Peugeot 308 CC Dag (2010.5). Manual

COMFORT

STEERING WHEEL ADJUSTMENT



When stationary , pull the control

lever to release the steering wheel.

 Adjust the height and reach to suit

your driving position.

 Push the control lever to lock the

steering wheel.

As a safety precaution, it is impera-
tive that these operations are carried
out while the vehicle is stationary.

Automatic day/night model

By means of a sensor, which measures
the light from the rear of the vehicle, this
system automatically and progressively
changes  between  the  day  and  night
uses.
It has an anti-dazzle system which dark-
ens  the  mirror  glass:  this  reduces  any
driver  discomfort  caused  by  the  light
beams of following vehicles, the sun...

  In  order  to  ensure  optimum  vis-
ibility during your manoeuvres, the
mirror  lightens  automatically  when
reverse gear is engaged.

ACCESS

Unlocking and partial opening of the
boot

 Press this button for more

than  two seconds  to  un-
lock  the  boot.  The  boot
opens slightly.

This action unlocks the vehicle ﬁ rst.

 Press the open padlock

once to unlock the driver's
door only.

Selective unlocking using the
remote control

Each unlocking is conﬁ rmed by rapid

ﬂ ashing of the direction indicators for

approximately two seconds.
According to version, the door mirrors

unfold at the same time as the ﬁ rst un-

locking action.

Selective unlocking using the key

 Turn the key to the left in the driver's

door lock once to unlock the driver's
door only.

 Turn the key to the left in the driver's

door lock again to unlock the pas-
senger's door and the boot.

The complete or selective
unlocking parameter is set
via the multifunction screen

conﬁ guration menu.

REMOTE CONTROL KEY

System  which  permits  central  unlock-
ing and locking of the vehicle using the
lock or from a distance, as well as of the
interior  storage  compartments  (glove
box and front armrest). It is also used to
locate  and  start  the  vehicle,  as  well  as
providing protection against theft.

Unfolding the key

 First press this button to unfold the

key.

Unlocking the vehicle

Unlocking is conﬁ rmed by rapid ﬂ ashing

of  the  direction  indicators  for  approxi-
mately two seconds.
The  central  unlocking  also  unlocks  the
glove  box  and  the  front  armrest  com-
partment.
According  to  version,  the  door  mirrors
unfold at the same time.

 Press the open padlock to

unlock the vehicle.

Complete unlocking using the key

 Turn the key to the left in the driver's

door lock to unlock the vehicle.

Complete unlocking using the
remote control

 Press the open padlock again to un-

lock the passenger's door and the
boot.

Complete unlocking is activated by
default.

ACCESS

Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual cen-
tral control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

If one of the doors or the boot is still

open, the central locking does not

take place.
After unlocking the vehicle, if none
of the openings - door or boot - are
opened within thirty seconds, the
vehicle will lock itself again auto-
matically.

Deadlocking using the remote
control

Deadlocking using the key

The  folding  and  unfolding  of  the
door  mirrors  using  the  remote
control  can  be  deactivated  by  a
PEUGEOT dealer.

 Press the closed padlock

to lock the vehicle com-
pletely.

 Press the closed padlock

again within ﬁ ve seconds

to deadlock the vehicle.

Locking the vehicle

 Press the closed padlock

to lock the vehicle com-
pletely.

Normal locking using the key

 Turn the key to the right in the driv-

er's door lock to lock the vehicle
completely.

Normal locking using the remote
control

Deadlocking is conﬁ rmed by ﬁ xed

lighting of the direction indicators for
approximately two seconds.
According to version, the door mirrors
fold at the same time.

Locking is conﬁ rmed by ﬁ xed lighting of

the direction indicators for approximately

two seconds.
The central locking also locks the glove

box and the front armrest compartment.
According to version, the door mirrors
fold at the same time.

 Turn the key to the right in the driver's

door lock to lock the vehicle com-
pletely.

 Turn the key to the right again within

ﬁ ve seconds to deadlock the vehicle.

ACCESS

Locating your vehicle

 Press the closed padlock

to locate your locked ve-
hicle in a car park.

Electronic engine immobiliser

The  key  contains  an  electronic  chip
which  has  a  special  code.  When  the
ignition  is  switched  on,  this  code  must
be recognised in order for starting to be
possible.
This electronic engine immobiliser locks
the  engine  management  system  a  few
minutes after the ignition is switched off
and  prevents  starting  of  the  engine  by
anyone who does not have the key.

Anti-theft protection

In  the  event  of  a  malfunction,
you  are  informed  by  lighting  of
this  warning  lamp,  an  audible
signal  and  a  message  on  the
multifunction screen.

In this case, your vehicle does not start;
contact a PEUGEOT dealer as soon as
possible.

Folding the key

 First press this button to fold the

key.

This is indicated by lighting of the cour-
tesy lamps and side spotlamps and

ﬂ ashing of the direction indicators for a

few seconds.

ACCESS

Starting the vehicle

 Insert the key in the ignition switch.

The system recognises the starting
code.

 Turn the key fully towards the dash-

board to position 3 (Starting) .

 When the engine starts, release

the key.

Switching the vehicle off

 Immobilise the vehicle.
 Turn the key fully towards you to po-

sition 1 (Stop) .

 Remove the key from the ignition

switch.

Remote control problem

Following  disconnection  of  the  vehicle
battery, replacement of the remote con-
trol  battery  or  in  the  event  of  a  remote
control  malfunction,  you  can  no  longer
unlock, lock or locate your vehicle.
      First of all, use the key in the lock to

unlock or lock your vehicle.

 Then, reinitialise the remote control.
If the problem persists, contact a
PEUGEOT dealer as soon as possible.

Changing the battery

Battery ref.: CR1620/3 volts.

Reinitialisation

      Switch off the ignition.
     Turn the key to position  2 (Ignition   on  ) .
     Press  the  closed  padlock  immedi-

ately for a few seconds.

 Switch off the ignition and remove

the key from the ignition switch.

The remote control is fully operational
again.

 Unclip the casing using a coin at the

notch.



Slide the ﬂ at battery out of its location.

 Slide the new battery into its loca-

tion observing the original direction.

 Clip the casing.
 Reinitialise the remote control.

This replacement battery is available
from PEUGEOT dealers.

If the battery is ﬂ at, you are in-

formed by illumination of this
warning lamp, an audible signal
and a message in the multifunc-
tion screen.

Key left in the "Ignition on"
position

If  the  key  has  been  left  in  the  ig-
nition  switch,  the  ignition  will  be
switched  off  automatically  after
one hour.
To switch the ignition back on, turn
the  key  to  position   1  (Stop) ,  then
back to position  2 (Ignition   on  ) .

ACCESS

Lost keys

Visit a PEUGEOT dealer with the vehicle's V5 registration document and your

personal identiﬁ cation documents.
The PEUGEOT dealer will be able to retrieve the key code and the trans-
ponder code required to order a replacement key.

Do not throw the remote control bat-
teries away, they contain metals which
are harmful to the environment.
Take them to an approved collec-
tion point.

Remote control

The  high  frequency  remote  control  is  a  sensitive  system;  do  not  operate  it
while it is in your pocket as there is a possibility that it may unlock the vehicle,
without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and
out of sight of your vehicle. You run the risk of stopping it from working and the
remote control would have to be reinitialised.
The  remote  control  does  not  operate  when  the  key  is  in  the  ignition,  even
when the ignition is switched off, except for reinitialisation.

Locking the vehicle

Driving with the doors locked may make access to the passenger compart-

ment by the emergency services more difﬁ cult in an emergency.
As a safety precaution (with children on board), remove the key from the igni-
tion when you leave the vehicle, even for a short time.

Anti-theft protection

Do not make any modiﬁ cations to the electronic engine immobiliser system;

this could cause malfunctions.

When purchasing a second-hand vehicle

Have the key codes memorised by a PEUGEOT dealer, to ensure that the
keys in your possession are the only ones which can start the vehicle.

ACCESS

Locating your vehicle

 Press the closed padlock

to locate your locked ve-
hicle in a car park.

Electronic engine immobiliser

Anti-theft protection

In  the  event  of  a  malfunction,
you  are  informed  by  lighting  of
this  warning  lamp,  an  audible
signal  and  a  message  on  the
multifunction screen.

In this case, your vehicle does not start;
contact a PEUGEOT dealer as soon as
possible.

Folding the key

 First press this button to fold the

key.

This is indicated by lighting of the cour-
tesy lamps and side spotlamps and

ﬂ ashing of the direction indicators for a

few seconds.

ACCESS

Lost keys

Visit a PEUGEOT dealer with the vehicle's V5 registration document and your

personal identiﬁ cation documents.
The PEUGEOT dealer will be able to retrieve the key code and the trans-
ponder code required to order a replacement key.

Do not throw the remote control bat-
teries away, they contain metals which
are harmful to the environment.
Take them to an approved collec-
tion point.

Remote control

Locking the vehicle

Driving with the doors locked may make access to the passenger compart-

ment by the emergency services more difﬁ cult in an emergency.
As a safety precaution (with children on board), remove the key from the igni-
tion when you leave the vehicle, even for a short time.

Anti-theft protection

Do not make any modiﬁ cations to the electronic engine immobiliser system;

this could cause malfunctions.

When purchasing a second-hand vehicle

Have the key codes memorised by a PEUGEOT dealer, to ensure that the
keys in your possession are the only ones which can start the vehicle.

ACCESS

Starting the vehicle

 Insert the key in the ignition switch.

The system recognises the starting
code.

 Turn the key fully towards the dash-

board to position 3 (Starting) .

 When the engine starts, release

the key.

Switching the vehicle off

 Immobilise the vehicle.
 Turn the key fully towards you to po-

sition 1 (Stop) .

 Remove the key from the ignition

switch.

Remote control problem

unlock or lock your vehicle.

 Then, reinitialise the remote control.
If the problem persists, contact a
PEUGEOT dealer as soon as possible.

Changing the battery

Battery ref.: CR1620/3 volts.

Reinitialisation

      Switch off the ignition.
     Turn the key to position  2 (Ignition   on  ) .
     Press  the  closed  padlock  immedi-

ately for a few seconds.

 Switch off the ignition and remove

the key from the ignition switch.

The remote control is fully operational
again.

 Unclip the casing using a coin at the

notch.



Slide the ﬂ at battery out of its location.

 Slide the new battery into its loca-

tion observing the original direction.

 Clip the casing.
 Reinitialise the remote control.

This replacement battery is available
from PEUGEOT dealers.

If the battery is ﬂ at, you are in-

formed by illumination of this
warning lamp, an audible signal
and a message in the multifunc-
tion screen.

Key left in the "Ignition on"
position

ACCESS

ALARM

System which protects and provides a
deterrent against theft and break-ins.
It provides the following types of moni-
toring.

Locking the vehicle with full
alarm system

For all work on the alarm system,
contact a PEUGEOT dealer.

Activation

 Switch off the ignition and get out of

the vehicle.

 Press the locking button on the re-

mote control.

The monitoring system is active: the in-

dicator lamp in the button ﬂ ashes once

per second.
After the locking button on the remote
control is pressed, the exterior perime-
ter monitoring is activated after a delay
of 5 seconds and the interior volumetric
monitoring after a delay of 45 seconds.

Exterior perimeter

The system checks for opening of the
vehicle.
The alarm is triggered if anyone tries to
open a door, the boot, the bonnet...

Interior volumetric

The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks
a window, enters the passenger com-
partment or moves inside the vehicle.

Self-protection function

The system checks for the putting out of
service of its components.
The alarm is triggered if the battery, the
central control or the wires of the siren
are put out of service or damaged.

Deactivation

 Press the unlocking button on the

remote control.

The alarm system is deactivated: the indi-
cator lamp in the button goes off.

If  an  opening  (door,  boot...)  is  not
closed fully, the vehicle is not locked
but  the  exterior perimeter  monitor-
ing  will  be  activated  after  a  delay
of 45 seconds at the same time as
the interior volumetric monitoring.

ACCESS

Triggering of the alarm

The monitoring functions remain
active until the alarm has been trig-
gered eleven times in succession.
When the vehicle is unlocked using

the remote control, rapid ﬂ ashing

of  the  indicator  lamp  in  the  button
informs you that the alarm was trig-
gered  during  your  absence.  When
the  ignition  is  switched  on,  this

ﬂ ashing stops immediately.

Failure of the remote control

To deactivate the monitoring functions:

Locking the vehicle without
activating the alarm

 Unlock the vehicle using the key in

the driver's door lock.

 Open the door; the alarm is trig-

gered.

 Switch on the ignition; the alarm

stops. The indicator lamp in the but-
ton goes off.

 Lock or deadlock the vehicle using

the key in the driver's door lock.

To be effective, this deactivation
must be carried out each time the
ignition is switched off.
In "cabriolet" conﬁ guration, interior

volumetric monitoring is deactivat-
ed automatically.

Deactivation of the interior
volumetric monitoring

 Switch off the ignition.
 Within ten seconds, press the but-

ton until the indicator lamp is on
continuously.

 Get out of the vehicle.
 Press the locking button on the re-

mote control immediately.

The exterior perimeter monitoring alone
is activated: the indicator lamp in the

button ﬂ ashes once per second.

Locking the vehicle with exterior
perimeter monitoring only

Deactivate the interior volumetric moni-
toring to avoid unwanted triggering of
the alarm in certain cases such as:
-

leaving a pet in the vehicle,

leaving a window partially open,

washing your vehicle,

Reactivation of the interior
volumetric monitoring

 Press the unlocking button on the

remote control to deactivate the ex-
terior perimeter monitoring.

 Press the locking button on the re-

mote control to activate all the moni-
toring functions.

The indicator lamp in the button again

ﬂ ashes once per second.

This is indicated by sounding of the si-

ren and ﬂ ashing of the direction indica-

tors for thirty seconds.

Operating fault

When the ignition is switched on, ﬁ xed

illumination of the indicator lamp in the
button indicates a fault with the system.
Have it checked by a PEUGEOT dealer.

Automatic activation *

2 minutes after the last door or the boot
is closed, the system is activated auto-
matically.
 To avoid triggering the alarm on en-

tering the vehicle, ﬁ rst press the un-

locking button on the remote control.

* According to country.

ACCESS

The  rear  windows  do  not  have  an
automatic  mode  or  safety  anti-
pinch function for closing.
Approximately 45 seconds after re-
moving  the  ignition  key  or  opening
a door none of the windows can be
opened or closed. The ignition must
be  switched  back  on  in  order  to
open or close the windows.

ELECTRIC WINDOW
CONTROLS

Fitted with an anti-pinch system on the
front windows and a system which con-
trols all four windows on all models.

   1.    Driver's electric window switch.
  2.    Passenger's electric window switch.
  3.    Rear right electric window switch.
  4.    Rear left electric window switch.
  5.    Deactivation  of  the  rear  electric

window switches.

If the window opens unintentionally
when closing is requested (for ex-
ample, in the presence of ice):
 press the switch until the win-

dow opens completely,

 then pull the switch immediately

until the window closes,

 continue to pull the switch for

approximately

three seconds

after the window has closed.

The safety anti-pinch function is
not active during these operations.

Front windows safety anti-pinch
In automatic mode, when the front win-
dow rises and meets and obstacle it
stops and partially lowers again.

automatic mode

 Press or pull switch 1 fully. The win-

dow opens or closes completely
when the switch is released.

 Pressing the switch again stops the

movement of the window.

One-touch electric windows

You have two options:
-

manual mode

 Press or pull switch 1 gently. The

window stops as soon as the switch
is released.

Deactivation of the rear electric
window controls

 For the safety of your children, press

switch  5  to deactivate the rear elec-
tric  window  switches  regardless  of
their position.

When the indicator lamp is on, the rear
switches are deactivated.
When the indicator lamp is off, the rear
switches are activated.

ACCESS

This procedure reinitialises the op-
eration of the electric windows and
the automatic partial opening of the
door windows

Switch for all four windows

This switch opens or closes all of the
windows at once.

Always  remove  the  key  from  the
ignition  when  leaving  the  vehicle,
even for a short time.
In  the  event  of  contact  during  op-
eration  of  the  windows,  you  must
reverse  the  movement  of  the  win-
dow.  To  do  this,  press  the  switch
concerned.
When  the  driver  operates  the  pas-
senger electric window switches, he
must ensure that no one is prevent-
ing correct closing of the windows.
The  driver  must  ensure  that  the
passengers  use  the  electric  win-
dows correctly.
Be aware of children when operat-
ing the windows.

Reinitialisation

Following reconnection of the battery or
in  the  event  of  a  malfunction  you  must
reinitialise  the  operation  of  the  electric
windows.  For  each  of  the  controls  on
the control pad on the driver's side:
      release  the  switch  and  pull  it  again

until it closes completely,

 hold the switch for approximately

three seconds after closing,

 press the switch to lower the window

automatically,

 when the window has reached the

low position, press the switch again
for approximately one second.

The safety anti-pinch function is not
active during these operations.

 Press switch 6 and release it. The

windows open completely.

 Pressing the switch again stops the

movement of the windows.

or
 Pull switch 6 and hold it in this posi-

tion. The windows close completely.

 If you release the switch before the

windows have closed completely,
the windows stop.

This switch is operated under the
full responsibility of the driver.

ACCESS

DOORS

 After unlocking the vehicle com-

pletely using the remote control or
the key, take hold of the door handle
then pull it.

The window lowers automatically by
a few millimetres to permit opening
of the door.

From inside

 Pull the door control to open the

door; this unlocks this vehicle com-
pletely.

The window lowers automatically by
a few millimetres to permit opening
of the door.

The interior door controls do not
operate when the vehicle is dead-
locked.

If you leave the door open for more
than one minute, the window rises
again.
Pull the handle again to reactivate
the system.

Opening

From outside

When the selective unlocking is ac-

tivated, the ﬁ rst press of the remote

control unlocking button permits
unlocking of the driver's door only.

With the selective unlocking acti-
vated:
-

the driver's door control unlocks
the driver's door only,

the  passenger's  door  control
unlocks  the  passenger's  door
and the boot.

  In freezing conditions, the presence
of ice may hinder the automatic par-
tial  opening  of  the  window;  remove
the ice which may have formed along
the lower seal, located at the base of
the window.

ACCESS

If the vehicle is locked or dead-
locked from the outside, the red in-

dicator lamp ﬂ ashes and button A

is inactive.
 In this case, use the remote

control or the key to unlock the
vehicle.

Manual centralised control

System which provides full manual lock-
ing or unlocking of the doors and boot
from the inside.

Locking

 Press button A to lock the vehicle.
The red indicator lamp on the button
comes on.

If  one  of  the  doors  or  the  boot  is
open,  the  central  locking  from  the
inside does not take place.

Unlocking

 Press button A again to unlock the

vehicle.

The red indicator lamp on the button
switches off.

The glove box and the front arm-
rest compartment are not locked so
that they remain accessible.

Closing

The window rises automatically after a
few seconds and adjusts to provide per-
fect sealing when closed.

when the engine is running ,
this warning lamp comes on,
accompanied by a message
on the multifunction screen
for a few seconds,

when the vehicle is moving  (speed
higher  than  6  mph  (10  km/h)),  this
warning  lamp  comes  on,  accompa-
nied by an audible signal and a mes-
sage on the multifunction screen for
a few seconds.

When washing your vehicle:
- ﬁ rst lock the vehicle using the

remote control or the key,

avoid spraying the upper part of
the windows,

keep  the  end  of  the  high  pres-
sure  nozzle  at  least  1 metre
from  the  windows  and  door
seals.

When a door is not closed correctly:

Be aware of the risk of pinching
when the window rises automati-
cally on closing the door.

ACCESS

Activation

 Press this button for more than

two seconds.

A conﬁ rmation message appears in the

multifunction screen.

Deactivation

 Press this button again for more

than two seconds.

A conﬁ rmation message appears in the

multifunction screen.

Emergency locking

To lock or unlock the doors mechani-
cally in the event of a central locking

system failure or ﬂ at battery.

 Using the key, remove the black cap

on the edge of the door.

 Insert the key in the cavity without

forcing, then without turning it, move
the the latch sideways towards the
interior of the door.



Remove the key and reﬁ t the cap.

Locking the driver's door

 Insert the key in the lock, then turn it

to the right.

Unlocking the driver's door

 Insert the key in the lock, then turn it

to the left.

Locking the passenger door

Unlocking the passenger door

 Pull the interior door opening control.

If one of the doors is open, the au-
tomatic  central  locking  does  not
take place.
If  the  boot  is  open,  the  automatic
central locking of the doors is active.

Anti-intrusion security

System which provides full automatic
locking or unlocking of the doors and
boot while driving.
You can activate or deactivate this function.

Unlocking

 Above 6 mph (10 km/h), press this

button to unlock the doors and boot
temporarily.

Locking

When the speed exceeds 6 mph
(10 km/h), the doors and boot lock au-
tomatically.

Peugeot 308 CC Dag (2010.5). Manual - part 5
