABLE commands use at least three files:

the control file, the message file, and one or more data output files.

Multiple Output-File Possibilities

You can have more than one UNLOAD TABLE or UNLOAD DBSPACE

command within a single invocation of the utility; each command must

unload data to a separate file, or the data is lost.

You can unload data to a multiple-volume tape file. You can also unload data

to multiple files on a single tape volume in one execution of the Database

Services Utility. Each UNLOAD operation must unload to a separate file. The

Database Services Utility does not rewind the tape when each file is opened

for output.

Figure 43 on page 68 shows the relationship between the UNLOAD files and the

appropriate definition facility (FILEDEF or SQLDBSU) for each.

Chapter 3. Unloading Data with the Database Services Utility

Message

Control File

UNLOAD

File Output

Input (Use the

(Use the SQLDBSU

SQLDBSU EXEC)

Processing

EXEC)

Data File Output

(Use a CMS

FILEDEF Command)

Figure 43. UNLOAD Files

Each file of a multiple-file tape volume must be identified with the correct ddname

and label specification in the CMS FILEDEF command issued for it. Tape rewind

processing is controlled by FILEDEF command specifications and performed by

CMS OS/QSAM.

Specify VBS Record Format in the UNLOAD FILEDEFs

Always specify a record format (RECFM) of VBS for UNLOAD processing.

UNLOAD processing changes the record format to U if the system required

logical record length is greater than the specified block size (BLOCK) value

minus 4. Otherwise, UNLOAD processing changes the record format to VB.

See Appendix B, “FILEDEF Command Syntax and Notes,” on page 249 for

more information about undefined (U) record format usage.

A block size (BLOCK) greater than 8 244 is recommended for tape output files

created by UNLOAD processing.

An example of a FILEDEF statement defining a tape output file is:

FILEDEF SAVE2 TAP1 (RECFM VBS BLOCK 8244

where SAVE2 is the ddname that you used in the UNLOAD command.

FILEDEFs Supporting UNLOAD Command Processing

The FILEDEF command defining the UNLOAD output data file can identify a

CMS file with 4 appended to the file mode letter (for example, A4) or a sequential

tape file supported by CMS OS/OSAM. Always specify a record format of VBS or

a block size value (or both) in the FILEDEF command defining the data file.

UNLOAD processing changes the record format to U if the system-required logical

record length is greater than the specified block size (BLOCK) value minus 4.

Otherwise, UNLOAD processing changes the record format to VB. See Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249 for more information about

undefined (U) record format usage.

Note: The message ARI0868I identifies the file characteristics used in the Database

Services Utility’s processing. If message ARI0868I, generated during

UNLOAD command processing, identified RECFM=U or VB for the

UNLOAD output file, the CMS FILEDEF command that defines the

Database Services Utility

RELOAD input data file must still specify RECFM=VBS. CMS FILEDEF

command information for RELOAD command processing must be identical

to the information in the FILEDEF command used when UNLOAD

command processing created the file. If message ARI0868I indicates

RECFM=U for a tape output file, you can obtain significant performance

improvements by increasing the block size value specified in the FILEDEF

command that defines the ddname.

An example of a FILEDEF command defining a CMS file for UNLOAD processing

is:

FILEDEF DBSFILE DISK DBSFILE DATA A4 (RECFM VBS BLOCK 2048

where DBSFILE is the ddname used in your UNLOAD command, and DBSFILE

refers to the output file DBSFILE DATA A4.

For more information on FILEDEF parameters and options, see Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249.

Release Coexistence Considerations for DB2 Server for VM

Changes were required in Version 7 Release 1 to handle file I/O correctly when

using CMS 15 and later. These changes affect the format of data that is unloaded

and reloaded by the UNLOAD and RELOAD commands of the DBS Utility. If you

use the DBS Utility’s UNLOAD and RELOAD commands with databases at

different release levels, you must ensure that the code changes have been applied

at all release levels. For releases prior to Version 7 Release 1, you must apply the

following APARs:

Release

APAR

3.5

PQ28584

5.1

PQ28583

6.1

PQ27957

Chapter 3. Unloading Data with the Database Services Utility

Chapter 4. Reloading Data with the Database Services Utility

The Database Services Utility RELOAD commands work in conjunction with the

UNLOAD commands. You can reload a dbspace or a table, and you can reload the

data into tables that already exist or create new tables as you reload. This chapter

explains how to use RELOAD DBSPACE and RELOAD TABLE and describes the

table information that is preserved after the data is reloaded.

Refer to the appropriate sections of the earlier chapters for details about invoking

the Database Services Utility and defining files.

RELOAD Procedures

Reloading Data in System-Defined Format

The RELOAD commands, like their UNLOAD counterparts, do not support

user-defined data formats. System-defined format is the only option. You must use

the OUTFILE output of the UNLOAD DBSPACE or UNLOAD TABLE commands

as input to the RELOAD DBSPACE and RELOAD TABLE commands.

Note: For a VM application requestor, the RELOAD DBSPACE and RELOAD

TABLE commands can only be used if a DB2 Server for VM application

server is used and the protocol is either SQLDS or AUTO. For a VSE

application requestor, the RELOAD DBSPACE and RELOAD TABLE

commands can only be used if a DB2 Server is running on the same VSE

system as the Database Services Utility or if the DB2 Server for VM is on

VM and is accessed through Guest Sharing.

Assuming that you have output from UNLOAD processing, and you want to use it

as input to a DB2 Server for VSE & VM database, you must now decide whether

to use the RELOAD DBSPACE or the RELOAD TABLE command.

Note: Use the UNLOAD command, not the DATAUNLOAD command. The unit

of output of the DATAUNLOAD command is the table row whereas the

UNLOAD commands have the table as their unit of output.

RELOAD DBSPACE is usually associated with UNLOAD DBSPACE, and RELOAD

TABLE is associated with UNLOAD TABLE. In practice, this is the most frequent

pairing, but all four commands use identical data formatting. Sometimes changing

the object when you go from UNLOAD to RELOAD is appropriate. Briefly, the

objects that each command manipulates are:

v UNLOAD DBSPACE unloads an entire dbspace.

v UNLOAD TABLE unloads just one table.

v RELOAD DBSPACE reloads an entire dbspace.

v RELOAD TABLE reloads just one table.

You might want to use RELOAD DBSPACE with UNLOAD TABLE if you unload a

single table and want to reload it into a dbspace. If you do not want to specify

where the table goes in the dbspace, the RELOAD DBSPACE command achieves

the same result as the RELOAD TABLE command. RELOAD DBSPACE is even

more convenient because it has fewer parameters to specify.

You might want to use RELOAD TABLE with UNLOAD DBSPACE if you unload

an entire dbspace and want to reload just one of its tables into another dbspace.

Using the RELOAD DBSPACE command reloads the entire UNLOAD output file,

not just the desired table.

Processing Multiple Tables or Multiple Files

The Database Services Utility’s RELOAD processing does not support the

concurrent loading of multiple tables. Sequential loading, however, is

supported, as long as the tables are in the same file.

During one invocation of the Database Services Utility, you can reload data

from a multiple-volume tape file or from a multiple-file tape volume.

In DB2 Server for VSE, to reload data from a multiple-file tape volume, you

must specify the correct file name and file sequence number on the TLBL

statement for each tape file. Because the Database Services Utility rewinds the

tape when each file is opened for input, this information is necessary to locate

the correct file on the tape.

RELOAD DBSPACE processing loads tables serially in the order that they appear

in the input file. Use the RELOAD DBSPACE command to supply four pieces of

information to the Database Services Utility:

v The name of the command

v The identity of the dbspace to be loaded

v The replacement method (NEW or PURGE) to use

v The identity of the data input file.

Figure 44 shows the command flow.

RELOAD DBSPACE

(RESOURCES)

NEW INFILE (HISTORY)

RESOURCES

HISTORY

EMPLOYEE

ACTIVITY

EMP_ACT

(DBSPACE)

Figure 44. Diagram of the RELOAD DBSPACE Command

This figure shows a RELOAD DBSPACE operation on the RESOURCES dbspace,

and the creation of new tables from the input file called HISTORY.

The RELOAD TABLE command is more precise than the RELOAD DBSPACE

command. RELOAD TABLE specifies that you want to reload only one table no

Database Services Utility

matter how many exist in the input file. In the RELOAD TABLE command, you

give the following five pieces of information to the Database Services Utility:

v The name of the command

v The identity of the target table to be loaded

v The replacement method (NEW or PURGE) to use

- If NEW, the identity of the dbspace in which the table is to be created.

v Optionally, the identity of the source table being loaded

v The identity of the data input file.

Figure 45 shows the command flow.

RELOAD TABLE

(SMITH.DEPARTMENT)

PURGE INTABLE (DEPARTMENT) INFILE (SAVE)

SMITH.PERSONNEL

SAVE

EMPLOYEE

DEPARTMENT

PROJECT

(DBSPACE)

Figure 45. Diagram of the RELOAD TABLE Command

This figure shows a RELOAD TABLE operation on Smith’s DEPARTMENT table,

which must be purged first. The SAVE file is used as input.

If the UPDATE STATISTICS setting is ON, the RELOAD command automatically

causes table statistics to be generated while the data is being reloaded.

Chapter 4. Reloading Data with the Database Services Utility

Indexing Notes

With the PURGE Parameter:

When a table is purged, the default clustering rules are used because all

indexes for the purged table are dropped.

With the NEW Parameter:

When a new table is created, the column definitions are identical to the

definitions of the table contained in the input file, except the keys and unique

constraints are not reproduced. The new table also does not have any indexes

defined for it. You must construct them yourself by issuing subsequent SQL

CREATE INDEX statements.

Using the NEW Parameter with Field Procedures:

When a new table is created, the field procedures are not reproduced. Thus,

using the reload ’NEW’ parameter is not recommended for tables with field

procedures. To reload tables with field procedures, use the ’PURGE’

parameter.

When reloading a dbspace or a table, you must either create new tables for the

RELOAD input or purge old tables before reloading them. A particular table in the

input file replaces the like-named table in the target dbspace if the PURGE

parameter is specified, but it remains unloaded if the NEW parameter is in effect.

Similarly, under the NEW option, a particular table in the input file remains

unloaded when a like-named table with that name exists in any dbspace of the

entire database; if no table with that name exists, however, the Database Services

Utility creates a table into which the given input is loaded.

Referential Integrity and the RELOAD Commands

Referential integrity might affect the RELOAD commands. Specifically, if you

create an unloaded file when there is no primary key, and there is a primary

key on the target table at the time of RELOAD PURGE, the primary key

becomes active after the RELOAD PURGE operation. If you do not want the

primary key active, you must drop the primary key manually by using the

ALTER TABLE statement.

If the table being reloaded has an active primary key, the Database Services Utility

records this fact and issues an ALTER TABLE table-name DEACTIVATE PRIMARY

KEY command. The Database Services Utility also saves the active foreign key

names, unique constraints, and their owner’s name, before issuing an ALTER

TABLE table-name DEACTIVATE FOREIGN KEY or DEACTIVATE UNIQUE KEY

command. After the data has been loaded, the Database Services Utility reactivates

the keys.

For more information about referential integrity, see the DB2 Server for VSE & VM

Database Administration manual.

Database Services Utility

The Database Services Utility also preserves the tags for character and graphic data

(single byte, double byte, and mixed) that identify the data format, such as US or

Kanji. The tags are reloaded with the data when you use the RELOAD command.

A user is allowed to use a DBSU module from one release to connect to a database

server containing a DBSU package at a different release. Specifically, in an

UNLOAD TABLE/DBSPACE and RELOAD TABLE/DBSPACE scenario, there are 4

objects being used that may all be at different releases. For Data Capture, it is only

necessary to consider whether the R750 release of the object is being used or a

pre-R510 release is being used. In the chart below, ″Unload Module″ refers to the

release of the DBSU module which the user is accessing when performing the

unload operation. This may not be the same as the release of the database server

which the user is connecting to. Similarly, ″Reload Module″ refers to the release of

the DBSU module which the user is accessing when performing the reload

operation. This may not be the same as the release of the database server which

the user is connecting to. ″Unload P/S″ refers to the release of the database server

and the release of the DBSU package contained in the database server in which the

table is being unloaded. Similarly, ″Reload P/S″ refers to the release of the

database server and the release of the DBSU package contained in the database

server in which the table is being reloaded. The release of the DBSU package must

be equal to the release of the database server where it is contained. Mixed releases

are not supported.

In the most general case, a user can use a DBSU module at release A to unload a

table from a database server which is at release B. Then, the user can use a DBSU

module at release C to reload the table to another database server at release D. The

chart below can be used to determine whether the DATA CAPTURE setting for the

table will be restored.

Table 3. DATA CAPTURE settings and DBSU RELOAD and UNLOAD

Unload

Reload

Unload P/S

Module

Reload P/S

Module

Comments

pre-R510

n/a

Tables in a pre-R510 server do not

contain a Data Capture setting.

R730

pre-R510

n/a

The pre-R510 unload module

does not save the Data Capture

setting so the setting will not be

restored on the reload.

R730

pre-R510

n/a

Data Capture setting will be

saved in the unload file but

pre-R510 servers do not allow a

Data Capture setting for tables so

the setting will not be restored on

the reload.

R730

pre-R510

Data Capture setting will be

saved in the unload file but the

pre-R510 reload module does not

restore the Data Capture setting

so the setting will not be restored

on the reload.

R730

Data Capture setting will be

saved in the unload file and will

be restored by the reload module.

Chapter 4. Reloading Data with the Database Services Utility

Using the PURGE Parameter

The PURGE keyword tells the Database Services Utility that the target table exists,

and that all rows must be deleted from it before RELOAD TABLE processing

begins. (If the target table does not exist, you receive an error message.) Of course,

the column definitions of the target table must be identical to those of the source

table.

The Database Services Utility, as part of PURGE processing, drops the clustering

index, deactivates any active primary keys, active foreign keys, and active unique

keys, and deletes all indexes on the target table before deleting and reloading the

data. Therefore, you must have DBA authority to do a RELOAD with the PURGE

option if the target table or any of its indexes are not yours. After all tables have

been reloaded, the Database Services Utility reactivates the clustering index,

primary key and unique keys, and re-creates the remaining indexes. It ensures that

the first index that was created for the table (as recorded at PURGE time) is also

the first index re-created. After all the tables are processed, the Database Services

Utility reactivates all the foreign keys that it deactivated. DB2 Server for VSE &

VM packages are invalidated because of table index deletions, but are

automatically preprocessed the next time someone attempts to execute the package.

The following example illustrates the PURGE parameter:

RELOAD DBSPACE (RESOURCES) PURGE INFILE(HISTORY)

PURGE tells the Database Services Utility to delete all the rows of the table before

loading the data. The table must, however, exist in the specified dbspace. Note also

that fully qualified table names are always used internally for RELOAD DBSPACE.

That is, if you unload JONES.EMP_ACT and use RELOAD DBSPACE with a

PURGE option, JONES.EMP_ACT is the only table affected by the reload.

Using the NEW Parameter

The specified dbspace must already exist before you can reload tables into it. The

NEW parameter causes the utility to create tables, not dbspaces. If you are using

UNLOAD and RELOAD processing to duplicate an existing dbspace (as for testing

application programs), first acquire an appropriate dbspace. The SQL ACQUIRE

DBSPACE statement is described in the DB2 Server for VSE & VM SQL Reference. If

the table you are reloading does not replace a table already in the dbspace, the

Database Services Utility can create the target table for you. In the following

example, the source table EMPTABLE is not in the target dbspace:

RELOAD TABLE(EMPTABLE) NEW(PRODUCTION)

INTABLE(EMPLOYEE)

INFILE(SAVE)

The NEW parameter in the above command tells the Database Services Utility that

the table (EMPTABLE) to be loaded does not exist and must be created. It also

identifies the dbspace (PRODUCTION) where you want the table created. The

Database Services Utility creates the EMPTABLE, finds the EMPLOYEE table on

the input file (SAVE), and loads the data. The new table is created in a private

dbspace, PRODUCTION, that the current user owns. If the current user does not

own a private dbspace with the specified name, the table is created in a public

dbspace with this name. If you want to have the new table created in a particular

dbspace, specify:

NEW (dbspace-name)

where dbspace-name is the name of the dbspace.

Database Services Utility

In another example, suppose that user ID BOB is the current Database Services

Utility user. BOB issues this command:

RELOAD DBSPACE (RESOURCES) NEW INFILE(HISTORY)

Suppose, also, that one of the tables in the HISTORY file is called

BOB.EMPLOYEE. If BOB already owns a table called BOB.EMPLOYEE in any

other dbspace, the table cannot be created and loaded in the RESOURCES dbspace.

The user ID concatenated to the table name uniquely identifies a table within the

database. Thus, if BOB.EMPLOYEE already exists, it is impossible for the utility to

create another BOB.EMPLOYEE anywhere else in the database.

Using the RELOAD DBSPACE Command

Percent Free Space

During RELOAD processing, the current percent free value for the dbspace being

loaded, or for the dbspace where the table being loaded resides, can be critical.

Before RELOAD processing begins, increase the percent free space value to reserve

free space for additional rows inserted after the RELOAD process is completed.

Immediately after RELOAD processing is completed, reduce the percent free value

to allow the reserved free space to be used for the new rows. Refer to the DB2

Server for VSE & VM Database Administration for more information on the dbspace

percent free specification.

Reloading Several Tables into a Dbspace Where They Are

Already Defined

To reload multiple tables into a dbspace where they already exist, proceed as

follows:

In VSE

Provide the following Database Services Utility command:

RELOAD DBSPACE (dbspace-name)

where dbspace-name is the name of the dbspace.

On the same record as the RELOAD DBSPACE command, leave one space and

put the replacement method for existing tables:

PURGE

Also on the same record, leave one space and put:

INFILE(ddname)

where ddname identifies the input file. Use the same ddname in a TLBL or DLBL

statement, depending on whether the data is stored on tape or in a DASD file.

Submit the job to run.

In VM

Issue the SQLINIT command to initialize the user machine. If you have already

done this, proceed to Step 2.

Create a control file to contain the command you construct in the following

steps. See “Working with a Control File in DB2 Server for VM” on page 13 for

detailed information on creating a control file.

Enter the command and dbspace name. Type:

RELOAD DBSPACE (dbspace-name)

where dbspace-name is the name of the dbspace.

Chapter 4. Reloading Data with the Database Services Utility

4. On the same line as the RELOAD DBSPACE command, enter the replacement

method for existing tables. Leave one space; then type:

PURGE

5. On the same line, leave one space; then type:

INFILE(ddname)

where ddname identifies the input data file. You need to use the same ddname

when you specify the FILEDEF statement for the input file.

6. Store the control file.

7. In CMS, specify the necessary FILEDEF statements. For general information

about FILEDEF statements, see “Using File Definitions” on page 14. For

command specific information, see “Using File Definitions with DB2 Server for

VM RELOAD DBSPACE and RELOAD TABLE Commands” on page 81.

8. Specify an SQLDBSU EXEC statement; if you did not specify FILEDEFs for the

control and message files, use the default values in the SQLDBSU EXEC. For

more information on the SQLDBSU EXEC, see “Using the SQLDBSU EXEC” on

page 15.

Reloading Several Tables into a Dbspace Where They Do Not

Exist

To reload multiple tables into a database where they do not exist, follow the

procedure given in “Reloading Several Tables into a Dbspace Where They Are

Already Defined” on page 77, but substitute NEW for PURGE. NEW indicates the

replacement method for new tables.

Loading a Single Table with the RELOAD DBSPACE Command

If you have just one table to load into a dbspace (that was unloaded with an

UNLOAD TABLE command), use the RELOAD DBSPACE command. Follow the

procedure in “Reloading Several Tables into a Dbspace Where They Are Already

Defined” on page 77, and use the appropriate replacement method (PURGE or

NEW) for the table to be loaded.

Note: If your input file contains multiple tables but you do not want to reload all

of them, use the RELOAD TABLE command.

Using the RELOAD TABLE Command

The reason for using the RELOAD TABLE command rather than the RELOAD

DBSPACE command is to reload one particular table into a dbspace. The RELOAD

DBSPACE command loads an entire input file of table data into a dbspace (subject

to the constraints imposed by the NEW or PURGE parameters). Although

RELOAD processing follows the input order of the data, UNLOAD output is

unpredictable: you have no way of knowing the sequence of tables in the

UNLOAD DBSPACE output file. In general, if you use output from an UNLOAD

DBSPACE as input to RELOAD TABLE processing (meaning that you want to

reload a specific table), use the INTABLE parameter with the RELOAD TABLE

command.

Reloading a Single Table into a Dbspace Where It Is Already

Defined

To reload a single table into a dbspace where it already exists, proceed as follows:

In VSE

1. Provide the following Database Services Utility command:

RELOAD TABLE (table-name)

Database Services Utility

where table-name is the name of the table.

On the same record as the RELOAD TABLE command, leave one space and

put:

PURGE

Also on the same record, leave one space and put:

INFILE (ddname)

where ddname identifies the input file. Use the same ddname in a TLBL or DLBL

statement, depending on whether the data is stored on tape or in a DASD file.

Submit the job to run.

In VM

Issue the SQLINIT command to initialize the user machine to the application

server where the data is to be reloaded. If you have already done this, proceed

to Step 2.

Create a control file to contain the command you construct in the following

steps. See “Working with a Control File in DB2 Server for VM” on page 13 for

detailed information on creating a control file.

Enter the command and table name. Type:

RELOAD TABLE (table-name)

where table-name is the name of the table.

On the same line as the RELOAD TABLE command, enter the replacement

method for existing tables. Leave one space; then type:

PURGE

On the same line, leave one space; then type:

INFILE(ddname)

where ddname identifies the input data file. You need to use the same ddname

when you specify the FILEDEF statement for the input file.

Store the control file.

In CMS, specify the necessary FILEDEF statements. When you specify the

FILEDEF statement for the input data file, use the same ddname you assigned to

the INFILE in this procedure. For general information about FILEDEF

statements, see “Using File Definitions” on page 14. For command specific

information, see “Using File Definitions with DB2 Server for VM RELOAD

DBSPACE and RELOAD TABLE Commands” on page 81.

Specify an SQLDBSU EXEC statement; if you did not specify FILEDEFs for the

control and message files, use the default values in the SQLDBSU EXEC. For

more information on the SQLDBSU EXEC, see “Using the SQLDBSU EXEC” on

page 15.

Nonrecoverable Storage Pools

Before RELOAD PURGE table insert processing begins, the message:

ARI8990I The table table-name is in a

nonrecoverable storage pool.

is written if one of the tables you are reloading is found in a nonrecoverable

storage pool. This message indicates that changes made to this table by the

RELOAD command are not deleted by a ROLLBACK statement if an error

occurs.

Chapter 4. Reloading Data with the Database Services Utility

Reloading Views

You can also reload views if the view meets the restrictions defined under the

RELOAD TABLE command description (see “RELOAD TABLE” on page 196). Use

the PURGE parameter to reload a view that was previously unloaded. Using

PURGE makes use of an existing view definition and does not violate the rule that

a view is a virtual table. The only difference between reloading a table and

reloading a view is that statistics are not collected for a view.

Reloading a Single Table into a Dbspace Where It Does Not Exist

To reload a single table into a dbspace where it is not defined, follow the

procedure in “Reloading a Single Table into a Dbspace Where It Is Already

Defined” on page 78, but use the following replacement method instead of

PURGE:

NEW (dbspace)

where dbspace is the name of the dbspace where you want to create a new table.

Reloading a Specific Table from a Multitable Input Source

The multitable input source referred to in this section is the output file from an

UNLOAD DBSPACE command. If you do regular backups of a dbspace, and the

data in one table is lost or modified incorrectly, reload the one table with the

RELOAD TABLE command. Use the procedure in “Reloading a Single Table into a

Dbspace Where It Is Already Defined” on page 78, but with the following

differences:

v Use the appropriate replacement method, NEW or PURGE.

v After providing the replacement method, leave one space, and then put:

INTABLE(table)

where table is the name of the source table.

v Leave one space and put:

INFILE (ddname)

where ddname identifies the input data file.

If you are reloading DB2 Server for VSE data from magnetic tape, identify each file

of a multiple-file tape volume with the correct file name and file sequence number

on the TLBL statement for each tape file. Because the Database Services Utility

rewinds the tape when each file is opened for input, this information is necessary

to locate the correct file on the tape.

Notification of Records Reloaded

If you are reloading more than 15,000 data records, messages (ARI8995I) are

written to your terminal after every 15,000 records to inform you that a

multiple of 15,000 records has been loaded.

Suppose that a dbspace was unloaded and the dbspace contained two tables

named EMPLOYEE. One of these EMPLOYEE tables was originally created by

SCOTT, the other by MIKE. If you want to reload the EMPLOYEE table that was

created by SCOTT, you should identify the table by prefixing the table name

EMPLOYEE with the owner SCOTT in the INTABLE parameter:

Database Services Utility

RELOAD TABLE(EMPTABLE) NEW(PRODUCTION)

INTABLE(SCOTT.EMPLOYEE)

INFILE(SAVE)

If you do not, the Database Services Utility reloads the data of the first table it

finds in the input file that has the same name. If you omit the INTABLE parameter

completely, the utility uses the data of the first table it finds in the input file,

regardless of the table name and owner.

Using File Definitions with DB2 Server for VM RELOAD

DBSPACE and RELOAD TABLE Commands

RELOAD processing requires a control file and a data file for input, and a message

file for output.

Use the Same File Definition for RELOAD As for UNLOAD

CMS FILEDEF command information for RELOAD command processing

should be identical to the information in the FILEDEF command you used

when UNLOAD command processing created the file.

Figure 46 shows the relationship of the RELOAD files and the appropriate

definition facility (FILEDEF or SQLDBSU) for each.

Control File

Output

Input

Message File

(Use the SQLDBSU

EXEC)

RELOAD

Processing

Input

Data File

(Use a FILEDEF

Command)

Figure 46. RELOAD DBSPACE and RELOAD TABLE Files

The default record format for RELOAD processing is variable-length blocked

spanned (VBS). If you specify a RECFM value other than VBS or a LRECL value

with the CMS FILEDEF command, it is ignored and overridden. RELOAD

processing changes the record format from VBS to VB. The message ARI0868I

identifies the file characteristics used by Database Services Utility processing.

Isolation Level for RELOAD Operations

Set the isolation level to repeatable read when you reload data to ensure a

consistent state of the database during backup or migration.

Chapter 4. Reloading Data with the Database Services Utility

Identify each file of a multiple-file tape volume with the ddname and label

specifications in the CMS FILEDEF command that you issue for each tape file. The

Database Services Utility does not perform any tape rewind processing. Tape

rewind processing is controlled by FILEDEF command specifications and

performed by CMS OS/QSAM.

Use the UNLOAD and RELOAD commands (RELOAD with the PURGE option) to

reorder the data records to match the indexes. Use the FILEDEF to specify a DISK

file for quick and easy unloading and reloading. This reordering improves the

efficiency of queries performed on your tables.

FILEDEFs Supporting RELOAD Command Processing

The FILEDEF command defining the Database Services Utility RELOAD output

data file identifies a CMS file with 4 appended to the file mode letter (for example,

A4) or a sequential tape file supported by CMS OS/QSAM. Always specify a

record format of VBS or a block size value (or both) in the FILEDEF command

defining the data file. RELOAD processing changes the record format from VBS to

VB.

A sample of a FILEDEF command defining a CMS file for RELOAD processing is:

FILEDEF DBSFILE DISK DBSFILE DATA A4 (RECFM VBS BLOCK 2048

where DBSFILE is the ddname used in your RELOAD command and DBSFILE

DATA A4 is the name of the input file.

For more information on FILEDEF parameters and options, see Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249.

Release Coexistence Considerations for DB2 Server for VM

Changes were required in Version 7 Release 1 to handle file I/O correctly when

using CMS 15 and later. These changes affect the format of data that is unloaded

and reloaded by the UNLOAD and RELOAD commands of the DBS Utility. If you

use the DBS Utility’s UNLOAD and RELOAD commands with databases at

different release levels, you must ensure that the code changes have been applied

at all release levels. For releases prior to Version 7 Release 1, you must apply the

following APARs:

Release

APAR

3.5

PQ28584

5.1

PQ28583

6.1

PQ27957

Statistics Collection

If SET UPDATE STATISTICS is on, table statistics are automatically generated

while the data is reloading. This method of creating statistics avoids a dbspace

scan and a separate scan of the index pages, which occurs when an UPDATE

STATISTICS statement is issued. If SET UPDATE STATISTICS is off, the statistics

are not updated.

Note: Consider using SET UPDATE STATISTICS ON for all RELOAD processing

to update the table statistics while the data is reloading.

Database Services Utility

Chapter 5. Unloading and Reloading Packages with the

Database Services Utility

This chapter explains how to use the UNLOAD and RELOAD PACKAGE

commands to distribute packages to connected application servers that use the

Database Services Utility. The two commands work together to transport a package

from one application server to another. When the package is reloaded, you have a

choice of purging the old package or creating a new one in the database. Finally,

the owner of the package has to authorize the people who will use the package.

Refer to the appropriate sections of the earlier chapters for details about invoking

the Database Services Utility and defining files.

Package Procedures

This section describes SQL preprocessing the PACKAGE commands.

Preprocessing

SQL statements in an application program are preprocessed (that is, analyzed and

converted) by the system before the program is compiled (or assembled).

DB2 Server for VSE & VM preprocessors do the following:

v Generate a modified version of the source code

v Convert SQL statements into a package and save the package in the application

server

v Verify that the current user has authority to access the data and, if so, grant the

user the privilege to use the package generated

v Update the database catalogs.

The preprocessor action is shown graphically below.

Host language

Preprocessor

Updates to the

source code

routine for the host

catalog in the SQL

with embedded

language

application server

SQL statements

Host language

Package in the

source code

database manager

with package calls

application server

(in place of the

embedded SQL)

Normal compilation

Executable code

(or assembly) for the

of the application

host language

Figure 47. Preprocessing

A package contains code for the SQL statements used in the program. The access

path is based on available data statistics and applicable table indexes.

A package is available when its program needs it; moreover, because it is stored in

a database, a package is monitored by database manager security mechanisms and

change-management facilities.

You must preprocess an application program that switches between application

servers on every application server that it accesses. To avoid distributing the

program source code and preprocessing it on multiple systems, distribute packages

to the connected (local or remote) application servers using the Database Services

Utility.

To prevent you from unintentionally running an updated program against an old

package, when you preprocess the package, a consistency token is generated and

stored in both the program and the package. If the SQL request is to succeed when

you run the program, the consistency token, which is based on a timestamp, must

match the one in the package.

Each time that you preprocess a program, a consistency token is generated. You

can choose to generate a blank consistency token. If you are running the program

against multiple application servers, the package for that program, which is stored

in all the application servers, must have the same consistency token as the

program. If the consistency tokens do not match, the program cannot be run on the

application server, or an error may occur. To ensure that the consistency tokens

match, preprocess the program once in a DB2 Server for VSE & VM environment

and distribute the package to other application servers using the UNLOAD

PACKAGE command and the RELOAD PACKAGE command.

The PROGRAM command is a synonym for PACKAGE. The RELOAD or

UNLOAD PROGRAM, and RELOAD or UNLOAD PACKAGE are therefore

equivalent commands.

Database Services Utility

The UNLOAD PACKAGE and RELOAD PACKAGE commands are

complementary: UNLOAD PACKAGE copies a package to a sequential file and

RELOAD PACKAGE reads the package back into an application server.

To ensure that only authorized users manipulate packages in the database, only

owners of programs and database administrators are entitled to unload or reload

packages.

Keep Interconnected Databases at the Same Level

If you move a package between application servers at different release levels,

and a facility of the database manager used by the reloaded package is not

available on the new application server, an error occurs. The error occurs

when the unloaded package is dynamically preprocessed again during the

RELOAD.

When RELOAD processing is completed, the system updates the TIMESTAMP

column of the SYSACCESS catalog table to the date and time of the RELOAD.

Using the UNLOAD PACKAGE Command

The UNLOAD PACKAGE command generates output records that contain:

v Preprocessing information

v Each SQL statement used in the associated program

v Information about its corresponding host variables.

In using the UNLOAD PACKAGE command, you must be either the owner of the

program whose package you are unloading or a database administrator. Supply the

following information to the Database Services Utility:

v Name of the command

v Identity of the package to be unloaded

v Optionally, the name of the application server containing the package

v Identity of the output file.

Note: The UNLOAD PACKAGE command is not supported if you are using

DRDA flow.

Unloading a Package

Your system must have database switching capability to access other application

servers.

To unload a package for backup or to transfer to another application server,

proceed as follows:

In VSE

1. Provide the following Database Services Utility command:

UNLOAD PACKAGE (owner.package-name)

where owner is the name of the owner of the associated package, and

package-name is the name of the package. If you omit owner, the database

manager uses your user ID but still checks to ensure that you have the RUN

privilege for the named package.

2. If the package resides in an application server other than the one you are

accessing, leave one space and type:

FROM (server-name)

Chapter 5. Unloading and Reloading Packages with the Database Services Utility

where server-name is the name of the other application server.

3. On the same record, leave one space and type:

OUTFILE (ddname)

where ddname identifies the sequential output file on tape. Use the same ddname

in a TLBL statement. If the output file is on DASD, specify PDEV(DASD) after

the ddname and use the same ddname in a DLBL statement. Do not use SYSPCH

as the ddname, because the output file content may be invalid and may cause

the RELOAD PACKAGE command to fail.

4. Submit the job for processing.

An example of the UNLOAD PACKAGE command is:

UNLOAD PACKAGE(MARCY.PROG3) OUTFILE(PROGOUT3) FROM(server-name)

where PROG3 is the name of the package, MARCY is the owner, PROGOUT3 is

the output data file, and server-name is the name of the other application server.

In VM

Issue the SQLINIT command to initialize the user machine to the application

server where the package to be unloaded resides. If you have already done this,

proceed to Step 2.

Create a control file to contain the command you construct in the following

steps. See “Working with a Control File in DB2 Server for VM” on page 13 for

detailed information on creating a control file.

Enter the command and the package name. Type:

UNLOAD PACKAGE (owner.package-name)

where owner is the name of the owner of the associated package, and

package-name is the name of the package. If you omit owner, the system uses

your user ID but still checks to ensure that you have the RUN privilege for the

named package.

If the package resides in an application server other than the one you are

logged on to, leave one space and type:

FROM(server-name)

where server-name is the name of the other application server.

Note: The use of FROM always ignores any preceding CONNECT operations

and uses the VM user ID as a default. In some situations, the user ID

received at the target application server is different from your VM user

ID. For example, an entry in the COMDIR might change the user ID, or

the target system might change it. If you find this procedure

unacceptable, issue the explicit CONNECTs as required, and use the

UNLOAD command without the FROM parameter.

On the same line, leave one space and type:

OUTFILE(ddname)

where ddname identifies the output data file.

Store the control file.

In CMS, specify the necessary FILEDEF statements. When you specify the

FILEDEF statement for the output data file, use the same ddname you assigned

to the OUTFILE in this procedure. For general information about FILEDEF

statements, see “Using File Definitions” on page 14. For command specific

information, see “Using File Definitions with DB2 Server for VM UNLOAD and

RELOAD PACKAGE Commands” on page 92.

Database Services Utility

8. Specify an SQLDBSU EXEC statement; if you did not specify FILEDEFs for the

control and message files, use the default values in the SQLDBSU EXEC. For

more information on the SQLDBSU EXEC, see “Using the SQLDBSU EXEC” on

page 15.

An example of the UNLOAD PACKAGE command is:

UNLOAD PACKAGE(MARCY.PROG3) FROM(PAYROLL) OUTFILE(PROGOUT3)

where PROG3 is the name of the package, MARCY is the owner, the package is in

the PAYROLL database, and the output data file is PROGOUT3.

Using the RELOAD PACKAGE Command

For a VM application requestor, the RELOAD PACKAGE can be used against a

DB2 Server for VM application server or any non-DB2 Server for VM application

server that uses DRDA flow. For a VSE application requestor, the RELOAD

PACKAGE can be used against a DB2 Server for VSE running on the same VSE

system as the Database Services Utility, a VM Database via Guest Sharing, or any

non-DB2 Server for VSE application server that uses DRDA flow.

The following tables show the different package migration scenarios:

Table 4. Different Reload Package Scenarios in DB2 Server for VM

Reloading To

Unloaded From

Application

Unloaded Using

Reloading Using

Application

Server Release

DBSU Release

Server Release

Using Protocol

Result

2.2

2.2, 3.1 or later

SQLDS

No Error

3.1 or later

2.2, 3.1 or later

2.2

SQLDS

Error

3.1 or later

2.2

3.1 or later

SQLDS

No Error

3.1 or later

2.2

3.1 or later

SQLDS

Error

3.1 or later

2.2,3.1 or later

3.1 or later

SQLDS

No Error

3.1 or later

SQLDS

No Error

2.2

2.2,3.1 or later

3.3 or later

DRDA

Error

2.2

2.2,3.1 or later

3.3 or later

Non DB2 for VM

DRDA

Error

3.1 or later

2.2

3.3 or later

DRDA

Error

3.1 or later

2.2

3.3 or later

Non DB2 for VM

DRDA

Error

3.1 or later

3.3 or later

DRDA

No Error

3.1 or later

3.3 or later

Non DB2 for VM

DRDA

No Error

2.2, 3.1 or later

3.3 or later

2.2, 3.1 or 3.2

DRDA

Error

Table 5. Different Reload Package Scenarios in DB2 Server for VSE

Reloading To

Unloaded From

Application

Unloaded Using

Reloading Using

Application

Server Release

DBSU Release

Server Release

Using Protocol

Result

2.2

2.2, 3.1 or later

SQLDS

No Error

3.1 or later

2.2, 3.1 or later

2.2

SQLDS

Error

3.1 or later

2.2

3.1 or later

SQLDS

No Error

3.1 or later

2.2

3.1 or later

SQLDS

Error

3.1 or later

2.2,3.1 or later

3.1 or later

SQLDS

No Error

Chapter 5. Unloading and Reloading Packages with the Database Services Utility

Table 5. Different Reload Package Scenarios in DB2 Server for VSE (continued)

Reloading To

Unloaded From

Application

Unloaded Using

Reloading Using

Application

Server Release

DBSU Release

Server Release

Using Protocol

Result

3.1 or later

SQLDS

No Error

2.2

2.2,3.1 or later

7.1

DRDA

Error

2.2

2.2,3.1 or later

7.1

Non DB2 for VSE

DRDA

Error

3.1 or later

2.2

7.1

DRDA

Error

3.1 or later

2.2

7.1

Non DB2 for VSE

DRDA

Error

3.1 or later

7.1

DRDA

No Error

3.1 or later

7.1

Non DB2 for VSE

DRDA

No Error

2.2,

3.1

or later

2.2, 3.1 or later

7.1

DRDA

Error

Notes:

1. You cannot reload a portable package created under SQL/DS Version 2 Release

2 using the DRDA flow because it does not have the necessary information

required for RELOAD PACKAGE command processing using DRDA flow.

2. Backward migration is also not possible; that is, you cannot reload DB2 Server

for VSE & VM Version 7 Release 5 or later portable package with SQL/DS

Version 2 Release 2.

3. Modifiable packages created using Extended dynamic statements cannot be

reloaded using DRDA flow.

4. Fortran, and any other packages created using Extended dynamic statements

that were originally preprocessed using SQLDS protocol, cannot be reloaded

using DRDA flow.

5. Fortran, and any other packages created using Extended dynamic statements

that were originally preprocessed using DRDA flow, cannot be reloaded using

SQLDS protocol.

In using the RELOAD PACKAGE command, you must be either the owner of the

program whose package you are trying to reload or a database administrator. DB2

Server for VSE & VM authorization checking grants the owner the RUN privilege

after the following information is supplied to the Database Services Utility:

v The name of the command

v The identity of the package to be reloaded

v The replacement method (NEW or REPLACE) to use

- If REPLACE, the disposition of previous package user privileges (KEEP or

REVOKE)

v Optionally, in VSE only, the identity of additional application servers where the

package is to be reloaded

v The identity of the input file.

Reloading a Package into an Application Server in Which Its

Application Does Not Exist

To reload a package ported from another application server or from backup,

proceed as follows:

In VSE

1. Provide the following Database Services Utility command:

Database Services Utility

RELOAD PACKAGE (ownerpackage-name)

where owner is the name of the owner of the associated package, and

package-name is the name of the package. If you omit owner, the database

manager uses your user ID but still checks to ensure that you have the RUN

privilege for the named package.

2. Specify the replacement method. Because the application associated with the

package to be loaded does not exist for the application server (or application

servers) being loaded, leave one space, and type:

NEW

3. On the same record, enter the names of any additional application servers onto

which the package is to be reloaded. Leave one space and put:

TO (server-name)

where server-name is the name of the other application server. If the package is

to be reloaded onto several application servers, leave one space, then type:

TO (application server1,application server2,application server3...)

4. On the same record, identify the input file. Leave one space, and type:

INFILE (ddname)

where ddname identifies the sequential input file on tape. Use the same ddname

in a TLBL statement. If the input file is on DASD, specify PDEV(DASD) after

the ddname and use the same ddname in a DLBL statement.

5. Submit the job to run.

An example of the RELOAD PACKAGE command is:

RELOAD PACKAGE(MARCY.PROG3) NEW INFILE(PROGOUT3) TO(server-name)

where PROG3 is the name of the package, MARCY is the owner, and server-name

is the name of the other application server. The input data file PROGOUT3 is on

tape.

In VM

1. Issue the SQLINIT command to initialize the user machine to the application

server where the package is to be reloaded. If you have already done this,

proceed to Step 2.

2. Create a control file to contain the command you construct in the following

steps. See “Working with a Control File in DB2 Server for VM” on page 13 for

detailed information on creating a control file.

3. Enter the command and package name. Type:

RELOAD PACKAGE (owner.package-name)

where owner is the name of the owner of the associated package, and

package-name is the name of the package. If you omit owner, the database

manager uses your user ID as the owner.

4. Indicate that you are loading a new package since the application associated

with the package does not exist on the application server (or application

servers) being loaded, by leaving one space and typing:

NEW

5. On the same line, enter the names of any additional application servers to be

reloaded. Leave one space; then type:

TO(server-name)

where server-name is the name of the other application server. If several

application servers are to be reloaded, leave one space; then type:

TO(application server1,application server2,application server3...)

Chapter 5. Unloading and Reloading Packages with the Database Services Utility

Notes:

a. Your system must have database switching capability to access other

application servers.

b. The use of TO means that any preceding CONNECT operations are not

used, and TO uses the VM user ID as a default. In some situations, the user

ID received at the target database is different from your VM user ID. For

example, an entry in the COMDIR may change the user ID, or the target

system may change it. If you do not want to use the TO clause procedure,

issue the explicit CONNECT command as required, and use the RELOAD

command without a TO clause. If the TO clause is not specified, the

package is reloaded onto the currently connected application server only.

On the same line, enter the identity of the input file. Leave one space; then

type:

INFILE(ddname)

where ddname identifies the input data file.

Store the control file.

In CMS, specify the necessary FILEDEF statements. When you specify the

FILEDEF statement for the input data file, use the same ddname you assigned to

the INFILE in this procedure. For general information about FILEDEF

statements, see “Using File Definitions” on page 14. For command specific

information, see “Using File Definitions with DB2 Server for VM UNLOAD and

RELOAD PACKAGE Commands” on page 92.

Specify an SQLDBSU EXEC statement; if you did not specify FILEDEFs for the

control and message files, use the default values in the SQLDBSU EXEC. For

more information on the SQLDBSU EXEC, see “Using the SQLDBSU EXEC” on

page 15.

An example of the RELOAD PACKAGE command is:

RELOAD PACKAGE(MARCY.PROG3) NEW TO(HOLIDAY) INFILE(PROGOUT3)

where PROG3 is the name of the package, and MARCY is the owner. The package

is created in the HOLIDAY database and the input data file is PROGOUT3.

Reloading a Package into an Application Server to Update an Existing

Application: Your system must have the capability to switch to other application

servers.

To reload a package into an application server where a package with the same

name already exists, proceed as in “Reloading a Package into an Application

Server in Which Its Application Does Not Exist” on page 88, but type:

REPLACE

REPLACE REVOKE

where REPLACE indicates that the existing package is to be replaced by the input

package with previous user privileges intact, and REPLACE REVOKE indicates

that the existing package is to be replaced by the input package with previous user

privileges revoked. An example of the RELOAD PACKAGE command is:

RELOAD PACKAGE(MARCY.PROG3) REPLACE REVOKE TO(PAYROLL) INFILE(PROGOUT3)

Database Services Utility

where PROG3 is the name of the package, and MARCY is the owner. The package

exists in the PAYROLL database; therefore, you use REPLACE to replace it and

REVOKE to revoke user privileges on the package. The input data file is

PROGOUT3.

Authorizing the Use of Packages

When a package is reloaded, the owner of the package is assigned the appropriate

run privilege. If NEW or REPLACE REVOKE is one of the RELOAD parameters,

the only privilege for the package is the owner’s run privilege. The user ID for the

owner of the reloaded package must exist so that the necessary privileges can be

granted. A user with DBA authority can reload a package without being the owner

and can grant the RUN privileges to other users. For more information on package

privileges, see the DB2 Server for VSE & VM Application Programming manual.

Errors with RELOAD

The Database Services Utility SET ERRORMODE CONTINUE command can

be used with the RELOAD PACKAGE command. If an error occurs during

reloading of the package on an application server, RELOAD processing ends

on that application server. RELOAD processing then continues on subsequent

application servers listed in the TO clause if ERRORMODE CONTINUE

processing is in effect and the error is not severe.

Example of Authorizing the Use of Packages

Gene writes an application program GENE.TTIME to display each employee’s

working hours to date. The table containing this information is

HOURS.TOTAL. This program is to be distributed to all the offices and

installed by a user with DBA authority at each site.

When the DBA reloads this new package, only the owner (GENE) possesses

the RUN privilege. This privilege is granted during the RELOAD. The user

ID GENE must exist for the DBA to be able to grant the RUN privilege for

the package GENE.TTIME. GENE must also have the necessary table

privileges to run the package successfully.

Preprocessing and Distributing an Application

To preprocess and distribute the SQL application created by Gene in the above

example, the company proceeds as follows:

1. The person with the user ID HOURS grants the SELECT privilege on

HOURS.TOTAL to user ID GENE.

2. Gene creates the application program TTIME.

3. Gene unloads the package TTIME.

Setting Up to Run an Application

To set up and run the application described in “Preprocessing and Distributing an

Application,” the company proceeds as follows:

1. Tom, a DBA, grants the CONNECT privilege to user ID GENE.

2. Tom connects as HOURS.

Chapter 5. Unloading and Reloading Packages with the Database Services Utility

3. Tom (connected as HOURS) grants the SELECT privilege on HOURS.TOTAL to

user ID GENE.

4. Tom connects as GENE.

5. Tom (connected as GENE) reloads the package GENE.TTIME.

6. Tom (connected as GENE) grants the RUN privilege on GENE.TTIME to

USERA, USERB, and USERC.

7. USERA, USERB, and USERC can now run the package GENE.TTIME to display

each employee’s total working hours to date.

Using File Definitions with DB2 Server for VM UNLOAD and RELOAD

PACKAGE Commands

Use the Same File Definition for RELOAD as for UNLOAD

CMS FILEDEF command information for package RELOAD processing

should be identical to the information in the FILEDEF command used when

the file was created by the package’s UNLOAD command processing.

Figure 48 shows the relationship of the load-program files and the appropriate

definition facility (FILEDEF or SQLDBSU) for each.

Control File Input

UNLOAD

Output “Data” File

(Use the SQLDBSU

Processing

(Use a FILEDEF

EXEC)

Command)

Message File Output

(Use the SQLDBSU

EXEC)

Control File Inout

RELOAD

Message File Output

(Use the SQLDBSU

Processing

(Use the SQLDBSU

EXEC)

Input “Data” File

(Use a FILEDEF

Command)

Figure 48. File Definition Diagram—UNLOAD PACKAGE and RELOAD PACKAGE

Database Services Utility

FILEDEFs Supporting UNLOAD and RELOAD PACKAGE

CMS FILEDEF commands must be used to define the input or output data files

processed by these commands.

Except for the ddname, CMS FILEDEF command information for RELOAD

command processing should be identical to the information in the FILEDEF

command used when the file was created by the UNLOAD command processing.

If either a RECFM value other than FB or an LRECL value is specified by the CMS

FILEDEF command, the value is ignored and overridden.

A sample CMS FILEDEF command defining a CMS file for UNLOAD or RELOAD

command processing is:

FILEDEF DBSFILE DISK DBSFILE DATA A

For more information on FILEDEF parameters and options, see Appendix B,

“FILEDEF Command Syntax and Notes,” on page 249.

Chapter 5. Unloading and Reloading Packages with the Database Services Utility

Chapter 6. Interpreting the Output of the Database Services

Utility

You can encounter two types of Database Services Utility output: the information

that the Database Services Utility feeds back to the report or message file, and the

data and control information that you unload for backup or eventual reloading.

Most often, you must understand the report output because it shows you what

happened during the Database Services Utility processing. This chapter describes

report and message file output.

This chapter builds on material presented in the foregoing chapters. Refer to the

appropriate sections of the earlier chapters for basic concepts and procedures.

Understanding the Report and Message File Output

The report is a log of Database Services Utility processing activity on DB2 Server

for VSE. You can use JCL to assign the output to a variety of output devices:

printer, tape, or disk.

The message file is a log of Database Services Utility processing activity on DB2

Server for VM. The SQLDBSU EXEC or the CMS FILEDEF command can direct the

message file to a variety of output devices; you can display or print its contents in

three distinct forms.

Everything in a report or message file belongs in one of three categories:

v Command input

v System output

v Data.

Command Input (DB2 Server for VSE & VM)

All parts of a set of commands, SQL or Database Services Utility, are considered

command input. Even the data embedded in a DATALOAD TABLE statement is

command input. Record for record or line for line, this type of output matches the

format of the (input) control file. A command-input record in the report starts with

an arrow (------>).

System Output (DB2 Server for VSE & VM)

Except when suppressed by a Database Services Utility control parameter in a

calling application program, all system messages, SQL and Database Services

Utility, are sent to either the report or message file. A system-output record or line

starts with a message identifier beginning with ARI.

Inclusion of Data in a Report (DB2 Server for VSE)

To include data in a report, use the LIST (YES) parameter in DATALOAD’s INFILE

subcommand. You can identify data in the report by the absence of arrows

(------>) or message identifiers (ARI...). Figure 49 on page 96 shows a simulated

report printout.

Inclusion of Data in a Message File (DB2 Server for VM)

To include data in a message file, use the LIST (YES) parameter in DATALOAD’s

INFILE subcommand. Through the SELECT statement, the Database Services

Utility allows a limited amount of system-user interaction. Do not use the utility as

an alternative to ISQL, but if you are in a Database Services Utility session, you

can enter SQL commands to query the database from your workstation (assigned

as control file) without leaving the utility. You can identify data in the message file

by the absence of arrows (------>) or message identifiers (ARI...). Figure 49

shows

a simulated message-file printout.

ARI0801I DBS Utility started: 07/24/89 17:38:53.

AUTOCOMMIT = OFF ERRORMODE = OFF

ISOLATION LEVEL = REPEATABLE READ

------> CONNECT "TARA

" IDENTIFIED BY ********;

ARI8004I User TARA connected to database SQLDBA.

ARI0500I SQL processing was successful.

ARI0505I SQLCODE = 0

SQLSTATE = 00000

ROWCOUNT = 0

------> ACQUIRE PRIVATE DBSPACE NAMED TARASPACE;

ARI0500I SQL processing was successful.

ARI0505I SQLCODE = 0

SQLSTATE = 00000

ROWCOUNT = 0

------> CREATE TABLE DEPARTMENT (DEPTNO CHAR(3)

NOT NULL,

------>

DEPTNAME VARCHAR(36) NOT NULL,

------>

MGRNO

CHAR(6)

------>

ADMRDEPT CHAR(3)

NOT NULL,

------>

PRIMARY KEY (DEPTNO)) IN TARASPACE;

ARI0500I SQL processing was successful.

ARI0505I SQLCODE = 0

SQLSTATE = 00000

ROWCOUNT = 0

------> DATALOAD TABLE (DEPARTMENT)

------>

DEPTNO

1-3

------>

DEPTNAME 5-32

------>

MGRNO

34-39

NULL IF POS (34-39)=’

’

------>

ADMRDEPT 41-43

------> INFILE(*)

ARI0852I DATALOAD TABLE processing started.

ARI8981I Dynamic statistic accumulation was disallowed

for table ’TARA’.’DEPARTMENT’,

reason code = 01.

------> A00 SPIFFY COMPUTER SERVICE DIV. 000010 A00

------> B01 PLANNING

000020 A00

------> C01 INFORMATION CENTER

000030 A00

------> D01 DEVELOPMENT CENTER

A00

------> E01 SUPPORT SERVICES

000050 A00

------> D11 MANUFACTURING SYSTEMS

000060 D01

------> D21 ADMINISTRATION SYSTEMS

000070 D01

------> E11 OPERATIONS

000090 E00

------> E21 SOFTWARE SUPPORT

000100 E00

------> ENDDATA

ARI0875I 9 row(s) loaded into table TARA.DEPARTMENT.

ARI8996I ...Begin UPDATE STATISTICS for TARA.DEPARTMENT.

ARI0855I DATALOAD processing successful.

------> SELECT * FROM DEPARTMENT;

Figure 49. Sample Output

In Figure 49, note that the arrows show command input. Each arrow corresponds

to either a record in the input control card file or a line in the control file. Note

also that the rest of the records or lines start with ARI, denoting messages.

Database Services Utility

Figure 50 illustrates the next part of the simulated report or message file printout.

SELECT * FROM DEPARTMENT

PAGE

DEPTNO DEPTNAME

MGRNO ADMRDEPT

------ ------------------------------------ ------ --------

A00

SPIFFY COMPUTER SERVICE DIV.

000010 A00

B01

PLANNING

000020 A00

C01

INFORMATION CENTER

000030 A00

D01

DEVELOPMENT CENTER

A00

E01

SUPPORT SERVICES

000050 A00

D11

MANUFACTURING SYSTEMS

000060 D01

D21

ADMINISTRATION SYSTEMS

000070 D01

E11

OPERATIONS

000090 E00

E21

SOFTWARE SUPPORT

000100 E00

ARI0850I SQL SELECT processing successful: Rowcount = 9

Figure 50. Sample Output Containing Data

The output is formatted such that the data in columns and rows as a normal table.

Figure 50 is an example of the column (or tabular) form of output. No message- or

command-input designations appear at the start of data records. Figure 51 shows

the end of the simulated report printout.

ARI0802I End of command file input

ARI8997I ...Begin COMMIT processing.

ARI0811I ...COMMIT of any database changes successful.

ARI0809I ...No error(s) occurred during command processing.

ARI0808I DBS processing completed: 07/24/89/17:38:55.

Figure 51. Concluding Messages

Every Database Services Utility job ends with messages from the Database Services

Utility that summarize the errors, if any, that occurred and give the completion

timestamp, the system status, and a return code. For a complete listing of

messages, see the DB2 Server for VM Messages and Codes manual.

If either command-file input or query results data has record or line lengths too

wide for the page or screen, the Database Services Utility automatically switches to

a block-form presentation. Figure 52 on page 98 shows a simulated printout in

block form.

Chapter 6. Interpreting the Output of the Database Services Utility

DB2 Server for VSE. Operations Guide / Handbooks (2004-2007) - page 35
