Peugeot 308 CC Dag (2010.5). Manual

ACCESS

Unlocking and partially opening
the boot

BOOT

Boot anti-theft protection

The boot is designed to remain secure,

even in the "cabriolet" conﬁ guration, if

the vehicle is locked.
So, when the vehicle is locked and the
roof is open, the boot cannot be un-
locked:
-

by means of the interior door open-
ing control,

by  pressing  the  manual  centralised
control  A , when the key is not in the
ignition switch.

Opening

 After unlocking the boot or the vehi-

cle using the remote control or the
key, press the opening control, then
raise the boot lid.

When the selective unlocking is ac-
tivated, the boot can be opened at
the second press of the unlocking
button on the remote control.

 Press this button for more

than  two seconds  to  un-
lock  the  boot.  The  boot
opens slightly.

This action also unlocks the doors.

If a battery failure occurs, the boot
is locked. Consult a PEUGEOT
dealer.

Closing

 Lower the boot lid using the interior

grab handle.

 Press on the top of the boot lid to

close it fully.

If the boot lid is not closed correctly:

- when the engine is running ,

this warning lamp comes on,
accompanied by a message
on the multifunction screen
for a few seconds,

when  the  vehicle  is  moving   (speed
above  6  mph  (10  km/h)),  this  warning
lamp  comes  on,  accompanied  by  an
audible  signal  and  a  message  on  the
multifunction screen for a few seconds.

ACCESS

  The  key  cannot  be  removed  from
the lock until the cap is put back on
the tank.
Opening the cap may trigger an in-
rush  of  air.  This  vacuum,  which  is
completely  normal,  is  caused  by
the sealing of the fuel system.

FUEL TANK

Capacity of the tank: approximately
60 litres.

To ﬁ ll the tank safely:
 the engine must be switched off,


open the fuel ﬁ ller ﬂ ap,

 insert the key in the cap, then turn it

to the left,

When refueling is complete:
 put the cap back in place,
 turn the key to the right, then remove

it from the cap,



close the ﬁ ller ﬂ ap.

 remove the cap and secure it on the

hook, located on the inside of the

ﬂ ap,



ﬁ ll the tank, but do not continue

after the 3rd cut-off of the nozzle ;
this could cause malfunctions.

Low fuel level

Refueling

A label afﬁ xed to the inside of the ﬁ ller

ﬂ ap reminds you of the type of fuel to be

used according to your engine.
More than 5 litres of fuel must be add-
ed in order to be registered by the fuel
gauge.

When  the  low  fuel  level  is
reached,  this  warning  lamp
comes  on  in  the  instrument
panel,  accompanied  by  an

audible signal and a message in the
multifunction screen. When the lamp

ﬁ rst comes on, there is approximately

6 litres of fuel remaining.
Until sufﬁ cient fuel has been added, this

warning  lamp  appears  every  time  the
ignition is switched on, accompanied by
an audible signal and a message. When
driving, this audible signal and message
are repeated with increasing frequency,
as the fuel level drops towards  "0" .
You must refuel to avoid running out of
fuel.
If you run out of fuel (Diesel), refer also
to the "Checks" section.

Operating fault

A malfunction of the fuel gauge is indi-
cated by the return to zero of the fuel
gauge needle.
Have it checked by a PEUGEOT dealer.

ACCESS

Quality of the fuel used for
petrol engines

  The  petrol  engines  are  perfectly  com-
patible  with  E10  type  petrol  biofuels
(containing  10 %  ethanol),  conforming
to  European  standards  EN  228  and
EN 15376.
E85  type  fuels  (containing  up  to  85 %
ethanol) are reserved exclusively for ve-
hicles marketed for the use of this type
of fuel (BioFlex vehicles). The quality of
the ethanol must comply with European
standard EN 15293.
For  Brazil  only,  special  vehicles  are
marketed to run on fuels containing up
to 100 % ethanol (E100 type).

Quality of the fuel used for
Diesel engines

  The  Diesel  engines  are  perfectly  com-
patible  with  biofuels  which  conform  to
current and future European standards
(Diesel  fuel  which  complies  with  stan-
dard EN 590 mixed with a biofuel which
complies  with  standard  EN 14214)
available  at  the  pumps  (containing  up
to 7 % Fatty Acid Methyl Ester).
The  B30  biofuel  can  be  used  in  cer-
tain  Diesel  engines;  however,  this  use
is  subject  to  strict  application  of  the
special  servicing  conditions.  Consult  a
PEUGEOT dealer.
The  use  of  any  other  type  of  (bio)fuel
(vegetable or animal oils, pure or dilut-
ed, domestic fuel...) is strictly prohibited
(risk  of  damage  to  the  engine  and  fuel
system).

VISIBILITY

EXTERIOR LIGHTING
CONTROLS

Control stalk for the selection and
control of the various front and rear
lamps providing the vehicle's lighting.

Main lighting

The various front and rear lamps of the
vehicle are designed to adapt the driv-
er's visibility progressively in relation to
the climatic conditions:
-

sidelamps, to be seen,

dipped beam headlamps to see
without dazzling other drivers,

main beam headlamps to see clearly
when the road is clear.

Additional lighting

Other lamps are ﬁ tted to fulﬁ l the

requirements of particular driving condi-
tions:
-

a rear foglamp to be seen from a
distance,

front foglamps for even better for-
ward vision,

directional headlamps for improved
visibility when cornering,

daytime running lamps to be seen
during the day.

Programming

Various

automatic

lighting

control

modes are also available depending on
options:
-

guide-me-home lighting,

automatic illumination of headlamps,

directional lighting.

Model without AUTO lighting

Model with AUTO lighting

Automatic illumination of
headlamps.

Manual controls

The  lighting  commands  are  issued  di-
rectly by the driver by means of the ring  A
and the stalk  B .
  A.

Main lighting mode selection ring:
turn it to position the symbol re-
quired facing the mark.

Lamps off.

Sidelamps only.

Stalk for switching headlamps: pull
to switch the lighting between dipped
headlamps/main beam headlamps.

In the lamps off and sidelamps modes,
the driver can switch on the main beam
headlamps

temporarily

("headlamp

ﬂ ash") by maintaining a pull on the

stalk.

Dipped headlamps or
main beam headlamps.

Displays

Lighting of the corresponding indicator

lamp on the instrument panel conﬁ rms the

switching on of the lighting selected.

VISIBILITY

Front and rear foglamps.

Press, turning ring C :
 forwards once to switch on the front

foglamps,

 forwards again to switch on the rear

foglamp,

 rearwards once to switch off the rear

foglamp,

 rearwards again to switch off the

front foglamps.

When the lighting is switched off auto-

matically (with AUTO model) or when the

dipped beam headlamps are switched
off manually, the front foglamps and the
sidelamps will remain on.
 Turn the ring rearwards to switch off

the front foglamps, the sidelamps
will then switch off.

      In good or rainy weather, both day
and  night,  the  front  foglamps  and
the rear foglamp are prohibited. In
these situations, the power of their
beams  may  dazzle  other  drivers.
They should only be used in fog or
snow.
In  these  weather  conditions,  it  is
your responsibility to switch on the
foglamps  and  dipped  beam  head-
lamps  manually  as  the  sunshine

sensor may detect sufﬁ cient light.
Do not forget to switch off the front
foglamps  and  the  rear  foglamp
when  they  are  no  longer  neces-
sary.

Switching off of the lamps when
the ignition is switched off

On  switching  off  the  ignition,  all
of  the  lamps  turn  off  immediately,
except  for  dipped  beam  if  guide-
me-home lighting is activated.

C. Foglamp selection ring.
The foglamps operate with the dipped
and main beam headlamps.

In some weather conditions (e.g.

low temperature or humidity), the

presence of misting on the internal
surface  of  the  glass  of  the  head-
lamps  and  rear  lamps  is  normal;
it  disappears  after  the  lamps  have
been on for a few minutes.

Switching on the lamps after the
ignition is switched off

To reactivate the lighting control, rotate
ring  A  to the  "0"  position - lamps off,
then to the desired position.
On opening the driver's door a tem-
porary  audible  signal  warns  the
driver that the lighting is on.
The  lamps,  with  the  exception  of
the sidelamps, switch off automati-
cally  after  a  maximum  duration  of
thirty  minutes  to  prevent  discharg-
ing of the battery.

VISIBILITY

Manual guide-me-home lighting

Temporarily  keeping  the  dipped  beam
headlamps  on  after  the  vehicle's  igni-
tion  has  been  switched  off  makes  the
driver's  exit  easier  when  the  light  is
poor.

Switching on



With the ignition off, "ﬂ ash" the

headlamps using the lighting stalk.



A further "headlamp ﬂ ash" switches

the function off.

Switching off

The  manual  guide-me-home  lighting
switches  off  automatically  after  a  set
time.

Automatic illumination of
headlamps

The sidelamps and dipped beam head-
lamps  are  switched  on  automatically,
without  any  action  on  the  part  of  the
driver, when a low level of external light
is detected or in certain cases of activa-
tion of the windscreen wipers.
As  soon  as  the  brightness  returns  to  a

sufﬁ cient level or after the windscreen

wipers are switched off, the lamps are
switched off automatically.

Activation

 Turn the ring to the "AUTO" position.

The automatic illumination of head-
lamps is accompanied by a mes-
sage on the multifunction screen.

Deactivation

 Turn the ring to another position.

Deactivation  is  accompanied  by
a  message  on  the  multifunction
screen.

Daytime running lamps

Daytime lighting, compulsory in certain
countries, which comes on automati-
cally when the engine is started making
the vehicle more visible to other users.

This function is assured:
-

in countries where it is imposed by
regulations,

by illumination of the dipped beam
headlamps with the sidelamps and
number plate lamps.

for other countries where it is provid-
ed, by the use of dedicated lamps.

The instruments and controls (instru-
ment panel, multifunction screen, air

conditioning control panel, ...) are not

illuminated,  except  in  night  mode  with
manual  or  automatic  illumination  of
headlamps.

This function can be ac-
tivated or deactivated via

the vehicle conﬁ guration

menu.

AUTO

VISIBILITY

In fog or snow, the sunshine sensor

may detect sufﬁ cient light. Therefore,

the  lighting  will  not  come  on  auto-
matically.
Do not cover the sunshine sensor,
coupled  with  the  rain  sensor  and
located  in  the  centre  of  the  wind-
screen behind the rear view mirror;
the  associated  functions  would  no
longer be controlled.

Associated with the automatic
"Guide-me-home" lighting

Association  with  the  automatic  lighting
provides  the  "guide-me-home"  lighting
with the following additional options:
   -

selection of the lighting duration of
15, 30 or 60 seconds in the vehicle
parameters on the multifunction

screen conﬁ guration menu,

automatic activation of "guide-me-
home" lighting when automatic light-
ing is in operation.

Operating fault

In the event of a malfunction of
the sunshine sensor, the light-
ing comes on, this warning
lamp is displayed on the instru-

ment panel and/or a message appears
on the multifunction screen, accompa-
nied by an audible signal.
Consult a PEUGEOT dealer.

EXTERIOR WELCOME
LIGHTING

  The  remote  switching  on  of  the  light-
ing  and  side  spotlamps  makes  your
approach  to  the  vehicle  easier  in  poor
light.  It  is  activated  in  accordance  with
the light intensity detected by the bright-
ness sensor.

Switching on

 Press the open padlock on the re-

mote control.

The  dipped  beam  headlamps  and
the  sidelamps  come  on,  as  well  as
the  side  spotlamps,  located  in  the
exterior mirrors; your vehicle is also
unlocked.

Programming

The lighting duration is
selected via the multifunc-

tion screen conﬁ guration

menu.

The  welcome  lighting  duration  is
associated  with  and  identical  to
that  of  the  automatic  guide-me-
home lighting.

MANUAL ADJUSTMENT OF
HALOGEN HEADLAMPS

Initial setting is position "0".

To avoid dazzling other road users, the
height of the halogen bulb headlamps
must be adjusted according to the load
in the vehicle.
0.

1 or 2 people in the front seats.

3 people.

4 people.

Intermediate setting.

4 people + maximum authorised
loads.

Intermediate setting.

Driver + maximum authorised loads.

Switching off

The exterior welcome lighting switches
off automatically after a set time, when
the ignition is switched on or on locking
the vehicle.

VISIBILITY

Manual guide-me-home lighting

Temporarily  keeping  the  dipped  beam
headlamps  on  after  the  vehicle's  igni-
tion  has  been  switched  off  makes  the
driver's  exit  easier  when  the  light  is
poor.

Switching on



With the ignition off, "ﬂ ash" the

headlamps using the lighting stalk.



A further "headlamp ﬂ ash" switches

the function off.

Switching off

The  manual  guide-me-home  lighting
switches  off  automatically  after  a  set
time.

Automatic illumination of
headlamps

sufﬁ cient level or after the windscreen

wipers are switched off, the lamps are
switched off automatically.

Activation

 Turn the ring to the "AUTO" position.

The automatic illumination of head-
lamps is accompanied by a mes-
sage on the multifunction screen.

Deactivation

 Turn the ring to another position.

Deactivation  is  accompanied  by
a  message  on  the  multifunction
screen.

Daytime running lamps

Daytime lighting, compulsory in certain
countries, which comes on automati-
cally when the engine is started making
the vehicle more visible to other users.

This function is assured:
-

in countries where it is imposed by
regulations,

by illumination of the dipped beam
headlamps with the sidelamps and
number plate lamps.

for other countries where it is provid-
ed, by the use of dedicated lamps.

The instruments and controls (instru-
ment panel, multifunction screen, air

conditioning control panel, ...) are not

illuminated,  except  in  night  mode  with
manual  or  automatic  illumination  of
headlamps.

This function can be ac-
tivated or deactivated via

the vehicle conﬁ guration

menu.

AUTO

VISIBILITY

In fog or snow, the sunshine sensor

may detect sufﬁ cient light. Therefore,

Associated with the automatic
"Guide-me-home" lighting

Association  with  the  automatic  lighting
provides  the  "guide-me-home"  lighting
with the following additional options:
   -

selection of the lighting duration of
15, 30 or 60 seconds in the vehicle
parameters on the multifunction

screen conﬁ guration menu,

automatic activation of "guide-me-
home" lighting when automatic light-
ing is in operation.

Operating fault

In the event of a malfunction of
the sunshine sensor, the light-
ing comes on, this warning
lamp is displayed on the instru-

ment panel and/or a message appears
on the multifunction screen, accompa-
nied by an audible signal.
Consult a PEUGEOT dealer.

EXTERIOR WELCOME
LIGHTING

Switching on

 Press the open padlock on the re-

mote control.

The  dipped  beam  headlamps  and
the  sidelamps  come  on,  as  well  as
the  side  spotlamps,  located  in  the
exterior mirrors; your vehicle is also
unlocked.

Programming

The lighting duration is
selected via the multifunc-

tion screen conﬁ guration

menu.

The  welcome  lighting  duration  is
associated  with  and  identical  to
that  of  the  automatic  guide-me-
home lighting.

MANUAL ADJUSTMENT OF
HALOGEN HEADLAMPS

Initial setting is position "0".

To avoid dazzling other road users, the
height of the halogen bulb headlamps
must be adjusted according to the load
in the vehicle.
0.

1 or 2 people in the front seats.

3 people.

4 people.

Intermediate setting.

4 people + maximum authorised
loads.

Intermediate setting.

Driver + maximum authorised loads.

Switching off

The exterior welcome lighting switches
off automatically after a set time, when
the ignition is switched on or on locking
the vehicle.

AUTO

VISIBILITY

In fog or snow, the sunshine sensor

may detect sufﬁ cient light. Therefore,

Associated with the automatic
"Guide-me-home" lighting

Association  with  the  automatic  lighting
provides  the  "guide-me-home"  lighting
with the following additional options:
   -

selection of the lighting duration of
15, 30 or 60 seconds in the vehicle
parameters on the multifunction

screen conﬁ guration menu,

automatic activation of "guide-me-
home" lighting when automatic light-
ing is in operation.

Operating fault

In the event of a malfunction of
the sunshine sensor, the light-
ing comes on, this warning
lamp is displayed on the instru-

ment panel and/or a message appears
on the multifunction screen, accompa-
nied by an audible signal.
Consult a PEUGEOT dealer.

EXTERIOR WELCOME
LIGHTING

Switching on

 Press the open padlock on the re-

mote control.

The  dipped  beam  headlamps  and
the  sidelamps  come  on,  as  well  as
the  side  spotlamps,  located  in  the
exterior mirrors; your vehicle is also
unlocked.

Programming

The lighting duration is
selected via the multifunc-

tion screen conﬁ guration

menu.

The  welcome  lighting  duration  is
associated  with  and  identical  to
that  of  the  automatic  guide-me-
home lighting.

MANUAL ADJUSTMENT OF
HALOGEN HEADLAMPS

Initial setting is position "0".

To avoid dazzling other road users, the
height of the halogen bulb headlamps
must be adjusted according to the load
in the vehicle.
0.

1 or 2 people in the front seats.

3 people.

4 people.

Intermediate setting.

4 people + maximum authorised
loads.

Intermediate setting.

Driver + maximum authorised loads.

Switching off

The exterior welcome lighting switches
off automatically after a set time, when
the ignition is switched on or on locking
the vehicle.

AUTO

VISIBILITY

In fog or snow, the sunshine sensor

may detect sufﬁ cient light. Therefore,

Associated with the automatic
"Guide-me-home" lighting

Association  with  the  automatic  lighting
provides  the  "guide-me-home"  lighting
with the following additional options:
   -

selection of the lighting duration of
15, 30 or 60 seconds in the vehicle
parameters on the multifunction

screen conﬁ guration menu,

automatic activation of "guide-me-
home" lighting when automatic light-
ing is in operation.

Operating fault

In the event of a malfunction of
the sunshine sensor, the light-
ing comes on, this warning
lamp is displayed on the instru-

ment panel and/or a message appears
on the multifunction screen, accompa-
nied by an audible signal.
Consult a PEUGEOT dealer.

EXTERIOR WELCOME
LIGHTING

Switching on

 Press the open padlock on the re-

mote control.

The  dipped  beam  headlamps  and
the  sidelamps  come  on,  as  well  as
the  side  spotlamps,  located  in  the
exterior mirrors; your vehicle is also
unlocked.

Programming

The lighting duration is
selected via the multifunc-

tion screen conﬁ guration

menu.

The  welcome  lighting  duration  is
associated  with  and  identical  to
that  of  the  automatic  guide-me-
home lighting.

MANUAL ADJUSTMENT OF
HALOGEN HEADLAMPS

Initial setting is position "0".

To avoid dazzling other road users, the
height of the halogen bulb headlamps
must be adjusted according to the load
in the vehicle.
0.

1 or 2 people in the front seats.

3 people.

4 people.

Intermediate setting.

4 people + maximum authorised
loads.

Intermediate setting.

Driver + maximum authorised loads.

Switching off

The exterior welcome lighting switches
off automatically after a set time, when
the ignition is switched on or on locking
the vehicle.

VISIBILITY

AUTOMATIC ADJUSTMENT OF
XENON HEADLAMPS

Do not touch the xenon headlamp
bulbs. Consult a PEUGEOT dealer.

In order to avoid causing a nuisance to
other road users, this system corrects the
height of the xenon headlamp beams au-
tomatically and when stationary, in relation
to the load in the vehicle.

If  a  malfunction  occurs,  this
warning  lamp  and/or  the  ser-
vice  warning  lamp  is  displayed
on  the  instrument  panel,  ac-

companied by an audible signal and a
message on the multifunction screen.
The system then places your headlam-
ps in the lowest position.

DIRECTIONAL LIGHTING

When the dipped or main beam head-
lamps are on, this function enables the
light beams to provide improved lighting
of the side of the road when cornering.
The use of this function, from approxi-

mately 12 mph (20 km/h) and associ-

ated with the xenon headlamps only,
considerably improves the quality of
your lighting when cornering.

with directional lighting

without directional lighting

Programming

Operating fault

The function is activated or
deactivated via the multi-

function screen conﬁ gura-

tion menu.

If a malfunction occurs, this

warning lamp ﬂ ashes on the in-

strument panel, accompanied
by a message on the multifunc-
tion screen.

Consult a PEUGEOT dealer.

When stationary or moving at very
low speed or when reverse gear is
engaged, the function is inactive.
The status of the function remains
in the memory when the ignition is
switched off.

VISIBILITY

AUTOMATIC ADJUSTMENT OF
XENON HEADLAMPS

Do not touch the xenon headlamp
bulbs. Consult a PEUGEOT dealer.

In order to avoid causing a nuisance to
other road users, this system corrects the
height of the xenon headlamp beams au-
tomatically and when stationary, in relation
to the load in the vehicle.

If  a  malfunction  occurs,  this
warning  lamp  and/or  the  ser-
vice  warning  lamp  is  displayed
on  the  instrument  panel,  ac-

companied by an audible signal and a
message on the multifunction screen.
The system then places your headlam-
ps in the lowest position.

DIRECTIONAL LIGHTING

When the dipped or main beam head-
lamps are on, this function enables the
light beams to provide improved lighting
of the side of the road when cornering.
The use of this function, from approxi-

mately 12 mph (20 km/h) and associ-

ated with the xenon headlamps only,
considerably improves the quality of
your lighting when cornering.

with directional lighting

without directional lighting

Programming

Operating fault

The function is activated or
deactivated via the multi-

function screen conﬁ gura-

tion menu.

If a malfunction occurs, this

warning lamp ﬂ ashes on the in-

strument panel, accompanied
by a message on the multifunc-
tion screen.

Consult a PEUGEOT dealer.

When stationary or moving at very
low speed or when reverse gear is
engaged, the function is inactive.
The status of the function remains
in the memory when the ignition is
switched off.

VISIBILITY

WIPER CONTROLS

Control stalk for the various windscreen
wiping modes for the elimination of rain
and cleaning.

Manual operation of the
windscreen wipers

Model with intermittent wiping

Model with AUTO wiping

fast (heavy rain),

normal (moderate rain),

intermittent (proportional to

the speed of the vehicle),

automatic,

then

single

wipe (see following page).

park,

single wipe (press down and

release),

Programming

An automatic mode is also available,
providing automatic rain sensitive wind-
screen wipers.

This control stalk allows selection of the
most suitable wiping speed according
to the weather conditions:

VISIBILITY

Windscreen and headlamp
wash

 Pull the windscreen wiper stalk to-

wards you. The windscreen wash
then the windscreen wipers operate

for a ﬁ xed period.

The  headlamp  washers  only  operate
when   the  dipped  beam  headlamps
are on .

Screenwash/headlamp wash low

In the case of vehicles ﬁ tted with

headlamp washers, when the
minimum level of the reservoir is
reached, this warning lamp and/or

the service warning lamp is displayed on
the instrument panel, accompanied by an
audible signal and a message on the multi-
function screen.
Next time you stop, ﬁ ll the screenwash/

headlamp wash reservoir.
The warning lamp is displayed when the ig-
nition is switched on, or every time the stalk

is operated, until the reservoir is ﬁ lled.

Automatic rain sensitive
windscreen wipers

The windscreen wipers operate automati-
cally, without any action on the part of the
driver, if rain is detected (sensor behind the

rear view mirror), adapting their speed to

the intensity of the rainfall.

Activation

This is controlled manually by the driver
by pushing the  stalk downwards  to the
"AUTO"  position.
It is accompanied by a message on the
multifunction screen.

Do not cover the rain sensor, linked
with the sunshine sensor and locat-
ed in the centre of the windscreen
behind the rear view mirror.
Switch  off  the  automatic  rain  sen-
sitive  wipers  when  using  an  auto-
matic car wash.
In  winter,  to  avoid  damaging  the
wiper blades, it is advisable to wait
until  the  windscreen  is  completely
clear  of  ice  before  activating  the
automatic rain sensitive wipers.

The automatic rain sensitive wipers
must be reactivated if the ignition has
been off for more than one minute, by
pushing the stalk downwards.

Switching off

This is controlled manually by the driver
by moving the stalk upwards then re-
turning it to position "0" .
It is accompanied by a message on the
multifunction screen.

Operating fault

If an automatic wiping malfunction oc-
curs, the wipers will operate in intermit-
tent mode.
Have it checked by a PEUGEOT dealer.

VISIBILITY

Special position of the
windscreen wipers

This  position  permits  release  of  the
windscreen wiper blades.
It  is  used  for  cleaning  or  replacement
of  the  blades.  It  can  also  be  useful,  in
winter,  to  detach  the  blades  from  the
windscreen.
In the moment following switching off of
the ignition, any action on the stalk posi-
tions  the  wipers  vertically  on  the  wind-
screen.
To  park  the  wipers  after  this  has  been
done, switch on the ignition and operate
the stalk.

For maintain the effectiveness of

the "ﬂ at-blade" wiper blades, it is

advisable to:
-

handle them with care,

clean them regularly using
soapy water,

avoid using them to retain card-
board on the windscreen.

- replace them at the ﬁ rst signs of

wear.

COURTESY LAMPS

   1.    Front courtesy lamp
  2.    Map reading lamp
  3.    Rear courtesy lamp

Front and rear courtesy lamps

In this position, the courtesy
lamp comes on gradually:

In permanent lighting mode, different
lighting times are available:
-

with the ignition off, approxi-
mately ten minutes,

in energy economy mode, ap-
proximately thirty seconds,

with the engine running, unlimited.

when the vehicle is unlocked,

when the key is removed from the
ignition,

when the remote control locking but-
ton is activated, in order to locate
your vehicle.

Permanently off.

Permanent lighting.

Map reading lamps

 With the ignition on, press the cor-

responding switch.

It switches off gradually:
-

when the vehicle is locked,

when the ignition is switched on,

30 seconds after the last door is
closed.

Peugeot 308 CC Dag (2010.5). Manual - part 6
