Peugeot 308 CC Dag (2010.5). Manual - part 7

VISIBILITY

Windscreen and headlamp
wash

 Pull the windscreen wiper stalk to-

wards you. The windscreen wash
then the windscreen wipers operate

for a ﬁ xed period.

The  headlamp  washers  only  operate
when   the  dipped  beam  headlamps
are on .

Screenwash/headlamp wash low

In the case of vehicles ﬁ tted with

headlamp washers, when the
minimum level of the reservoir is
reached, this warning lamp and/or

the service warning lamp is displayed on
the instrument panel, accompanied by an
audible signal and a message on the multi-
function screen.
Next time you stop, ﬁ ll the screenwash/

headlamp wash reservoir.
The warning lamp is displayed when the ig-
nition is switched on, or every time the stalk

is operated, until the reservoir is ﬁ lled.

Automatic rain sensitive
windscreen wipers

The windscreen wipers operate automati-
cally, without any action on the part of the
driver, if rain is detected (sensor behind the

rear view mirror), adapting their speed to

the intensity of the rainfall.

Activation

This is controlled manually by the driver
by pushing the  stalk downwards  to the
"AUTO"  position.
It is accompanied by a message on the
multifunction screen.

Do not cover the rain sensor, linked
with the sunshine sensor and locat-
ed in the centre of the windscreen
behind the rear view mirror.
Switch  off  the  automatic  rain  sen-
sitive  wipers  when  using  an  auto-
matic car wash.
In  winter,  to  avoid  damaging  the
wiper blades, it is advisable to wait
until  the  windscreen  is  completely
clear  of  ice  before  activating  the
automatic rain sensitive wipers.

The automatic rain sensitive wipers
must be reactivated if the ignition has
been off for more than one minute, by
pushing the stalk downwards.

Switching off

This is controlled manually by the driver
by moving the stalk upwards then re-
turning it to position "0" .
It is accompanied by a message on the
multifunction screen.

Operating fault

If an automatic wiping malfunction oc-
curs, the wipers will operate in intermit-
tent mode.
Have it checked by a PEUGEOT dealer.

VISIBILITY

Special position of the
windscreen wipers

This  position  permits  release  of  the
windscreen wiper blades.
It  is  used  for  cleaning  or  replacement
of  the  blades.  It  can  also  be  useful,  in
winter,  to  detach  the  blades  from  the
windscreen.
In the moment following switching off of
the ignition, any action on the stalk posi-
tions  the  wipers  vertically  on  the  wind-
screen.
To  park  the  wipers  after  this  has  been
done, switch on the ignition and operate
the stalk.

For maintain the effectiveness of

the "ﬂ at-blade" wiper blades, it is

advisable to:
-

handle them with care,

clean them regularly using
soapy water,

avoid using them to retain card-
board on the windscreen.

- replace them at the ﬁ rst signs of

wear.

COURTESY LAMPS

   1.    Front courtesy lamp
  2.    Map reading lamp
  3.    Rear courtesy lamp

Front and rear courtesy lamps

In this position, the courtesy
lamp comes on gradually:

In permanent lighting mode, different
lighting times are available:
-

with the ignition off, approxi-
mately ten minutes,

in energy economy mode, ap-
proximately thirty seconds,

with the engine running, unlimited.

when the vehicle is unlocked,

when the key is removed from the
ignition,

when the remote control locking but-
ton is activated, in order to locate
your vehicle.

Permanently off.

Permanent lighting.

Map reading lamps

 With the ignition on, press the cor-

responding switch.

It switches off gradually:
-

when the vehicle is locked,

when the ignition is switched on,

30 seconds after the last door is
closed.

VISIBILITY

INTERIOR MOOD LIGHTING

Different lighting times are available:
-

when the ignition is off, approxi-
mately ten minutes,

in energy economy mode, ap-
proximately thirty seconds,

when the engine is running, no
limit.

Your vehicle is ﬁ tted with two boot lamps;

one in the left-hand boot side trim and a
second in the boot lid interior trim.
They come on automatically when the
boot is opened and switch off automati-
cally when the boot is closed.
They cannot be deactivated manually.

INTERIOR WELCOME LIGHTING

BOOT LIGHTING

The remote switching on of the passen-
ger  compartment  lighting  makes  your
entry  into  the  vehicle  easier  in  poor
light.  It  is  activated  in  accordance  with
the light intensity detected by the bright-
ness sensor.

Switching on

 Press the open padlock on the re-

mote control.

The  front  door  sill  lighting,  the  footwell
lighting  and  the  courtesy  lamps  come
on; your vehicle is also unlocked.

Switching off

The interior welcome lighting switches off
automatically after a set time or when one
of the doors is opened.

Programming

The dimmed passenger compartment
lighting improves visibility in the vehicle
when the light is poor.

Switching on

At  night,  the  footwell  lighting  and  the
front  courtesy  mood  lamp  come  on
automatically  when  the  sidelamps  are
switched on.

Switching off

The  interior  mood  lighting  switches  off
automatically  when  the  sidelamps  are
switched off.

Programming

The  welcome  lighting  duration  is
associated  with  and  identical  to
that  of  the  automatic  guide-me-
home lighting.

The function is activated or
deactivated via the multi-

function screen conﬁ gura-

tion menu.
This function is activated
by default.

The lighting duration is
selected via the multifunc-

tion screen conﬁ guration

menu.

FITTINGS

INTERIOR FITTINGS

1. Sun visor

(see details on following page)

2. Storage compartment

3. Storage for oddments

4. Bag hook

(see details on following page)

5. Lockable, refrigerated glove box

(see details on following page)

6. Large door trays

7. Small door trays

8. Illuminated ashtray

(see details on following page)

9. Storage compartment with

non-slip carpet

10. 12 V accessory socket

(see details on following page)

11. Lockable front armrest

(see details on following page)

12. Storage box

(see details on following page)

FITTINGS

LOCKABLE, REFRIGERATED
GLOVE BOX

This has areas for storing a bottle of wa-
ter, the vehicle's handbook pack...
Its lid has areas for storing a pen, a pair
of spectacles, tokens, cards, a can...
It is also locked or unlocked when the
vehicle is locked or unlocked using the
remote control or the key.
 To open the glove box, raise the

handle.

The lighting comes on when the lid is
opened.
The glove box is ﬁ tted with an air vent A ,

which can be opened or closed. It dis-
tributes the same conditioned air as the
vents in the passenger compartment.

SUN VISOR

Component which protects against sunlight
from the front or the side, also equipped
with an illuminated courtesy mirror.

 With the ignition on, raise the conceal-

ing ﬂ ap; the mirror is lit automatically.

This sun visor is also equipped with a
ticket holder.

BAG HOOK

 Press the lower part of the hook to

unfold it.

 Hang the strap of your bag on the

hook to secure it.

FITTINGS

LOCKABLE FRONT ARMREST

Comfort and storage device for the driver
and front passenger.

The height and longitudinal position
of the armrest lid can be adjusted for
greater comfort.

Its compartment is also locked or unlocked
when the vehicle is locked or unlocked us-
ing the remote control or the key.

Storage

It can hold up to 6 CDs.
 Raise the lever 1 .
 Raise the lid fully.

 Slide the lid fully forwards or rear-

wards.

 Raise the lid to the required position

(low, intermediate or high).

 If you raise the lid slightly beyond

the high position, guide it when low-
ering it to the low position.

Longitudinal adjustment

Height adjustment

PEUGEOT CONNECT USB

This connection box, consisting of a
USB port, is located in the front armrest.
It permits the connection of portable
equipment, such as an iPod

digital au-

dio player of generation 5 or later or a
USB stick.
It reads the audio ﬁ le formats (mp3,

ogg, wma, wav...) which are transmitted
to your audio equipment and played via
the vehicle's speakers.
You can manage these ﬁ les using the

steering  wheel  controls  or  the  audio
equipment  control  panel  and  display
them on the multifunction screen.

When it is in use, the portable equip-
ment charges automatically.

For more information on the use of this
equipment, refer to the "PEUGEOT
Connect

Media"

"PEUGEOT

Connect Sound" part of the "Audio and
Telematics" section.

FITTINGS

STORAGE BOX

Storage area, built into the rear of the
front armrest, for the rear passengers.

 To empty the box, after opening,

press the tab and remove it.

To avoid any risk of jamming of the
pedals:
-

only use mats which are suited to

the ﬁ xings already present in the

vehicle; their use is essential,

- never ﬁ t one mat on top of an-

other.

MATS

Removable carpet protection component.

Refitting

To reﬁ t the mat on the driver's side:
 position the mat correctly,


reﬁ t the ﬁ xings by pressing,

 check that the mat is secured correctly.

Fitting

When ﬁ tting the mat for the ﬁ rst time,

on the driver's side, use only the ﬁ xings

provided in the wallet attached.
The other mats are simply placed on
the carpet.

Removal

To remove the mat on the driver's side:
 move the seat as far back as possible,


unclip the ﬁ xings,

 remove the mat.

12 V ACCESSORY SOCKET

 To connect a 12 V accessory (max

power: 120 W), lift the cover and
connect a suitable adaptor.

ILLUMINATED ASHTRAY

 Pull the drawer for access to the

ashtray.

 To empty the ashtray, after opening,

press the tab and remove the ashtray.

FITTINGS

LOCKABLE, REFRIGERATED
GLOVE BOX

handle.

The lighting comes on when the lid is
opened.
The glove box is ﬁ tted with an air vent A ,

which can be opened or closed. It dis-
tributes the same conditioned air as the
vents in the passenger compartment.

SUN VISOR

Component which protects against sunlight
from the front or the side, also equipped
with an illuminated courtesy mirror.

 With the ignition on, raise the conceal-

ing ﬂ ap; the mirror is lit automatically.

This sun visor is also equipped with a
ticket holder.

BAG HOOK

 Press the lower part of the hook to

unfold it.

 Hang the strap of your bag on the

hook to secure it.

FITTINGS

LOCKABLE FRONT ARMREST

Comfort and storage device for the driver
and front passenger.

The height and longitudinal position
of the armrest lid can be adjusted for
greater comfort.

Its compartment is also locked or unlocked
when the vehicle is locked or unlocked us-
ing the remote control or the key.

Storage

It can hold up to 6 CDs.
 Raise the lever 1 .
 Raise the lid fully.

 Slide the lid fully forwards or rear-

wards.

 Raise the lid to the required position

(low, intermediate or high).

 If you raise the lid slightly beyond

the high position, guide it when low-
ering it to the low position.

Longitudinal adjustment

Height adjustment

PEUGEOT CONNECT USB

This connection box, consisting of a
USB port, is located in the front armrest.
It permits the connection of portable
equipment, such as an iPod

digital au-

dio player of generation 5 or later or a
USB stick.
It reads the audio ﬁ le formats (mp3,

ogg, wma, wav...) which are transmitted
to your audio equipment and played via
the vehicle's speakers.
You can manage these ﬁ les using the

steering  wheel  controls  or  the  audio
equipment  control  panel  and  display
them on the multifunction screen.

When it is in use, the portable equip-
ment charges automatically.

For more information on the use of this
equipment, refer to the "PEUGEOT
Connect

Media"

"PEUGEOT

Connect Sound" part of the "Audio and
Telematics" section.

FITTINGS

STORAGE BOX

Storage area, built into the rear of the
front armrest, for the rear passengers.

 To empty the box, after opening,

press the tab and remove it.

To avoid any risk of jamming of the
pedals:
-

only use mats which are suited to

the ﬁ xings already present in the

vehicle; their use is essential,

- never ﬁ t one mat on top of an-

other.

MATS

Removable carpet protection component.

Refitting

To reﬁ t the mat on the driver's side:
 position the mat correctly,


reﬁ t the ﬁ xings by pressing,

 check that the mat is secured correctly.

Fitting

When ﬁ tting the mat for the ﬁ rst time,

on the driver's side, use only the ﬁ xings

provided in the wallet attached.
The other mats are simply placed on
the carpet.

Removal

To remove the mat on the driver's side:
 move the seat as far back as possible,


unclip the ﬁ xings,

 remove the mat.

12 V ACCESSORY SOCKET

 To connect a 12 V accessory (max

power: 120 W), lift the cover and
connect a suitable adaptor.

ILLUMINATED ASHTRAY

 Pull the drawer for access to the

ashtray.

 To empty the ashtray, after opening,

press the tab and remove the ashtray.

FITTINGS

BOOT FITTINGS

1. Stowing rings

2. Luggage retaining net

(see details on following page)

3. Boot screen

(see details on following page)

4. Storage net

5. Luggage retaining strap

Storage box (version ﬁ tted with a

temporary tyre repair kit)

(see details on following page)

Tool box (version ﬁ tted with a

standard spare wheel

(refer to the section "Practical
information - § Changing a wheel")

FITTINGS

Hooked onto the stowing rings, this en-
ables you to secure your luggage.

Luggage retaining net

 Raise the boot carpet to gain access

to the storage box.

 Hook the boot carpet on the boot

seal using its handle.

This has areas for storing the windstop
and two warning triangles.
By removing this box you gain access
to the temporary tyre repair kit and the
vehicle tools.

Storage box

Boot screen

In the "cabriolet" conﬁ guration, this de-

ﬁ nes the luggage space in the boot.
 When the boot screen is unfolded,

check that the luggage:

- never raises it,
- is never placed on top of it.

The  load  space  cover  must  always
be  unfolded  before  a  roof  opening
manoeuvre  is  triggered  (refer  to  the
"Familiarisation - § Opening" section).

SAFETY

DIRECTION INDICATORS

If you forget to cancel the direc-
tion indicators for more than twenty
seconds, the volume of the audible
signal will increase if the speed is
above 40 mph (60 km/h).

 Left: lower the lighting stalk passing

the point of resistance.

 Right: raise the lighting stalk passing

the point of resistance.

HAZARD WARNING LAMPS

A visual warning by means of the di-
rection indicators to alert other road
users to a vehicle breakdown, towing or
accident.

 Press this button, the direction indi-

cators ﬂ ash.

They can operate with the ignition off.

Automatic operation of hazard
warning lamps

When braking in an emergency, de-
pending on the deceleration, the hazard
warning lamps come on automatically.
They switch off automatically the ﬁ rst

time you accelerate.
 You can also switch them off by

pressing the button.

SAFETY

HORN

 Press one of the spokes of the steer-

ing wheel.

Use the horn moderately and only
in the following cases:
-

immediate danger,

overtaking a cyclist or pedestrian

when approaching an area where
there is no visibility.

Audible warning to alert other road users
to an imminent danger.

EMERGENCY OR ASSISTANCE
CALL

This  system  allows  you  to  make  an
emergency  or  assistance  call  to  the
emergency services or to the dedicated
PEUGEOT service.
For  more  information  on  the  use  of  this
function, refer to the "Audio and telematics"
section.

SAFETY

TYRE UNDER-INFLATION
DETECTION

System which automatically and contin-
uously checks the pressure of the tyres
while driving.

All repairs and changing of tyres on

a wheel ﬁ tted with this system must

be carried out by a PEUGEOT
dealer.
If, when changing a tyre, you in-
stall a wheel which is not detected

by your vehicle (example: ﬁ tting

of snow tyres), you must have the
system reinitialised by a PEUGEOT
dealer.

This  system  does  not  avoid  the
need  to  have  the  tyre  pressures
checked  regularly  (refer  to  the

"Identiﬁ cation markings" section) to

ensure that the optimum dynamic
performance of the vehicle is main-
tained and prevent premature wear
of the tyres, particularly in arduous
driving conditions (heavy load, high
speed).
The

tyre

pressures

must

checked  cold,  at  least  once  a
month.  Remember  to  check  the
pressure of the spare wheel.
The  tyre  under-inﬂ ation  detection

system  may  experience  temporary
interference due to electro-magnetic
emissions  on  a  frequency  close  to
that used by the system.

Sensors ﬁ tted in each valve trigger a

warning in the event of problem (speed
above 12 mph (20 km/h)).

This warning lamp is displayed on the
instrument panel and/or a message
appears on the multifunction screen,
accompanied by an audible signal,
to locate the wheel concerned.

 Check the tyre pressures as soon

as possible.

This check must be carried out when
the tyres are cold.

Under-inﬂ ated tyre

The  STOP  warning lamp comes on
and/or this warning lamp is displayed
on  the  instrument  panel,  accompa-
nied by an audible signal and a mes-
sage  on  the  multifunction  screen
locating the wheel concerned.

 Stop as soon as it is safe to do so,

avoiding any sudden movement of
the steering wheel and the brakes.

 Repair or change the damaged

wheel (punctured or very deﬂ ated

tyre), and have the tyre pressure
checked as soon as possible.

Puncture

The tyre under-inﬂ ation detection

system is an aid to driving which does
not replace the need for the driver to
be vigilant or to drive responsibly.

Sensor(s) not detected or faulty

This warning lamp is displayed
on the instrument panel and/
or a message appears on the
multifunction screen, accompa-

nied by an audible signal, to locate the
wheel or wheels which are not detected
or to indicate a fault in the system.
Contact a PEUGEOT dealer to replace
the faulty sensor(s).

This message is also displayed
when one of the wheels is away
from the vehicle (being repaired) or
when one or more wheels without a

sensor are ﬁ tted.
If your vehicle is equipped with a

spare wheel, this is not ﬁ tted with

a sensor.

SAFETY

BRAKING ASSISTANCE
SYSTEMS

Group  of  supplementary  systems  which
help  you  to  obtain  optimum  braking  in
complete safety in emergency situations:
   -

anti-lock braking system (ABS),

electronic brake force distribution
(EBFD),

emergency braking assistance (EBA).

Anti-lock braking system

and electronic brake force
distribution

Linked systems which improve the sta-
bility and manoeuvrability of your vehicle
when braking, in particular on poor or
slippery surfaces.

When braking in an emergency,

press very ﬁ rmly without releasing

the pressure.

  When  replacing  wheels  (tyres  and
rims),  ensure  that  they  conform
to  the  manufacturer's  recommen-
dations.

Operating fault

If this warning lamp comes on,
accompanied by an audible sig-
nal and a message on the mul-
tifunction screen, it indicates a

malfunction of the anti-lock braking sys-
tem which could result in loss of control
of the vehicle when braking.

If this warning lamp comes on,
together with the STOP and ABS
warning lamps, accompanied by
an audible signal and a message

on the multifunction screen, it indicates a
malfunction of the electronic brake force
distribution which could result in loss of
control of the vehicle when braking.

Emergency braking assistance

System which, in an emergency, ena-
bles you to obtain the optimum braking
pressure more quickly, thus reducing
the stopping distance.

Activation

The anti-lock braking system comes
into operation automatically when there
is a risk of wheel lock.
Normal operation of the ABS may make
itself felt by slight vibration of the brake
pedal.

Activation

It is triggered by the speed at which the
brake pedal is pressed.
The effect of this is a reduction in the
resistance of the pedal and an increase

in braking efﬁ ciency.

When braking in an emergency,

press ﬁ rmly without releasing the

pressure.

Deactivation
If your vehicle is ﬁ tted with the 1.6 litre

THP 200 hp petrol engine, you can deac-
tivate this function; refer to the "Trajectory
control systems - § Deactivation" section.

  You  must  stop  as  soon  as  it  is  safe
to do so.
In  either  case,  contact  a  PEUGEOT
dealer.

Content .. 5 6 7 8 ..
